Power Mirrors - Electrical Diagnostics: Other Dodge Durango II

When Monitored

1. When Monitored: Continuously

Set Condition

1. Set Condition: Whenever the Mirror Switch Supply circuit is below 6.8 volts for over 2 seconds, this code will set.

Possible Causes

Possible Causes

1. PCM BATTERY VOLTAGE LOW DTC
2. (P550) MIRROR SWITCH SUPPLY CIRCUIT PARTIAL SHORT TO GROUND
3. MIRROR SWITCH
4. DRIVER MEMORY MIRROR MODULE

Scheme 8

Scheme 9

Scheme 10

Scheme 11

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTC's Operate the driver mirror several times from the mirror switch Cycle the ignition from on to off 3 times. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display SWITCH POWER SUPPLY CIRCUIT LOW? Yes : Go To 2 No : The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors.
2. CHECK ENGINE DTC's With the scan tool, read engine DTC's Does the scan tool display any BATTERY VOLTAGE LOW related DTC's? Yes : Refer to the «DTC INDEX»(ref-212813-S15254736242006050900000) for problems related to ENGINE. No : Go to 3
3. MIRROR SWITCH SHORTED Disconnect the Mirror Switch connector. Measure the voltage between the (P550) Mirror Switch Supply circuit and ground. Is the voltage above 10.0 volts? Yes : Replace the Mirror Switch. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . No : Go to 4
4. (P550) MIRROR SWITCH SUPPLY CIRCUIT PARTIAL SHORT TO GROUND Turn the ignition off. Disconnect the Driver Memory Mirror Module connector. Measure the resistance between ground and the (P550) Mirror Switch Supply circuit. Is the resistance below 5000.0 ohms? Yes : Repair the (P550) Mirror Switch Supply circuit for a short to ground. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . No : Replace the Driver Memory Mirror Module. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) .

Scheme 12

For the Memory Mirror System circuit diagram (Refer to SCHEMATICS AND DIAGRAMS ).

For a complete wiring diagram Refer to SYSTEM WIRING DIAGRAMS .

1. When Monitored: Continuously

1. Set Condition: When the Door Lock Switch Mux circuit or the Memory Select Switch Mux circuit is above 5.25 volts for over 30 msec.

Possible Causes

1. (G161) DRIVER DOOR LOCK SWITCH MUX WIRE SHORT TO VOLTAGE
2. (P339) MEMORY SELECT SWITCH MUX WIRE SHORT TO VOLTAGE
3. WINDOW/DOOR LOCK SWITCH
4. DRIVER MEMORY MIRROR MODULE

1. When Monitored: Continuously

1. Set Condition: When the Door Lock Switch Mux circuit or the Memory Select Switch Mux is under 2.6 volts for over 30 seconds.

Possible Causes

1. (G161) DRIVER DOOR LOCK SWITCH MUX WIRE PARTIAL SHORT TO GROUND
2. (G161) DRIVER DOOR LOCK SWITCH MUX CIRCUIT SHORTED TO THE (G775) DRIVER DOOR LOCK SWITCH RETURN CIRCUIT
3. (P339) MEMORY SELECT SWITCH MUX WIRE PARTIAL SHORT TO GROUND
4. (P339) MEMORY SELECT SWITCH MUX CIRCUIT SHORTED TO THE (G920) MEMORY SELECT SWITCH RETURN CIRCUIT
5. MEMORY SELECTOR SWITCH
6. DRIVER WINDOW/DOOR LOCK SWITCH STUCK
7. DRIVER MEMORY MIRROR MODULE

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

1. TEST FOR INTERMITTENT CONDITION With the scan tool, record and erase DTC's Press the Memory Selector Switch several times in all positions. Cycle the ignition from on to off 3 times. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display MEMORY SWITCH INPUT CIRCUIT STUCK? Yes : Go To 2 No : The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) .
2. DRIVER DOOR LOCK SWITCH SHORTED TO GROUND With the scan tool, erase DTC's. Cycle the ignition from on to off 3 times. Disconnect the Driver Window/Door Lock Switch C1 connector. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display MEMORY SWITCH INPUT CIRCUIT STUCK? No : Replace the Driver Window/Door Lock Switch. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . Yes : Go to 3
3. MEMORY SELECTOR SWITCH SHORTED TO GROUND With the scan tool, erase DTC's. Disconnect the Memory Selector Switch connector. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display MEMORY SWITCH INPUT CIRCUIT STUCK? No : Replace the Memory Selector Switch. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . Yes : Go to 4
4. (G161) DRIVER DOOR LOCK SWITCH MUX WIRE SHORT TO GROUND Disconnect the Driver Memory Mirror Module C1 connector. Measure the resistance between ground and the (G161) Driver Door Lock Switch Mux circuit in the Memory Mirror Module connector. Is the resistance below 10000.0 ohms? Yes : Repair the (G161) Driver Door Lock Switch Mux circuit for a short to ground. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . No : Go to 5
5. (G161) DRIVER DOOR LOCK SWITCH MUX CIRCUIT SHORTED TO THE (G775) DRIVER DOOR LOCK SWITCH RETURN CIRCUIT Measure the resistance between the (G161) Driver Door Lock Switch Mux circuit and the (G775) Driver Door Lock Switch Return circuit in the Memory Mirror Module connector. Is the resistance below 10000.0 ohms? Yes : Repair the (G161) Driver Door Lock Switch Mux circuit for a short to the (G775) Driver Door Lock Switch Return circuit. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . No : Go to 6
6. (P339) MEMORY SELECT SWITCH MUX CIRCUIT SHORT TO THE GROUND Disconnect the Driver Memory Mirror Module C2 connector. Measure the resistance between ground and the (P339) Memory Select Switch Mux circuit. Is the resistance below 10000.0 ohms? Yes : Repair the Memory Select Switch Mux wire for a short to ground. Perform the «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . No : Go to 7
7. (P339) MEMORY SELECT SWITCH MUX CIRCUIT SHORT TO THE (G920) MEMORY SELECT SWITCH RETURN CIRCUIT Measure the resistance between the (P339) Memory Select Switch Mux circuit and the (G920) Memory Select Switch Return circuit in the Driver Memory Mirror Module C2 connector. Is the resistance below 10000.0 ohms? Yes : Repair the (P339) Memory Select Switch Mux circuit for a short to the (G920) Memory Select Switch return circuit. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . No : Replace the Driver Memory Mirror Module. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) .

Scheme 20

For a complete wiring diagram Refer to SYSTEM WIRING DIAGRAMS .

