FASTENER TORQUE
| Description | N.m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| All Screws NOT Listed Below | 1.2 | 10 | |
| A/C Compressor to Engine Bolts | 25 | 18 | |
| A/C Pressure Transducer | 5.6 | 50 | |
| Front Air Distribution Housing Screws | 2.2 | 20 | |
| Front A/C Expansion Valve Bolts | 11 | 97 | |
| Front HVAC Actuator Mounting Screws | 2 | 17 | |
| Front HVAC Housing to Dash Panel Nuts | 4.5 | 40 | |
| Front Floor Duct to HVAC Housing Screw | 2 | 17 | |
| Front Mode Door Actuator Bracket Screws | 2 | 17 | |
| Instrument Panel Center Duct Screws | 2.2 | 20 | |
| Heat Shield to Dash Panel Nuts | 1 | 10 | |
| Liquid Refrigerant Lines to A/C Receiver/Drier Nut | 20 | 15 | |
| Lower to Upper Suction line Nut | 20 | 15 | |
| Rear A/C expansion Valve to Tapping Plate Bolts | 11 | 97 | |
| Rear Heater-A/C Housing to Quarter Panel Bolts | 3 | 27 | |
| Rear Seat Floor Duct to Floor Support Screw | 2.2 | 20 | |
| Refrigerant Lines to A/C Compressor Nuts | 20 | 15 | |
| Refrigerant Lines to A/C Condenser Nuts | 20 | 15 | |
| Refrigerant Lines to Front Expansion Valve Nut | 20 | 15 | |
| Refrigerant Lines to Rear Expansion Valve Nut | 11 | 97 | |
| Refrigerant Lines to Underbody Refrigerant Line Nut | 23 | 17 | |
| Seat Belt Retractor to D-Pillar Bolts | 52 | 38.5 | |
| Upper Seat Belt Bracket to D-Pillar Bolts | 52 | 38.5 | |
| Underbody and Extension Refrigerant Line Nuts | 23 | 17 |
Scheme 1
Scheme 2
Scheme 3
Scheme 4
The blend door actuators (1) for the front heating-A/C system are reversible, 12-volt direct current (DC) servo motors. Models with the front single zone heating-A/C system have a single blend-air door, which is controlled by a single blend door actuator. Models with the front dual zone heating-A/C system have dual blend-air doors, which are controlled by two blend door actuators.
The blend door actuator for the single zone heating-A/Csystem is located on the driver side front HVAC air distribution housing. For the dual zone heating-A/C system, the same blend door actuator used for the single zone system becomes the driver side blend door actuator, which is mechanically connected to only the driver side blend-air door. A second separate blend door actuator is also located on the passenger side of the front air distribution housing which is mechanically connected to only the passenger side blend-air door.
The blend door actuators are contained within a black molded plastic housing with an integral wire connector receptacle (2). An output shaft with splines (3) connect the blend door actuators to the blend door linkage. Three integral mounting tabs (4) allow the actuators to be secured to the air distribution housing. The blend door actuators do not require mechanical indexing to the blend door linkage, as they are electronically calibrated by the A/C-heater control.
The A/C-heater control must be recalibrated each time an actuator motor is replaced. Refer to DTC-Based Diagnostics/HVAC - Standard Procedure .
The blend door actuators are interchangeable with the actuators for the recirculation and mode-air doors.
REFRIGERANT CHARGE CAPACITY
| Application | Capacity |
|---|---|
| Front A/C Only | 0.624 kg (22 oz.) |
| Front and Rear A/C | 0.907 kg (32 oz.) |
REFRIGERANT CHARGE CAPACITY
Scheme 5
The A/C expansion valve controls the amount of refrigerant entering the A/C evaporator. The A/C expansion valve is of a thermostatic expansion valve (TXV) design and consists of an aluminum H-valve type body (1) with an inlet port (2), outlet port (3) and an integral thermal sensor (4).
The A/C expansion valve is located in the engine compartment at the dash panel, between the A/C refrigerant lines and the A/C evaporator.
