545RFE Automatic Transmission - Electrical Diagnostics: Other Dodge Durango II

Monitor Conditions

1. When Monitored: Continuously with the ignition on and engine running.

Set Conditions

1. Set Condition: This DTC will set if the monitored TPS voltage drops below .078 volts for the period of 0.48 seconds.

Possible Causes

Possible Causes

1. RELATED ENGINE TPS/APPS DTC'S PRESENT
2. POWERTRAIN CONTROL MODULE

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: Continuously with the ignition on and engine running.

1. Set Condition: This DTC will set if the monitored TPS voltage rises above 4.94 volts for the period of 0.48 seconds.

Possible Causes

1. RELATED ENGINE TPS/APPS DTC'S PRESENT
2. POWERTRAIN CONTROL MODULE

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: Continuously with the ignition on and engine running.

1. Set Condition: This DTC will set if the monitored TPS throttle angle between the angles of 6° and 120° and the degree change is greater than 5° within a period of less than 7.0 ms

Possible Causes

1. RELATED TPS ENGINE DTC'S PRESENT
2. THROTTLE POSITION SENSOR
3. POWERTRAIN CONTROL MODULE

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: Whenever the engine is running.

1. Set Condition: Immediately after a Overheat shift schedule is activated when the Transmission temperature exceeds 116° C or 240° F.

Possible Causes

1. HIGH TEMPERATURE OPERATIONS ACTIVATED

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: With the engine running and the PCM has closed the Transmission Control Relay.

1. Set Condition: If the battery voltage of the Transmission Control Relay Output Sense circuit(s) to the PCM is less than 10.0 volts for the period of 15 seconds. Note: P0562 generally indicates a gradually falling battery voltage or a resistive connection(s) to the PCM. The DTC will also set if the battery voltage sensed at the PCM is less than 6.5-volts for 200ms or where Transmission Control Relay Output circuits are less than 7.2-volts for 200ms.

Possible Causes

1. RELATED CHARGING SYSTEM DTC'S
2. (Z908, Z977) GROUND CIRCUIT OPEN OR HIGH RESISTANCE
3. (A104) FUSED B+ CIRCUIT TO PCM OPEN OR HIGH RESISTANCE
4. (T16) TRANSMISSION CONTROL RELAY OUTPUT CIRCUIT OPEN OR HIGH RESISTANCE
5. TRANSMISSION CONTROL RELAY
6. POWERTRAIN CONTROL MODULE

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: Check for generic software is made at power-up

1. Set Condition: If genie software is found, the MIL will light immediately. This DTC is designed to signal the technician that the controller still has generic software installed.

Possible Causes

1. PCM - PROGRAMMING ERROR

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS )

1. When Monitored: One time after the controller is reset (ignition turned to the RUN position).

1. Set Condition: Whenever the Powertrain Control Module (PCM) detects an internal controller problem.

Possible Causes

1. POWER OR GROUND CIRCUIT
2. POWERTRAIN CONTROL MODULE

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: One time after the controller is reset (ignition turned to the RUN position).

1. Set Condition: Whenever the Powertrain Control Module (PCM) detects an internal controller problem.

Possible Causes

1. POWER OR GROUND CIRCUIT
2. POWERTRAIN CONTROL MODULE

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: One time after the controller is reset (ignition turned to the RUN position) and every 60 seconds thereafter. The Delay Test is executed after a reset only. 2 seconds after an invalid test.

1. Set Condition: If either of the following conditions occur 3 times: The watchdog fault line remains high after the period has elapsed for the too early - too late watchdog test. The Transmission Control Relay remains on after the watchdog delay expired.

Possible Causes

1. POWER OR GROUND CIRCUIT
2. POWERTRAIN CONTROL MODULE

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: Continuously with the ignition on.

1. Set Condition: The DTC will set if there are 3 occurrences in one ignition cycle of an invalid PRNDL code which last for more than 0.1 seconds.

Possible Causes

1. SHIFTER OUT OF ADJUSTMENT
2. TRS SENSE CIRCUIT OPEN
3. TRS SENSE CIRCUIT SHORT TO GROUND
4. TRS SENSE CIRCUIT SHORT TO VOLTAGE
5. TRANSMISSION RANGE SENSOR
6. POWERTRAIN CONTROL MODULE

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: Continuously with the ignition on and engine running.

1. Set Condition: This DTC will set when the desired transmission temperature does not reach a normal operating temperature within a given time frame. Time is variable due to ambient temperature. Approximate times are starting temperature to warm up time: (-40° F / -40° C - 35 min) (-20° F / -28° C - 25 min) (20° F / -6.6° C - 20 min) (60° F / 15.5 ° C - 10 min)

Possible Causes

1. RELATED DTC'S PRESENT
2. TRANSMISSION TEMPERATURE SENSOR
3. POWERTRAIN CONTROL MODULE

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: Continuously with the ignition on and engine running.

1. Set Condition: The DTC will set when the monitored Temperature Sensor voltage drops below 0.078 volts for the period of 0.45 seconds.

Possible Causes

1. RELATED DTC'S PRESENT
2. (T54) TRANSMISSION TEMPERATURE SENSOR SIGNAL CIRCUIT SHORT TO GROUND
3. TRANSMISSION TEMPERATURE SENSOR
4. POWERTRAIN CONTROL MODULE

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: Continuously with the ignition on and engine running.

1. Set Condition: The DTC will set when the monitored Temperature Sensor voltage rises above 4.94 volts for the period of 0.45 seconds.

Possible Causes

1. RELATED DTC'S PRESENT
2. (T54) TRANSMISSION TEMPERATURE SENSOR SIGNAL CIRCUIT SHORT TO OTHER CIRCUITS
3. TRANSMISSION TEMPERATURE SENSOR
4. POWERTRAIN CONTROL MODULE

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: Continuously with the ignition on and engine running.

1. Set Condition: The DTC will set when the monitored Temperature Sensor voltage fluctuates or changes abruptly within a predetermined period of time.

Possible Causes

1. RELATED DTC'S PRESENT
2. TRANSMISSION TEMPERATURE SENSOR
3. POWERTRAIN CONTROL MODULE

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: The transmission gear ratio is monitored continuously while the transmission is in gear.

