SPECIFICATIONS
| CAUTION | DO NOT USE CHROME PLATED LUG NUTS WITH CHROME PLATED WHEELS. |
TORQUE SPECIFICATIONS
| DESCRIPTION | N.m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| Wheel Lug Nut | 183 +/- 10 | 135 +/- 10 |
TORQUE SPECIFICATIONS
Scheme 1
Scheme 2
- Raise and support the vehicle.
- Remove the wheel and tire assembly.
- Remove the brake caliper, caliper adapter and rotor, (Refer to - «REMOVAL»(ref-163273-S19296389592004062400000) ).
- Remove the wheel speed sensor from the hub.
- Press the stud from the hub using special tool C-4150A (1).
- Remove the stud (2) from the hub (1) through the backing plate access hole (3).
Scheme 3
- Install the new stud (2) into the hub flange (1).
- Install three proper sized washers onto the stud, then install lug nut with the flat side of the nut against the washers.
- Tighten the lug nut until the stud is pulled into the hub flange. Verify that the stud is properly seated into the flange.
- Remove the lug nut and washers.
- Install the brake rotor, caliper adapter, and caliper, (Refer to - «INSTALLATION»(ref-163273-S01489549022004062400000) ).
- Install the wheel speed sensor.
- Install the wheel and tire assembly, use new lug nut on the stud or studs that were replaced.
- Remove the support and lower the vehicle.
