DIAGNOSTIC TEST PROCEDURE

Diagnostic test procedures are designed to detect system faults as quickly as possible. Body fault codes are accessed through Chrysler Collision Detection (CCD) bus diagnostic connector. On Dynasty and New Yorker, CCD bus diagnostic connector is located under middle of dashboard. On Fifth Avenue and Imperial, CCD bus diagnostic connector is located under left side of dash. (Scheme 451) Chrysler's Diagnostic Readout Box II (DRB-II) tester is used to access information from CCD bus diagnostic connector.

Scheme 451

DRB-II tester, jumper wires, analog volt/ohmmeter and circuit tester will be needed for testing. Proceed to TEST 1: IDENTIFYING VEHICLE EQUIPMENT & SYSTEM PROBLEMS in this article. When system problem is identified according to customer's complaint, perform diagnostic test indicated in flow chart. Information for using the DRB-II during testing is given in diagnostic charts. Once problem has been determined, perform test procedures using these guidelines

1. Always start at the first test in each category or incorrect results may occur.
2. Only perform test steps indicated. It is NOT necessary to perform all steps in a test.
3. At the end of each test step, reconnect all wires and install any components removed for testing.
4. Vehicle battery must be fully charged.
5. Use extreme care when connecting or disconnecting wiring during testing to prevent accidental grounding or shorting.
6. DO NOT use a test light in place of a voltmeter. Damage to electronic components may occur.

CCD BUS TESTING

Using DRB-II tester, a bus problem will show up in one of 3 ways. Despite passing automatic bus test, a NO RESPONSE message may be displayed rather than an expected value on the DRB-II. It is impossible to use DRB-II until reason for NO RESPONSE message is found and corrected. A NO RESPONSE message can be caused by

1. a bus wire open or poorly connected at a module
2. ground or power supply is missing at certain modules
3. ignition is turned off and body controller has timed out

A major bus failure can cause anything from an ENGINE NO START CONDITION to a blank message screen on Electronic Vehicle Information Center (EVIC) head. The automatic bus test will not complete or allow access to further system tests at this point and Red light on DRB-II will come on. A major bus failure can be caused by

1. Short To Ground
2. Short To Battery Voltage
3. Short To 5 Volts
4. Bus "+" & Bus "-" Shorted Together

Critical bus messages preventing bus from operating properly are

1. NO TERMINATION
2. BIAS LEVEL TOO HIGH
3. BIAS LEVEL TOO LOW
4. NO BUS BIAS
5. BUS - OPEN
6. BUS + OPEN
7. BUS + & BUS - OPEN
8. NOT RECEIVING BUS MESSAGES CORRECTLY

DRB-II will display any of these messages on display screen and then go to the next level of testing with no Red light. The only interference will come when trying to access a module directly related to or causing bus failure. A NO RESPONSE message will then appear.

Scheme 452

Scheme 453

Scheme 454

Scheme 455

Note. The following trouble shooting charts and illustrations are Courtesy of Chrysler Motors.