1. Set Condition: If there is an excessive change in input RPM in any gear. This DTC can take up to five minutes of problem identification before illuminating the MIL.

Possible Causes

1. (T52) INPUT SPEED SENSOR SIGNAL CIRCUIT OPEN
2. (T13) SPEED SENSOR GROUND CIRCUIT OPEN
3. (T52) INPUT SPEED SENSOR SIGNAL CIRCUIT SHORT TO GROUND
4. (T13) SPEED SENSOR GROUND CIRCUIT SHORT TO GROUND
5. (T52) INPUT SPEED SENSOR SIGNAL CIRCUIT SHORT TO VOLTAGE
6. (T13) SPEED SENSOR GROUND CIRCUITSHORT TO VOLTAGE
7. INPUT SPEED SENSOR
8. POWERTRAIN CONTROL MODULE

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: The transmission gear ratio is monitored continuously while the transmission is in gear.

1. Set Condition: If there is an excessive change in output RPM in any gear. This DTC can take up to five minutes of problem identification before illuminating the MIL.

Possible Causes

1. OUTPUT SPEED SENSOR SIGNAL CIRCUIT OPEN
2. PEED SENSOR GROUND CIRCUIT OPEN
3. OUTPUT SPEED SENSOR SIGNAL CIRCUIT SHORT TO GROUND
4. SPEED SENSOR GROUND CIRCUIT SHORT TO GROUND
5. OUTPUT SPEED SENSOR SIGNAL CIRCUIT SHORT TO VOLTAGE
6. SPEED SENSOR GROUND CIRCUIT SHORT TO VOLTAGE
7. OUTPUT SPEED SENSOR
8. POWERTRAIN CONTROL MODULE

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: Continuously every 7 msec with the ignition on and engine running.

1. Set Condition: This DTC will set when the calculated engine speed is less than 390 RPM, or greater than 8000 RPM, for the period of 2.0 seconds. The PCM will place the Transmission in Limp-in after 10.0 seconds of repeated problem identification. Note: This is not a Transmission Input Speed Sensor DTC.

Possible Causes

1. RELATED ENGINE DTC'S PRESENT
2. POWERTRAIN CONTROL MODULE

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: Continuously with the ignition on, engine running, with the transmission in gear.

1. Set Condition: If the ratio of the Input RPM to the Output RPM does not match the current gear ratio. This DTC can take up to five minutes of problem identification before illuminating the MIL

Possible Causes

1. CUT UD PISTON SEAL
2. LOW FLUID LEVEL
3. CRACKED OR MISINSTALLED PRIMARY OIL FILTER OR SEAL
4. STUCK OR STICKING MAIN REGULATOR VALVE
5. FAILED OVERRUNNING CLUTCH
6. CUT UD ACCUMULATOR SEAL RING
7. BROKEN UD ACCUMULATOR PISTON
8. BROKEN REACTION SHAFT SUPPORT SEAL RING
9. LOW LINE PRESSURE
10. BROKEN / MISSING MAIN VALVE BODY BLEED ORIFICE
11. BROKEN / MISSING DRIBBLER ORIFICE ASSEMBLY IN REACTION SHAFT SUPPORT
12. POOR MACHINING ON PUMP VALVE BODY FACE
13. INPUT SPEED SENSOR AND RELATED WIRING
14. TRANSMISSION SOLENOID/TRS ASSEMBLY
15. POWERTRAIN CONTROL MODULE

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: Continuously with the ignition on, engine running, with the transmission in gear.

1. Set Condition: If the ratio of the Input RPM to the Output RPM does not match the current gear ratio. This DTC can take up to five minutes of problem identification before illuminating the MIL

Possible Causes

1. RELATED DTC'S PRESENT
2. INPUT SPEED SENSOR OR WIRING
3. LOW FLUID LEVEL
4. CRACKED OR MISINSTALLED PRIMARY OIL FILTER OR SEAL
5. WORN SOLENOID SWITCH VALVE OR PLUGS
6. STUCK OR STICKING MAIN REGULATOR VALVE
7. BURNED UD OR 2C CLUTCH
8. CUT 2C OR UD PISTON SEAL
9. BROKEN 2C PISTON CASTING
10. BROKEN OR MISSING 2C BLEED ORIFICE
11. BROKEN OR MISSING UD BLEED ORIFICE
12. CUT 2C OR UD ACCUMULATOR PISTON SEAL
13. CRACKED 2C OR UD ACCUMULATOR PISTON
14. CUT OR MISSING #5 OR #7 CHECK BALL
15. TRANSMISSION SOLENOID/TRS ASSEMBLY
16. BROKEN WELD - REACTION CARRIER TO REVERSE SUN GEAR
17. MISSING TEETH ON INPUT CLUTCH HUB TONE WHEEL

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: Continuously with the ignition on, engine running, with the transmission in gear.

1. Set Condition: If the ratio of the Input RPM to the Output RPM does not match the current gear ratio. This DTC can take up to five minutes of problem identification before illuminating the MIL

Possible Causes

1. RELATED DTCS PRESENT
2. INPUT SPEED SENSOR OR WIRING
3. LOW FLUID LEVEL
4. CRACKED OR MISINSTALLED PRIMARY OIL FILTER OR SEAL
5. BENT OR BROKEN ACCUMULATOR COVER ON MAIN VALVE BODY
6. WORN SOLENOID SWITCH VALVE OR PLUGS
7. STUCK OR STICKING MAIN REGULATOR VALVE
8. BURNED UD OR OD CLUTCH
9. CUT OD OR UD PISTON SEAL
10. BROKEN OR MISSING UD OR OD BLEED ORIFICE IN MAIN VALVE BODY
11. BROKEN OR MISSING BLEED ORIFICE IN UD OR OD CLUTCH PISTON
12. CUT OD OR UD ACCUMULATOR PISTON SEAL
13. CRACKED OD OR UD ACCUMULATOR PISTON
14. CUT OR MISSING #6 CHECK BALL
15. TRANSMISSION SOLENOID/TRS ASSEMBLY
16. BROKEN WELD - REVERSE CARRIER HUB TO CARRIER
17. BROKEN REACTION SHAFT SUPPORT SEAL RING
18. POOR MACHINING ON PUMP VALVE BODY FACE

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: Continuously with the ignition on, engine running, with the transmission in gear.