1. When Monitored: Continuously

1. Set Condition: Whenever the Can B Bus (+) circuit is open, shorted to voltage or shorted to ground, this code will set.

Possible Causes

1. CAN B BUS (+) DTC's IN FRONT CONTROL MODULE
2. (D55) CAN B BUS (+) CIRCUIT OPEN
3. MEMORY MIRROR MODULE

Scheme 21

Scheme 22

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTC's Cycle the ignition from on to off 3 times. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display U1000 CAN B BUS (+) CIRCUIT? Yes : Go To 2 No : The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors.
2. CHECK FRONT CONTROL MODULE DTC's With the scan tool, read Front Control Module DTC's Does the scan tool display any CAN B BUS DTC's - ACTIVE? Yes : Refer to the symptom list for problems related to Communication in «ELECTRONIC CONTROL MODULES - ELECTRICAL DIAGNOSTICS»(ref-212762) . No : Go to 3
3. CAN B BUS (+) CIRCUIT OPEN Turn the ignition off. Disconnect the appropriate Memory Mirror Module C1 connector. Disconnect the Front Control Module C1 connector. Measure the resistance of the (D55) Can B Bus (+) circuit between the Front Control Module C1 connector and the Memory Mirror Module connector. Is the resistance below 2.0 ohms? Yes : Replace the Memory Mirror Module. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . No : Repair the Can B Bus (+) circuit for an open. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) .

Scheme 23

For a complete wiring diagram Refer to SYSTEM WIRING DIAGRAMS .

1. When Monitored: Continuously

1. Set Condition: Whenever the Can B Bus (-) circuit is open, shorted to voltage or shorted to ground, this code will set.

Possible Causes

1. CAN B BUS (-) DTC's IN FRONT CONTROL MODULE
2. (D54) CAN B BUS (-) CIRCUIT OPEN
3. MEMORY MIRROR MODULE

Scheme 24

Scheme 25

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTC's Cycle the ignition from on to off 3 times. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display U1001 CAN B BUS (-) CIRCUIT? Yes : Go To 2 No : The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors.
2. CHECK FRONT CONTROL MODULE DTC's With the scan tool, read Front Control Module DTC's Does the scan tool display any CAN B BUS DTC's - ACTIVE? Yes : Refer to the symptom list for problems related to Communication in «ELECTRONIC CONTROL MODULES - ELECTRICAL DIAGNOSTICS»(ref-212762) . No : Go to 3
3. CAN B BUS (-) CIRCUIT OPEN Turn the ignition off. Disconnect the Front Control Module C1 connector. Disconnect the appropriate Memory Mirror Module C1 connector. Measure the resistance of the (D54) Can B Bus (-) circuit between the Front Control Module connector and the Memory Mirror Module connector. Is the resistance below 2.0 ohms? Yes : Replace the Memory Mirror Module. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . No : Repair the Can B Bus (-) circuit for an open. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) .

Scheme 26

For the Memory Mirror System circuit diagram (Refer to SCHEMATICS AND DIAGRAMS ).

For a complete wiring diagram Refer to SYSTEM WIRING DIAGRAMS .

1. When Monitored: Continuously

1. Set Condition: When the Memory Mirror Module receives a mirror movement command from the switch but then senses an open or shorted circuit on one of the switch sense circuits for over 100 ms., this code will set.

Possible Causes

1. (P703) MIRROR HORIZONTAL LEFT SWITCH SENSE OPEN
2. (P703) MIRROR HORIZONTAL LEFT SWITCH SENSE SHORT TO GROUND
3. (P703) MIRROR HORIZONTAL LEFT SWITCH SENSE CIRCUIT SHORTED TO ANOTHER SWITCH SENSE CIRCUIT
4. (P704) MIRROR HORIZONTAL RIGHT SWITCH SENSE OPEN
5. (P704) MIRROR HORIZONTAL RIGHT SWITCH SENSE SHORT TO GROUND
6. (P704) MIRROR HORIZONTAL RIGHT SWITCH SENSE CIRCUIT SHORTED TO ANOTHER SWITCH SENSE CIRCUIT
7. (P705) MIRROR VERTICAL DOWN SWITCH SENSE OPEN
8. (P705) MIRROR VERTICAL DOWN SWITCH SENSE SHORT TO GROUND
9. (P705) MIRROR VERTICAL DOWN SWITCH SENSE CIRCUIT SHORTED TO ANOTHER SWITCH SENSE CIRCUIT
10. (P706) MIRROR VERTICAL UP SWITCH SENSE OPEN
11. (P706) MIRROR VERTICAL UP SWITCH SENSE SHORT TO GROUND
12. (P706) MIRROR VERTICAL UP SWITCH SENSE CIRCUIT SHORTED TO ANOTHER SWITCH SENSE CIRCUIT
13. (P710) MIRROR COMMON SWITCH SENSE OPEN
14. (P710) MIRROR COMMON SWITCH SENSE SHORT TO GROUND
15. (P710) MIRROR COMMON SWITCH SENSE CIRCUIT SHORTED TO ANOTHER SWITCH SENSE CIRCUIT MIRROR SWITCH
16. DRIVER MEMORY MIRROR MODULE

