TORQUE
| DESCRIPTION | N.m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| Shock Absorber Upper Nut | 102 | 75 | |
| Shock Absorber Lower Bolt | 81 | 60 | |
| Lower Suspension Arm Frame Nuts | 244 | 180 | |
| Lower Suspension Arm Ball Joint Nut | 95 | 70 | |
| Upper Suspension Arm Frame Nuts | 102 | 75 | |
| Upper Suspension Arm Ball Joint Nut | 75 | 55 | |
| Stabilizer Bar Frame Bolt | 61 | 45 | |
| Stabilizer Link to Lower Control Arm | 169 | 125 | |
| Stabilizer Link Stabilizer Bar Nut | 54 | 40 | |
| Hub/Bearing Bolts | 163 | 120 | |
| Tie Rod End to Knuckle Nut | 75 | 55 | |
| Tie Rod End Jam Nut | 130 | 96 |
Scheme 1
Scheme 2
Scheme 3
Scheme 4
Scheme 5
Scheme 6
TORQUE CHART
| DESCRIPTION | N.m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| Shock Absorber Lower Nut | 102 | 75 | |
| Shock Absorber Upper Bolt | 102 | 75 | |
| Stabilizer Retainer to the Axle | 61 | 45 | |
| Stabilizer Link to Stabilizer Bar | 102 | 75 | |
| Stabilizer Link to Frame | 102 | 75 | |
| Bell Crank to Differential Bolt | 251 | 185 | |
| Watts Link to Bell Crank | 108 | 80 | |
| Watts Lateral Link to Frame | 169 | 125 | |
| Lower Control Arm | 244 | 180 | |
| Upper Control Arm | 156 | 115 |
TORQUE SPECIFICATIONS
Scheme 7
- Raise and support the vehicle. NOTE: Rocking motion may be required while pulling the jounce bumper from the seating bracket
- Twist and pull out the jounce bumper to remove the jounce bumper from the seating bracket.