Test 1: Flow Chart (1 of 3). Scheme 456

Test 1: Flow Chart (2 of 3). Scheme 457

Test 1: Flow Chart (3 of 3). Scheme 458

Test 2: Circuit Diagram. Scheme 459

Test 2: Flow Chart (1 of 3). Scheme 460

Test 2: Flow Chart (2 of 3). Scheme 461

Test 2: Flow Chart (3 of 3). Scheme 462

Test 3: Flow Chart (1 of 2). Scheme 463

Test 3: Flow Chart (2 of 2). Scheme 464

Test 4: Circuit Diagram. Scheme 465

Test 4: Flow Chart. Scheme 466

Test 5: Circuit Diagram. Scheme 467

Test 5: Flow Chart. Scheme 468

Test 6: Circuit Diagram. Scheme 469

Test 6: Flow Chart. Scheme 470

Test 7: Circuit Diagram. Scheme 471

Test 7: Flow Chart. Scheme 472

Test 8: Circuit Diagram. Scheme 473

Test 8: Flow Chart. Scheme 474

Test 9: Circuit Diagram. Scheme 475

Test 9: Flow Chart. Scheme 476

Test 10: Circuit Diagram. Scheme 477

Test 10: Flow Chart. Scheme 478

Test 11: Circuit Diagram. Scheme 479

Test 11: Flow Chart. Scheme 480

Test 12: Circuit Diagram. Scheme 481

Test 12: Flow Chart (1 of 2). Scheme 482

Test 12: Flow Chart (2 of 2). Scheme 483

Test 13: Circuit Diagram. Scheme 484

Test 13: Flow Chart. Scheme 485

Test 14: Circuit Diagram. Scheme 486

Test 14: Flow Chart. Scheme 487

Test 15: Circuit Diagram (For 1 of 2). Scheme 488

Test 15: Flow Chart (1 of 2). Scheme 489

Test 15: Circuit Diagram (For 2 of 2). Scheme 490

Test 15: Flow Chart (2 of 2). Scheme 491

Test 16: Circuit Diagram (For 1 of 2). Scheme 492

Test 16: Flow Chart (1 of 2). Scheme 493

Test 16: Flow Chart (2 of 2). Scheme 494

Test 17: Circuit Diagram. Scheme 495

Test 17: Flow Chart. Scheme 496

Test 18: Circuit Diagram. Scheme 497

Test 18: Flow Chart. Scheme 498

Test 19: Circuit Diagram. Scheme 499

Test 19: Flow Chart. Scheme 500

Test 20: Circuit Diagram. Scheme 501

Test 20: Flow Chart. Scheme 502

Test 21: Circuit Diagram & Flow Chart. Scheme 503

Test 22: Circuit Diagram. Scheme 504

Test 22: Flow Chart. Scheme 505

Test 23: Circuit Diagram. Scheme 506

Test 23: Flow Chart. Scheme 507

Test 24: Circuit Diagram. Scheme 508

Test 24: Flow Chart. Scheme 509

Test 25: Flow Chart. Scheme 510

Test 26: Circuit Diagram. Scheme 511

Test 26: Flow Chart. Scheme 512

Test 27: Circuit Diagram. Scheme 513

Test 27: Flow Chart. Scheme 514

Test 28: Circuit Diagram. Scheme 515

Test 28: Flow Chart. Scheme 516

Test 29: Circuit Diagram. Scheme 517

Test 29: Flow Chart. Scheme 518

Test 30: Flow Chart. Scheme 519

Test 31: Circuit Diagram. Scheme 520

Test 31: Flow Chart. Scheme 521

Test 32: Circuit Diagram. Scheme 522

Test 32: Flow Chart (1 of 2). Scheme 523

Test 32: Flow Chart (2 of 2). Scheme 524

Test 33: Circuit Diagram & Flow Chart. Scheme 525

Test 34: Circuit Diagram (For 1 of 2). Scheme 526

Test 34: Flow Chart (1 of 2). Scheme 527

Test 34: Circuit Diagram & Flow Chart (2 of 2). Scheme 528

Test 35: Circuit Diagram. Scheme 529

Test 35: FLow Chart. Scheme 530

Test 36: Circuit Diagram. Scheme 531

Test 36: Flow Chart (1 of 2). Scheme 532

Test 36: Circuit Diagram & Flow Chart (2 of 2). Scheme 533

Test 37: Circuit Diagram. Scheme 534

Test 37: Flow Chart. Scheme 535

Test 38: Flow Chart. Scheme 536

Test 39: Flow Chart (1 of 4). Scheme 537

Test 39: Circuit Diagram (For 2 of 4). Scheme 538

Test 39: Flow Chart (2 of 4). Scheme 539

Test 39: Flow Chart (3 of 4). Scheme 540

Test 39: Flow Chart (4 of 4). Scheme 541

Test 40: Flow Chart (1 of 3). Scheme 542

Test 40: Circuit Diagram (For 2 of 3). Scheme 543

Test 40: Flow Chart (2 of 3). Scheme 544

Test 40: Circuit Diagram (For 3 of 3). Scheme 545

Test 40: Flow Chart (3 of 3). Scheme 546