Scheme 27

Scheme 28

Scheme 29

Scheme 30

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTC's Press the Mirror Switch in all directions several times. Cycle the ignition from on to off 3 times. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display B1D04-MIRROR ADJUST SWITCH INPUT CIRCUIT/PERFORMANCE? Yes : Go To 2 No : The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. If the conditions returns, replace the switch. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) .
2. TEST THE SWITCH Turn the ignition off. Remove the Driver Window/Door Lock Switch assembly. Test the Mirror Switch in all positions by using the procedure in «WINDOW/DOOR LOCK SWITCH»(ref-212796-S11376781542005122700000) . Does the switch pass the test in all positions No : Replace the Mirror Switch.. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . Yes : Go to 3
3. TEST FOR SWITCH SENSE WIRE SHORT TO GROUND Disconnect the Driver Memory Mirror Module C2 connector. Measure the resistance between Ground and the (P703) Mirror Horizontal Left Switch Sense circuit in the Driver Memory Mirror Module connector. Measure the resistance between Ground and the (P704) Mirror Horizontal Right Switch Sense circuit in the Driver Memory Mirror Module connector. Measure the resistance between Ground and the (P705) Mirror Vertical Down Switch Sense circuit in the Driver Memory Mirror Module connector. Measure the resistance between Ground and the (P706) Mirror Vertical Up Switch Sense circuit in the Driver Memory Mirror Module connector. Measure the resistance between Ground and the (P710) Mirror Common Switch Sense circuit in the Driver Memory Mirror Module connector. Is the resistance below 5000.0 ohms in any of the circuits? Yes : Repair the Appropriate Switch Sense circuit for a short to ground. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . No : Go to 4
4. TEST FOR SWITCH SENSE CIRCUIT OPEN Disconnect the Mirror Switch connector. Measure the resistance of the (P703) Mirror Horizontal Left Switch Sense circuit between the Driver Memory Mirror Module connector and the Mirror Switch connector. Measure the resistance of the (P704) Mirror Horizontal Right Switch Sense circuit between the Driver Memory Mirror Module connector and the Mirror Switch connector. Measure the resistance of the (P705) Mirror Vertical Down Switch Sense circuit between the Driver Memory Mirror Module connector and the Mirror Switch connector. Measure the resistance of the (P706) Mirror Vertical Up Switch Sense circuit between the Driver Memory Mirror Module connector and the Mirror Switch connector. Measure the resistance of the (P710) Mirror Common Switch Sense circuit between the Driver Memory Mirror Module connector and the Mirror Switch connector. Is the resistance below 2.0 ohms in all of the Switch Sense circuits? No : Repair the Appropriate Switch Sense circuit for an open. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . Yes : Go to 5
5. TEST FOR A SWITCH SENSE CIRCUIT SHORTED TO ANOTHER SWITCH SENSE CIRCUIT Measure the resistance between each of the switch sense circuits to each of the other switch sense circuits. Is the resistance below 10000.0 ohms between any of the switch sense circuits? Yes : Repair the appropriate switch sense circuit for a short to the other switch sense circuits. Perform the «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . No : Replace the Driver Memory Mirror Module. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) .

Scheme 31

For the Memory Mirror System circuit diagram (Refer to SCHEMATICS AND DIAGRAMS ).

For a complete wiring diagram Refer to SYSTEM WIRING DIAGRAMS .

1. When Monitored: Continuously

1. Set Condition: When the Memory Mirror Module receives a mirror movement command from the switch for over 30 seconds., this code will set.

Possible Causes

1. MIRROR SWITCH
2. DRIVER MEMORY MIRROR MODULE

Scheme 32

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTC's Press the Mirror Switch in all directions several times. Cycle the ignition from on to off 3 times. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display B1D04-MIRROR ADJUST SWITCH INPUT CIRCUIT STUCK? Yes : Go To 2 No : The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. If the conditions returns, replace the switch. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) .
2. TEST THE SWITCH Turn the ignition off. Remove the Driver Window/Door Lock Switch assembly. Remove the Mirror Switch. Test the Mirror Switch in all positions by using the procedure in «WINDOW/DOOR LOCK SWITCH»(ref-212796-S11376781542005122700000) . Does the switch pass the test in all positions No : Replace the Mirror Switch.. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . Yes : Replace the Driver Memory Mirror Module. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000)

Scheme 33

For the Memory Mirror System circuit diagram (Refer to SCHEMATICS AND DIAGRAMS ).

For a complete wiring diagram Refer to SYSTEM WIRING DIAGRAMS .

1. When Monitored: Continuously

1. Set Condition: When the Memory Mirror Module senses voltage below 4.3 volts on the Mirror Sensor Supply circuit for over 30ms., this code will set. Note: This test covers both the Driver and Passenger code depending on the side the code appeared in.

Possible Causes

1. (P669) OR (P666) MIRROR SENSOR SUPPLY CIRCUIT SHORT TO GROUND
2. (P669) OR (P666) MIRROR SENSOR SUPPLY CIRCUIT SHORTED TO (P69) OR (P66) MIRROR SENSOR GROUND CIRCUIT.
3. MIRROR SHORTED
4. DRIVER MEMORY MIRROR MODULE

Scheme 34

Scheme 35

Scheme 36

Scheme 37

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTC's Operate the Mirror Switch in all directions several times. Cycle the ignition from on to off 3 times. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display B1D09 or B1D12-MIRROR POSITION SENSOR POWER SUPPLY CIRCUIT LOW? Yes : Go To 2 No : The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) .
2. TEST FOR A SHORTED MIRROR Turn the ignition off. Disconnect the appropriate mirror connector. Turn the ignition on. Measure the voltage between the (P669) or (P666) Mirror Sensor Supply circuit and the ((P69) or (P66) Mirror Sensor Ground circuit. Is the voltage above 4.6 volts? Yes : Replace the Mirror. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . No : Go to 3
3. TEST THE (P669) OR (P666) MIRROR SENSOR SUPPLY WIRE Turn the ignition off. Disconnect the appropriate Memory Mirror Module connector. Measure the resistance between ground and the (P669) or (P666) Mirror Sensor Supply circuit. Is the resistance below 5000.0 ohms? Yes : Repair the (P669) or (P666) Mirror Sensor Supply circuit for a short to ground.. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . No : Go to 4
4. TEST THE (P669) OR (P666) MIRROR SENSOR SUPPLY WIRE SHORTED TO THE (P69) OR (P66) MIRROR SENSE OR GROUND CIRCUIT. Measure the resistance between the (P669) or (P666) Mirror Sensor Supply circuit and the (P69) or (P66) Mirror Sensor Ground circuit. Is the resistance below 5000.0 ohms? Yes : Repair the (P669) or (P666) Mirror Sensor Supply circuit for a short to the (P69) or (P66) Sensor Ground Circuit.. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . No : Replace the appropriate Memory Mirror Module. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) .

Scheme 38

For the Memory Mirror System circuit diagram (Refer to SCHEMATICS AND DIAGRAMS ).

For a complete wiring diagram Refer to SYSTEM WIRING DIAGRAMS .

1. When Monitored: Continuously

1. Set Condition: When the Memory Mirror Module senses voltage above 5.5 volts on the Mirror Sensor Supply circuit for over 30ms., this code will set. Note: This test covers both the Driver and Passenger code depending on the side the code appeared in.

