Overhead Console - Service Information: Overview Dodge Journey I

Scheme 13

There are two different style's of overhead console (1) available on this vehicle, High line and Mid or Low line. All overhead consoles are equipped with a sunglasses storage bin (2) and two reading and courtesy lamps (4). On High line models, the reading lamps are a Light Emitting Diode (LED) multi directional design, and on the Mid or Low line design the lamps are fixed with a replaceable incandescent bulb. The sunglasses storage bin also has a conversation mirror that is visible when the bin is locked in the partial open position. On vehicles equipped with a power sunroof, the sunroof switch (5) is located behind the sunglasses bin. On vehicles equipped with automatic climate control an infrared temperature sensor (3) is located between the reading and courtesy lamps. Both overhead console designs are mounted with six snap clips into a molded plastic retainer bracket located above the headliner to provide secure overhead console attachment.

Scheme 14

1. Remove the overhead console (5). See «Removal»(ref-353606-S14468226032010011200000) .
2. Remove the four fasteners (3) that secure the sunglasses bin (6) to the console.
3. Remove the bin from the console.

Scheme 15

1. Disconnect and isolate the battery negative cable.
2. Using your fingertips, grasp the sides of the overhead console (1) and pull straight down evenly to disengage the snap clips from the mounting bracket.
3. Lower the overhead console (5) far enough to access the wire harness connectors.
4. If equipped, disconnect the courtesy lamps (1), infrared temperature sensor (2) and power sunroof switch (4) electrical connectors.
5. Remove the overhead console assembly from the vehicle.
