Contents Section: Communication Devices All sections

Electronic Control Modules - Electrical Diagnostics: Diagnosis Dodge Durango II рестайлинг

Communication Devices 6 illustrations ~8688 words

DIAGNOSTIC CODE INDEX

DTCDescription
B210DBATTERY VOLTAGE LOW
B210EBATTERY VOLTAGE HIGH
B21125 VOLT SUPPLY CIRCUIT LOW
B21135 VOLT SUPPLY CIRCUIT HIGH
B2215FRONT CONTROL MODULE INTERNAL
U0001CAN C BUS CIRCUIT
U0021CAN B BUS (+) CIRCUIT OPEN
U0022CAN B BUS (+) CIRCUIT LOW
U0023CAN B BUS (+) CIRCUIT HIGH
U0024CAN B BUS (-) CIRCUIT OPEN
U0025CAN B BUS (-) CIRCUIT LOW
U0026CAN B BUS (-) CIRCUIT HIGH
U0027CAN B BUS (-) SHORTED TO BUS (+)
U0100LOST COMMUNICATION WITH ECM/PCM
U0101LOST COMMUNICATION WITH TCM
U0121LOST COMMUNICATION WITH ANTI-LOCK BRAKE SYSTEM (ABS) CONTROL MODULE
U0126LOST COMMUNICATION WITH SAS - CAN C (STEERING ANGLE SENSOR)
U0141LOST COMMUNICATION WITH FRONT CONTROL MODULE
U0151LOST COMMUNICATION WITH OCCUPANT RESTRAINT CONTROLLER (ORC)
U0155LOST COMMUNICATION WITH CLUSTER/CCN
U0156LOST COMMUNICATION WITH EOM
U0159LOST COMMUNICATION WITH PARK ASSIST CONTROL MODULE
U0164LOST COMMUNICATION WITH HVAC CONTROL MODULE
U0168LOST COMMUNICATION WITH VEHICLE SECURITY CONTROL MODULE (SKREEM/WCM)
U0184LOST COMMUNICATION WITH RADIO
U0186LOST COMMUNICATION WITH AUDIO AMPLIFIER
U0195LOST COMMUNICATION WITH SDARS
U0196LOST COMMUNICATION WITH VEHICLE ENTERTAINMENT CONTROL MODULE
U0197LOST COMMUNICATION WITH HANDS FREE PHONE MODULE
U0199LOST COMMUNICATION WITH DRIVER DOOR MODULE
U0200LOST COMMUNICATION WITH PASSENGER DOOR MODULE
U0208LOST COMMUNICATION WITH HEATED SEAT CONTROL MODULE
U0209LOST COMMUNICATION WITH MEMORY SEAT CONTROL MODULE
U0230LOST COMMUNICATION WITH POWER LIFTGATE MODULE
U1108ADDITIONAL CAN B ECU DETECTED
U110ALOST COMMUNICATION WITH SCM - CAN C (STEERING ANGLE SENSOR)

DIAGNOSTIC CODE INDEX

Diagnostic Test

  1. 1) CHECK FOR ANY POWERTRAIN CONTROL MODULES DTCS NOTE: Make sure the Battery is in good condition. Using the Midtronics Battery Tester, test the Battery before continuing. NOTE: Inspect the vehicle for after market accessories that may exceed the Generator System output. NOTE: Make sure the generator drive belt is in good operating condition. NOTE: Inspect the fuses in the IPM. If an open fuse is found, use the wire diagram/schematic as a guide, inspect the wiring and connectors for damage. Turn the ignition on. With the scan tool, read active PCM DTC's. Does the scan tool display any active PCM DTC's? Yes Refer to the appropriate Engine ELECTRICAL DIAGNOSTICS article for the diagnostic test procedure. No Check the above conditions that can cause a low voltage condition. Repair as necessary. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  1. 1) CHECK FOR ANY POWERTRAIN CONTROL MODULES DTCS NOTE: Make sure the Battery is in good condition. Using the Midtronics Battery Tester, test the Battery before continuing. NOTE: Inspect the vehicle for after market accessories that may exceed the Generator System output. NOTE: Make sure the generator drive belt is in good operating condition. NOTE: Inspect the fuses in the IPM. If an open fuse is found, use the wire diagram/schematic as a guide, inspect the wiring and connectors for damage. Turn the ignition on. With the scan tool, read active PCM DTC's. Does the scan tool display any active PCM DTC's? Yes Refer to the appropriate Engine ELECTRICAL DIAGNOSTICS article for the diagnostic test procedure. No Check the above conditions that can cause a high voltage condition. Repair as necessary. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .

