SENSOR - MAP - 6.1L Dodge Magnum I facelift

Fuel System 1 illustration

SENSOR - MAP - 6.1L

The Manifold Absolute Pressure (MAP) sensor (2) is located at the rear of the intake manifold (1).

Scheme 167

Scheme 167
Scheme 167
  1. Disconnect electrical connector at sensor.
  2. Remove two sensor mounting bolts (3).
  3. Check condition of sensor o-ring (2).