Possible Causes

1. (P669) OR (P666) MIRROR SENSOR SUPPLY CIRCUIT OPEN
2. (P669) OR (P666) MIRROR SENSOR SUPPLY CIRCUIT SHORT TO VOLTAGE
3. (P69) R (P66) MIRROR SENSOR GROUND CIRCUIT OPEN
4. MIRROR OPEN
5. DRIVER MEMORY MIRROR MODULE

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTC's Operate the Mirror Switch in all directions several times. Cycle the ignition from on to off 3 times. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display B1D0A or B1d13-MIRROR POSITION SENSOR POWER SUPPLY CIRCUIT HIGH? Yes : Go To 2 No : The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) .
2. TEST FOR A SHORTED MIRROR Turn the ignition off. Disconnect the appropriate mirror connector. Turn the ignition on. Measure the voltage between the (P669) or (P666) Mirror Sensor Supply circuit and the ((P69) or (P66) Mirror Sensor Ground circuit. Is the voltage between 4.8 and 5.2 volts? Yes : Replace the Mirror. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . No : Go to 3
3. TEST THE (P669) OR (P666) MIRROR SENSOR SUPPLY WIRE FOR AN OPEN Turn the ignition off. Disconnect the appropriate Memory Mirror Module connector. Measure the resistance between of the (P669) or (P666) Mirror Sensor Supply circuit between the Module connector and the Mirror connector.. Is the resistance below 2.0 ohms? No : Repair the (P669) or (P666) Mirror Sensor Supply circuit for an open.. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . Yes : Go to 4
4. TEST THE (P69) OR (P66) MIRROR SENSOR GROUND WIRE FOR AN OPEN Measure the resistance of the ((P69) or (P66) Mirror Sensor Ground circuit between the Module connector and the Mirror connector. Is the resistance below 2.0 ohms? No : Repair the (P69) or (P66) Mirror Sensor Ground circuit for an open. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . Yes : Go to 5 Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) .
5. TEST THE (P669) OR (P666) MIRROR SENSOR SUPPLY WIRE SHORTED TO VOLTAGE Turn the ignition on. Measure the voltage between ground and the (P669) or (P666) Mirror Sensor Supply circuit. Is there any voltage present? Yes : Repair the (P669) or (P666) Mirror Sensor Supply circuit for a short to voltage. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . No : Replace the appropriate Memory Mirror Module. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) .

Scheme 44

For the Memory Mirror System circuit diagram (Refer to SCHEMATICS AND DIAGRAMS ).

For a complete wiring diagram Refer to SYSTEM WIRING DIAGRAMS .

1. When Monitored: Continuously

1. Set Condition: When the Memory Mirror Module senses a value below the parameter of the mirror sensor on the Mirror Vertical Position Signal circuit for over 60ms., this code will set. Note: This test covers both the Driver and Passenger code depending on the side the code appeared in.

Possible Causes

1. (P67) OR (P64) MIRROR VERTICAL POSITION SIGNAL CIRCUIT SHORT TO GROUND
2. (P67) OR (P64) MIRROR VERTICAL POSITION SIGNAL CIRCUIT SHORTED TO (P69) OR (P66) MIRROR SENSOR GROUND CIRCUIT.
3. MIRROR SHORTED
4. DRIVER MEMORY MIRROR MODULE

Scheme 45

Scheme 46

Scheme 47

Scheme 48

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTC's Operate the Mirror Switch in all directions several times. Cycle the ignition from on to off 3 times. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display B1D0C or B1D15-MIRROR VERTICAL POSITION SENSOR INPUT CIRCUIT LOW? Yes : Go To 2 No : The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) .
2. TEST FOR A SHORTED MIRROR Disconnect the appropriate mirror connector. With the scan tool, erase DTC's. Operate the Mirror Switch in all directions several times. Cycle the ignition from on to off 3 times. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display B1D0C or B1D15-MIRROR VERTICAL POSITION SENSOR INPUT CIRCUIT LOW? No : Replace the Mirror. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . Yes : Go to 3
3. TEST THE (P67) OR (P64) MIRROR VERTICAL POSITION SIGNAL WIRE FOR A SHORT TO GROUND Turn the ignition off. Disconnect the appropriate Memory Mirror Module connector. Measure the resistance between ground and the (P67) or (P64) Mirror Vertical Position Signal circuit. Is the resistance below 5000.0 ohms? Yes : Repair the (P67) or (P64) Mirror Vertical Position Signal circuit for a short to ground. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . No : Go to 4
4. TEST THE (P67) OR (P64) MIRROR VERTICAL POSITION, SIGNAL CIRCUIT SHORTED TO THE (P69) OR (P66) MIRROR SENSOR GROUND CIRCUIT. Measure the resistance between the (P67) or (P64) Mirror Vertical Position Signal circuit and the (P69) or (P66) Mirror Sensor Ground circuit. Is the resistance below 5000.0 ohms? Yes : Repair the (P67) or (P64) Mirror Vertical Position Signal circuit for a short to the (P69) or (P66) Sensor Ground Circuit.. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . No : Replace the appropriate Memory Mirror Module. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) .

Scheme 49

For the Memory Mirror System circuit diagram (Refer to SCHEMATICS AND DIAGRAMS ).

For a complete wiring diagram Refer to SYSTEM WIRING DIAGRAMS .

1. When Monitored: Continuously

1. Set Condition: When the Memory Mirror Module senses a value above the parameter of the mirror sensor on the Mirror Vertical Position Signal circuit for over 60ms., this code will set. Note: This test covers both the Driver and Passenger code depending on the side the code appeared in.

Possible Causes

1. (P67) OR (P64) MIRROR VERTICAL POSITION SIGNAL CIRCUIT SHORT TO VOLTAGE
2. (P67) OR (P64) MIRROR VERTICAL POSITION SIGNAL CIRCUIT OPEN
3. (P69) OR (P66) MIRROR SENSOR GROUND CIRCUIT OPEN
4. MIRROR SHORTED
5. DRIVER MEMORY MIRROR MODULE

Scheme 50

Scheme 51

Scheme 52

Scheme 53

Scheme 54

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTC's Operate the Mirror Switch in all directions several times. Cycle the ignition from on to off 3 times. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display B1D0C or B1D15-MIRROR VERTICAL POSITION SENSOR INPUT CIRCUIT HIGH? Yes : Go To 2. No : The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) .
2. TEST FOR A SHORTED MIRROR Disconnect the appropriate mirror connector. With the scan tool, erase DTC's. Operate the Mirror Switch in all directions several times. Cycle the ignition from on to off 3 times. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display B1D0C or B1D15-MIRROR VERTICAL POSITION SENSOR INPUT CIRCUIT HIGH? No : Replace the Mirror. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . Yes : Go to 3
3. TEST THE (P67) OR (P64) MIRROR VERTICAL POSITION SIGNAL WIRE FOR A SHORT TO VOLTAGE Turn the ignition off. Disconnect the appropriate Memory Mirror Module connector. Measure the voltage between the (P67) or (P64) Mirror Vertical Position Signal circuit and ground. Is there any voltage present? Yes : Repair the (P67) or (P64) Mirror Vertical Position Signal circuit for a short to voltage. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . No : Go to 4
4. TEST THE (P69) OR (P66) MIRROR SENSOR GROUND WIRE FOR AN OPEN Measure the resistance of the (P69) or (P66) Mirror Sensor Ground circuit between the Module connector and the Mirror connector. Is the resistance below 2.0 ohms? No : Repair the (P69) or (P66) Mirror Sensor Ground circuit for an open. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . Yes : Go to 5
5. TEST THE (P67) OR (P64) MIRROR VERTICAL POSITION SIGNAL WIRE FOR AN OPEN Measure the resistance of the (P67) or (P65) Mirror Vertical Position Signal circuit between the Module connector and the Mirror connector. Is the resistance below 2.0 ohms? No : Repair the (P67) or (P64) Mirror Vertical Position Signal circuit for an open. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . Yes : Replace the appropriate Memory Mirror Module. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) .

