TORQUE
| DESCRIPTION | N.m | Ft. Lbs. | In. Lbs. |
|---|
| Automatic Belt Tensioner to Block Bolts | 41 | 30 | |
| Automatic Belt Tensioner Pulley Bolt | 61 | 45 | |
| Block Heater Bolt | 2 | | 18 |
| Generator/Compressor Mounting Bracket Bolts | 10 | 7 | 89 |
| Fan Shroud Mounting Bolts | 10 | 7 | 89 |
| Fan Blade to Fan Drive Bolts | 27 | 20 | |
| Fan Drive - All | 57 | 42 | |
| Idler Pulley Bolt | 54 | 40 | |
| Radiator to Support Bolts | 11 | 8 | 97 |
| Thermostat Housing Bolts - 3.7L | 23 | 17 | |
| Thermostat Housing Bolts - 4.7L | 13 | 10 | 115 |
| Transmission Auxiliary Oil Cooler Bolts | 10 | 7 | 89 |
| Upper Radiator Closure Panel Bolts | 10 | 7 | 89 |
| Water Pump Bolts (Except 4.7L (1) ) | 24 | 18 | |
| (1) For appropriate bolt tightening specification, refer to FASTENER IDENTIFICATION. |
| (1) | For appropriate bolt tightening specification, refer to FASTENER IDENTIFICATION. |
SPECIFICATIONS
| DESCRIPTION | SPECIFICATION |
|---|
| Metric | Standard |
| 3.7L | 15.4L | 16.2 qts. - to the middle of the cold fill range |
| 4.7L | 15.4L | 16.2 qts. |
Scheme 1
Scheme 2
