FASTENER USAGE
Fasteners and torque specifications references in this service information are identified in metric and SAE format. During any maintenance or repair procedures, it is important to salvage all fasteners (nuts, bolts, screws, etc.) for reassembly. If the fastener is not salvageable, a fastener of equivalent specification must be used.
INTERNATIONAL CONTROL AND DISPLAY SYMBOLS
Chrysler LLC uses international symbols to identify various systems on the vehicle.
The graphic symbols illustrated are used to identify various instrument controls, vehicle controls and service information references. The symbols correspond to the controls and displays that are located on the instrument panel and throughout the vehicle.
Scheme 3
| SYMBOL | DESCRIPTION | SYMBOL | DESCRIPTION |
|---|---|---|---|
| 1 | 115-Volt Power Inverter | 11 | Side Airbag |
| 2 | USB Connector | 12 | Seat Belt |
| 3 | Lighter | 13 | Airbag |
| 4 | Fuel Fill Side | 14 | Supplemental Restraint System |
| 5 | Spare Tire Winch | 15 | Power Steering Fluid |
| 6 | Fuse | 16 | See Owner's Manual |
| 7 | Key Activate (Power Outlet) | 17 | See Appropriate Service information |
| 8 | Warning | 18 | Emergency Release Handle |
| 9 | Child Seat Tether Anchor | 19 | Jack/Jack Tools Location |
| 10 | Lower Anchors and Tether for Children (latch) |
INTERNATIONAL INFORMATION SYMBOL IDENTIFICATION
Scheme 4
| SYMBOL | DESCRIPTION | SYMBOL | DESCRIPTION |
|---|---|---|---|
| 1 | Electronic Speed Control | 23 | Transmission Oil Temperature Light |
| 2 | Hill Descent Control | 24 | Diesel Exhaust Brake |
| 3 | Traction Control | 25 | High Beam |
| 4 | Electronic Stability Program/Brake System Assist System | 26 | Front Fog Light |
| 5 | Security Indicator | 27 | Rear Fog Light |
| 6 | Turn Signals | 28 | Cargo Lamp |
| 7 | Water In Fuel | 29 | Exterior Bulb Failure |
| 8 | Low Fuel | 30 | Door Ajar |
| 9 | Side Airbag | 31 | Liftgate Open |
| 10 | Seat Belt Reminder | 32 | Brake System Warning Parking Brake |
| 11 | Airbag Warning Light | 33 | All Wheel Drive |
| 12 | Passenger Airbag Off | 34 | Four Wheel Drive |
| 13 | Failure Of Anti-Lock Braking System | 35 | Four Wheel Drive Low |
| 14 | HEV Brake Regenerative Light | 36 | Tow/Haul |
| 15 | Electronic Throttle Control | 37 | Service Four Wheel Drive |
| 16 | HEV Service Light | 38 | Service Four Wheel Drive |
| 17 | Engine Oil | 39 | Cruise Indicator |
| 18 | Battery Charging | 40 | Brake System Warning Parking Brake |
| 19 | Glow Plug/Intake Air Heated | 41 | Tire Pressure Monitor |
| 20 | Power Steering Fluid | 42 | Sway Bar Disconnect Indicator |
| 21 | Engine Coolant Temperature | 43 | Front Axle Lock |
| 22 | Malfunction Indicator Light | 44 | Rear Axle Lock |
INTERNATIONAL INDICATOR SYMBOL IDENTIFICATION
Scheme 5
| SYMBOL | DESCRIPTION | SYMBOL | DESCRIPTION | SYMBOL | DESCRIPTION |
|---|---|---|---|---|---|
| 1 | Rear Window Wiper | 26 | Passenger Air Bag Off | 51 | Door Ajar |
| 2 | Rear Window Intermittent Wiper | 27 | Electronic Speed Control | 52 | Liftgate Release |
| 3 | Rear Window Washer | 28 | Cruise Indicator | 53 | Sliding Door |
| 4 | Rear Window Defrost | 29 | Hill Descent Control | 54 | Sliding Door |
| 5 | Heated Mirror | 30 | Park Assist Off | 55 | Convertible Top Down |
| 6 | Turn Signals | 31 | Electronic Stability Program/Brake System Assist System | 56 | Convertible Top Up |
| 7 | Adjustable Pedals | 32 | Park Brake Release | 57 | Door Lock |
| 8 | Horn | 33 | Adjustable Headlights | 58 | Window Lift |
| 9 | Windshield Wiper Intermittent | 34 | Low Beam | 59 | Convertible 4 Window Down |
| 10 | Windshield Washer | 35 | Front Fog Light | 60 | Window Lock |
| 11 | Windshield Washer Fluid Level | 36 | Rear Fog Light | 61 | Power Rear Window |
| 12 | Windshield Electrically Heated | 37 | Cargo Lamp | 62 | Voice Recognition Button |
| 13 | Windshield Defrost | 38 | Hazard Lights | 63 | Uconnect™ Button |