Scheme 1

Scheme 1: Circuit Schematic
Scheme 1: Circuit Schematic
  1. 1) REPLACE THE FRONT CONTROL MODULE IF DTC IS ACTIVE With the scan tool, read the active DTC's. Does the scan tool display this DTC as active? Yes Replace and program the Front Control Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No If the DTC is stored, check for an intermittent condition. Visually inspect the related wiring harness connectors. Look for broken, bent, pushed out, or corroded terminals.

Scheme 2

Scheme 2: Circuit Schematic
Scheme 2: Circuit Schematic
  1. 1) TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase FCM DTC's. Cycle the ignition from on to off 3 times. Turn the ignition on. With the scan tool, read active FCM DTC's. Does the scan tool display this DTC as active? Yes Go to 2) . No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors.
  2. 2) CHECK THE (D55) CAN B BUS (+) CIRCUIT FOR A SHORT TO THE (D54) CAN B BUS (-) CIRCUIT Turn the ignition off. Disconnect the Front Control Module C1 harness connector. Measure the resistance between the (D55) CAN B Bus (+) circuit and (D54) CAN B Bus (-) circuit. Is resistance below 1000.0 ohms? Yes Go to 3) . No Inspect the wiring and connectors for damage or shorted circuits. If OK, replace the Front Control Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  3. 3) (D55) CAN B BUS (+) CIRCUIT SHORTED TO THE (D54) CAN B BUS (-) CIRCUIT Measure the resistance between the (D55) CAN B Bus (+) circuit and (D54) CAN B Bus (-) circuit. While monitoring the ohmmeter, disconnect each CAN B Bus module one at a time. NOTE: This is to determine if the short together is internal within a module or if the circuits are shorted together. NOTE: Disconnecting an in-line connector can eliminate a module or group of modules from the list of possible causes for this fault. Refer to the wiring diagrams to assist in diagnosis. Is resistance below 1000.0 ohms with all the CAN B Bus modules disconnected? Yes Repair the (D55) CAN B Bus (+) circuit for a short to the (D54) CAN B Bus (-) circuit. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Replace the module that when disconnected the short to ground was eliminated, in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .

Scheme 3

Scheme 3: Circuit Schematic
Scheme 3: Circuit Schematic
  1. 1) VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go to 2) . No Refer to the Stored Lost Communication test procedure. Refer to «DIAGNOSTIC CODE INDEX»(ref-285334-S11816595622008052100000) table. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  2. 2) CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read all active DTCs from all modules. NOTE: Check for FCM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to «DIAGNOSTIC CODE INDEX»(ref-285334-S11816595622008052100000) table for a complete list of the symptoms. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Go to 3) .
  3. 3) VERIFY THAT THE ECM/PCM IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select Network Diagnostics. Verify that the ECM/PCM is active on the bus. Is the ECM/PCM active on the bus? Yes Go to 4) . No See «DIAGNOSIS AND TESTING»(ref-285334-S40494593062008052100000) for NO RESPONSE diagnostic procedures. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  4. 4) CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network Diagnostics. Is there more than one module with active DTCs "Logged Against" the ECM/PCM? Yes Replace/update the ECM/PCM in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Replace/update the module that set this DTC in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  1. 1) VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go to 2) . No Refer to the Stored Lost Communication test procedure. Refer to «DIAGNOSTIC CODE INDEX»(ref-285334-S11816595622008052100000) table. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  2. 2) CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read all active DTCs from all modules. NOTE: Check for FCM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to «DIAGNOSTIC CODE INDEX»(ref-285334-S11816595622008052100000) table for a complete list of the symptoms. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Go to 3) .
  3. 3) VERIFY THAT THE TCM IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select Network Diagnostics. Verify that the TCM is active on the bus. Is the TCM active on the bus? Yes Go to 4) . No See «DIAGNOSIS AND TESTING»(ref-285334-S40494593062008052100000) for NO RESPONSE diagnostic procedures. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  4. 4) CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network Diagnostics. Is there more than one module with active DTCs "Logged Against" the TCM? Yes Replace/update the TCM (PCM) in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Replace/update the module that set this DTC in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  1. 1) VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go to 2) . No Refer to the Stored Lost Communication test procedure. Refer to «DIAGNOSTIC CODE INDEX»(ref-285334-S11816595622008052100000) table. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  2. 2) CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read all active DTCs from all modules. NOTE: Check for FCM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to «DIAGNOSTIC CODE INDEX»(ref-285334-S11816595622008052100000) table for a complete list of the symptoms. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Go to 3) .
  3. 3) VERIFY THAT THE ABS IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select Network Diagnostics. Verify that the ABS is active on the bus. Is the ABS active on the bus? Yes Go to 4) . No See «DIAGNOSIS AND TESTING»(ref-285334-S40494593062008052100000) for NO RESPONSE diagnostic procedures. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  4. 4) CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network Diagnostics. Is there more than one module with active DTCs "Logged Against" the ABS? Yes Replace/update the Antilock Brake Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Replace/update the module that set this DTC in accordance with the service information Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  1. 1) VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go to 2) . No Refer to the Stored Lost Communication test procedure. Refer to «DIAGNOSTIC CODE INDEX»(ref-285334-S11816595622008052100000) table. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  2. 2) CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read all active DTCs from all modules. NOTE: Check for FCM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to «DIAGNOSTIC CODE INDEX»(ref-285334-S11816595622008052100000) table for a complete list of the symptoms. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Go to 3) .
  3. 3) VERIFY THAT THE SCM (SAS) IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select Network Diagnostics. Verify that the SCM (SAS) is active on the bus. Is the SCM (SAS) active on the bus? Yes Go to 4) . No See «DIAGNOSIS AND TESTING»(ref-285334-S40494593062008052100000) for NO RESPONSE diagnostic procedures. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  4. 4) CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network Diagnostics. Is there more than one module with active DTCs "Logged Against" the SCM (SAS)? Yes Replace/update the Steering Angle Sensor (internal to the clockspring) in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Replace/update the module that set this DTC in accordance with the service information Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  1. 1) VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go to 2) . No Refer to the Stored Lost Communication test procedure. Refer to «DIAGNOSTIC CODE INDEX»(ref-285334-S11816595622008052100000) table. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  2. 2) CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read all active DTCs from all modules. NOTE: Check for FCM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to «DIAGNOSTIC CODE INDEX»(ref-285334-S11816595622008052100000) table for a complete list of the symptoms. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Go to 3) .
  3. 3) VERIFY THAT THE FCM IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select Network Diagnostics. Verify that the FCM is active on the bus. Is the FCM active on the bus? Yes Go to 4) . No See «DIAGNOSIS AND TESTING»(ref-285334-S40494593062008052100000) for NO RESPONSE diagnostic procedures. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  4. 4) CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network Diagnostics. Is there more than one module with active DTCs "Logged Against" the FCM? Yes Replace/update the Front Control Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Replace/update the module that set this DTC in accordance with the service information Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  1. 1) VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go to 2) . No Refer to the Stored Lost Communication test procedure. Refer to «DIAGNOSTIC CODE INDEX»(ref-285334-S11816595622008052100000) table. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  2. 2) CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read all active DTCs from all modules. NOTE: Check for FCM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to «DIAGNOSTIC CODE INDEX»(ref-285334-S11816595622008052100000) table for a complete list of the symptoms. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Go to 3) .