1. Set Condition: If the ratio of the Input RPM to the Output RPM does not match the current gear ratio. This DTC can take up to five minutes of problem identification before illuminating the MIL.

Possible Causes

1. LOW FLUID LEVEL
2. INPUT SPEED SENSOR OR WIRING
3. VALVE BODY ACCUMULATOR COVER FAILED
4. CUT OD OR 4C ACCUMULATOR SEAL
5. CRACKED OD OR 4C ACCUMULATOR PISTON
6. BROKEN OR MISSING OD BLEED ORIFICE IN MAIN VALVE BODY
7. CUT 4C TOWER SEAL
8. TRANSMISSION SOLENOID/TRS ASSEMBLY
9. CUT OR MISSING #5 OR #6 CHECK BALL
10. WORN SOLENOID SWITCH VALVE OR PLUGS
11. CUT OD OR 4C PISTON SEAL
12. STUCK MAIN REGULATOR VALVE
13. BURNED OD OR 4C CLUTCH
14. BROKEN OR MISSING 4C BLEED ORIFICE IN 2C/4C RETAINER
15. BROKEN REACTION SHAFT SUPPORT SEAL RING
16. POOR MACHINING ON PUMP VALVE BODY FACE
17. LOOSE / MISSING DRIBBLER ORIFICE ASSEMBLY IN REACTION SHAFT SUPPORT
18. CRACKED / LOOSE / MISSING OD/REVERSE PISTON BLEED ORIFICE
19. BROKEN REVERSE CARRIER HUB WELD
20. BROKEN REVERSE SUN GEAR WELD TO REACTION CARRIER

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: Continuously with the ignition on, engine running, with the transmission in gear.

1. Set Condition: If the ratio of the Input RPM to the Output RPM does not match the current gear ratio. This DTC can take up to five minutes of problem identification before illuminating the MIL.

Possible Causes

1. LOW FLUID LEVEL
2. INPUT SPEED SENSOR OR WIRING
3. VALVE BODY ACCUMULATOR COVER FAILED
4. CUT OD OR 2C ACCUMULATOR SEAL
5. CRACKED OD OR 2C ACCUMULATOR PISTON
6. BROKEN OR MISSING OD BLEED ORIFICE IN MAIN VALVE BODY
7. CUT 2C TOWER SEAL
8. TRANSMISSION SOLENOID/TRS ASSEMBLY
9. CUT OR MISSING #5, #6, OR #7 CHECK BALL
10. WORN SOLENOID SWITCH VALVE OR PLUGS
11. CUT OD OR 2C PISTON SEAL
12. STUCK MAIN REGULATOR VALVE
13. BURNED OD OR 2C CLUTCH
14. BROKEN OR MISSING 2C BLEED ORIFICE IN 2C/4C RETAINER
15. BROKEN REACTION SHAFT SUPPORT SEAL RING
16. POOR MACHINING ON PUMP VALVE BODY FACE
17. LOOSE / MISSING DRIBBLER ORIFICE ASSEMBLY IN REACTION SHAFT SUPPORT
18. CRACKED / LOOSE / MISSING OD/REVERSE PISTON BLEED ORIFICE
19. BROKEN REVERSE CARRIER HUB WELD
20. BROKEN REVERSE SUN GEAR WELD TO REACTION CARRIER

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: Continuously with the ignition on, engine running, with the transmission in gear.

1. Set Condition

Possible Causes

If the ratio of the Input RPM to the Output RPM does not match the current gear ratio. This DTC can take up to five minutes of problem identification before illuminating the MIL

1. LOW FLUID LEVEL
2. CUT LR TOWER SEAL ON MAIN VALVE BODY
3. CUT LR CLUTCH PISTON SEALS
4. BROKEN OR MISSING LR CLUTCH BLEED ORIFICE (IN LR CLUTCH RETAINER)
5. CUT LR ACCUMULATOR PISTON SEAL IN MAIN VALVE BODY
6. CRACKED LR ACCUMULATOR PISTON IN MAIN VALVE BODY
7. CUT OD/REV PISTON SEALS
8. BROKEN OR MISSING OD/REV BLEED ORIFICE (IN OD/REV CLUTCH PISTON)
9. BROKEN REVERSE CARRIER HUB WELD
10. BROKEN REVERSE SUN GEAR WELD TO THE REACTION CARRIER

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: During Electronically Modulated Converter Clutch (EMCC) Operation.

1. Set Condition: Transmission must be in EMCC, with input speed greater than 1750 RPM. TCC-L/R Solenoid achieves the maximum duty cycle and can not pull engine speed within 60 RPM of input speed. Also when the transmission is in FEMCC and the engine slips TCC less than 100 RPM for 10 seconds. This DTC can take up to five minutes of problem identification before illuminating the MIL.

Possible Causes

1. RELATED DTC P0750 PRESENT
2. L/R SOLENOID
3. TORQUE CONVERTER AND/OR INTERNAL TRANSMISSION

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: Initially at power-up, then every 10 seconds thereafter. The solenoid circuits will also be tested immediately after a gear ratio or pressure switch error is detected.

1. Set Condition: After three consecutive solenoid continuity test failures, or one failure if test is run in response to a gear ratio or pressure switch error

Possible Causes

1. RELATED RELAY DTC'S PRESENT
2. (T20) LR SOLENOID CONTROL CIRCUIT SHORT TO OTHER CIRCUITS
3. (T20) LR SOLENOID CONTROL CIRCUIT OPEN
4. (T20) LR SOLENOID CONTROL CIRCUIT SHORT TO GROUND
5. TRANSMISSION SOLENOID/TRS ASSEMBLY
6. POWERTRAIN CONTROL MODULE

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: Initially at power-up, then every 10 seconds thereafter. The solenoid circuits will also be tested immediately after a gear ratio or pressure switch error is detected.

1. Set Condition: After three consecutive solenoid continuity test failures, or one failure if test is run in response to a gear ratio or pressure switch error

Possible Causes

1. RELATED RELAY DTC'S PRESENT
2. (T219) 2C SOLENOID CONTROL CIRCUIT SHORT TO OTHER CIRCUITS
3. (T219) 2C SOLENOID CONTROL CIRCUIT OPEN
4. (T219) 2C SOLENOID CONTROL CIRCUIT SHORT TO GROUND
5. TRANSMISSION SOLENOID/TRS ASSEMBLY
6. POWERTRAIN CONTROL MODULE

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: Initially at power-up, then every 10 seconds thereafter. The solenoid circuits will also be tested immediately after a gear ratio or pressure switch error is detected.

