Power Windows - Electrical Diagnostics: Diagnosis Dodge Magnum I

Windows 3 illustrations ~603 words

DIAGNOSTIC CODE INDEX

DTCDescription
B1852DRIVER WINDOW SWITCH CIRCUIT STUCK - DDM
B1868DRIVER PASSENGER WINDOW SWITCH CIRCUIT STUCK - DDM
B1854DRIVER WINDOW MOTOR CONTROL CIRCUIT LOW - DDM
B1855DRIVER WINDOW MOTOR CONTROL CIRCUIT HIGH - DDM
B1858DRIVER WINDOW POSITION SENSOR POWER SUPPLY LOW - DDM
B1859DRIVER WINDOW POSITION SENSOR POWER SUPPLY HIGH - DDM
B185ADRIVER WINDOW POSITION SENSOR CIRCUIT PERFORMANCE - DDM
B185DPASSENGER WINDOW SWITCH CIRCUIT STUCK - PDM
B185FPASSENGER WINDOW MOTOR CONTROL CIRCUIT LOW - PDM
B1860PASSENGER WINDOW MOTOR CONTROL CIRCUIT HIGH - PDM
B1863PASSENGER WINDOW POSITION SENSOR POWER SUPPLY LOW - PDM
B1864PASSENGER WINDOW POSITION SENSOR POWER SUPPLY HIGH - PDM
B1865PASSENGER WINDOW POSITION SENSOR CIRCUIT PERFORMANCE - PDM
B210DBATTERY VOLTAGE LOW - DDM/PDM
B210EBATTERY VOLTAGE HIGH - DDM/PDM
B2218, B2219DRIVER/PASSENGER DOOR MODULE INTERNAL - DDM/PDM
U0019CAN B BUS-DDM/PDM
B16A4PASSENGER WINDOW SWITCH BACKLIGHTING CIRCUIT LOW - PDM
B16A5PASSENGER WINDOW SWITCH BACKLIGHTING CIRCUIT HIGH - PDM
U0141LOST COMMUNICATION WITH FRONT CONTROL MODULE
U0151LOST COMMUNICATION WITH OCCUPANT RESTRAINT CONTROLLER
U0154LOST COMMUNICATION WITH OCCUPANT CLASSIFICATION MODULE
U0155LOST COMMUNICATION WITH CLUSTER/CCN
U0156LOST COMMUNICATION WITH EOM
U0159LOST COMMUNICATION WITH PARKING ASSIST CONTROL MODULE
U0164LOST COMMUNICATION WITH HVAC CONTROL MODULE
U0168LOST COMMUNICATION WITH VEHICLE SECURITY CONTROL MODULE (SKREEM/WCM)
U0169LOST COMMUNICATION WITH SUNROOF CONTROL MODULE
U0181LOST COMMUNICATION WITH HEADLAMP LEVELING TRANSLATOR
U0184LOST COMMUNICATION WITH RADIO
U0186LOST COMMUNICATION WITH AUDIO AMPLIFIER
U0195LOST COMMUNICATION WITH SDARS
U0200LOST COMMUNICATION WITH PASSENGER DOOR MODULE
U0208LOST COMMUNICATION WITH HEATED SEAT CONTROL MODULE
U0209LOST COMMUNICATION WITH MEMORY SEAT CONTROL MODULE
U0212LOST COMMUNICATION WITH SCCM - CAN B
U0231LOST COMMUNICATION WITH RAIN SENSING MODULE
U0199LOST COMMUNICATION WITH DRIVER DOOR MODULE

DIAGNOSTIC CODE INDEX

Scheme 1

Scheme 1: B1852 - DRIVER WINDOW SWITCH CIRCUIT STUCK - DDM

For the Power Window circuit diagram (Refer to ELECTRICAL/POWER WINDOWS - SCHEMATICS AND DIAGRAMS)

