TRANSFER CASE SKID PLATE "RIV-NUT" REPAIR
- Remove the old riv nut by grinding the head off.
- Remove the damaged nut from the frame using a magnet or equivalent.
- Using a long full threaded bolt and thread a nut to the near of the head of the bolt.
- Put a larger nut onto the bolt so that it is free spinning on the bolt with the bearing side away from the head of the bolt.
- Thread the riv nut onto the end of the bolt.
- Insert the riv nut and bolt into the hole in the frame.
- Hold the larger nut with a wrench and torque the nut against the larger nut to collapse the riv nut.
INTERNATIONAL CONTROL AND DISPLAY SYMBOLS
Chrysler LLC uses international symbols to identify various systems on the vehicle.
The graphic symbols illustrated are used to identify various instrument controls, vehicle controls and service information references. The symbols correspond to the controls and displays that are located on the instrument panel and throughout the vehicle.
Scheme 5
| SYMBOL | DESCRIPTION | SYMBOL | DESCRIPTION |
|---|---|---|---|
| 1 | 115-Volt Power Inverter | 11 | Side Airbag |
| 2 | USB Connector | 12 | Seat Belt |
| 3 | Lighter | 13 | Airbag |
| 4 | Fuel Fill Side | 14 | Supplemental Restraint System |
| 5 | Spare Tire Winch | 15 | Power Steering Fluid |
| 6 | Fuse | 16 | See Owner's Manual |
| 7 | Key Activate (Power Outlet) | 17 | See Appropriate Service Information |
| 8 | Warning | 18 | Emergency Release Handle |
| 9 | Child Seat Tether Anchor | 19 | Jack/Jack Tools Location |
| 10 | Lower Anchors and Tether for Children (latch) |
INTERNATIONAL INFORMATION SYMBOL IDENTIFICATION
Scheme 6
| SYMBOL | DESCRIPTION | SYMBOL | DESCRIPTION |
|---|---|---|---|
| 1 | Electronic Speed Control | 23 | Transmission Oil Temperature Light |
| 2 | Hill Descent Control | 24 | Diesel Exhaust Brake |
| 3 | Traction Control | 25 | High Beam |
| 4 | Electronic Stability Program/Brake System Assist System | 26 | Front Fog Light |
| 5 | Security Indicator | 27 | Rear Fog Light |
| 6 | Turn Signals | 28 | Cargo Lamp |
| 7 | Water In Fuel | 29 | Exterior Bulb Failure |
| 8 | Low Fuel | 30 | Door Ajar |
| 9 | Side Airbag | 31 | Liftgate Open |
| 10 | Seat Belt Reminder | 32 | Brake System Warning Parking Brake |
| 11 | Airbag Warning Light | 33 | All Wheel Drive |
| 12 | Passenger Airbag Off | 34 | Four Wheel Drive |
| 13 | Failure Of Anti-Lock Braking System | 35 | Four Wheel Drive Low |
| 14 | HEV Brake Regenerative Light | 36 | Tow/Haul |
| 15 | Electronic Throttle Control | 37 | Service Four Wheel Drive |
| 16 | HEV Service Light | 38 | Service Four Wheel Drive |
| 17 | Engine Oil | 39 | Cruise Indicator |
| 18 | Battery Charging | 40 | Brake System Warning Parking Brake |
| 19 | Glow Plug/Intake Air Heated | 41 | Tire Pressure Monitor |
| 20 | Power Steering Fluid | 42 | Sway Bar Disconnect Indicator |
| 21 | Engine Coolant Temperature | 43 | Front Axle Lock |
| 22 | Malfunction Indicator Light | 44 | Rear Axle Lock |
INTERNATIONAL INDICATOR SYMBOL IDENTIFICATION
Scheme 7
| SYMBOL | DESCRIPTION | SYMBOL | DESCRIPTION | SYMBOL | DESCRIPTION |
|---|---|---|---|---|---|
| 1 | Rear Window Wiper | 26 | Passenger Air Bag Off | 51 | Door Ajar |
| 2 | Rear Window Intermittent Wiper | 27 | Electronic Speed Control | 52 | Liftgate Release |
| 3 | Rear Window Washer | 28 | Cruise Indicator | 53 | Sliding Door |