Scheme 55

For the Memory Mirror System circuit diagram (Refer to SCHEMATICS AND DIAGRAMS ).

For a complete wiring diagram Refer to SYSTEM WIRING DIAGRAMS .

1. When Monitored: Continuously

1. Set Condition: When the Memory Mirror Module senses a Value below the parameter of the mirror sensor on the Mirror Horizontal Position Signal circuit for over 60ms;, this code will set. Note: This test covers both the Driver and Passenger code depending on the side the code appeared in.

Possible Causes

1. (P65) OR (P68) MIRROR HORIZONTAL POSITION SIGNAL CIRCUIT SHORT TO GROUND
2. (P65) OR (P68) MIRROR HORIZONTAL POSITION SIGNAL CIRCUIT SHORTED TO (P69) OR (P66) MIRROR SENSOR GROUND CIRCUIT.
3. MIRROR SHORTED
4. DRIVER MEMORY MIRROR MODULE

Scheme 56

Scheme 57

Scheme 58

Scheme 59

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTC's Operate the Mirror Switch in all directions several times. Cycle the ignition from on to off 3 times. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display B1D0F or B1D18-MIRROR HORIZONTAL POSITION SENSOR INPUT CIRCUIT LOW? Yes : Go To 2 No : The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) .
2. TEST FOR A SHORTED MIRROR Disconnect the appropriate mirror connector. With the scan tool, erase DTC's. Operate the Mirror Switch in all directions several times. Cycle the ignition from on to off 3 times. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display B1D0F or B1D18-MIRROR HORIZONTAL POSITION SENSOR INPUT CIRCUIT LOW? No : Replace the Mirror. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . Yes : Go to 3
3. TEST THE (P65) OR (P68) MIRROR HORIZONTAL POSITION SIGNAL WIRE FOR A SHORT TO GROUND Turn the ignition off. Disconnect the appropriate Memory Mirror Module connector. Measure the resistance between ground and the (P65) or (P68) Mirror Horizontal Position Signal circuit. Is the resistance below 5000.0 ohms? Yes : Repair the (P65) or (P68) Mirror Horizontal Position Signal circuit for a short to ground. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . No : Go to 4
4. TEST THE (P65) OR (P68) MIRROR HORIZONTAL POSITION SIGNAL CIRCUIT SHORTED TO THE (P69) OR (P66) MIRROR SENSOR GROUND CIRCUIT. Measure the resistance between the (P65) or (P68) Mirror Horizontal Position Signal circuit and the (P69) or (P66) Mirror Sensor Ground circuit. Is the resistance below 5000.0 ohms? Yes : Repair the (P65) or (P68) Mirror Horizontal Position Signal circuit for a short to the (P69) or (P66) Sensor Ground Circuit. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . No : Replace the appropriate Memory Mirror Module. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) .

Scheme 60

For the Memory Mirror System circuit diagram (Refer to SCHEMATICS AND DIAGRAMS ).

For a complete wiring diagram Refer to SYSTEM WIRING DIAGRAMS .

1. When Monitored: Continuously

1. Set Condition: When the Memory Mirror Module senses a value above the parameter of the mirror sensor on the Mirror Horizontal Position Signal circuit for over 60ms., this code will set. Note: This test covers both the Driver and Passenger code depending on the side the code appeared in.

Possible Causes

1. (P65) OR (P68) MIRROR HORIZONTAL POSITION SIGNAL CIRCUIT SHORT TO VOLTAGE
2. (P65) OR (P68) MIRROR HORIZONTAL POSITION SIGNAL CIRCUIT OPEN
3. (P69) OR (P66) MIRROR SENSOR GROUND CIRCUIT OPEN
4. MIRROR OPEN
5. MEMORY MIRROR MODULE

Scheme 61

Scheme 62

Scheme 63

Scheme 64

Scheme 65

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTC's Operate the Mirror Switch in all directions several times. Cycle the ignition from on to off 3 times. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display B1D10 or B1D19-MIRROR HORIZONTAL POSITION SENSOR INPUT CIRCUIT HIGH? Yes : Go To 2 No : The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) .
2. TEST FOR AN OPEN MIRROR Disconnect the appropriate mirror connector. Turn the ignition on. Measure the voltage between the (P65) or (p68) Mirror Horizontal Position Signal circuit and the (P69) or (P66) Mirror Sensor Ground circuit. Is the voltage between 4.8 and 5.2 volts? Yes : Replace the Mirror. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . No : Go to 3
3. TEST THE (P65) OR (P68) MIRROR HORIZONTAL POSITION SIGNAL WIRE FOR A SHORT TO VOLTAGE Turn the ignition off. Disconnect the appropriate Memory Mirror Module connector. Turn the ignition on. Measure the voltage between the (P65) or (P68) Mirror Horizontal Position Signal circuit and ground. Is there any voltage present? Yes : Repair the (P65) or (P68) Mirror Horizontal Position Signal circuit for a short to voltage. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . No : Go to 4
4. TEST THE (P69) OR (P66) MIRROR SENSOR GROUND WIRE FOR AN OPEN Turn the ignition off. Measure the resistance of the (P69) or (P66) Mirror Sensor Ground circuit between the Module connector and the Mirror connector. Is the resistance below 2.0 ohms? No : Repair the (P69) or (P66) Mirror Sensor Ground circuit for an open.. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . Yes : Go to 5
5. TEST THE (P65) OR (P68) MIRROR HORIZONTAL POSITION SIGNAL WIRE FOR AN OPEN Measure the resistance of the (P65) or (P68) Mirror Horizontal Position Signal circuit between the Module connector and the Mirror connector. Is the resistance below 2.0 ohms? No : Repair the (P65) or (P68) Mirror Horizontal Position Signal circuit for an open. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . Yes : Replace the appropriate Memory Mirror Module. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) .

