SPECIFICATIONS - RESTRAINT SYSTEMS

TORQUE SPECIFICATIONS

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

This vehicle is equipped with a Lower Anchors and Tether for Children, or LATCH child restraint anchorage system. The LATCH system provides for the installation of suitable child restraints in certain seating positions without using the standard equipment seat belt provided for that seating position. The second row seats in this vehicle are equipped with a fixed-position child restraint upper tether anchor (2) for both outboard seating positions as well as the center position of vehicles so equipped, and child restraint lower anchors (1) for the two outboard seating positions only. On vehicles equipped with a split bench third row seat there is also an upper tether anchor provided for the center seating position of that seat, but no lower anchors.

Scheme 8

The upper tether anchors (3) are integral to the second row seat cushion frames. One anchor is integral to the cushion frame of the center seat section (2), and one is integral to cushion frames of each outboard seat section (1). These anchors are each constructed from a heavy-gauge steel wire loop that is securely welded to the seat cushion frame.

Scheme 9

The upper tether anchor (3) for the third row split bench seat is integral to the left seat back panel (1). This anchor is also constructed of a heavy gauge steel wire loop that is welded to the seat back panel and surrounded by a molded plastic bezel (3). The child restraint upper tether anchors cannot be adjusted or repaired and, if ineffective or damaged, they must be replaced as a unit with their respective second row seat cushion frame unit or third row seat back panel.

Scheme 10

The lower anchors (2) for this vehicle are also integral to their respective second row outboard seat cushion frame. These anchors are also constructed from a heavy-gauge steel wire loop that is securely welded to the seat cushion frame. They are each accessed from the front of their respective seats, at each side where the seat back (1) meets the seat cushion (3). These lower anchors cannot be adjusted or repaired and, if ineffective or damaged, they must be replaced as a unit with the second row seat cushion frame unit.