  3. 3) VERIFY THAT THE ORC IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select Network Diagnostics. Verify that the ORC is active on the bus. Is the ORC active on the bus? Yes Go to 4) . No See «DIAGNOSIS AND TESTING»(ref-285334-S40494593062008052100000) for NO RESPONSE diagnostic procedures. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  4. 4) CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network Diagnostics. Is there more than one module with active DTCs "Logged Against" the ORC? Yes Replace/update the Occupant Restraint Controller in accordance with the service information. Perform «*AIRBAG SYSTEM VERIFICATION TEST - VER 1»(ref-285381-S18028643042008052100000) . No Replace/update the module that set this DTC in accordance with the service information Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  1. 1) VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go to 2) . No Refer to the Stored Lost Communication test procedure. Refer to «DIAGNOSTIC CODE INDEX»(ref-285334-S11816595622008052100000) table. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  2. 2) CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read active DTCs from all modules. NOTE: Check for FCM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to «DIAGNOSTIC CODE INDEX»(ref-285334-S11816595622008052100000) table for a complete list of the symptoms. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Go to 3) .
  3. 3) VERIFY THAT THE CCN IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select Network Diagnostics. Verify that the CCN is active on the bus. Is the CCN active on the bus? Yes Go to 4) . No See «DIAGNOSIS AND TESTING»(ref-285334-S40494593062008052100000) for NO RESPONSE diagnostic procedures. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  4. 4) CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network Diagnostics. Is there more than one module with active DTCs "Logged Against" the CCN? Yes Replace/update the Cluster (CCN) in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Replace/update the module that set this DTC in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  1. 1) VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go to 2) . No Refer to the Stored Lost Communication test procedure. Refer to «DIAGNOSTIC CODE INDEX»(ref-285334-S11816595622008052100000) table. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  2. 2) CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read all active DTCs from all modules. NOTE: Check for FCM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to «DIAGNOSTIC CODE INDEX»(ref-285334-S11816595622008052100000) table for a complete list of the symptoms. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Go to 3) .
  3. 3) VERIFY THAT THE EOM IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select Network Diagnostics. Verify that the EOM is active on the bus. Is the EOM active on the bus? Yes Go to 4) . No See «DIAGNOSIS AND TESTING»(ref-285334-S40494593062008052100000) for NO RESPONSE diagnostic procedures. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  4. 4) CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network Diagnostics. Is there more than one module with active DTCs "Logged Against" the EOM? Yes Replace/update the Electronic Overhead Module (EOM) in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Replace/update the module that set this DTC in accordance with the service information Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  1. 1) VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go to 2) . No Refer to the Stored Lost Communication test procedure. Refer to «DIAGNOSTIC CODE INDEX»(ref-285334-S11816595622008052100000) table. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  2. 2) CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read all active DTCs from all modules. NOTE: Check for FCM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to «DIAGNOSTIC CODE INDEX»(ref-285334-S11816595622008052100000) table for a complete list of the symptoms. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Go to 3) .
  3. 3) VERIFY THAT THE PTS IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select ECU View. Verify that the PTS is active on the bus. Is the PTS active on the bus? Yes Go to 4) . No Refer to «DIAGNOSTIC CODE INDEX»(ref-285334-S11816595622008052100000) table for a NO RESPONSE test procedure. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  4. 4) CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network View and select Advanced. Is there more than one module with active DTCs "Logged Against" the PTS? Yes Replace/update the Park Assist Module (PTS) in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Replace/update the module that set this DTC in accordance with the service information Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  1. 1) VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go to 2) . No Refer to the Stored Lost Communication test procedure. Refer to «DIAGNOSTIC CODE INDEX»(ref-285334-S11816595622008052100000) table. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  2. 2) CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read active DTCs from all modules. NOTE: Check for FCM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to «DIAGNOSTIC CODE INDEX»(ref-285334-S11816595622008052100000) table for a complete list of the symptoms. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Go to 3) .
  3. 3) VERIFY THAT THE HVAC IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select Network Diagnostics. Verify that the HVAC is active on the bus. Is the HVAC active on the bus? Yes Go to 4) . No See «DIAGNOSIS AND TESTING»(ref-285334-S40494593062008052100000) for NO RESPONSE diagnostic procedures. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  4. 4) CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network Diagnostics. Is there more than one module with active DTCs "Logged Against" the HVAC? Yes Replace/update the A/C Heater Control in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Replace/update the module that set the DTC in accordance with the service information Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  1. 1) VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go to 2) . No Refer to the Stored Lost Communication test procedure. Refer to «DIAGNOSTIC CODE INDEX»(ref-285334-S11816595622008052100000) table. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  2. 2) CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read active DTCs from all modules. NOTE: Check for FCM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to «DIAGNOSTIC CODE INDEX»(ref-285334-S11816595622008052100000) table for a complete list of the symptoms. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Go to 3) .
  3. 3) VERIFY THAT THE WCM IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select Network Diagnostics. Verify that the WCM is active on the bus. Is the WCM active on the bus? Yes Go to 4) . No See «DIAGNOSIS AND TESTING»(ref-285334-S40494593062008052100000) for NO RESPONSE diagnostic procedures. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  4. 4) CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network Diagnostics. Is there more than one module with active DTCs "Logged Against" the WCM? Yes Replace/update the Sentry Key Remote Entry Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Replace/update the module that set this DTC in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  1. 1) VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go to 2) . No Refer to the Stored Lost Communication test procedure. Refer to «DIAGNOSTIC CODE INDEX»(ref-285334-S11816595622008052100000) table. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  2. 2) CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read active DTCs from all modules. NOTE: Check for FCM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to «DIAGNOSTIC CODE INDEX»(ref-285334-S11816595622008052100000) table for a complete list of the symptoms. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Go to 3) .