1. Set Condition: After three consecutive solenoid continuity test failures, or one failure if test is run in response to a gear ratio or pressure switch error

Possible Causes

1. RELATED RELAY DTC'S PRESENT
2. (T60) OD SOLENOID CONTROL CIRCUIT SHORT TO OTHER CIRCUITS
3. (T60) OD SOLENOID CONTROL CIRCUIT OPEN
4. (T60) OD SOLENOID CONTROL CIRCUIT SHORT TO GROUND
5. TRANSMISSION SOLENOID/TRS ASSEMBLY
6. POWERTRAIN CONTROL MODULE

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: Initially at power-up, then every 10 seconds thereafter. The solenoid circuits will also be tested immediately after a gear ratio or pressure switch error is detected.

1. Set Condition: After three consecutive solenoid continuity test failures, or one failure if test is run in response to a gear ratio or pressure switch error

Possible Causes

1. RELATED RELAY DTC'S PRESENT
2. (T59) UD SOLENOID CONTROL CIRCUIT SHORT TO OTHER CIRCUITS
3. (T59) UD SOLENOID CONTROL CIRCUIT OPEN
4. (T59) UD SOLENOID CONTROL CIRCUIT SHORT TO GROUND
5. TRANSMISSION SOLENOID/TRS ASSEMBLY
6. POWERTRAIN CONTROL MODULE

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: Initially at power-up, then every 10 seconds thereafter. The solenoid circuits will also be tested immediately after a gear ratio or pressure switch error is detected.

1. Set Condition: After three consecutive solenoid continuity test failures, or one failure if test is run in response to a gear ratio or pressure switch error

Possible Causes

1. RELATED RELAY DTC'S PRESENT
2. (T259) 4C SOLENOID CONTROL CIRCUIT SHORT TO OTHER CIRCUITS
3. (T259) 4C SOLENOID CONTROL CIRCUIT OPEN
4. (T259) 4C SOLENOID CONTROL CIRCUIT SHORT TO GROUND
5. TRANSMISSION SOLENOID/TRS ASSEMBLY
6. POWERTRAIN CONTROL MODULE

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: Continuously with the ignition on and engine running.

1. Set Condition: The DTC will set if the LR Pressure Switch reads open or closed at the wrong time in a given gear.

Possible Causes

1. LOSS OF PRIME AND/OR TRANSMISSION CONTROL RELAY DTC PRESENT
2. LOW FLUID LEVEL
3. LOW LINE PRESSURE
4. REVERSE CARRIER SNAP RING DISLODGED
5. CRACKED OR MISINSTALLED PRIMARY OIL FILTER OR FILTER SEAL
6. STICKING MAIN REGULATOR VALVE IN PUMP VALVE BODY
7. NO. 1 CHECK BALL CUT OR DAMAGED
8. WIRING AND CONNECTORS
9. (T50) LR PRESSURE SWITCH SENSE CIRCUIT OPEN
10. (T50) LR PRESSURE SWITCH SENSE CIRCUIT SHORT TO GROUND
11. (T50) LR PRESSURE SWITCH SENSE CIRCUIT SHORT TO VOLTAGE
12. TRANSMISSION SOLENOID/TRS ASSEMBLY
13. POWERTRAIN CONTROL MODULE

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: In any forward gear with engine speed above-1000 RPM shortly after a shift and every minute thereafter.

1. Set Condition: After a shift into a forward gear, with engine speed above 1000 RPM, the PCM momentarily turns on element pressure to the Clutch circuits that don't have pressure to identify the correct Pressure Switch closes. If the Pressure Switch does not close 2 times, the DTC sets.

Possible Causes

1. LINE PRESSURE SENSOR
2. TRANSMISSION FLUID CONTAMINATION
3. RELATED DTC'S PRESENT
4. TRANSMISSION SOLENOID/TRS ASSEMBLY
5. EXCESSIVE DEBRIS IN OIL PAN
6. POOR LINE PRESSURE SENSOR CONNECTION
7. (T147) 2C PRESSURE SWITCH SENSE CIRCUIT OPEN
8. TRANSMISSION CONTROL RELAY DTCS PRESENT
9. (T147) 2C PRESSURE SWITCH SENSE CIRCUIT OPEN
10. (F856) 5-VOLT SUPPLY CIRCUIT OPEN
11. (T147) 2C PRESSURE SWITCH SENSE CIRCUIT SHORT TO GROUND
12. (F856) 5-VOLT SUPPLY CIRCUIT SHORT TO GROUND
13. (T147) 2C PRESSURE SWITCH SENSE CIRCUIT SHORT TO VOLTAGE
14. TRANSMISSION SOLENOID/TRS ASSEMBLY
15. INTERNAL TRANSMISSION
16. POWERTRAIN CONTROL MODULE

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: Continuously with the ignition on, engine running, with the transmission in gear.

1. Set Condition: The DTC is set if the 2C Pressure Switch reads open or closed at the wrong time in a given gear.

Possible Causes

1. RELATED RELAY DTC'S PRESENT
2. (T147) 2C PRESSURE SWITCH SENSE CIRCUIT OPEN
3. (T147) 2C PRESSURE SWITCH SENSE CIRCUIT SHORT TO GROUND
4. (T147) 2C PRESSURE SWITCH SENSE CIRCUIT SHORT TO OTHER CIRCUITS
5. EXCESSIVE FLUID LEAKAGE IN 2C CLUTCH CIRCUIT
6. NO. 5 AND/OR NO. 7 CHECK BALL CUT OR DAMAGED
7. EXTRA CHECK BALL DOWNSTEAM THE NO. 7 CHECK BALL SOCKET
8. LOW LINE PRESSURE
9. TRANSMISSION SOLENOID/TRS ASSEMBLY
10. POWERTRAIN CONTROL MODULE
11. WIRING AND CONNECTORS

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: Continuously while driving in a forward gear.

1. Set Condition: The PCM continuously monitors Actual Line Pressure and compares it to Desired Line Pressure. If the Actual Line Pressure is more than 10 PSI below Desired Line Pressure, this DTC will set.