Test 41: Flow Chart. Scheme 547

Test 42: Flow Chart. Scheme 548

Test 43: Flow Chart. Scheme 549

Test 44: Circuit Diagram. Scheme 550

Test 44: Flow Chart (1 of 2). Scheme 551

Test 44: Flow Chart (2 of 2). Scheme 552

Test 45: Circuit Diagram. Scheme 553

Test 45: Flow Chart (1 of 2). Scheme 554

Test 45: Flow Chart (2 of 2). Scheme 555

Test 46: Flow Chart (1 of 3). Scheme 556

Test 46: Circuit Diagram. Scheme 557

Test 46: Flow Chart (2 of 3). Scheme 558

Test 46: Flow Chart (3 of 3). Scheme 559

Test 47: Flow Chart. Scheme 560

Test 48: Flow Chart. Scheme 561

Test 49: Circuit Diagram. Scheme 562

Test 49: Flow Chart (1 of 2). Scheme 563

Test 49: Flow Chart (2 of 2). Scheme 564

Test 50: Circuit Diagram (For 1 & 2 of 6). Scheme 565

Test 50: Flow Chart (1 of 6). Scheme 566

Test 50: Flow Chart (2 of 6). Scheme 567

Test 50: Circuit Diagram (For 3 of 6). Scheme 568

Test 50: Flow Chart (3 of 6). Scheme 569

Test 50: Circuit Diagram (For 4 of 6). Scheme 570

Test 50: Flow Chart (4 of 6). Scheme 571

Test 50: Circuit Diagram (For 5 & 6 of 6). Scheme 572

Test 50: Flow Chart (5 of 6). Scheme 573

Test 50: Flow Chart (6 of 6). Scheme 574

Test 51: Flow Chart. Scheme 575

Test 52: Circuit Diagram. Scheme 576

Test 52: Flow Chart (1 of 2). Scheme 577

Test 52: Flow Chart (2 of 2). Scheme 578

Test 53: Flow Chart. Scheme 579

Test 54: Circuit Diagram. Scheme 580

Test 54: FLow Chart (1 of 2). Scheme 581

Test 54: Flow Chart (2 of 2). Scheme 582

Test 55: Circuit Diagram. Scheme 583

Test 55: Flow Chart (1 of 2). Scheme 584

Test 55: Flow Chart (2 of 2). Scheme 585

Test 56: Flow Chart (1 of 4). Scheme 586

Test 56: Flow Chart (2 of 4). Scheme 587

Test 56: Flow Chart (3 of 4). Scheme 588

Test 56: Flow Chart (4 of 4). Scheme 589

Test 57: Circuit Diagram. Scheme 590

Test 57: Flow Chart. Scheme 591

Test 58: Circuit Diagram. Scheme 592

Test 58: Flow Chart. Scheme 593

Test 59: Circuit Diagram. Scheme 594

Test 59: Flow Chart. Scheme 595

Test 60A: Flow Chart. Scheme 596

Test 60B: Circuit Diagram & Flow Chart. Scheme 597

Test 61: Circuit Diagram & Flow Chart. Scheme 598

Test 62: Circuit Diagram & Flow Chart. Scheme 599

Test 63: Circuit Diagram & Flow Chart. Scheme 600

Test 64: Circuit Diagram & Flow Chart. Scheme 601

Test 65: Flow Chart. Scheme 602

Test 66: Circuit Diagram & Flow Chart (1 of 2). Scheme 603

Test 66: Circuit Diagram & Flow Chart (2 of 2). Scheme 604

Test 67: Circuit Diagram & Flow Chart. Scheme 605

Test 68: Circuit Diagram & Flow Chart. Scheme 606

Test 69: Circuit Diagram & Flow Chart. Scheme 607

Test 70: Circuit Diagram & Flow Chart. Scheme 608

Test 71: Circuit Diagram & Flow Chart. Scheme 609

Test 72: Circuit Diagram & Flow Chart. Scheme 610

Test 73: Circuit Diagram & Flow Chart. Scheme 611

Test 74: Circuit Diagram & Flow Chart. Scheme 612

Test 75: Circuit Diagram & Flow Chart. Scheme 613

Test 76: Circuit Diagram & Flow Chart. Scheme 614

Test 77: Circuit Diagram & Flow Chart. Scheme 615

Test 78: Circuit Diagram & Flow Chart. Scheme 616

Test 79: Circuit Diagram & Flow Chart. Scheme 617

Test 80: Circuit Diagram. Scheme 618

Test 80: Flow Chart (1 of 2). Scheme 619

Test 80: Flow Chart (2 of 2). Scheme 620

Test 81: Circuit Diagram & Flow Chart. Scheme 621

Test 82: Circuit Diagram & Flow Chart. Scheme 622

Test 83: Circuit Diagram (For 1 of 3). Scheme 623

Test 83: Flow Chart (1 of 3). Scheme 624

Test 46: Circuit Diagram (For 2 & 3 of 3). Scheme 625

Test 83: Flow Chart (2 of 3). Scheme 626

Test 83: Flow Chart (3 of 3). Scheme 627

Test 84: Flow Chart (1 of 3). Scheme 628