Scheme 66

For the Memory Mirror System circuit diagram (Refer to SCHEMATICS AND DIAGRAMS ).

For a complete wiring diagram Refer to SYSTEM WIRING DIAGRAMS .

1. When Monitored: Continuously

1. Set Condition: When the Memory Mirror Module senses a value below the tolerance of the mirror motor on the Mirror Motor Common Control circuit for over 10ms., this code will set. Note: This test covers both the Driver and Passenger code depending on the side the code appeared in.

Possible Causes

1. (P73) OR (P70) MIRROR MOTOR COMMON DRIVER CIRCUIT SHORT TO GROUND
2. (P73) OR (P70) MIRROR MOTOR COMMON DRIVER CIRCUIT SHORTED TO (C910) OR (C917) MIRROR HEATER GROUND CIRCUIT.
3. MIRROR SHORTED
4. MEMORY MIRROR MODULE

Scheme 67

Scheme 68

Scheme 69

Scheme 70

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTC's Operate the Mirror Switch in all directions several times. Cycle the ignition from on to off 3 times. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display B1D1B or B1D27-MIRROR MOTOR COMMON CONTROL CIRCUIT LOW? Yes : Go To 2 No : The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) .
2. TEST FOR A SHORTED MIRROR Disconnect the appropriate mirror connector. With the scan tool, erase DTC's. Operate the Mirror Switch in all directions several times. Cycle the ignition from on to off 3 times. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display B1D1B or B1D27-MIRROR MOTOR COMMON CONTROL CIRCUIT LOW? No : Replace the Mirror. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . Yes : Go to 3
3. TEST THE (P73) OR (P70) MIRROR MOTOR COMMON DRIVER WIRE FOR A SHORT TO GROUND Turn the ignition off. Disconnect the appropriate Memory Mirror Module connector. Measure the resistance between ground and the (P73) or (P70) Mirror Motor Common Driver circuit. Is the resistance below 5000.0 ohms? Yes : Repair the (P73) or (P70) Mirror Motor Common Driver circuit for a short to ground. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . No : Go to 4
4. TEST THE (P73) OR (P70) MIRROR MOTOR COMMON DRIVER CIRCUIT SHORTED TO THE (C910) OR (C917) MIRROR HEATER GROUND CIRCUIT. Measure the resistance between the (P73) or (P70) Mirror Motor Common Driver circuit and the (C910) or (C917) Mirror Heater Ground circuit. Is the resistance below 5000.0 ohms? Yes : Repair the (P73) or (P70) Mirror Motor Common Driver circuit for a short to the (C910) or (C917) Mirror Heater Ground Circuit. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . No : Replace the appropriate Memory Mirror Module. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) .

Scheme 71

For the Memory Mirror System circuit diagram (Refer to SCHEMATICS AND DIAGRAMS ).

For a complete wiring diagram Refer to SYSTEM WIRING DIAGRAMS .

1. When Monitored: Continuously

1. Set Condition: When the Memory Mirror Module senses voltage present on the Mirror Motor Common Control circuit, when there should not be, for over 10ms., this code will set. Note: This test covers both the Driver and Passenger code depending on the side the code appeared in.

Possible Causes

1. (P73) OR (P70) MIRROR MOTOR COMMON DRIVER CIRCUIT SHORT TO VOLTAGE
2. MIRROR SHORTED
3. MEMORY MIRROR MODULE

Scheme 72

Scheme 73

Scheme 74

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTC's Operate the Mirror Switch in all directions several times. Cycle the ignition from on to off 3 times. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display B1D1C or B1D28-MIRROR MOTOR COMMON CONTROL CIRCUIT HIGH? Yes : Go To 2 No : The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) .
2. TEST FOR AN OPEN MIRROR Turn the ignition off. Disconnect the appropriate mirror connector. Turn the ignition on. With the scan tool, record and erase DTC's Operate the Mirror Switch in all directions several times. Cycle the ignition from on to off 3 times. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display B1D1C or B1D28-MIRROR MOTOR COMMON CONTROL CIRCUIT HIGH? No : Replace the Mirror. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . Yes : Go to 3
3. TEST THE (P73) OR (P70) MIRROR MOTOR COMMON DRIVER WIRE FOR A SHORT TO VOLTAGE Measure the voltage between the (P73) or (P70) Mirror Motor Common Driver circuit and ground. Is the voltage above 0.5 volts? Yes : Repair the (P73) or (P70) Mirror Motor Common Driver circuit for a short to voltage. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . No : Replace the appropriate Memory Mirror Module. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) .

Scheme 75

For the Memory Mirror System circuit diagram (Refer to SCHEMATICS AND DIAGRAMS ).

For a complete wiring diagram Refer to SYSTEM WIRING DIAGRAMS .

1. When Monitored: Continuously

1. Set Condition: When the Memory Mirror Module senses an open condition on the Mirror Motor Common Driver circuit during a mirror opeation, for over 10ms., this code will set. Note: This test covers both the Driver and Passenger code depending on the side the code appeared in.

Possible Causes

1. (P73) OR (P70) MIRROR MOTOR COMMON DRIVER CIRCUIT OPEN
2. MIRROR OPEN
3. MEMORY MIRROR MODULE

Scheme 76

Scheme 77

Scheme 78

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTC's Operate the Mirror Switch in all directions several times. Cycle the ignition from on to off 3 times. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display B1D1B or B1D27-MIRROR MOTOR COMMON CONTROL CIRCUIT OPEN? Yes : Go To 2 No : The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) .
2. TEST FOR AN OPEN MIRROR Disconnect the appropriate mirror connector. Connect a test light between the (P73) or (P70) Mirror Common Driver circuit and the (P71) or (P72) Mirror Vertical Driver circuit. Operate the mirror switch Up and Down several times. Does the testlight illuminate when the switch is operated? Yes : Replace the Mirror. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . No : Go to 3
3. TEST THE (P73) OR (P70) MIRROR MOTOR COMMON DRIVER WIRE FOR AN OPEN Turn the ignition off. Disconnect the appropriate Memory Mirror Module connector. Measure the resistance of the (P73) or (P70) Mirror Motor Common Driver circuit between the mirror connector and the module connector. Is the resistance below 2.0 ohms? No : Repair the (P73) or (P70) Mirror Motor Common Driver circuit for an open.. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . Yes : Replace the appropriate Memory Mirror Module. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) .