| 14 | Windshield Wiper And Washer | 39 | 115-Volt Power Inverter | 64 | SwayBar Disconnect |
| 15 | Ventilating Fan | 40 | Key Activate (Power Outlet) | 65 | All Wheel Drive |
| 16 | Air Conditioning | 41 | Exterior Bulb Failure | 66 | Four Wheel Drive |
| 17 | Upper Air Outlet | 42 | Master Lighting Switch | 67 | Two Wheel Drive |
| 18 | Upper And Lower Air Outlet | 43 | Dome Light | 68 | Four Wheel Drive Low |
| 19 | Lower Air Outlet | 44 | Park Lights | 69 | Four Wheel Drive Lock |
| 20 | Defrost And Lower Air Outlet | 45 | Instrument Panel Illumination | 70 | Four Wheel Drive Auto |
| 21 | Heated Seat Low | 46 | Electronic Stability Program Off | 71 | Front Axle Lock |
| 22 | Heated Seat High | 47 | Diesel Exhaust Brake | 72 | Rear Axle Lock |
| 23 | Ventilated Seat | 48 | Overdrive Off | 73 | EVIC Menu |
| 24 | Recirculation | 49 | Hood Release | 74 | Navigation Button |
| 25 | Heated Steering Wheel | 50 | Trunk/Deck Release | 75 | Step |
| 76 | Reset | 77 | Axle Lock Button | 78 | Traction Control Off |
INTERNATIONAL CONTROL SYMBOL IDENTIFICATION
Scheme 6
The illustration symbols illustrated are used to identify engine compartment lubricant and fluid inspection and fill locations. The symbols correspond to the caps located within the engine compartment.
THREADED HOLE REPAIR
Most stripped threaded holes can be repaired using a Helicoil®. Follow the vehicle or Helicoil® recommendations for application and repair procedures.
Scheme 7
Scheme 8
A vehicle certification label is attached to every Chrysler LLC vehicle. The label certifies that the vehicle conforms to all applicable Federal Motor Vehicle Standards. The label also lists
- Month and year of vehicle manufacture.
- Gross Vehicle Weight Rating (GVWR). The gross front and rear axle weight ratings (GAWR's) are based on a minimum rim size and maximum cold tire inflation pressure.
- Vehicle Identification Number (VIN).
- Type of vehicle.
- Type of rear wheels.
- Bar code.
- Month, Day and Hour (MDH) of final assembly.
- Paint and Trim codes.
- Country of origin.
The label is located on the driver-side door shut-face.
Scheme 9
The Vehicle Identification Number (VIN) plate is attached to the top left side of the instrument panel. The VIN contains 17 characters that provide data concerning the vehicle. Refer to the VIN DECODING INFORMATION chart to determine the identification of a vehicle.
To protect the consumer from theft and possible fraud the manufacturer is required to include a Check Digit at the ninth position of the Vehicle Identification Number. The check digit is used by the manufacturer and government agencies to verify the authenticity of the vehicle and official documentation. The formula to use the check digit is not released to the general public.
| POSITION | INTERPRETATION | CODE = DESCRIPTION |
|---|---|---|
| 1 | Country of Origin | 3 = Manufactured By Chrysler De Mexico Inc. |
| 2 | Make | D = Dodge |
| 3 | Vehicle Type | 4 = Multipurpose Passenger Vehicle Without Side Airbags. |
| 8 = Multipurpose Passenger Vehicle With Side Airbags. | ||
| 4 | Gross Vehicle Weight Rating | G = (2268 - 2721 kg) 5001 - 6000 lbs |
| 5 | Vehicle Line | G = Journey (LHD) (FWD) (D-49) |
| H = Journey (LHD) (AWD) (E-49) | ||
| 5 = Journey (RHD) (FWD) (B-49) | ||
| 6 | Series | 4 = High Line |
| 5 = Premium | ||
| 6 = Sport | ||
| 6 - Export | Series | B = 4 Speed Automatic |
| C = 6 Speed Manual | ||
| H = 6 Speed Automatic | ||
| N = 5-Speed Manual | ||
| 7 | Body Style | 7 = Hatchback Tall |
| 8 | Engine | Y = 2.0L 4 CYL Diesel (ECE) |
| B = 2.4L 4 CYL Gasoline Non - Turbo (EDG,ED3) | ||
| D = 2.7L 6 CYL Gasoline Non - Turbo (EER) | ||
| V = 3.5L 6 CYL Gasoline Non - Turbo (EGF) | ||
| 9 | Check Digit | 0 through 9 or X |
| 10 | Model Year | 9 = 2009 |
| 11 | Assembly Plant | T = Toluca Assembly Plant |
| 12 Through 17 | Vehicle Build Sequence | Six Digit Number Assigned By Assembly Plant |
VIN DECODING INFORMATION
