Scheme 1

Scheme 1: LOCATION AND DECODING
1 - PRIMARY PAINT
2 - SECONDARY PAINT
3 - VINYL ROOF
4 - VEHICLE ORDER NUMBER
5 - CAR LINE SHELL
6 - PAINT PROCEDURE
7 - ENGINE
8 - TRIM
9 - TRANSMISSION
10 - MARKET
11 - VIN

The Body Code Plate is located in the engine compartment on the front right side shock tower mounting front panel.

Scheme 2

Scheme 2: BODY CODE PLATE LINE 3

There are seven lines of information on the body code plate. Lines 4, 5, 6, and 7 are not used to define service information. Information reads from left to right, starting with line 3 in the center of the plate to line 1 at the bottom of the plate.

DESCRIPTION

The SAE bolt strength grades range from grade 2 to grade 8. The higher the grade number, the greater the bolt strength. Identification is determined by the line marks on the top of each bolt head. The actual bolt strength grade corresponds to the number of line marks plus 2. The most commonly used metric bolt strength classes are 9.8 and 10.9. The metric strength class identification number is imprinted on the head of the bolt. The higher the class number, the greater the bolt strength. Some metric nuts are imprinted with a single-digit strength class on the nut face. Refer to the following charts and (Scheme 3).

Bolt Markings8.8/8.910.912.9
Bolt Dia.N.mFt. Lbs.N.mFt. Lbs.N.mFt. Lbs.
612105*14120*1612
825250*32233828
10544060457455
12957010880135100
14155115175130216160
16243180324210324240
* Inch Lbs.

Bolt Markings and Torques - Metric

Bolt MarkingsGrade 5Grade 8
Bolt Dia.N.mFt. LbsN.mFt. Lbs
1/4 - 201095*14125*
1/4 - 281095*17150*
5/16 - 1822200*30270*
5/16 - 2426240*33300*
3/8 - 1640305540
3/8 - 2447356045
7/16 - 1468508865
7/16 - 2074559570
1/2 - 1310175135100
1/2 -2011585150110
9/16 - 12135105182135
9/16 - 18155115202150
5/8 - 11202150263195
5/8 - 18215160284210
3/4 - 10230170297220
3/4 - 16236175304225
7/8 - 14405300540400
* Inch Lbs.

Bolt Markings and Torques - U. S. Customary

Scheme 3

Scheme 3
WARNINGUse of an incorrect fastener may result in component damage or personal injury.

Fasteners and torque specifications references in this Service Information are identified in metric and SAE format.

During any maintenance or repair procedures, it is important to salvage all fasteners (nuts, bolts, etc.) for reassembly. If the fastener is not salvageable, a fastener of equivalent specification must be used.

Most stripped threaded holes can be repaired using a Helicoil®. Follow the vehicle or Helicoil® recommendations for application and repair procedures.

Scheme 4

Scheme 4: DESCRIPTION
1High Beam13Rear Window Washer
2Fog Lamps14Fuel
3Headlamp, Parking Lamps, Panel Lamps15Engine Coolant Temperature
4Turn Warning16Battery Charging Condition
5Hazard Warning17Engine Oil
6Windshield Washer18Seat Belt
7Windshield Wiper19Brake Failure
8Windshield Wiper and Washer20Parking Brake
9Windscreen Demisting and Defrosting21Front Hood
10Ventilating Fan22Rear hood (Decklid)
11Rear Window Defogger23Horn
12Rear Window Wiper24Lighter

The graphic symbols illustrated in the following International Control and Display Symbols Chart are used to identify various instrument controls. The symbols correspond to the controls and displays that are located on the instrument panel.

Scheme 5

Scheme 5: DESCRIPTION

The Manufacturer Plate is located in the engine compartment on the passenger side rear corner of the hood. The plate contains five lines of information

  1. Vehicle Identification Number (VIN)
  2. Gross Vehicle Mass (GVM)
  3. Gross Train Mass (GTM)
  4. Gross Front Axle Rating (GFAR)
  5. Gross Rear Axle Rating (GRAR)

Scheme 6

Scheme 6: DESCRIPTION

The metric system is based on quantities of one, ten, one hundred, one thousand and one million.

The following chart will assist in converting metric units to equivalent English and SAE units, or vise versa.

(Scheme 6)to convert torque values listed in metric Newton- meters (N.m). Also, use the chart to convert between millimeters (mm) and inches (in.).

MULTIPLYBYTO GETMULTIPLYBYTO GET
In-lbsX 0.11298= Newton Meters (N.m)N.mX 8.851= in-lbs
Ft-lbsX 1.3558= Newton Meters (N.m)N.mX 0.7376= ft-lbs
Inches Hg (60° F)X 3.377= Kilopascals (kPa)KPaX 0.2961= Inches Hg
PsiX 6.895= Kilopascals (kPa)KPaX 0.145= psi
InchesX 25.4= Millimeters (mm)MmX 0.03937= Inches
FeetX 0.3048= Meters (M)MX 3.281= Feet
YardsX 0.9144= MetersMX 1.0936= Yards
MphX 1.6093= Kilometers/Hr. (Km/h)Km/hX 0.6214= mph
Feet/SecX 0.3048= Meters/Sec (M/S)M/SX 3.281= Feet/Sec
MphX 0.4470= Meters/Sec (M/S)M/SX 2.237= mph
Kilometers/Hr. (Km/h)X 0.27778= Meters/Sec (M/S)M/SX 3.600Kilometers/Hr. (Km/h)