Scheme 79

For the Memory Mirror System circuit diagram (Refer to SCHEMATICS AND DIAGRAMS ).

For a complete wiring diagram Refer to SYSTEM WIRING DIAGRAMS .

1. When Monitored: Continuously

1. Set Condition: When the Memory Mirror Module senses a value below the tolerance of the mirror motor on the Mirror Vertical Motor Control circuit for over 10ms., this code will set. Note: This test covers both the Driver and Passenger code depending on the side the code appeared in.

Possible Causes

1. (P71) OR (P72) MIRROR VERTICAL DRIVER CIRCUIT SHORT TO GROUND
2. (P71) OR (P72) MIRROR VERTICAL DRIVER CIRCUIT SHORTED TO THE (C910) OR (C917) MIRROR HEATER GROUND CIRCUIT.
3. MIRROR SHORTED
4. MEMORY MIRROR MODULE

Scheme 80

Scheme 81

Scheme 82

Scheme 83

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTC's Operate the Mirror Switch in all directions several times. Cycle the ignition from on to off 3 times. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display B1D1F or B1D2B-MIRROR VERTICAL MOTOR CONTROL CIRCUIT LOW? Yes : Go To 2 No : The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) .
2. TEST FOR A SHORTED MIRROR Disconnect the appropriate mirror connector. With the scan tool, erase DTC's. Operate the Mirror Switch in all directions several times. Cycle the ignition from on to off 3 times. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display B1D1F or B1D2B-MIRROR VERTICAL MOTOR CONTROL CIRCUIT LOW? No : Replace the Mirror. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . Yes : Go to 3
3. TEST THE (P71) OR (P72) MIRROR VERTICAL MOTOR DRIVER WIRE FOR A SHORT TO GROUND Turn the ignition off. Disconnect the appropriate Memory Mirror Module connector. Measure the resistance between ground and the (P71) or (P72) Mirror Vertical Motor Driver circuit. Is the resistance below 5000.0 ohms? Yes : Repair the (P71) or (P72) Mirror Vertical Motor Driver circuit for a short to ground. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . No : Go to 4
4. TEST THE (P71) OR (P72) MIRROR VERTICAL MOTOR DRIVER CIRCUIT SHORTED TO THE (C910) OR (C917) MIRROR HEATER GROUND CIRCUIT. Measure the resistance between the (P71) or (P72) Mirror Vertical Motor Driver circuit and the (C910) or (C917) Mirror Heater Ground circuit. Is the resistance below 5000.0 ohms? Yes : Repair the (P71) or (P72) Mirror Vertical Motor Driver circuit for a short to the (C910) or (C917) Mirror Heater Ground Circuit. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . No : Replace the appropriate Memory Mirror Module. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) .

Scheme 84

For the Memory Mirror System circuit diagram (Refer to SCHEMATICS AND DIAGRAMS ).

For a complete wiring diagram Refer to SYSTEM WIRING DIAGRAMS .

1. When Monitored: Continuously

1. Set Condition: When the Memory Mirror Module senses voltage present on the Mirror Vertical Motor Driver circuit, when there should not be, for over 10ms., this code will set. Note: This test covers both the Driver and Passenger code depending on the side the code appeared in.

Possible Causes

1. (P71) OR (P72) MIRROR VERTICAL MOTOR DRIVER CIRCUIT SHORT TO VOLTAGE
2. MIRROR SHORTED
3. MEMORY MIRROR MODULE

Scheme 85

Scheme 86

Scheme 87

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTC's Operate the Mirror Switch in all directions several times. Cycle the ignition from on to off 3 times. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display B1D20 or B1D2C-MIRROR VERTICAL MOTOR CONTROL CIRCUIT HIGH? Yes : Go To 2 No : The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) .
2. TEST FOR A SHORTED MIRROR Turn the ignition off. Disconnect the appropriate mirror connector. Turn the ignition on. With the scan tool, record and erase DTC's Operate the Mirror Switch in all directions several times. Cycle the ignition from on to off 3 times. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display B1D20 or B1D2C-MIRROR VERTICAL MOTOR CONTROL CIRCUIT HIGH? No : Replace the Mirror. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . Yes : Go to 3
3. TEST THE (P713) OR (P72) MIRROR VERTICAL MOTOR DRIVER WIRE FOR A SHORT TO VOLTAGE Measure the voltage between the (P71) or (P72) Mirror Vertical Motor Driver circuit and ground. Is the voltage above 0.5 volts? Yes : Repair the (P71) or (P72) Mirror Vertical Motor Driver circuit for a short to voltage. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . No : Replace the appropriate Memory Mirror Module. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) .

Scheme 88

For the Memory Mirror System circuit diagram (Refer to SCHEMATICS AND DIAGRAMS ).

For a complete wiring diagram Refer to SYSTEM WIRING DIAGRAMS .

1. When Monitored: Continuously

1. Set Condition: When the Memory Mirror Module senses an open condition on the Mirror Vertical Motor Driver circuit during a mirror opeation, for over 10ms., this code will set. Note: This test covers both the Driver and Passenger code depending on the side the code appeared in.

Possible Causes

1. (P71) OR (P72) MIRROR MOTOR DRIVER CIRCUIT OPEN
2. MIRROR OPEN
3. MEMORY MIRROR MODULE

Scheme 89

Scheme 90

Scheme 91

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTC's Operate the Mirror Switch in all directions several times. Cycle the ignition from on to off 3 times. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display B1D21 or B1D2d-MIRROR VERTICAL MOTOR CONTROL CIRCUIT OPEN? Yes : Go To 2 No : The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) .
2. TEST FOR AN OPEN MIRROR Disconnect the appropriate mirror connector. Connect a test light between the (P73) or (P70) Mirror Common Driver circuit and the (P71) or (P72) Mirror Vertical Driver circuit. Operate the mirror switch Up and Down several times. Does the testlight illuminate when the switch is operated? Yes : Replace the Mirror. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . No : Go to 3
3. TEST THE (P71) OR (P72) MIRROR VERTICAL MOTOR DRIVER WIRE FOR AN OPEN Turn the ignition off. Disconnect the appropriate Memory Mirror Module connector. Measure the resistance of the (P71) or (P72) Mirror Vertical Motor Driver circuit between the mirror connector and the module connector. Is the resistance below 2.0 ohms? No : Repair the (P71) or (P72) Mirror Vertical Motor Driver circuit for an open.. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . Yes : Replace the appropriate Memory Mirror Module. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) .

Scheme 92

For the Memory Mirror System circuit diagram (Refer to SCHEMATICS AND DIAGRAMS ).