Test 84: Flow Chart (2 of 3). Scheme 629

Test 84: Flow Chart (3 of 3). Scheme 630

Test 85: Circuit Diagram & Flow Chart (1 of 2). Scheme 631

Test 85: Circuit Diagram & Flow Chart (2 of 2). Scheme 632

Test 86: Circuit Diagram & Flow Chart. Scheme 633

Test 87: Circuit Diagram. Scheme 634

Test 87: Flow Chart. Scheme 635

Test 88: Flow Chart (1 of 2). Scheme 636

Test 88: Circuit Diagram & Flow Chart (2 of 2). Scheme 637

Test 89: Flow Chart. Scheme 638

Test 90: Circuit Diagram. Scheme 639

Test 90: Flow Chart. Scheme 640

Test 91: Circuit Diagram. Scheme 641

Test 91: Flow Chart. Scheme 642

Test 92: Circuit Diagram. Scheme 643

Test 92: Flow Chart. Scheme 644

Test 93: Flow Chart (1 of 3). Scheme 645

Test 93: Flow Chart (2 of 3). Scheme 646

Test 93: Circuit Diagram & Flow Chart (3 of 3). Scheme 647

Test 94: Circuit Diagram & Flow Chart. Scheme 648

Test 95: Circuit Diagram & Flow Chart. Scheme 649

Test 96: Circuit Diagram & Flwo Chart. Scheme 650

Test 97: Circuit Diagram & Flow Chart. Scheme 651

Test 98: Circuit Diagram (For 1 of 2). Scheme 652

Test 98: FLow Chart (1 of 2). Scheme 653

Test 98: Circuit Diagram (For 2 of 2). Scheme 654

Test 98: Flow Chart (2 of 2). Scheme 655

Test 99: Circuit Diagram & Flow Chart. Scheme 656

Test 100: Circuit Diagram & Flow Chart. Scheme 657

Test 101: Flow Chart (1 of 4). Scheme 658

Test 101: Circuit Diagram & Flow Chart (2 of 4). Scheme 659

Test 101: Circuit Diagram & Flow Chart (3 of 4). Scheme 660

Test 101: Circuit Diagram & Flow Chart (4 of 4). Scheme 661

Test 102: Circuit Diagram. Scheme 662

Test 102: Flow Chart. Scheme 663

Test 103: Flow Chart (1 of 2). Scheme 664

Test 103: Circiut Diagram & Flow Chart (2 of 2). Scheme 665

Test 104: Circuit Diagram & Flow Chart. Scheme 666

Test 105: Circuit Diagram & Flow Chart. Scheme 667

Test 106: Circuit Diagram & Flow Chart. Scheme 668

Test 107: Circuit Diagram & Flow Chart. Scheme 669

Test 108: Flow Chart. Scheme 670

Test 109: Flow Chart (1 of 2). Scheme 671

Test 109: Circuit Diagram & Flow Chart (2 of 2). Scheme 672

Test 110: Flow Chart (1 of 2). Scheme 673

Test 110: Flow Chart (2 of 2). Scheme 674

Test 111: Circuit Diagram & Flow Chart (1 of 4). Scheme 675

Test 111: Flow Chart (2 of 4). Scheme 676

Test 111: Flow Chart (3 of 4). Scheme 677

Test 111: Flow Chart (4 of 4). Scheme 678

Test 112: Flow Chart (1 of 2). Scheme 679

Test 112: Flow Chart (2 of 2). Scheme 680

Test 113: Flow Chart (1 of 3). Scheme 681

Test 113: Flow Chart (2 of 3). Scheme 682

Test 113: Flow Chart (3 of 3). Scheme 683

Test 114: Flow Chart (1 of 3). Scheme 684

Test 114: Flow Chart (2 of 3). Scheme 685

Test 114: Flow Chart (3 of 3). Scheme 686

Test 115: Flow Chart (1 of 3). Scheme 687

Test 115: Flow Chart (2 of 3). Scheme 688

Test 115: Flow Chart (3 of 3). Scheme 689

Test 116: Circuit Diagram & Flow Chart. Scheme 690

Test 117: Circuit Diagram & Flow Chart. Scheme 691

Test 118: Circuit Diagram & Flow Chart. Scheme 692

Test 119: Circuit Diagram & Flow Chart. Scheme 693

Test 120: Circuit Diagram & Flow Chart. Scheme 694

Test 121: Circuit Diagram. Scheme 695

Test 121: Flow Chart. Scheme 696

Test 122: Flow Chart (1 of 2). Scheme 697

Test 122: Flow Chart (2 of 2). Scheme 698

Test 123: Circuit Diagram & Flow Chart. Scheme 699

Test 124: Flow Chart (1 of 2). Scheme 700

Test 124: Flow Chart (2 of 2). Scheme 701

Test 125: Flow Chart (1 of 2). Scheme 702

Test 125: Flow Chart (2 of 2). Scheme 703

Test 126: Flow Chart (1 of 2). Scheme 704

Test 126: Flow Chart (2 of 2). Scheme 705

Test 127: Circuit Diagram & Flow Chart. Scheme 706
