TORQUE SPECIFICATIONS
| DESCRIPTION | N.m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| Shock Absorber Upper Nut | 102 | 75 | |
| Shock Absorber Lower Bolt | 81 | 60 | |
| Lower Suspension Arm Frame Nuts | 244 | 180 | |
| Lower Suspension Arm Ball Joint Nut | 75 | 55 | |
| Upper Suspension Arm Frame Nuts | 102 | 75 | |
| Upper Suspension Arm Ball Joint Nut | 75 | 55 | |
| Stabilizer Bar Frame Bolt | 61 | 45 | |
| Stabilizer Link to Lower Control Arm | 169 | 125 | |
| Stabilizer Link Stabilizer Bar Nut | 37 | 27 | |
| Hub/Bearing Bolts | 163 | 120 | |
| Tie Rod End to Knuckle Nut | 75 | 55 | |
| Tie Rod End Jam Nut | 130 | 96 |
TORQUE SPECIFICATIONS
Scheme 5
Scheme 6
Scheme 7
Scheme 8
Scheme 9
Scheme 10
Scheme 11
- Remove lower control arm (Refer to - «REMOVAL»(ref-212732-S02222998212005122700000) ).
- Remove the lower control arm (Refer to - «REMOVAL»(ref-212732-S02222998212005122700000) ).
- Secure the control arm in a vise. NOTE: Extreme pressure lubrication must be used on the threaded portions of the tool. This will increase the longevity of the tool and insure proper operation during the removal and installation process.