CONVERSION FORMULAS AND EQUIVALENT VALUES

1 inch = 25 Millimeters1 Cubic Inch = 16 Cubic Centimeters
1 Foot = 0.3 Meter1 Cubic Foot = 0.03 Cubic Meter
1 Yard = 0.9 Meter1 Cubic Yard = 0.8 Cubic Meter
1 Mile = 1.6 Kilometers

COMMON METRIC EQUIVALENTS

ClassDiameter mmPitch mmSpecified torque
Hexagon head boltHexagon flange bolt
N.mKgf-cmFt-lbfN.mKgf-cmFt-lbf
4T6155548 in.-lbf66052 in.-lbf
81.2512.513091414510
101.2526260192929021
121.2547480355354039
141.574760558485061
161.51151,15083
5T616.56556 in.-lbf7.57565 in.-lbf
81.2515.51601217.517513
101.2532330243636026
121.2559600436567048
141.591930671001,05076
161.51401,400101
6T6188069 in.-lbf99078 in.-lbf
81.2519195142121015
101.2539400294444032
121.2571730538081059
141.51101,100801251,25090
161.51701,750127
7T6110,51108121209
81.2525260192829021
101.2552530385859043
121.2595970701051,05076
141.51451,5001081651,700123
161.52302,300166
8T81.2529300223333024
101.2561620456869050
121.251101,100801201,25090
9T81.2534340253738027
101.2570710517879057
121.251251,300941401,450105
10T81.2538390284243031
101.2578800588889064
121.251401,4501051551,600116
11T81.2542430314748035
101.2587890649799072
121.251551,6001161751,800130

SPECIFIED TORQUE FOR STANDARD BOLTS

Individual Torque Charts appear within many or the service categories. Refer to the Standard Torque Specifications Chart for torque references not listed in the individual torque charts.

All vehicles are equipped with a combined VECI label. This label is located in the engine compartment.

The VECI label contains the following

  1. Engine family and displacement
  2. Evaporative family
  3. Emission control system schematic
  4. Certification application
  5. Engine timing specifications (if adjustable)
  6. Idle speeds (if adjustable)
  7. Spark plug and gap

The label also contains an engine vacuum schematic. There are unique labels for vehicles built for sale in the state of California and the country of Canada. Canadian labels are written in both the English and French languages. These labels are permanently attached and cannot be removed without defacing information and destroying label.

Scheme 7

Scheme 7: DESCRIPTION

The Vehicle Identification Number (VIN) plate is attached to the top left side of the instrument panel. The VIN contains 17 characters that provide data concerning the vehicle. Refer to the decoding chart to determine the identification of a vehicle.

To protect the consumer from theft and possible fraud the manufacturer is required to include a Check Digit at the ninth position of the Vehicle Identification Number. The check digit is used by the manufacturer and government agencies to verify the authenticity of the vehicle and official documentation. The formula to use the check digit is not released to the general public.

POSITIONINTERPRETATIONCODE = DESCRIPTION
1Country of Origin1 = Manufactured by DaimlerChrysler Canada Inc.
2MakeC = Chrysler
D = Dodge
3Vehicle Type3 = Passenger Car
4 = Multipurpose Passenger Vehicle With Side Airbags
8 = Multipurpose Passenger Vehicle with Side Airbags
4Restraint SystemJ = Restraint System Air bags Front Next Generation Multi-Stage Sales Code (CG1) Without Side Air Bags Sales Code (CGS)
Gross Vehicle Weight RatingH = 6001-7000 lbs.
5Vehicle LineA = 300 / 300C / SRT-8 (RWD)
K = 300 (AWD)
V = TBD (RWD)
Z = TBD (AWD)
6Series2 = L Low Line
3 = M Medium
4 - H High Line
5 = P Premium
6 = S Sport
7 = S Special
7Body Style3 = LX - 48
8 = LX - 49
8EngineR = 2.7L V-6 cyl. DOHC 24 Valve MPI Gasoline
G = 3.5L V-6 cyl. High Output 24 Valve MPI Gasoline
H = 5.7L V-8 cyl. HEMI Multiple Displacement Gasoline
W = 6.1L V-8 cyl. Gasoline (SMPI)
9Check Digit0 through 9 or X
10Model Year5 = 2005
11Assembly PlantH = Brampton Assembly
12 Through 17Vehicle Build SequenceSix Digit Number Assigned By Assembly Plant

VIN DECODING INFORMATION

Scheme 8

Scheme 8: DESCRIPTION

A vehicle certification label is attached to every DaimlerChrysler Corporation vehicle. The label certifies that the vehicle conforms to all applicable Federal Motor Vehicle Standards. The label also lists

  1. Month and year of vehicle manufacture.
  2. Gross Vehicle Weight Rating (GVWR). The gross front and rear axle weight ratings (GAWR's) are based on a minimum rim size and maximum cold tire inflation pressure.
  3. Vehicle Identification Number (VIN).
  4. Type of vehicle.
  5. Type of rear wheels.
  6. Bar code.
  7. Month, Day and Hour (MDH) of final assembly.
  8. Paint and Trim codes.
  9. Country of origin.

The label is located on the driver-side door shut-face.
