Power windows — Power windows circuit, premium Dodge Journey I facelift

Components on these wiring diagrams 39

Click a component to highlight it on every diagram it appears on.

• Circuit Breaker
• Computer Data Lines
• Driver Door Module
• Driver Window Motor
• Driver Window/Door Lock Switch
• Drv Ctrl Mdl Fd
• Drv Wnd Drv Up
• Fsd B2
• Fsd Ign Run-Acc
• Ground2
• Interior Power Distribution Power Center
• Left Rear Power Window Switch
• Left Rear Window Motor
• Lr Mstr Wnd Sw
• Lr Mstr Wnd Sw Dwn
• Lr Mstr Wnd Sw Up
• Lr Pwr Wnd Sw Lck Out Fed
• Lr Pwr Wnd Sw Lk Out Fd
• Lr Wdo Dwn
• Lr Wdo Up
• Lr Wnd Dwn
• Lr Wnd Up
• Pass Dr Lk Sw Mux
• Pass Wnd Drv Up
• Pass Wnd Sw Ill Drv
• Pass Wnd Sw Mux
• Passenger Door Module
• Passenger Window Motor
• Passenger Window/ Door Lock Switch
• Pwr Ign Run/ Acc Ctrl Output
• Pwr Ign/Run Acc Ctrl Output
• Right End Of Dash
• Right Rear Power Window Switch
• Right Rear Window Motor
• Rr Mstr Wnd Sw Dwn2
• Rr Mstr Wnd Sw Up2
• Rr Wdo Dwn
• Rr Wdo Up
• System
