Power Distribution System Dodge Grand Caravan IV

Fuses & Circuit Breakers 8 illustrations ~179 words

Scheme 4

Scheme 4: Integrated Power Module (Front View)
Scheme 4: Integrated Power Module (Front View)

Scheme 5

Scheme 5: Integrated Power Module (Front View)
Scheme 5: Integrated Power Module (Front View)

Scheme 6

Scheme 6: Integrated Power Module (Rear View)
Scheme 6: Integrated Power Module (Rear View)

Scheme 7

Scheme 7: Fuse Identification Reference Chart
Scheme 7: Fuse Identification Reference Chart

Positive Temperature Coefficients Reference Chart

PTC NO.AMPSFUSED CIRCUITFUNCTION
48AC16 20DB/GYFUSED REAR WINDOW DEFOGGER RELAY OUTPUT
713AA105 18DB/RDFUSED B(+)

POSITIVE TEMPERATURE COEFFICIENTS REFERENCE CHART

Scheme 8

Scheme 8: A/C COMPRESSOR CLUTCH RELAY
Scheme 8: A/C COMPRESSOR CLUTCH RELAY

ACCESSORY RELAY

CAVITYCIRCUITFUNCTION
30INTERNALB(+)
85FCM 35ACCESSORY RELAY CONTROL (RUN-ACC)
86INTERNALB(+)
87INTERNALFUSED ACCESSORY RELAY OUTPUT
87A

ACCESSORY RELAY CAVITY FUNCTION

AUTO SHUTDOWN RELAY (GAS)

CAVITYCIRCUITFUNCTION
30K342 16BR/WTAUTOMATIC SHUT DOWN RELAY OUTPUT
85K51 18BR/WTAUTOMATIC SHUT DOWN RELAY CONTROL
86INTERNALFUSED B(+)
87INTERNALFUSED B(+)
87A

AUTO SHUTDOWN RELAY (GAS) CAVITY FUNCTION

DEFOGGER RELAY CAVITY FUNCTION

CAVITYCIRCUITFUNCTION
30INTERNALB(+)
85FCM31REAR WINDOW DEFOGGER RELAY CONTROL
86INTERNALB(+)
87INTERNALFUSED REAR WINDOW DEFOGGER RELAY OUTPUT
87A

DEFOGGER RELAY CAVITY FUNCTION

ECM/PCM RELAY (DIESEL)

CAVITYCIRCUITFUNCTION
30INTERNALFUSED B(+)
85K51 20BR/WTECM/PCM RELAY CONTROL
86INTERNALFUSED B(+)
87K342 16BR/WTECM/PCM RELAY OUTPUT
87A

ECM/PCM RELAY (DIESEL) CAVITY FUNCTION

FRONT BLOWER MOTOR RELAY

CAVITYCIRCUITFUNCTION
30INTERNALB(+)
85FCM 30FRONT BLOWER MOTOR RELAY CONTROL
86INTERNALB(+)
87C7 12DBFUSED FRONT BLOWER MOTOR RELAY OUTPUT
87A

FRONT BLOWER MOTOR RELAY CAVITY FUNCTION

FRONT FOG LAMP RELAY

CAVITYCIRCUITFUNCTION
30INTERNALFUSED B(+)
85FCM33FRONT FOG LAMP RELAY CONTROL
86INTERNALFUSED B(+)
87INTERNALFRONT FOG LAMP RELAY OUTPUT
87A

FRONT FOG LAMP RELAY CAVITY FUNCTION

FRONT WIPER HIGH/LOW RELAY

CAVITYCIRCUITFUNCTION
30INTERNALFRONT WIPER ON/OFF RELAY/OUTPUT
85FCM 34FRONT WIPER HIGH/LOW RELAY CONTROL
86INTERNALFRONT WIPER ON/OFF RELAY OUTPUT
87W4 12BR/ORFRONT WIPER HIGH/LOW RELAY HIGH SPEED OUTPUT
87AW3 12BR/WTFRONT WIPER HIGH/LOW RELAY LOW SPEED OUTPUT