Possible Causes

1. CHECK FOR RELATED DTC'S
2. (F856) 5-VOLT SUPPLY CIRCUIT OPEN
3. POOR LINE PRESSURE SENSOR CONNECTION
4. (F856) 5-VOLT SUPPLY CIRCUIT SHORT TO GROUND
5. (F856) 5-VOLT SUPPLY CIRCUIT SHORT TO VOLTAGE
6. PRESSURE CONTROL SOLENOID CONTROL CIRCUIT SHORT TO VOLTAGE
7. INTERNAL TRANSMISSION
8. LINE PRESSURE SENSOR
9. PLUGGED TRANSMISSION OIL FILTER
10. POWERTRAIN CONTROL MODULE

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: Continuously while driving in a forward gear.

1. Set Condition: The PCM continuously monitors Actual Line Pressure. If the Actual Line Pressure reading is greater than the highest Desired Line Pressure ever used in the current gear, while the Pressure Control Solenoid duty cycle is at or near its maximum value (which should result in minimum line pressure), the DTC will set.

Possible Causes

1. (F856) 5-VOLT SUPPLY CIRCUIT OPEN
2. LINE PRESSURE SENSOR CONNECTION
3. (T140) PRESSURE CONTROL SOLENOID CONTROL CIRCUIT OPEN
4. (F856) 5-VOLT SUPPLY CIRCUIT SHORT TO GROUND
5. (T140) PRESSURE CONTROL SOLENOID CONTROL CIRCUIT SHORT TO GROUND
6. INTERNAL TRANSMISSION
7. LINE PRESSURE SENSOR
8. POWERTRAIN CONTROL MODULE

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: In any forward gear with engine speed above 1000 RPM shortly after a shift and every minute thereafter.

1. Set Condition: After a shift into a forward gear, with engine speed above 1000 RPM, the PCM momentarily turns on element pressure to the Clutch circuits that don't have pressure to identify the correct Pressure Switch closes. If the Pressure Switch does not close 2 times, the DTC sets.

Possible Causes

1. LINE PRESSURE SENSOR
2. TRANSMISSION FLUID CONTAMINATION
3. RELATED DTC'S PRESENT
4. TRANSMISSION SOLENOID/TRS ASSEMBLY
5. EXCESSIVE DEBRIS IN OIL PAN
6. POOR LINE PRESSURE SENSOR CONNECTION
7. (T9) OD PRESSURE SWITCH SENSE CIRCUIT OPEN
8. TRANSMISSION CONTROL RELAY DTCS PRESENT
9. (T9) OD PRESSURE SWITCH SENSE CIRCUIT OPEN
10. (F856) 5-VOLT SUPPLY CIRCUIT OPEN
11. TRANSMISSION CONTROL RELAY OUTPUT CIRCUIT OPEN
12. (T9) OD PRESSURE SWITCH SENSE CIRCUIT SHORT TO GROUND
13. (F856) 5-VOLT SUPPLY CIRCUIT SHORT TO GROUND
14. (T9) OD PRESSURE SWITCH SENSE CIRCUIT SHORT TO OTHER CIRCUITS
15. TRANSMISSION SOLENOID/TRS ASSEMBLY
16. INTERNAL TRANSMISSION
17. POWERTRAIN CONTROL MODULE

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: Continuously with the ignition on and engine running.

1. Set Condition: The appropriate DTC is set if one of the pressure switches are open or closed at the wrong time in a given gear.

Possible Causes

1. RELATED RELAY DTC'S PRESENT
2. LINE PRESSURE DTCS PRESENT
3. NO. 4 OR 6 CHECK BALL CUT OR DAMAGED
4. (T9) OD PRESSURE SWITCH SENSE CIRCUIT OPEN
5. (T9) OD PRESSURE SWITCH SENSE CIRCUIT SHORT TO GROUND
6. (T9) OD PRESSURE SWITCH SENSE CIRCUIT SHORT TO OTHER CIRCUITS
7. LOW LINE PRESSURE
8. WIRING AND CONNECTORS
9. CUT OD/REV PISTON SEAL
10. BROKEN OR MISSING DO/REV PISTON BLEED ORIFICE
11. BROKEN REACTION SHAFT SUPPORT SEAL RING
12. POOR MACHINING ON PUMP VALVE BODY FACE
13. BROKEN OR MISSING DRIBBLER ORIFICE ASSEMBLY IN REACTION SHAFT SUPPORT
14. TRANSMISSION SOLENOID/TRS ASSEMBLY
15. CUT OD ACCUMULATOR PISTON SEAL
16. CRACKED OD ACCUMULATOR PISTON
17. BROKEN OR MISSING OD BLEED ORIFICE IN MAIN VALVE BODY
18. POWERTRAIN CONTROL MODULE

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: In any forward gear with engine speed above 1000 RPM shortly after a shift and every minute thereafter.

1. Set Condition: After a shift into a forward gear, with engine speed above 1000 RPM, the PCM momentarily turns on element pressure to the Clutch circuits that don't have pressure to identify the correct Pressure Switch closes. If the Pressure Switch does not close 2 times, the DTC sets.

Possible Causes

1. LINE PRESSURE SENSOR
2. TRANSMISSION FLUID CONTAMINATION
3. RELATED DTC'S PRESENT
4. TRANSMISSION SOLENOID/TRS ASSEMBLY
5. EXCESSIVE DEBRIS IN OIL PAN
6. POOR LINE PRESSURE SENSOR CONNECTION
7. (T29) UD PRESSURE SWITCH SENSE CIRCUIT OPEN
8. TRANSMISSION CONTROL RELAY DTCS PRESENT
9. (T29) UD PRESSURE SWITCH SENSE CIRCUIT OPEN
10. (F856) 5-VOLT SUPPLY CIRCUIT OPEN
11. (T29) UD PRESSURE SWITCH SENSE CIRCUIT SHORT TO GROUND
12. (F856) 5-VOLT SUPPLY CIRCUIT SHORT TO GROUND
13. (T29) UD PRESSURE SWITCH SENSE CIRCUIT SHORT TO VOLTAGE
14. TRANSMISSION SOLENOID/TRS ASSEMBLY
15. INTERNAL TRANSMISSION
16. POWERTRAIN CONTROL MODULE

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: Continuously with the ignition on and engine running.