  3. 3) VERIFY THAT THE RADIO IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select Network Diagnostics. Verify that the Radio is active on the bus. Is the Radio active on the bus? Yes Go to 4) . No See «DIAGNOSIS AND TESTING»(ref-285334-S40494593062008052100000) for NO RESPONSE diagnostic procedures. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  4. 4) CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network Diagnostics. Is there more than one module with active DTCs "Logged Against" the Radio? Yes Replace/update the Radio in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Replace/update the module that set this DTC in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  1. 1) VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go to 2) . No Refer to the Stored Lost Communication test procedure. Refer to «DIAGNOSTIC CODE INDEX»(ref-285334-S11816595622008052100000) table. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  2. 2) CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read active DTCs from all modules. NOTE: Check for FCM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to «DIAGNOSTIC CODE INDEX»(ref-285334-S11816595622008052100000) table for a complete list of the symptoms. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Go to 3) .
  3. 3) VERIFY THAT THE AMPLIFIER IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select Network Diagnostics. Verify that the Amplifier is active on the bus. Is the Amplifier active on the bus? Yes Go to 4) . No See «DIAGNOSIS AND TESTING»(ref-285334-S40494593062008052100000) for NO RESPONSE diagnostic procedures. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  4. 4) CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network Diagnostics. Is there more than one module with active DTCs "Logged Against" the Amplifier? Yes Replace/update the Amplifier in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Replace/update the module that set this DTC in accordance with the service information Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  1. 1) VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go to 2) . No Refer to the Stored Lost Communication test procedure. Refer to «DIAGNOSTIC CODE INDEX»(ref-285334-S11816595622008052100000) table. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  2. 2) CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read active DTCs from all modules. NOTE: Check for FCM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to «DIAGNOSTIC CODE INDEX»(ref-285334-S11816595622008052100000) table for a complete list of the symptoms. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Go to 3) .
  3. 3) VERIFY THAT THE SATELLITE RECEIVER IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select Network Diagnostics. Verify that the SDARS is active on the bus. Is the SDARS active on the bus? Yes Go to 4) . No See «DIAGNOSIS AND TESTING»(ref-285334-S40494593062008052100000) for NO RESPONSE diagnostic procedures. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  4. 4) CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network Diagnostics. Is there more than one module with active DTCs "Logged Against" the SDARS? Yes Replace/update the Satellite Receiver in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Replace/update the module that set the DTC in accordance with the service information Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  1. 1) VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go to 2) . No Refer to the Stored Lost Communication test procedure. Refer to «DIAGNOSTIC CODE INDEX»(ref-285334-S11816595622008052100000) table. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  2. 2) CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read active DTCs from all modules. NOTE: Check for FCM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to «DIAGNOSTIC CODE INDEX»(ref-285334-S11816595622008052100000) table for a complete list of the symptoms. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Go to 3) .
  3. 3) VERIFY THAT THE VEHICLE ENTERTAINMENT SYSTEM (VES) IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select Network Diagnostics. Verify that the VES is active on the bus. Is the VES active on the bus? Yes Go to 4) . No See «DIAGNOSIS AND TESTING»(ref-285334-S40494593062008052100000) for NO RESPONSE diagnostic procedures. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  4. 4) CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network Diagnostics. Is there more than one module with active DTCs "Logged Against" the VES? Yes Replace/update the Monitor/DVD Media System (DVD Player) in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Replace/update the module that set this DTC in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  1. 1) VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go to 2) . No Refer to the Stored Lost Communication test procedure. Refer to «DIAGNOSTIC CODE INDEX»(ref-285334-S11816595622008052100000) table. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  2. 2) CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read active DTCs from all modules. NOTE: Check for FCM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to «DIAGNOSTIC CODE INDEX»(ref-285334-S11816595622008052100000) table for a complete list of the symptoms. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Go to 3) .
  3. 3) VERIFY THAT THE HFM IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select Network Diagnostics. Verify that the HFM is active on the bus. Is the HFM active on the bus? Yes Go to 4) . No See «DIAGNOSIS AND TESTING»(ref-285334-S40494593062008052100000) for NO RESPONSE diagnostic procedures. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  4. 4) CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network Diagnostics. Is there more than one module with active DTCs "Logged Against" the HFM? Yes Replace/update the Hands Free Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Replace/update the module that set this DTC in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  1. 1) VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go to 2) . No Refer to the Stored Lost Communication test procedure. Refer to «DIAGNOSTIC CODE INDEX»(ref-285334-S11816595622008052100000) table. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  2. 2) CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read active DTCs from all modules. NOTE: Check for FCM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to «DIAGNOSTIC CODE INDEX»(ref-285334-S11816595622008052100000) table for a complete list of the symptoms. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Go to 3) .