Diagnostic Test

  1. 1) CHECK ENGINE DTC's With the scan tool, read ENGINE DTC's Are there any ENGINE DTC's present? No Go to step 2) . Yes Refer to symptom list for problems related to ENGINE.
  2. 2) TEST FOR INTERMITTENT CONDITION With the scan tool, record and erase DTC's Start the engine and run for 2 minutes. With the scan tool, read DTC's. Does the scan tool display B210D - BATTERY VOLTAGE LOW? Yes Replace the appropriate Door Module. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1.»(ref-246912-S19033985802007011000000) No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1.»(ref-246912-S19033985802007011000000)
  1. 1) CHECK ENGINE DTC's With the scan tool, read ENGINE DTC's Are there any ENGINE DTC's present? No Go to step 2) . Yes Refer to symptom list for problems related to ENGINE.
  2. 2) TEST FOR INTERMITTENT CONDITION With the scan tool, record and erase DTC's Start the engine and run for 2 minutes. With the scan tool, read DTC's. Does the scan tool display B210E - BATTERY VOLTAGE HIGH? Yes Replace the appropriate Door Module. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1.»(ref-246912-S19033985802007011000000) No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1.»(ref-246912-S19033985802007011000000)
  1. 1) Replace the Door Module NOTE: Anytime this code is logged, the module must be replaced. Repair Replace the appropriate Door Module. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1.»(ref-246912-S19033985802007011000000)

Scheme 2

Scheme 2: U0019 - CAN B BUS-DDM/PDM

(Refer to ELECTRICAL/ELECTRONIC CONTROL MODULES - DIAGNOSIS AND TESTING) for the diagnostic test procedure.

(Refer to ELECTRICAL/ELECTRONIC CONTROL MODULES - DIAGNOSIS AND TESTING) for the diagnostic test procedure.

(Refer to ELECTRICAL/ELECTRONIC CONTROL MODULES - DIAGNOSIS AND TESTING) for the diagnostic test procedure.

(Refer to ELECTRICAL/ELECTRONIC CONTROL MODULES - DIAGNOSIS AND TESTING) for the diagnostic test procedure.

(Refer to ELECTRICAL/ELECTRONIC CONTROL MODULES - DIAGNOSIS AND TESTING) for the diagnostic test procedure.

(Refer to ELECTRICAL/ELECTRONIC CONTROL MODULES - DIAGNOSIS AND TESTING) for the diagnostic test procedure.

(Refer to ELECTRICAL/ELECTRONIC CONTROL MODULES - DIAGNOSIS AND TESTING) for the diagnostic test procedure.

(Refer to ELECTRICAL/ELECTRONIC CONTROL MODULES - DIAGNOSIS AND TESTING) for the diagnostic test procedure.

(Refer to ELECTRICAL/ELECTRONIC CONTROL MODULES - DIAGNOSIS AND TESTING) for the diagnostic test procedure.

(Refer to ELECTRICAL/ELECTRONIC CONTROL MODULES - DIAGNOSIS AND TESTING) for the diagnostic test procedure.

(Refer to ELECTRICAL/ELECTRONIC CONTROL MODULES - DIAGNOSIS AND TESTING) for the diagnostic test procedure.

(Refer to ELECTRICAL/ELECTRONIC CONTROL MODULES - DIAGNOSIS AND TESTING) for the diagnostic test procedure.

(Refer to ELECTRICAL/ELECTRONIC CONTROL MODULES - DIAGNOSIS AND TESTING) for the diagnostic test procedure.

(Refer to ELECTRICAL/ELECTRONIC CONTROL MODULES - DIAGNOSIS AND TESTING) for the diagnostic test procedure.

(Refer to ELECTRICAL/ELECTRONIC CONTROL MODULES - DIAGNOSIS AND TESTING) for the diagnostic test procedure.

(Refer to ELECTRICAL/ELECTRONIC CONTROL MODULES - DIAGNOSIS AND TESTING) for the diagnostic test procedure.

(Refer to ELECTRICAL/ELECTRONIC CONTROL MODULES - DIAGNOSIS AND TESTING) for the diagnostic test procedure.

(Refer to ELECTRICAL/ELECTRONIC CONTROL MODULES - DIAGNOSIS AND TESTING) for the diagnostic test procedure.

(Refer to ELECTRICAL/ELECTRONIC CONTROL MODULES - DIAGNOSIS AND TESTING) for the diagnostic test procedure.

Scheme 3

Scheme 3: SCHEMATICS AND DIAGRAMS
