TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Mounting Bolts |
| Dakota 2.5L | 40 (55) |
| Dakota & Durango 4.7L |
| Short Horizontal Bolt | 55 (74) |
| All Other Bolts | 40 (55) |
| Diesel | 40 (55) |
| All Others | 30 (41) |
| INCH Lbs. (N.m) |
| Field Terminal Nuts | 25 (3) |
| Ground & B+ Terminal Nuts | 75 (8) |
Charging System Wiring Diagram (Dakota). Scheme 1
Scheme 1: Charging System Wiring Diagram (Dakota)
Charging System Wiring Diagram (Durango). Scheme 2
Scheme 2: Charging System Wiring Diagram (Durango)
Charging System Wiring Diagram (Ram Pickup). Scheme 3
Scheme 3: Charging System Wiring Diagram (Ram Pickup)
Charging System Wiring Diagram (Ram Van & Ram Wagon). Scheme 4
Scheme 4: Charging System Wiring Diagram (Ram Van & Ram Wagon)