  3. 3) VERIFY THAT THE DDM IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select Network Diagnostics. Verify that the DDM is active on the bus. Is the DDM active on the bus? Yes Go to 4) . No See «DIAGNOSIS AND TESTING»(ref-285334-S40494593062008052100000) for NO RESPONSE diagnostic procedures. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  4. 4) CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network Diagnostics. Is there more than one module with active DTCs "Logged Against" the DDM? Yes Replace/update the Driver Memory Mirror Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Replace/update the module that set this DTC in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  1. 1) VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go to 2) . No Refer to the Stored Lost Communication test procedure. Refer to «DIAGNOSTIC CODE INDEX»(ref-285334-S11816595622008052100000) table. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  2. 2) CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read active DTCs from all modules. NOTE: Check for FCM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to «DIAGNOSTIC CODE INDEX»(ref-285334-S11816595622008052100000) table for a complete list of the symptoms. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Go to 3) .
  3. 3) VERIFY THAT THE PDM IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select Network Diagnostics. Verify that the PDM is active on the bus. Is the PDM active on the bus? Yes Go to 4) . No See «DIAGNOSIS AND TESTING»(ref-285334-S40494593062008052100000) for NO RESPONSE diagnostic procedures. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  4. 4) CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network Diagnostics. Is there more than one module with active DTCs "Logged Against" the PDM? Yes Replace/update the Passenger Memory Mirror Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Replace/update the module that set this DTC in accordance with the service information Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  1. 1) VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go to 2) . No Refer to the Stored Lost Communication test procedure. Refer to «DIAGNOSTIC CODE INDEX»(ref-285334-S11816595622008052100000) table. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  2. 2) CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read active DTCs from all modules. NOTE: Check for FCM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to «DIAGNOSTIC CODE INDEX»(ref-285334-S11816595622008052100000) table for a complete list of the symptoms. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Go to 3) .
  3. 3) VERIFY THAT THE HSM IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select Network Diagnostics. Verify that the HSM is active on the bus. Is the HSM active on the bus? Yes Go to 4) . No See «DIAGNOSIS AND TESTING»(ref-285334-S40494593062008052100000) for NO RESPONSE diagnostic procedures. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  4. 4) CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network Diagnostics. Is there more than one module with active DTCs "Logged Against" the HSM? Yes Replace/update the Heated Seat Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Replace/update the module that set this DTC in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  1. 1) VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go to 2) . No Refer to the Stored Lost Communication test procedure. Refer to «DIAGNOSTIC CODE INDEX»(ref-285334-S11816595622008052100000) table. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  2. 2) CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read active DTCs from all modules. NOTE: Check for FCM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to «DIAGNOSTIC CODE INDEX»(ref-285334-S11816595622008052100000) table for a complete list of the symptoms. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Go to 3) .
  3. 3) VERIFY THAT THE MSMD IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select Network Diagnostics. Verify that the MSMD is active on the bus. Is the MSMD active on the bus? Yes Go to 4) . No See «DIAGNOSIS AND TESTING»(ref-285334-S40494593062008052100000) for NO RESPONSE diagnostic procedures. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  4. 4) CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network Diagnostics. Is there more than one module with active DTCs "Logged Against" the MSMD? Yes Replace/update the Seat Memory Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Replace/update the module that set this DTC in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  1. 1) VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go to 2) . No Refer to the Stored Lost Communication test procedure. Refer to «DIAGNOSTIC CODE INDEX»(ref-285334-S11816595622008052100000) table. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  2. 2) CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read active DTCs from all modules. NOTE: Check for FCM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to «DIAGNOSTIC CODE INDEX»(ref-285334-S11816595622008052100000) table for a complete list of the symptoms. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Go to 3) .
  3. 3) VERIFY THAT THE PLGM IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select Network Diagnostics. Verify that the PLGM is active on the bus. Is the PLGM active on the bus? Yes Go to 4) . No See «DIAGNOSIS AND TESTING»(ref-285334-S40494593062008052100000) for NO RESPONSE diagnostic procedures. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  4. 4) CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network Diagnostics. Is there more than one module with active DTCs "Logged Against" the PLGM? Yes Replace/update the Power Liftgate Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Replace/update the module that set this DTC in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  1. 1) RECONFIGURE THE FRONT CONTROL MODULE Turn the ignition on. With the scan tool, select network view and press the gateway button. This will list the CAN modules on the vehicle. Read and record the listed modules. With the scan tool, select FCM, miscellaneous functions then add/remove ECUs. With the scan tool, add or remove the module that was not configured in the FCM. With the scan tool, erase DTC's. Cycle the ignition from on to off 3 times and read the active FCM DTC's. Does the scan tool display this DTC as active? Yes Retest system and attempt to reconfigure the FCM. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Repair is complete. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  1. 1) VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go to 2) . No Refer to the Stored Lost Communication test procedure. Refer to «DIAGNOSTIC CODE INDEX»(ref-285334-S11816595622008052100000) table. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  2. 2) CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read all active DTCs from all modules. NOTE: Check for FCM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to «DIAGNOSTIC CODE INDEX»(ref-285334-S11816595622008052100000) table for a complete list of the symptoms. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Go to 3) .
  3. 3) VERIFY THAT THE SCM (SAS) IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select Network Diagnostics. Verify that the SCM (SAS) is active on the bus. Is the SCM (SAS) active on the bus? Yes Go to 4) . No See «DIAGNOSIS AND TESTING»(ref-285334-S40494593062008052100000) for NO RESPONSE diagnostic procedures. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  4. 4) CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network Diagnostics. Is there more than one module with active DTCs "Logged Against" the SCM (SAS)? Yes Replace/update the Steering Angle Sensor (internal to the clockspring) in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Replace/update the module that set this DTC in accordance with the service information Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .

