SPECIFICATIONS
| Application | Specification |
|---|
| Compressor Type | Nippondenso 10PA17 |
| Compressor Belt Tension (1) (2) |
| New Belt | 150-170 lbs. |
| Used Belt | 120 lbs. |
| System Oil Capacity | (3) 5.0 ozs. |
| Refrigerant (R-134a) Capacity | 1.56 lbs./25.0 ozs. |
| System Operating Pressures (4) |
| High Side | 210-250 psi (14.8-17.6 kg/cm 2 ) |
| Low Side | 20-30 psi (1.4-2.1 kg/cm 2 ) |
| (1) Measured with Belt Tension Gauge (7198). (2) See ADJUSTMENTS. (3) Use ND-8 PAG refrigerant oil. (4) With ambient temperature at 80°F (27°C). |
| (1) | Measured with Belt Tension Gauge (7198). |
| (3) | Use ND-8 PAG refrigerant oil. |
| (4) | With ambient temperature at 80°F (27°C). |
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| A/C Belt Tensioner Pivot Bolt |
| 2.7L Engine | 21 (28) |
| 3.2L & 3.5L Engine | 40 (54) |
| Accessory Drive Belt Tensioner Pulley Lock Nut | 40 (54) |
| Compressor Mounting Bolts | 21 (28) |
| Discharge Line-To-Condenser | 17 (23) |
| High Pressure Relief Valve | 10 (14) |
| Liquid Line Retainers | 15 (20) |
| Receiver-Drier Fittings | 10 (14) |
| Suction Line-To-Compressor Bolt | 17 (23) |
| INCH Lbs. (N.m) |
| A/C Pressure Transducer | 50 (5.6) |
| Condenser-To-Radiator Bolt | 45 (5.1) |
| Cooling Fan Module-To-Radiator Screw | 45 (5.1) |
| Liquid Line Plastic Bracket Screws | 60 (6.8) |
Manual A/C-Heater System Wiring Diagram (2000 Concorde & Intrepid). Scheme 15
Scheme 15: Manual A/C-Heater System Wiring Diagram (2000 Concorde & Intrepid)
Manual A/C-Heater System Wiring Diagram (2001 Concorde & Intrepid). Scheme 16
Scheme 16: Manual A/C-Heater System Wiring Diagram (2001 Concorde & Intrepid)
