Scheme 133
Scheme 134
- Remove the screws (5 & 7). CAUTION: Trim panel is attached to the door using hooks molded into the panel. Do not pull the trim panel straight off or damage to the panel and/or power switch assembly may occur.
- Lift the trim panel up off the lock rod (4) and attachment hooks and separate the panel from the door slightly.
- Disconnect the electrical connectors (1).
- Disconnect the inside handle actuator rod (3) and remove the trim panel (6).
- Remove the switch panel (1) if necessary.
Scheme 135
Scheme 136
- Install the switch assembly (1).
- Position the trim panel (6) and connect the inside handle actuator rod (3).
- Connect the electrical connectors (1).
- Lift the trim panel up and onto the lock rod (4) and attachment hooks.
- Install the screws (5 & 7).
