TORQUE
| DESCRIPTION | N.m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| Fasteners-Accessory Drive Belt Tensioner Bracket (2.0L Diesel) | 30 | 22 | |
| Fastener-Accessory Drive Belt Tensioner Assembly(2.4L) | 54 | 40 | |
| Fasteners-Accessory Drive Belt Tensioner Bracket (2.7L) | 28 | 21 | |
| Fastener-Accessory Drive Belt Tensioner (2.4L) | 24 | 18 | |
| Fastener-Accessory Drive Belt Tensioner (3.5L) | 41 | 30 | |
| Fastener-Idler Pulley (2.4L) | 35 | 26 | |
| Fastener-Idler Pulley (2.5L) | 35 | 26 | |
| Fastener-Idler Pulley (2.0L Diesel) | 35 | 26 | |
| Fasteners-A/C Condenser to Radiator | 5 | 44 | |
| Fastener-Block Heater (2.7L) | 12 | 9 | 106 |
| Fastener-Block Heater (3.5L) | 12 | 9 | 106 |
| Bolts-Coolant Outlet Connector (3.5L) | 12 | 9 | 106 |
| Cooling System Bleed Valve | 12 | 9 | 106 |
| ETC Sensor (2.4L) | 19 | 14 | |
| ETC Sensor (2.7L) | 19 | 14 | |
| ETC Sensor (3.5L) | 28 | 20 | |
| Fasteners-Fan Module to Radiator | 5 | 44 | |
| Fasteners-Fan Motor to Shroud | 5 | 44 | |
| Bolts-Thermostat Housing (3.5L) | 12 | 9 | 106 |
| Bolts-Thermostat Housing to cylinder head (2.0L Diesel/2.4L) | 28 | 21 | |
| Bolts-Thermostat Housing (2.7L) | 12 | 9 | 106 |
| Fastener-Transmission Cooler Tube Bracket | 5 | 44 | |
| Fastener-Transmission Cooler Tube | 9 | 80 | |
| Fitting - Transmission oil cooler quick connect fitting | 15 | 11 | |
| Bolts-Water Pump (2.7L/3.5L) | 12 | 9 | 106 |
| Hose Clamps-Transmission Cooler | 3 | 27 | |
| Bolts-Water Pump Mounting (2.0L Diesel/2.4L) | 24 | 18 | |
| Bolts-Water Pump Inlet Tube to Block (2.0L Diesel/2.4L) | 12 | 9 | 106 |
| Bolts-EGR Bypass assembly-to EGR Cooler body | 10 | 7 | 89 |
| Bolts-EGR Tube -to-Exhaust manifold | 20 | 15 | |
| Bolts, Water Pump Inlet Tube to water pump housing (2.0L Diesel/2.4L) | 24 | 18 | |
| Bolts, Water Pump to Water Pump Adapter (2.4L) | 22 | 16 | |
| Bolts, Water Pump Pulley to Water Pump (2.4L) | 9 | 80 |
Scheme 1
Scheme 2
Scheme 3
Scheme 4
Scheme 5
Scheme 6
Scheme 7
Scheme 8
| 1 - POWER STEERING PUMP |
|---|
| 2 - ACCESSORY DRIVE BELT |
| 3 - GENERATOR |
| 4 - A/C COMPRESSOR |
| 5 - LOWER IDLER PULLEY |
| 6 - CRANKSHAFT PULLEY |
| 7 - WATER PUMP PULLEY |
| 8 - ACCESSORY DRIVE BELT TENSIONER |
| 9 - UPPER IDLER PULLEY |
The accessory drive belt is a Poly-V type belt. On the 2.4L engine, the accessory drive belt drives the generator, P/S pump and air conditioning compressor.
Scheme 9
| 1 - GENERATOR |
|---|
| 2 - IDLER/TENSIONER |
On the 2.7L engine, the accessory drive belt drives the generator, and air conditioning compressor. The P/S is driven by a separate, stretch to fit drive belt.
Scheme 10
| 1 - IDLER PULLEY |
|---|
| 2 - P/S PUMP PULLEY |
| 3 - ACCESSORY DRIVE BELT TENSIONER |
| 4 - A/C COMPRESSOR PULLEY |
| 5 - ACCESSORY DRIVE BELT |
| 6 - GENERATOR PULLEY |
On the 3.5L, the accessory drive belt drives the generator, P/S pump, and A/C compressor.
Scheme 11
| 1 - P/S PULLEY |
|---|
| 2 - GENERATOR PULLEY |
| 3 - IDLER PULLEY |
| 4 - A/C COMPRESSOR |
| 5 - CRANKSHAFT PULLEY |
| 6 - ACCESSORY DRIVE BELT TENSIONER |
| 7 - ACCESSORY DRIVE BELT |
The 2.0L Diesel engine accessory drive belt drives the P/S pump, Generator, and A/C compressor. Belt tension is maintained by an automatic accessory drive belt tensioner.
