Lighting System - Interior Dodge Grand Caravan IV

Interior/illumination Lights 8 illustrations ~499 words

INTERIOR LAMPS

BULB APPLICATION TABLE

LAMPBULB
ABSLED
AIRBAGLED
ALARM SETPC74
AUTOSTICKVFD (1)
BRAKE SYSTEM WARNINGLED
CONSOLE194
CRUISE INDICATORVFD (1)
DOME/RAIL LAMPS578
DOOR AJAR INDICATORLED
DOOR COURTESY LAMP578
FRONT DOOR COURTESY567
GLOVE BOX194
HIGH BEAM INDICATOR (BASE CLUSTER)LED
HIGH BEAM INDICATORPC74
CLUSTER ILLUMINATIONPC74
LIFTGATE578
LIFTGATE AJARLED
LOW FUEL INDICATORLED
LOW WASHER FLUID INDICATORLED
MIL (BASE CLUSTER)LED
MILPC74
OIL INDICATOR (BASE CLUSTER)LED
OIL INDICATORPC74
OVERHEAD CONSOLE READINGPC579
OVERDRIVE OFF INDICATORVFD (1)
READING578
SEAT BELT INDICATORLED
TEMPERATURE INDICATORLED
TRAC OFF INDICATORVFD (1)
TURN SIGNAL INDICATOR (BASE CLUSTER)LED
TURN SIGNAL INDICATORPC74
VISOR VANITY6501966
VOLTAGE INDICATORLED
(1) * VFD = VACUUM FLUORESCENT DISPLAY
(1)* VFD = VACUUM FLUORESCENT DISPLAY

BULB APPLICATION SPECIFICATIONS

REMOVAL

  1. Disconnect and isolate the battery negative cable.
  2. Open console lid and remove tray.
  3. Using a flat bladed tool, pry up on the switch.
  4. Remove bulb from switch.

INSTALLATION

  1. Install bulb into switch.
  2. Push switch into console opening.
  3. Install tray and close lid.
  4. Connect battery negative cable.
  1. Remove the Instrument Cluster. Refer to INSTRUMENT CLUSTER - REMOVAL .
  2. Turn over cluster and expose the illumination bulb sockets.
  3. Identify which bulb is defective and twist it out of the cluster using a counterclockwise motion.
  1. Install the new bulb socket into the cluster using a clockwise motion.
  2. Install the Instrument Cluster. Refer to INSTRUMENT CLUSTER - INSTALLATION .

Scheme 1

Scheme 1: REMOVAL
  1. Disconnect and isolate the battery negative cable.
  2. Using a trim stick, pry lamp from door panel (Scheme 1)
  3. Disconnect wire harness from the lamp.
  4. Remove lens from the lamp and remove bulb.
  1. Install bulb and lens to lamp.
  2. Reconnect wire harness to lamp.
  3. Press lamp into the door panel.
  4. Reconnect battery negative cable.
  1. Disconnect and isolate the battery negative cable.
  2. Using a flat bladed tool, pry off the lamp lens.
  3. Remove bulb from lamp.
  1. Install bulb to lamp.
  2. Press lens into place.
  3. Connect battery negative cable.

Scheme 2

Scheme 2: REMOVAL
  1. Disconnect and isolate the battery negative cable.
  2. Open glove box door.
  3. Push switch through from behind (Scheme 2)
  4. Disconnect wire harness from switch.
  5. Pull bulb from switch.
  1. Push bulb into switch.
  2. Connect wire harness to switch.
  3. Push switch into instrument panel.
  4. Close glove box door.
  5. Reconnect the battery negative cable.

Scheme 3

Scheme 3: REMOVAL
  1. Disconnect and isolate the battery negative cable.
  2. Using a flat bladed tool, pry lamp from trim panel (Scheme 3)
  3. Disconnect wire harness connector from lamp.
  4. Pry off lens and remove bulb.
  1. Install bulb and snap lens into place.
  2. Reconnect wire harness connector to lamp.
  3. Position lamp onto trim panel and snap into place.
  4. Reconnect battery negative cable.

The front reading lamps are incorporated into the overhead console. If the reading lamps require replacement, the overhead console must be replaced. (Refer to REMOVAL ). The rear reading lamps are incorporated into the assist handle. If the rear reading lamps require replacement, the assist handle must be replaced. (Refer to ASSIST HANDLE - REMOVAL ). The bulbs can be serviced separately.

Scheme 4

Scheme 4: REMOVAL

Scheme 5

Scheme 5

Scheme 6

Scheme 6

Scheme 7

Scheme 7
  1. Disconnect and isolate the battery negative cable.
  2. Using a flat bladed tool, pry off the lamp lens (Scheme 4), (Scheme 5)
  3. Remove bulb from lamp (Scheme 6), (Scheme 7)
  1. Install bulb to lamp.
  2. Press lens into place.
  3. Reconnect the battery negative cable.

The vanity lamp is incorporated into the visor assembly. If the vanity lamp needs to be replaced, the entire visor must be replaced. The bulbs are serviced separately.

Scheme 8

Scheme 8: REMOVAL
  1. Disconnect and isolate the battery negative cable.
  2. Using a pick or other suitable tool, pry the lens from the lamp (Scheme 8)
  3. Remove bulb.
  1. Install bulb.
  2. Snap lamp lens into position.
  3. Connect the battery negative cable.