FRONT WIPER HIGH/LOW RELAY CAVITY FUNCTION

FRONT WIPER ON/OFF RELAY

CAVITYCIRCUITFUNCTION
30INTERNALFRONT WIPER ON/OFF RELAY OUTPUT
85INTERNALFUSED B(+)
86FCM 14FRONT WIPER ON/OFF RELAY CONTROL
87INTERNALFUSED B(+)
87AINTERNALGROUND

FRONT WIPER ON/OFF RELAY CAVITY FUNCTION

FUEL HEATER RELAY (DIESEL)

CAVITYCIRCUITFUNCTION
30INTERNALFUSED B(+)
85Z114 18BK/LGGROUND
86INTERNALFUSED IGNITION SWITCH OUTPUT (RUN-START)
87N1 16DB/ORFUEL HEATER RELAY OUTPUT
87A

FUEL HEATER RELAY (DIESEL) CAVITY FUNCTION

FUEL PUMP RELAY (GAS)

CAVITYCIRCUITFUNCTION
30N1 18DB/ORFUEL PUMP RELAY OUTPUT
85K31 18BRFUEL PUMP RELAY CONTROL
86INTERNALFUSED IGNITION SWITCH OUTPUT (RUN-START)
87INTERNALFUSED B(+)
87A

FUEL PUMP RELAY (GAS) CAVITY FUNCTION

HEADLAMP WASHER RELAY (EXPORT)

CAVITYCIRCUITFUNCTION
30INTERNALFUSED B(+)
85FCM 32HEADLAMP WASHER RELAY CONTROL
86INTERNALFUSED B(+)
87V53 12BR/ORHEADLAMP WASHER RELAY OUTPUT
87A

HEADLAMP WASHER RELAY (EXPORT) CAVITY FUNCTION

HORN RELAY

CAVITYCIRCUITFUNCTION
30INTERNALFUSED B(+)
85FCM 10HORN RELAY CONTROL
86INTERNALFUSED B(+)
87X2 18DG/ORHORN RELAY OUTPUT
87A

HORN RELAY CAVITY FUNCTION

LIFT PUMP RELAY (DIESEL)

CAVITYCIRCUITFUNCTION
30INTERNALFUSE DB(+)
85N21 20DB/TNLIFT PUMP RELAY CONTROL
86F202 18PK/GYFUSED IGNITION SWITCH OUTPUT (RUN-START)
87N2 18DB/YLLIFT PUMP RELAY OUTPUT
87A

LIFT PUMP RELAY (DIESEL) CAVITY FUNCTION

NAME BRAND SPEAKER RELAY

CAVITYCIRCUITFUNCTION
30INTERNALFUSED B(+) (I.O.D.)
85FCM 11NAME BRAND SPEAKER (NBS) RELAY CONTROL
86INTERNALFUSED B(+) (I.O.D.)
87X1 16DG/BRNAME BRAND SPEAKER (NBS) RELAY OUTPUT
87A

NAME BRAND SPEAKER RELAY CAVITY FUNCTION

PARK LAMP RELAY

CAVITYCIRCUITFUNCTION
30INTERNALB(+)
85FCM 13PARK LAMP RELAY CONTROL
86INTERNALB(+)
87INTERNALPARK LAMP RELAY OUTPUT
87A

PARK LAMP RELAY CAVITY FUNCTION

REAR BLOWER MOTOR RELAY (3 ZONE)

CAVITYCIRCUITFUNCTION
30INTERNALB(+)
85FCM 30REAR BLOWER MOTOR RELAY CONTROL
86INTERNALB(+)
87C51 12LB/BRFUSED REAR BLOWER MOTOR RELAY OUTPUT
87A

REAR BLOWER MOTOR RELAY (3 ZONE) CAVITY FUNCTION

Scheme 9

Scheme 9: STARTER MOTOR RELAY
Scheme 9: STARTER MOTOR RELAY

Scheme 10

Scheme 10: TRANSMISSION CONTROL RELAY (EATX)
Scheme 10: TRANSMISSION CONTROL RELAY (EATX)

Scheme 11

Scheme 11: FRONT CONTROL MODULE
Scheme 11: FRONT CONTROL MODULE
