Stationary Glass: Overview Dodge Durango II

DESCRIPTION

The rear door quarter glass is seated within the rear glass run channel and glass run weatherstrip.

1. To remove the quarter glass, remove the rear glass run channel and remove the glass from the channel. (Refer to «CHANNEL-GLASS»(ref-212838-S13551233262005122700000) )

Scheme 3

Scheme 4

1. Before proceeding with the following repair procedure, review all warnings and cautions. (Refer to «WARNING»(ref-212845-S17195832252005122700000) )
2. Remove quarter panel trim. (Refer to «PANEL-QUARTER TRIM»(/dodge/durango/ii-2003-2006/remont/exteriorinterior-trim/#interior) )
3. Using a windshield cut-out wire (4) or other suitable tool, separate the adhesive (2). NOTE: Windshield removal shown, quarter glass similar.
4. Release the tabs (2) and the tabs on the alignment pin (4) and carefully remove the quarter glass.