1. Set Condition: This DTC is set if the UD pressure switch is in the wrong state for the current gear. For example, this code would be set if the UD pressure switch remained off while the transmission was in second gear.

Possible Causes

1. RELATED RELAY DTC'S PRESENT
2. LOW FLUID LEVEL
3. NO. 2 CHECK BALL CUT OR DAMAGED
4. LOW LINE PRESSURE
5. CRACKED OR MISINSTALLED SUMP FILTER OR SEAL
6. STICKING MAIN REGULATOR VALVE IN PUMP VALVE BODY
7. (T29) UD PRESSURE SWITCH SENSE CIRCUIT OPEN
8. (T29) UD PRESSURE SWITCH CIRCUIT SHORT TO GROUND
9. (T29) UD PRESSURE SWITCH SENSE CIRCUIT SHORT TO OTHER CIRCUITS
10. TRANSMISSION SOLENOID/TRS ASSEMBLY
11. POWERTRAIN CONTROL MODULE

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: When Powertrain Control Module initially powers up. Due to the integration of the Powertrain and Transmission Control Modules, the transmission part of the PCM has its own specific power and ground circuits.

1. Set Condition: This DTC will set if the PCM powers up and senses the vehicle in a valid forward gear, with no PRNDL DTCs, and a output speed above 800 RPM, approximately 32Km/h or 20 MPH.

Possible Causes

1. POWER UP AT SPEED

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: When the ignition is turned from "OFF" position to "RUN" position and/or the ignition is turned from "START" position to "RUN" position.

1. Set Condition: This DTC is set when less than 3.0 volts are present at the transmission control relay output circuits at the Powertrain Control Module when the PCM is energizing the relay.

Possible Causes

1. (A104) FUSED B+ CIRCUIT OPEN
2. (T16) TRANSMISSION CONTROL RELAY OUTPUT CIRCUIT OPEN
3. (T16) TRANSMISSION CONTROL RELAY OUTPUT CIRCUIT SHORT TO GROUND
4. (T15) TRANSMISSION CONTROL RELAY CONTROL CIRCUIT OPEN
5. (T15) TRANSMISSION CONTROL RELAY CONTROL CIRCUIT SHORT TO GROUND
6. (Z915) TRANSMISSION CONTROL RELAY GROUND CIRCUIT OPEN
7. TRANSMISSION CONTROL RELAY STUCK OPEN
8. POWERTRAIN CONTROL MODULE

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: When the ignition is turned from "OFF" position to "RUN" position and/or the ignition is turned from "START" position to "RUN" position.

1. Set Condition: This DTC is set if the Powertrain Control Module senses voltage on any of the pressure switch inputs prior to the Transmission Control Relay being energized.

Possible Causes

1. PRESSURE SWITCH SENSE CIRCUITS SHORT TO VOLTAGE
2. TRANSMISSION SOLENOID/TRS ASSEMBLY
3. POWERTRAIN CONTROL MODULE

Always perform the before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: When the ignition is turned from "OFF" position to "RUN" position and/or the ignition is turned from "START" position to "RUN" position.

1. Set Condition: This DTC is set if the Powertrain Control Module senses greater than 3.0 volts on the Transmission Control Relay Output circuits prior to a request from the PCM to energize the Transmission Control Relay.

Possible Causes

1. (T15) TRANSMISSION CONTROL RELAY CONTROL CIRCUIT SHORT TO VOLTAGE
2. (T16) TRANSMISSION CONTROL RELAY OUTPUT CIRCUIT SHORT VOLTAGE
3. TRANSMISSION CONTROL RELAY
4. TRANSMISSION SOLENOID/TRS ASSEMBLY
5. POWERTRAIN CONTROL MODULE

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: Continuously with the ignition on, engine running, with the transmission in gear.

1. Set Condition: The PCM continuously monitors Actual Line Pressure and compares it to Desired Line Pressure. If the Actual Line Pressure reading is more than 172.4 kPa (25 psi) higher than the Desired Line Pressure, but is less than the highest Line Pressure ever used in the current gear, the DTC sets.

Possible Causes

1. RELATED DTC'S PRESENT
2. LINE PRESSURE CONNECTOR AND WIRING
3. INTERNAL TRANSMISSION
4. POWERTRAIN CONTROL MODULE

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: Continuously with the ignition on and engine running.

1. Set Condition: This DTC will set when the Line Pressure is 10 PSI below Desired Line Pressure and the Duty Cycle is less than or equal to the minimum Duty Cycle for 3.57 sec.

Possible Causes

1. (F856) 5-VOLT SUPPLY CIRCUIT OPEN
2. (F856) 5-VOLT SUPPLY CIRCUIT SHORT TO GROUND
3. (T38) LINE PRESSURE SENSOR SIGNAL CIRCUIT SHORT TO GROUND
4. LINE PRESSURE SENSOR
5. POWERTRAIN CONTROL MODULE

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: Continuously with ignition on and engine running.

1. Set Condition: This DTC will set if line pressure is greater than 120 PSI and the Duty Cycle is greater than Duty Cycle maximum for 3.57 sec

Possible Causes

1. (T38) LINE PRESSURE SENSOR SIGNAL CIRCUIT OPEN
2. (K900) SENSOR GROUND CIRCUIT OPEN
3. (T38) LINE PRESSURE SENSOR SIGNAL CIRCUIT SHORT TO VOLTAGE
4. LINE PRESSURE SENSOR
5. POWERTRAIN CONTROL MODULE

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: If the transmission is slipping in any forward gear and all the pressure switches are not indicating pressure, a loss of prime test is run.

1. Set Condition: If the transmission begins to slip in a forward gear and all the pressure switch(s) that should be closed are open a loss of prime test begins. Available elements are turned on by the PCM to see if pump prime exists. The DTC sets if no pressure switch(s) respond.

Possible Causes

1. INVALID PRNDL CODE
2. INPROPER FLUID LEVEL
3. TRANSMISSION OIL FILTER
4. TRANSMISSION OIL PUMP

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: In any forward gear with engine speed above 1000 RPM shortly after a shift and every minute thereafter.

