AXLE SPECIFICATIONS
| DESCRIPTION | SPECIFICATION |
|---|---|
| Axle Ratio | 3.55, 3.92 |
| Differential Case Flange Runout | 0.076 mm (0.003 in.) |
| Differential Side Gear Clearance | 0-0.15 mm (0-0.006 in.) |
| Ring Gear Diameter | 205 mm (7.562 in.) |
| Ring Gear Backlash | 0.12-0.20 mm (0.005-0.008 in.) |
| Ring Gear Runout | 0.12 mm (0.005 in.) |
| Pinion Bearing Preload - Original Bearings | 1-2 N.m (10-20 in. lbs.) |
| Pinion Bearing Preload - New Bearings | 17-2.5 N.m (15-22 in. lbs.) |
AXLE SPECIFICATIONS
TORQUE SPECIFICATIONS
| DESCRIPTION | N.m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| Differential Fill Hole Plug | 34 | 25 | |
| Differential Cover Bolts | 22.5 | 16.5 | 199 |
| Bearing Cap Bolts | 61 | 45 | |
| Ring Gear Bolts | 108 | 80 | |
| Pinion Nut | 271-474 | 200-350 | |
| Axle Mounting Bolts/Nuts | 95 | 70 |
TORQUE SPECIFICATIONS
