Wiring diagram: Computer data lines — Computer data lines circuit Dodge Dakota III facelift

Components on these wiring diagrams 20

Click a component to highlight it on every diagram it appears on.

• 13 2 Can B Bus Can B Bus
• 14 13 Can B Bus Can B Bus
• 15 23 Can C Bus Can C Bus
• 16 15 Can B Bus Can B Bus
• 3 4 Can B Bus Can B Bus
• 6 17 Can B Bus Can B Bus
• A/C Heater Control
• Anti-Lock Brakes Module
• Can B Bus
• Can C Bus
• Cluster
• Data Link Connector
• Electronic Overhead Module
• Front Control Module
• Inside Rearview Mirror
• Integrated Power Module
• Occupant Restraint Controller Module
• Powertrain Control Module
• Radio Amplifier
• Wireless Control Module
