SPECIFICATION - TORQUE
| DESCRIPTION | N.m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| Front Bumper Reinforcement Nuts | 109 | 80 | |
| Front End Sheet Metal Mount Bolt | 81 | 60 | |
| Front Crossmember Bolts/Nuts | 102 | 75 | |
| Front Tow Hook Bracket Nuts | 109 | 80 | |
| Front Tow Hook/Bumper Reinforcement Nuts | 109 | 80 | |
| Fuel Tank Skid Plate Bolts - Inboard | 41 | 30 | |
| Fuel Tank Skid Plate Bolts - Outboard | 37 | 27 | |
| Lower Radiator Crossmember Bolts | 28 | 21 | |
| Trailer Hitch Bolts/Nuts | 183 | 135 | |
| Transfer Case Skid Plate Bolts | 23 | 17 |
TORQUE SPECIFICATIONS
Scheme 1
Scheme 2
Scheme 3
- Remove the wheel well splash shield screws.
- Remove the two impact beam screws (1).
- Remove the two air dam to wheel liner screws (2).
- Disconnect the fog lamp electrical connectors, if equipped.
- Remove the fender screws (5).
- Release the upper tabs (1) and remove the fascia.
SPECIFICATION - WELDING
| CAUTION | All welds should conform to DaimlerChrysler vehicle engineering process standard "PS 9472". |
| WELDING PROCESS | FLUX CORED ARC | GAS METAL ARC (MIG)* | SHIELDED METAL ARC (STICK) |
|---|---|---|---|
| Material Thickness | 3.7 mm to 4.2 mm | 3.7 mm to 4.2 mm | 3.7 mm to 4.2 mm |
| Electrode Type | Lincoln Electrical Co. Product #: NR-211 MP (Do Not Substitute) | AWS ER70S-3 (Do Not Substitute) | ** AWS E 7018 |
| Electrodes Size Inches | .045 Tubular | .035 Solid | 3/32" |
| Electrode Stick Out | 3/8" - 1/2" | 1/2" - 5/8" | N/A |
| Polarity | Electrode "-" Work Piece "+" | Electrode "+" Work Piece "-" | Electrode "+" Work Piece "-" |
| Shielding Gas | Self Shielded | 75% Ar 25% CO2 | Self Shielded |
| Gas Flow Rate | N/A | 25 - 35 CFM | N/A |
| Wire Feed Speed (inches per minute) | 110 - 130 Vertical Down 70 - 90 Flat & Overhead | 245 - 250 Vertical Down 210 - 225 Flat & Overhead | N/A |
| Approximate Amperage | |||
| Vertical | 110 - 130 | 175 | 85 (3/32" Diameter) |
| Flat & Overhead | 70 - 90 | 155 | 90 (3/32" Diameter) |
| Voltage | 15 - 18 | 19 - 20 | N/A |
| Direction of Welding | |||
| Vertical | Vertical Down Hill (only) | Vertical Down Hill (only) | Vertical - Up Hill (only) |
| Flat & Overhead | Flat - Push or Drag | Flat - Push or Drag | Flat - Drag |
WELDING PARAMETERS
*First choice - Gas Metal Arc Welding Process: Butt joints - apply two layers (passes) of weld metal. First pass should only fill approximately 1/2 the thickness. Vertical position welds - maintain electrode wire at leading edge of weld puddle while traveling down hill to produce maximum penetration into the sleeve. These techniques work for FCAW as well.
**E7018 new electrodes may be exposed to the atmosphere for up to ten hours with no harmful effect. Reconditioning schedules should come from the manufacturer.
SPECIFICATIONS - FRAME DIMENSION
Frame dimensions are listed in metric scale. All dimensions are from center to center of Principal Locating Point (PLP), or from center to center of PLP and fastener location.
