Lamps/lighting - Interior - Service Information: Specifications Dodge Dart PF

Interior/illumination Lights 2 illustrations ~108 words

SPECIFICATIONS

LAMPBULB
CENTER CONSOLE FRONT CUBBY BIN LAMPLIGHT EMITTING DIODES (LED) SERVICED IN ASSEMBLY
CENTER CONSOLE REAR STORAGE BIN LAMPLIGHT EMITTING DIODES (LED) SERVICED IN ASSEMBLY
GLOVE BOX LAMPLIGHT EMITTING DIODES (LED) SERVICED IN ASSEMBLY
READING LAMP578/W5W
SHIFT INDICATOR LAMPIKLE14140
TRUNK LAMP579
VANITY LAMPA6220

BULB APPLICATION TABLE

Scheme 1

Scheme 1: REMOVAL
Scheme 1: REMOVAL

Scheme 2

Scheme 2
Scheme 2
  1. Disconnect and isolate the negative battery cable.
  2. Open the sunglass storage bin.
  3. Remove the two fasteners (2) from the overhead console (1).
  4. Place a trim stick or equivalent, between the headliner and the overhead console (1) front center.
  5. Pry gently until the retaining clips are released.
  6. If only replacing bulb, turn socket (3) clockwise to remove bulb with connector from the reading lamp assembly. Replace bulb and proceed to installation topic. Refer to «LAMP, READING, INSTALLATION»(ref-646265-S31971098952014072800000) .
  7. Disconnect the overhead console (1) wiring connector (2).
  8. Remove the overhead console (1) from the vehicle.