1. Set Condition: After a shift into a forward gear, with engine speed above 1000 RPM, the PCM momentarily turns on element pressure to the Clutch circuits that don't have pressure to identify the correct Pressure Switch closes. If the Pressure Switch does not close 2 times, the DTC sets.

Possible Causes

1. LINE PRESSURE SENSOR
2. TRANSMISSION FLUID CONTAMINATION
3. RELATED DTC'S PRESENT
4. TRANSMISSION SOLENOID/TRS ASSEMBLY
5. EXCESSIVE DEBRIS IN OIL PAN
6. POOR LINE PRESSURE SENSOR CONNECTION
7. TRANSMISSION CONTROL RELAY DTCS PRESENT
8. (T48) 4C PRESSURE SWITCH SENSE CIRCUIT OPEN
9. (F856) 5-VOLT SUPPLY CIRCUIT OPEN
10. (T48) 4C PRESSURE SWITCH SENSE CIRCUIT SHORT TO GROUND
11. (F856) 5-VOLT SUPPLY CIRCUIT SHORT TO GROUND
12. (T48) 4C PRESSURE SWITCH SENSE CIRCUIT SHORT TO OTHERS
13. TRANSMISSION SOLENOID/TRS ASSEMBLY
14. INTERNAL TRANSMISSION
15. POWERTRAIN CONTROL MODULE

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: Continuously with the ignition on, engine running, with the transmission in gear.

1. Set Condition: The DTC is set if the 4C Pressure Switch reads open or closed at the wrong time in a given gear.

Possible Causes

1. RELATED RELAY DTC'S PRESENT
2. DTC P0871 ALSO PRESENT
3. LOSS OF 12-VOLT FEED
4. (T48) 4C PRESSURE SWITCH SENSE CIRCUIT OPEN
5. (T48) 4C PRESSURE SWITCH SENSE CIRCUIT SHORT TO GROUND
6. EXCESSIVE FLUID LEAKAGE WITH 2C CLUTCH CIRCUIT
7. #5 AND/OR #7 CHECK BALL CUT OR DAMAGED
8. LOW LINE PRESSURE
9. TRANSMISSION SOLENOID/TRS ASSEMBLY
10. POWERTRAIN CONTROL MODULE
11. WIRING AND CONNECTORS

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: Whenever the ignition is in the Run/Start position.

1. Set Condition: This DTC will set whenever Powertrain Control Module is disconnected from Fused B+ or ground. It will also be set during the DRBIII® Battery Disconnect and/or Quick Learn procedure.

Possible Causes

1. BATTERY WAS DISCONNECTED
2. SCAN TOOL BATTERY DISCONNECT PERFORMED
3. PCM WAS REPLACED OR DISCONNECTED
4. QUICK LEARN WAS PERFORMED

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: Whenever the PRNDL code indicates Temp3.

1. Set Condition: This DTC sets when conditions for the DTC P1776 are satisfied or 3 unsuccessful attempts to engage 1st gear while the shifter is in the temp3 zone. This indicates a restricted port at the manual valve because the shifter is not fully engaged in the drive position.

Possible Causes

1. RELATED TRANSMISSION DTC'S PRESENT
2. CUSTOMER DRIVING HABITS
3. MISADJUSTED SHIFTER

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

Scheme 668

Scheme 669

1. DETERMINING IF RELATED DTC'S ARE PRESENT With the scan tool, check for other transmission DTC's Are any of the following DTC's P0731, P0732, P0733, P0734, P1736 or P0715 present? Yes : Refer to the Transmission category and perform the appropriate Symptom. Perform «45RFE/545RFE TRANSMISSION VERIFICATION TEST - VER 1»(ref-212828-S08485914552005122700000) . No : Go To 2
2. CHECK SHIFTER ADJUSTMENT Check Shifter adjustment. Is the shifter properly adjusted? Yes : Go To 3 No : Adjust the Shifter Assembly. Perform «45RFE/545RFE TRANSMISSION VERIFICATION TEST - VER 1»(ref-212828-S08485914552005122700000) .
3. CHECK CUSTOMER DRIVING HABIT This DTC can be set if the customer rests their hand on the shift lever while they are driving. The transmission can be put in the T3 position if just enough forward pressure is exerted on the shift lever. When this occurs, the feed port to the clutch is restricted, the transmission will declare neutral, and this DTC will be set. The customer should be informed not to rest their hand on the shifter while driving. This DTC can also be set by simply bumping the shift lever toward neutral while accelerating. With the scan tool, check the EATX DTC EVENT DATA to help identify the conditions in which the DTC was set. If there are no possible causes remaining, view repair. Repair This DTC can be set by putting too much forward pressure on the shift lever while it is in the OD position. Make sure the customer is informed. Perform «45RFE/545RFE TRANSMISSION VERIFICATION TEST - VER 1»(ref-212828-S08485914552005122700000) .

1. When Monitored: Continuously with the ignition on, engine running, with the transmission in gear.

1. Set Condition: If the ratio of the Input RPM to the Output RPM does not match the current gear ratio. This DTC can take up to five minutes of problem identification before illuminating the MIL

Possible Causes

1. RELATED DTCS PRESENT
2. INPUT SPEED SENSOR OR WIRING
3. LOW FLUID LEVEL
4. CRACKEC OR MISINSTALLED PRIMARY OIL FILTER OR SEAL
5. WORN SOLENOID SWITCH VALVE OR PLUGS
6. STUCK OR STICKING MAIN REGULATOR VALVE
7. BURNED UD OR 4C CLUTCH
8. CUT 4C OR UD PISTON SEAL
9. BROKEN 4C PISTON CASTING
10. BROKEN OR MISSING 4C BLEED ORIFICE
11. BROKEN OR MISSING UD BLEED ORIFICE
12. CUT 4C OR UD ACCUMULATOR PISTON SEAL
13. CRACKED 4C OR UD ACCUMULATOR PISTON
14. EXTRA CHECK BALL IN PASSAGE DOWNSTREAM OF #7 CHECK BALL POCKET
15. TRANSMISSION SOLENOID/TRS ASSEMBLY
16. BROKEN WELD - REACTION CARRIER TO REVERSE SUN GEAR
17. MISSING TEETH ON INPUT CLUTCH HUB TONE WHEEL

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: During an attempted shift into 1st gear.

