OPERATION
The automatic transmission fluid is selected based upon several qualities. The fluid must provide a high level of protection for the internal components by providing a lubricating film between adjacent metal components. The fluid must also be thermally stable so that it can maintain a consistent viscosity through a large temperature range. If the viscosity stays constant through the temperature range of operation, transmission operation and shift feel will remain consistent. Transmission fluid must also be a good conductor of heat. The fluid must absorb heat from the internal transmission components and transfer that heat to the transmission case.
DESCRIPTION
The fluid check/fill points and lubrication locations are located in each applicable Service Informations.
Scheme 1
| Cavity | Cartridge Fuse | Mini-Fuse | Description |
|---|---|---|---|
| 1 | Spare | ||
| 2 | Spare | ||
| 3 | 30 Amp Pink | Electric Brake | |
| 4 | 50 Amp Red | Power Seat | |
| 5 | Spare | ||
| 6 | 20 Amp Yellow | Ignition Off Draw (IOD) Cabin Compartment Node (CCN), Radio | |
| 7 | 10 Amp Red | Powertrain Control Module (PCM)/Fuel/RAD/AC Coils | |
| 8 | 10 Amp Red | Cabin Compartment Node (CCN)/Mirror/4x4 | |
| 9 | Spare | ||
| 10 | 2 Amp Gray | Low Current Ignition Switch | |
| 11 | 10 Amp Red | AC Clutch | |
| 12 | 15 Amp Blue | T Tow Lt Stop/Turn | |
| 13 | 15 Amp Blue | Trailer Tow Rt Stop/Turn | |
| 14 | 20 Amp Yellow | Ignition Off Draw (IOD) #2 | |
| 15 | 25 Amp Natural | Trans/Powertrain Control Module (PCM) | |
| 16 | 20 Amp Yellow | Horn | |
| 17 | 20 Amp Yellow | ABS Feed (Valves) | |
| 18 | 20 Amp Yellow | Fuel Pump | |
| 19 | 15 Amp Blue | Center High-Mounted Stop Light (CHMSL) | |
| 20 | 20 Amp Yellow | Cabin Compartment Node (CCN) Door Locks/Brake Transmission Shift Interlock (BTSI) | |
| 21 | 25 Amp Natural | Audio Amp | |
| 22 | 20 Amp Yellow | Power Outlet (Switchable) | |
| 23 | 20 Amp Yellow | Fog Lamps | |
| 24 | 20 Amp Yellow | Powertrain Control Module (PCM) B+ | |
| 25 | 15 Amp Blue | Cabin Compartment Node (CCN) Illumination | |
| 26 | 20 AmpYellow | Ignition Run/Start Feed | |
| 27 | 10 Amp Red | Power Mirror | |
| 28 | 20 AmpYellow | Power Outlet | |
| 29 | 20 Amp Yellow | Front Control Module (FCM) 4 (Wipers) | |
| 30 | Spare | ||
| 31 | 30 Amp Green | Ignition Accessory Feed | |
| 32 | 30 Amp Pink | Front Control Module (FCM)1 (Ext. Lights # 1) | |
| 33 | 30 Amp Pink | Auto Shut Down (ASD) | |
| 34 | 30 Amp Pink | Front Control Module (FCM)2 (Ext. Light # 2) | |
| 35 | 40 Amp Green | HVAC Blower Motor | |
| 36 | Spare | ||
| 37 | Spare | ||
| 38 | 20 Amp Blue | Spare | |
| 39 | 30 Amp Pink | Starter Solenoid | |
| 40 | 40 Amp Green | Ignition Run Feeds | |
| 41 | 30 Amp Pink | Wiper Motor | |
| 42 | 25 Amp Natural | Front Control Module (FCM) 5 (T-Case) | |
| 43 | 10 Amp Red | Lt Park Lamps | |
| 44 | 10 Amp Red | Rt Park Lamps | |
| 45 | 20 Amp Yellow | Trailer Tow Park Lamps | |
| 46 | 10 Amp Red | Airbag System # 2 | |
| 47 | Spare | ||
| 48 | 20 Amp Blue | Sunroof/Sound Box | |
| 49 | 30 Amp Pink | Trailer Tow B+ | |
| 50 | 40 Amp Green | Anti-Lock Brake System (ABS) Module (Pump) | |
| 51 | 40 Amp Green | Park Lamps | |
| 52 | Spare | ||
| 53 | 40 Amp Green | Rear Defogger | |
| 54 | Spare | ||
| 55 | Spare | ||
| 56 | 10 Amp Red | Heated Seats | |
| 57 | 20 Amp Yellow | Airbag System # 2 | |
| 58 | 20 Amp Yellow | Heated Seats | |
| 59 | 10 Amp Red | HVAC Module | |
| 60 | 10 Amp Red | ABS Module | |
| 61 | 20 Amp Yellow | Front Control Module (FCM) 3 (Reverse Lamps) | |
| 62 | Relay | AC Clutch Relay | |
| 63 | Relay | Transmission Relay | |
| 64 | Relay | Fuel Pump Relay | |
| 65 | Relay | Ignition Run/Start Relay | |
| 66 | Relay | ASD Relay | |
| 67 | Relay | HVAC Relay | |
| 68 | Relay | Trailer Tow LT Stop/Turn Relay | |
| 69 | Relay | Horn Relay | |
| 70 | Relay | Park Lamp Relay | |
| 71 | Relay | Fog Lamp relay | |
| 72 | Relay | Trailer Tow RT Stop/Turn Relay | |
| 73 | Relay | Rear Defogger Relay | |
| 74 | Relay | Starter Relay | |
| 75 | Relay | Ignition Run/ACC/ Window Relay | |
| 76 | Relay | Ignition Run Only Relay | |
| 77 | Relay | Intermittent Wiper Relay | |
| 78 | Relay | Wiper Hi/Low Relay |