Scheme 4

Scheme 4: Circuit Schematic
Scheme 4: Circuit Schematic
  1. 1) CHECK THE STATUS OF THE ERROR MESSAGE NOTE: Ensure the vehicle being tested is a CAN BUS VEHICLE. If not, false error messages may be displayed. NOTE: Ensure the scan tool is updated to the latest software. With the scan tool, record the error message. Disconnect the scan tool from the DLC. Cycle the ignition from on to off 3 times. Turn the ignition on. Does the scan tool display this same error message? Yes Go to step 2) . No The conditions that caused this error message to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors.
  2. 2) (D51) CAN C DIAGNOSTIC (-) CIRCUIT OPEN Turn the ignition off. Disconnect the Front Control Module C1 harness connector. Disconnect the scan tool from the DLC. Measure the resistance of the (D51) CAN C Diagnostic (-) circuit between the FCM connector and the DLC. Is the resistance below 5.0 ohms? Yes Inspect the wiring and connectors for damage or shorted circuits. If OK, replace the Front Control Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Repair the (D51) CAN C Diagnostic (-) circuit for an open. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  1. 1) CHECK THE STATUS OF THE ERROR MESSAGE NOTE: Ensure the vehicle being tested is a CAN BUS VEHICLE. If not, false error messages may be displayed. NOTE: Ensure the scan tool is updated to the latest software. With the scan tool, record the error message. Disconnect the scan tool from the DLC. Cycle the ignition from on to off 3 times. Turn the ignition on. Does the scan tool display this same error message? Yes Go to step 2) . No The conditions that caused this error message to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors.
  2. 2) (D52) CAN C DIAGNOSTIC (+) CIRCUIT OPEN Turn the ignition off. Disconnect the Front Control Module C1 harness connector. Disconnect the scan tool from the DLC. Measure the resistance of the (D52) CAN C Diagnostic (+) circuit between the FCM connector and the DLC. Is the resistance below 5.0 ohms? Yes Inspect the wiring and connectors for damage or shorted circuits. If OK, replace the Front Control Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Repair the (D52) CAN C Diagnostic (+) circuit for an open. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  1. 1) TEST FOR INTERMITTENT CONDITION Turn the ignition on. NOTE: Ensure the IOD fuse is installed and battery voltage is between 10.0 and 16.0 volts. With the scan tool, select ECU view. NOTE: A red X will be next to the module that is not communicating, indicating that the module is not active on the Bus network. A green check indicates that the module is active on the Bus network. Does the scan tool display a red X next to the module? Yes Go to step 2) . No The no response condition is not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring for chafed, pierced, pinched, and partially broken wires and the wiring harness connectors for broken, bent, pushed out, and corroded terminals.
  2. 2) (A215) FUSED B(+) CIRCUIT OPEN OR SHORTED Turn the ignition off. Disconnect the Driver Door Module C1 harness connector. Using a 12-volt test light connected to ground, check the (A215) Fused B(+) circuit. Does the test light illuminate brightly? Yes Go to step 3) . No Repair the (A215) Fused B(+) circuit for an open or short. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  3. 3) (Z940) GROUND CIRCUIT OPEN Using a 12-volt test light connected to 12-volts, check each (Z940) ground circuit. Does the test light illuminate brightly for each circuit? Yes Go to step 4) . No Repair the (Z940) ground circuit for an open. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  4. 4) (D55) AND (D54) CAN B BUS CIRCUITS OPEN NOTE: One open circuit will not cause this condition. Disconnect the Driver Door Module C2 harness connector. Turn the ignition on. Measure the voltage between the (D54) CAN B Bus (-) circuit and ground. Measure the voltage between the (D55) CAN B Bus (+) circuit and ground. Is there any voltage present on either circuit? Yes Replace the Driver Door Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Repair the (D55) and (D54) CAN B Bus circuits for an open. Inspect the connector for damage. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .

Scheme 5

Scheme 5: Circuit Schematic
Scheme 5: Circuit Schematic
  1. 1) TEST FOR INTERMITTENT CONDITION Turn the ignition on. NOTE: Ensure the IOD fuse is installed and battery voltage is between 10.0 and 16.0 volts. With the scan tool, select ECU view. NOTE: A red X will be next to the module that is not communicating, indicating that the module is not active on the Bus network. A green check indicates that the module is active on the Bus network. Does the scan tool display a red X next to the module? Yes Go to step 2) . No The no response condition is not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring for chafed, pierced, pinched, and partially broken wires and the wiring harness connectors for broken, bent, pushed out, and corroded terminals.
  2. 2) (A215) FUSED B(+) CIRCUIT OPEN OR SHORTED Turn the ignition off. Disconnect the Passenger Door Module C1 harness connector. Using a 12-volt test light connected to ground, check the (A215) Fused B(+) circuit. Does the test light illuminate brightly? Yes Go to step 3) . No Repair the (A215) Fused B(+) circuit for an open or short. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  3. 3) (Z944) GROUND CIRCUIT OPEN Using a 12-volt test light connected to 12-volts, check the (Z944) ground circuit. Does the test light illuminate brightly? Yes Go to step 4) . No Repair the (Z944) ground circuit for an open. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  4. 4) (D55) AND (D54) CAN B BUS CIRCUITS OPEN NOTE: One open circuit will not cause this condition. Disconnect the Passenger Door Module C2 harness connector. Turn the ignition on. Measure the voltage between the (D54) CAN B Bus (-) circuit and ground. Measure the voltage between the (D55) CAN B Bus (+) circuit and ground. Is there any voltage present on either circuit? Yes Replace the Passenger Door Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Repair the (D55) and (D54) CAN B Bus circuits for an open. Inspect the connector for damage. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .

Scheme 6

Scheme 6: Circuit Schematic
Scheme 6: Circuit Schematic
  1. 1) VERIFY DTC IS STORED NOTE: Stored faults may indicate a customer perceived intermittent condition. NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read stored DTCs. Is this DTC stored? Yes Go to step 2) . No Diagnose the active DTC. Refer to «DIAGNOSTIC CODE INDEX»(ref-285334-S11816595622008052100000) table for a list of the symptoms. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) .
  2. 2) CHECK THE ENVIRONMENTAL DATA With the scan tool, read the loss of communication environmental data. Does the loss of communication environmental odometer data match up to any of the previous service procedures listed in the possible causes or are their any stored CAN B or C hardware electrical, battery, ignition voltage, VIN missing/mismatch, FCM configuration DTCs present with match environmental data? Yes These DTCs may have been the result of other service procedures performed. Clear DTCs. Perform «BODY VERIFICATION TEST - VER 1»(ref-285334-S04155882182008052100000) . No Go to step 3) .
  3. 3) VERIFY INTERMITTENT LOST COMMUNICATION DTC-WIRING CONCERNS Turn the ignition on. With the scan tool, select Network Diagnostics. Is there more than one ECU with stored DTCs "Logged Against" the module and one or more lost communication DTCs stored in the offending module? Yes Verify if the vehicle was recently in for this type of service. Otherwise, visually inspect the related wiring harness for chafed, pierced, pinched, and partially broken wires and the wiring harness connectors for broken, bent, pushed out, and corroded terminals. Repair as necessary. No Go to step 4) .
  4. 4) VERIFY INTERMITTENT LOST COMMUNICATION DTC-OFFENDING MODULE Turn the ignition on. With the scan tool, select Network Diagnostics. Is there more than one ECU with stored DTCs "Logged Against" the module and NO lost communication DTCs stored in the offending module? Yes Check for TSB related to this offending module. No Go to step 5) .
  5. 5) VERIFY INTERMITTENT LOST COMMUNICATION DTC-REPORTING MODULE Turn the ignition on. With the scan tool, select Network Diagnostics. Is there ONLY ONE ECU with stored DTCs "Logged Against" the module? Yes Check for TSB related to the module that set this DTC. No Verify if the vehicle was recently in for this type of service. Otherwise, visually inspect the related wiring harness for chafed, pierced, pinched, and partially broken wires and the wiring harness connectors for broken, bent, pushed out, and corroded terminals. Repair as necessary.
  1. 1) Perform Body Verification Test Disconnect all jumper wires and reconnect all previously disconnected components and connectors. Ensure that all accessories are turned off. Ensure that the battery is fully charged. Turn the ignition on. With the scan tool, record and erase DTCs from all modules. If an electronic control module was replaced, select the applicable module from the scan tool menu and press "Misc. Functions". If the module has programmable features, program as necessary. If any repairs were made to the Power Liftgate, use the scan tool and perform the open and close system tests. Observe the instructions on the scan tool. For MTC systems only, if repairs were made to any of the HVAC door actuator circuits, with the scan tool in HVAC, select System Tests and then select Actuator DTC Detection. The test must pass before proceeding to the next step. For either ATC or MTC systems, if repairs were made to any of the HVAC doors, linkage, door actuators, or door actuator circuits, with the scan tool in HVAC, select System Tests and then select Actuator Calibration Test. The test must pass before proceeding to the next step. Turn the ignition off, wait 10 seconds, and then turn the ignition on. Operate all functions of the system that caused the original concern. With the scan tool, select ECU View. Check for DTCs in the modules. Are DTCs present in any of the modules or is the original condition still present? Yes The repair is not complete. Refer to the related category for the DTC or symptom that is still present. No The repair is complete.