1. Set Condition: This DTC is set if three unsuccessful attempts are made to shift into 1st gear in one given key start. This DTC can take up to five minutes to mature before illuminating the MIL.

Possible Causes

1. RELATED DTC P0841 PRESENT
2. SOLENOID SWITCH VALVE STICKING
3. LR PRESSURE SWITCH SENSE CIRCUIT SHORT TO OTHER CIRCUITS
4. TRANSMISSION SOLENOID/TRS ASSEMBLY
5. POWERTRAIN CONTROL MODULE

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: Continuously when performing partial or full EMCC - PEMCC or FEMCC.

1. Set Condition: If the transmission senses the L/R pressure switch closing while performing PEMCC or FEMCC. This DTC will set after two unsuccessful attempts to perform PEMCC or FEMCC. This DTC can take up to five minutes of problem identification before illuminating the MIL.

Possible Causes

1. RELATED DTC P0841 PRESENT
2. LR PRESSURE SWITCH SENSE CIRCUIT OPEN
3. LR PRESSURE SWITCH SENSE CIRCUIT SHORT TO GROUND
4. SOLENOID SWITCH VALVE
5. POWERTRAIN CONTROL MODULE
6. INTERMITTENT WIRING AND CONNECTORS

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: After a speed ratio error is stored.

1. Set Condition: This DTC is set if the associated speed ratio DTC is stored within 1.3 seconds after a shift.

Possible Causes

1. FAULT AFTER SHIFT

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: The gear ratio is monitored continuously while the Transmission is in gear.

1. Set Condition: After a controller reset in neutral and a ratio of input to output, of 1 to 2. This DTC can take up to five minutes of problem identification before illuminating the MIL.

Possible Causes

1. (T13) SPEED SENSOR GROUND CIRCUIT OPEN
2. (T13) SPEED SENSOR GROUND CIRCUIT SHORT TO GROUND
3. (T13) SPEED SENSOR GROUND CIRCUIT SHORT TO VOLTAGE
4. POWERTRAIN CONTROL MODULE

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: Whenever the engine is running. The LR volume is updated during a 3-1 or 2-1 manual downshift with throttle angle below 5 degrees. Trans temp must be at least 43 C (110 F)

1. Set Condition: When the LR volume falls below 16.

Possible Causes

1. L/R CLUTCH CIRCUIT LEAKS IN THE VALVE BODY
2. AIR CHECK L/R CLUTCH CIRCUIT
3. INTERNAL TRANSMISSION
4. POWERTRAIN CONTROL MODULE

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: Whenever the engine is running. The 2C CVI is updated during a 3-2 kickdown with throttle angle between 10 and 54 degrees. Transmission temperature must be at least 43° C or 110° F.

1. Set Condition: When the 2C CVI falls below 5.

Possible Causes

1. 2C CLUTCH CIRCUIT LEAKS IN THE VALVE BODY
2. AIR CHECK 2C CLUTCH CIRCUIT
3. INTERNAL TRANSMISSION
4. POWERTRAIN CONTROL MODULE

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: Whenever the engine is running. The OD volume is updated during a 2-3 upshift with throttle angle between 10 and 54 degrees. Trans temp must be at least 43° C (110° F)

1. Set Condition: When the OD volume falls below 5.

Possible Causes

1. OD HYDRAULIC CLUTCH CIRCUIT LEAKS IN THE VALVE BODY
2. BROKEN OD ACCUMULATOR SPRING
3. INTERNAL LEAKAGE IN PUMP ASSEMBLY
4. TRANSMISSION SOLENOID/TRS ASSEMBLY
5. POWERTRAIN CONTROL MODULE

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: Whenever the engine is running. The UD CVI is updated during a 4-3 kickdown with throttle angle between 10 and 54 degrees. Transmission temperature must be at least 43 C (110 F)

1. Set Condition: When the UD CVI falls below 11.

Possible Causes

1. BROKEN UD ACCUMULATOR SPRING(S)
2. INTERNAL LEAKAGE IN PUMP ASSEMBLY
3. TRANSMISSION SOLENOID/TRS ASSEMBLY
4. POWERTRAIN CONTROL MODULE

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: Whenever the engine is running. The 4C volume is updated during a 3-4 upshift with throttle angle between 10 and 54 degrees. Trans temp must be at least 43° C (110° F)

1. Set Condition: When the 4C volume falls below 5.

Possible Causes

1. BROKEN 4C RETURN SPRING OR DISLODGED SNAP RING
2. 4C HYDRAULIC CLUTCH CIRCUIT LEAK IN THE VALVE BODY
3. TRANSMISSION SOLENOID/TRS ASSEMBLY
4. POWERTRAIN CONTROL MODULE

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: Initially at power-up, then every 10 seconds thereafter. The solenoid circuits will also be tested immediately after a gear ratio or pressure switch error is detected.

1. Set Condition: After three consecutive solenoid continuity test failures, or one failure if test is run in response to a gear ratio or pressure switch error

Possible Causes

1. RELATED RELAY DTC'S PRESENT
2. (T118) MS SOLENOID CONTROL CIRCUIT SHORT TO OTHER CIRCUITS
3. (T118) MS SOLENOID CONTROL CIRCUIT OPEN
4. (T118) MS SOLENOID CONTROL CIRCUIT SHORT TO GROUND
5. TRANSMISSION SOLENOID/TRS ASSEMBLY
6. POWERTRAIN CONTROL MODULE

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. (Refer to - SCHEMATICS AND DIAGRAMS ).

1. When Monitored: Every 7 msec. Conditions: 1) Engine speed greater than 500 RPM. 2) Battery voltage greater than 10v but less than 16v.

1. Set Condition: CAN C bus messages not received for 10 seconds.

1. When Monitored: Every 7 msec, with the ignition on.

1. Set Condition: ECM/PCM CAN bus message not received by the Transmission Control System for the period of 10 seconds.

1. When Monitored: Every 7 msec. Conditions: 1) Engine speed greater than 500 RPM. 2) Battery voltage greater than 10v but less than 16v.

1. Set Condition: CAN C bus messages not received for 10 seconds.

1. When Monitored: Every 7 msec. Conditions: 1) Engine speed greater than 500 RPM. 2) Battery voltage greater than 10v but less than 16v.

1. Set Condition: CAN C bus messages not received for 10 seconds.