For a complete wiring diagram Refer to SYSTEM WIRING DIAGRAMS .

1. When Monitored: Continuously

1. Set Condition: When the Memory Mirror Module senses a value below the tolerance of the mirror motor on the Mirror Horizontal Motor Driver circuit for over 10ms., this code will set. Note: This test covers both the Driver and Passenger code depending on the side the code appeared in.

Possible Causes

1. (P75) OR (P74) MIRROR HORIZONTAL DRIVER CIRCUIT SHORT TO GROUND
2. (P75) OR (P74) MIRROR HORIZONTAL DRIVER CIRCUIT SHORTED TO THE (C910) OR (C917) MIRROR HEATER GROUND CIRCUIT.
3. MIRROR SHORTED
4. MEMORY MIRROR MODULE

Scheme 93

Scheme 94

Scheme 95

Scheme 96

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTC's Operate the Mirror Switch in all directions several times. Cycle the ignition from on to off 3 times. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display B1D23 or B1D2F-MIRROR HORIZONTAL MOTOR CONTROL CIRCUIT LOW? Yes : Go To 2 No : The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) .
2. TEST FOR A SHORTED MIRROR Disconnect the appropriate mirror connector. With the scan tool, erase DTC's. Operate the Mirror Switch in all directions several times. Cycle the ignition from on to off 3 times. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display B1D23 or B1D2F-MIRROR HORIZONTAL MOTOR CONTROL CIRCUIT LOW? No : Replace the Mirror. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . Yes : Go to 3
3. TEST THE (P75) OR (P74)) MIRROR HORIZONTAL MOTOR DRIVER WIRE FOR A SHORT TO GROUND Turn the ignition off. Disconnect the appropriate Memory Mirror Module connector. Measure the resistance between ground and the (P75) or (P74) Mirror Horizontal Motor Driver circuit. Is the resistance below 5000.0 ohms? Yes : Repair the (P75) or (P74) Mirror Horizontal Motor Driver circuit for a short to ground. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . No : Go to 4
4. TEST THE (P75) OR (P74) MIRROR HORIZONTAL MOTOR DRIVER CIRCUIT SHORTED TO THE (C910) OR (C917) MIRROR HEATER GROUND CIRCUIT. Measure the resistance between the (P75) or (P74) Mirror Horizontal Driver circuit and the (C910) or (C917) Mirror Heater Ground circuit. Is the resistance below 5000.0 ohms? Yes : Repair the (P75) or (P74) Mirror Horizontal Motor Driver circuit for a short to the (C910) or (C917) Mirror Heater Ground Circuit. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . No : Replace the appropriate Memory Mirror Module. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) .

Scheme 97

For the Memory Mirror System circuit diagram (Refer to SCHEMATICS AND DIAGRAMS ).

For a complete wiring diagram Refer to SYSTEM WIRING DIAGRAMS .

1. When Monitored: Continuously

1. Set Condition: When the Memory Mirror Module senses voltage present on the Mirror Horizontal Motor Driver circuit, when there should not be, for over 10ms., this code will set. Note: This test covers both the Driver and Passenger code depending on the side the code appeared in.

Possible Causes

1. (P75) OR (P74) MIRROR HORIZONTAL MOTOR DRIVER CIRCUIT SHORT TO VOLTAGE
2. MIRROR SHORTED
3. MEMORY MIRROR MODULE

Scheme 98

Scheme 99

Scheme 100

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTC's Operate the Mirror Switch in all directions several times. Cycle the ignition from on to off, 3 times. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display B1D24 or B1D30-MIRROR HORIZONTAL MOTOR CONTROL CIRCUIT HIGH? Yes : Go To 2 No : The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) .
2. TEST FOR A SHORTED MIRROR Turn the ignition off. Disconnect the appropriate mirror connector. Turn the ignition on. With the scan tool, record and erase DTC's Operate the Mirror Switch in all directions several times. Cycle the ignition from on to off 3 times. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display B1D24 or B1D30-MIRROR HORIZONTAL MOTOR CONTROL CIRCUIT HIGH? No : Replace the Mirror. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . Yes : Go to 3
3. TEST THE (P75) OR (P74) MIRROR HORIZONTALL MOTOR DRIVER WIRE FOR A SHORT TO VOLTAGE Measure the voltage between the (P75) or (P74) Mirror Horizontal Motor Driver circuit and ground. Is the voltage above 0.5 volts? Yes : Repair the (P75) or (P74) Mirror Horizontal Motor Driver circuit for a short to voltage. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . No : Replace the appropriate Memory Mirror Module. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) .

Scheme 101

For the Memory Mirror System circuit diagram (Refer to SCHEMATICS AND DIAGRAMS ).

For a complete wiring diagram Refer to SYSTEM WIRING DIAGRAMS .

1. When Monitored: Continuously

1. Set Condition: When the Memory Mirror Module senses an open condition on the Mirror Horizontal Motor Driver circuit during a mirror opeation, for over 10ms., this code will set. Note: This test covers both the Driver and Passenger code depending on the side the code appeared in.

Possible Causes

1. (P75) OR (P74) MIRROR HORIZONTAL MOTOR DRIVER CIRCUIT OPEN
2. MIRROR OPEN
3. MEMORY MIRROR MODULE

Scheme 102

Scheme 103

Scheme 104

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTC's Operate the Mirror Switch in all directions several times. Cycle the ignition from on to off 3 times. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display B1D25 or B1D31-MIRROR HORIZONTAL MOTOR CONTROL CIRCUIT OPEN? Yes : Go To 2 No : The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) .
2. TEST FOR AN OPEN MIRROR Disconnect the appropriate mirror connector. Connect a test light between the (P73) or (P70) Mirror Common Driver circuit and the (P75) or (P74) Mirror Horizontal Driver circuit. Operate the mirror switch Left and Right several times. Does the testlight illuminate when the switch is operated? Yes : Replace the Mirror. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . No : Go to 3
3. TEST THE (P75) OR (P74) MIRROR HORIZONTAL MOTOR DRIVER WIRE FOR AN OPEN Turn the ignition off. Disconnect the appropriate Memory Mirror Module connector. Measure the resistance of the (P75) or (P74) Mirror Horizontal Motor Driver circuit between the mirror connector and the module connector. Is the resistance below 2.0 ohms? No : Repair the (P75) or (P74) Mirror Horizontal Motor Driver circuit for an open. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) . Yes : Replace the appropriate Memory Mirror Module. Perform «BODY VERIFICATION TEST - VER 1»(ref-212797-S05728841372005122700000) .
