MAIN FUEL PUMP MODULE Dodge Journey I

Fuel System 7 illustrations ~258 words

MAIN FUEL PUMP MODULE

WARNINGRisk of injury to eyes and skin from contact with fuel, Wear protective clothing and eye protection. Risk of poisoning from inhaling and swallowing fuel. Pour fuel only into appropriately marked OSHA approved containers. Failure to comply may result in serious or fatal injury.
WARNINGThe fuel system is under constant high pressure even with engine off. Until the fuel pressure has been properly released from the system, do not attempt to open the fuel system. Do not smoke or use open flames/sparks when servicing the fuel system. Make sure the area in which the vehicle is being serviced is in a well ventilated area. Failure to comply may result in serious or fatal injury.

Scheme 98

Scheme 98
Scheme 98

Scheme 99

Scheme 99
Scheme 99

Scheme 100

Scheme 100
Scheme 100

Scheme 101

Scheme 101
Scheme 101

Scheme 102

Scheme 102
Scheme 102

Scheme 103

Scheme 103
Scheme 103

Scheme 104

Scheme 104
Scheme 104
  1. Drain and remove the fuel tank. See «Fuel System/Fuel Delivery/TANK, Fuel - Removal»(ref-353596-S23700345812010011200000) . NOTE: Prior to removing the main fuel pump module, use compressed air to remove any accumulated dirt and debris from around fuel tank opening.
  2. Position the lock-ring remover/installer 9340 into the notches on the outside edge of the lock-ring.
  3. Install a 1/2 inch drive breaker bar into the lock-ring remover/installer 9340.
  4. Rotate the breaker bar counterclockwise and remove the lock-ring. NOTE: The main fuel pump module has to be properly located in the fuel tank for the fuel level gauge to work properly.
  5. Mark the main fuel pump module orientation. WARNING: The fuel pump module reservoir does not empty out when the tank is drained. The fuel in the reservoir will spill out when the module is removed. NOTE: Do not spill fuel into the interior of the vehicle.
  6. Raise the main fuel pump module out of the fuel tank using caution not spill fuel inside the vehicle.
  7. Tip the main fuel pump module and drain enough fuel from the main fuel pump module reservoir to gain access to the internal fuel line without spilling fuel into the interior of the vehicle.
  8. If equipped with AWD, disconnect the internal fuel line from the main fuel pump module.
  9. Remove the main fuel pump module from the fuel tank using caution not to bend the float arm.
  10. Remove and discard the rubber O-ring seal.
