Overhead Console - Electrical Diagnostics: Other Dodge Magnum I

Monitor Conditions

1. When Monitored: With the ignition on.

Set Conditions

1. Set Condition: The Electronic Overhead Module detects the UGDO switch in the closed position for more than 2 minutes.

Possible Causes

1. When Monitored: With the ignition on.

1. Set Condition: The Electronic Overhead Module detects the UGDO switch in the closed position for more than 2 minutes.

1. When Monitored: With the ignition on.

1. Set Condition: The Electronic Overhead Module detects the UGDO switch in the closed position for more than 2 minutes.

1. When Monitored: With the ignition on, internal self test routine running.

1. Set Condition: The Electronic Overhead Module fails one of seven internal tests.

Scheme 16

1. 1) VERIFY OPERATION OF THE ELECTRONIC OVERHEAD MODULE Turn the ignition on. With the scan tool, erase Electronic Overhead Module DTCs. With the scan tool, activate the Electronic Overhead Module self test. Wait for self test to complete. With the scan tool, read Electronic Overhead Module DTCs. Does the scan tool display: B2217-EVIC/EOM/CMTC INTERNAL? YES Replace the Electronic Overhead Module. Refer to «OVERHEAD CONSOLE - SERVICE INFORMATION»(ref-246938-S30157780132007011000000) . Perform «BODY VERIFICATION TEST - VER 1»(ref-246912-S11713511292007011000000) . «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-246912-S19033985802007011000000) . NO Test complete. Perform «BODY VERIFICATION TEST - VER 1»(ref-246912-S11713511292007011000000) . «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-246912-S19033985802007011000000) .

B222D - ECU UNABLE TO CONFIGURE / CONFIGURATION NOT LEARNED

For the Electronic Overhead Module circuit diagram (Refer to ELECTRICAL/OVERHEAD CONSOLE - SCHEMATICS AND DIAGRAMS) .

1. When Monitored: With the ignition on.

1. Set Condition: The Electronic Overhead Module does not receive the configuration information from the Front Control Module.

1. When Monitored: Vehicle speed greater than 10 mph.

1. Set Condition: The magnetic feild around the vehicle is greater than 2.4 guass.

1. When Monitored: Continuously.

1. Set Condition: If the Can B Bus (+) or B Bus (-) circuit is open, shorted to voltage, or shorted to ground.

Scheme 17

Scheme 18

1. 1) CHECK FOR ACTIVE DTC U0019-CAN B BUS Turn the ignition on. With the scan tool, record and erase any Electronic Overhead Module DTCs. Turn the ignition off, wait 30 seconds then turn the ignition on. With the scan tool, read DTCs. Is DTC U0019-CAN B BUS active? Yes Go To step 2) . No The condition that caused this code to set is not present at this time. Check for an intermittent condition by inspecting the related wiring harness for chaffed, pierced, pinched, and partially broken wires. Also inspect the related connectors for broken, bent, pushed out, spread, corroded, or contaminated terminals. Perform «BODY VERIFICATION TEST - VER 1»(ref-246912-S11713511292007011000000) . «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-246912-S19033985802007011000000) .
2. 2) CHECK FOR ACTIVE CAN B BUS RELATED DTCS IN THE FRONT CONTROL MODULE With the scan tool, read Front Control Module DTCs Does the scan tool display any active CAN B BUS related DTCs? Yes Diagnose and repair the DTC(s). «(Refer to ELECTRICAL/ELECTRONIC CONTROL MODULES - DIAGNOSIS AND TESTING)»(ref-246941-S09324268122007011000000) No Go to step 3) .
3. 3) CHECK (D55) CAN B BUS (+) CIRCUIT FOR AN OPEN Turn the ignition off. Disconnect the negative battery cable. Disconnect the Electronic Overhead Module harness connector. Disconnect the Front Control Module C1 harness connector. Measure the resistance of the (D55) Can B Bus (+) circuit between the Front Control Module C1 harness connector and the Electronic Overhead Module harness connector. Is the resistance below 2.0 ohms? Yes Go To step 4) . No Repair the Can B Bus (+) circuit for an open. Perform «BODY VERIFICATION TEST - VER 1»(ref-246912-S11713511292007011000000) . «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-246912-S19033985802007011000000) .
4. 4) CHECK THE (D54) CAN B BUS (-) CIRCUIT FOR AN OPEN Measure the resistance of the (D54) Can B Bus (-) circuit between the Front Control Module C1 harness connector and the Electronic Overhead Module harness connector. Is the resistance below 2.0 ohms? Yes Replace the Electronic Overhead Module. Refer to «OVERHEAD CONSOLE - SERVICE INFORMATION»(ref-246938-S30157780132007011000000) . Perform «BODY VERIFICATION TEST - VER 1»(ref-246912-S11713511292007011000000) . «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-246912-S19033985802007011000000) . No Repair the Can B Bus (-) circuit for an open. Perform «BODY VERIFICATION TEST - VER 1»(ref-246912-S11713511292007011000000) . «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-246912-S19033985802007011000000) .