| 4 | Rear Window Defrost | 29 | Hill Descent Control | 54 | Sliding Door |
| 5 | Heated Mirror | 30 | Park Assist Off | 55 | Convertible Top Down |
| 6 | Turn Signals | 31 | Electronic Stability Program/Brake System Assist System | 56 | Convertible Top Up |
| 7 | Adjustable Pedals | 32 | Park Brake Release | 57 | Door Lock |
| 8 | Horn | 33 | Adjustable Headlights | 58 | Window Lift |
| 9 | Windshield Wiper Intermittent | 34 | Low Beam | 59 | Convertible 4 Window Down |
| 10 | Windshield Washer | 35 | Front Fog Light | 60 | Window Lock |
| 11 | Windshield Washer Fluid Level | 36 | Rear Fog Light | 61 | Power Rear Window |
| 12 | Windshield Electrically Heated | 37 | Cargo Lamp | 62 | Voice Recognition Button |
| 13 | Windshield Defrost | 38 | Hazard Lights | 63 | Uconnect™ Button |
| 14 | Windshield Wiper And Washer | 39 | 115-Volt Power Inverter | 64 | SwayBar Disconnect |
| 15 | Ventilating Fan | 40 | Key Activate (Power Outlet) | 65 | All Wheel Drive |
| 16 | Air Conditioning | 41 | Exterior Bulb Failure | 66 | Four Wheel Drive |
| 17 | Upper Air Outlet | 42 | Master Lighting Switch | 67 | Two Wheel Drive |
| 18 | Upper And Lower Air Outlet | 43 | Dome Light | 68 | Four Wheel Drive Low |
| 19 | Lower Air Outlet | 44 | Park Lights | 69 | Four Wheel Drive Lock |
| 20 | Defrost And Lower Air Outlet | 45 | Instrument Panel Illumination | 70 | Four Wheel Drive Auto |
| 21 | Heated Seat Low | 46 | Electronic Stability Program Off | 71 | Front Axle Lock |
| 22 | Heated Seat High | 47 | Diesel Exhaust Brake | 72 | Rear Axle Lock |
| 23 | Ventilated Seat | 48 | Overdrive Off | 73 | EVIC Menu |
| 24 | Recirculation | 49 | Hood Release | 74 | Navigation Button |
| 25 | Heated Steering Wheel | 50 | Trunk/Deck Release | 75 | Step |
| 76 | Reset | 77 | Axle Lock Button | 78 | Traction Control Off |
INTERNATIONAL CONTROL SYMBOL IDENTIFICATION
Scheme 8
The graphic symbols illustrated are used to identify engine compartment lubricant and fluid inspection and fill locations. The symbols correspond to the caps located within the engine compartment.
Scheme 9
| 1 - VEHICLE EMISSION CONTROL INFORMATION (VECI) LABEL |
All vehicles are equipped with a combined VECI label. This label is located in the engine compartment.
The VECI label contains the following
- Engine family and displacement
- Evaporative family
- Certification application
- Engine timing specifications (if adjustable)
- Idle speeds (if adjustable)
- Spark plug and gap
Scheme 10
The metric system is based on quantities of one, ten, one hundred, one thousand and one million.
The following chart will assist in converting metric units to equivalent English and SAE units, or vise versa.
Refer to the COMMON METRIC EQUIVALENTS table to convert torque values listed in metric Newton- meters (N.m). Also, use the CONVERSION FORMULAS AND EQUIVALENT VALUES table to convert between millimeters (mm) and inches (in.).
| MULTIPLY | BY | TO GET | MULTIPLY | BY | TO GET |
|---|---|---|---|---|---|
| In-lbs | X 0.11298 | = Newton Meters (N.m) | N.m | X 8.851 | = in-lbs |
| Ft-lbs | X 1.3558 | = Newton Meters (N.m) | N.m | X 0.7376 | = ft-lbs |
| Inches Hg (60° F) | X 3.377 | = Kilopascals (kPa) | KPa | X 0.2961 | = Inches Hg |
| Psi | X 6.895 | = Kilopascals (kPa) | KPa | X 0.145 | = psi |
| Inches | X 25.4 | = Millimeters (mm) | Mm | X 0.03937 | = Inches |
| Feet | X 0.3048 | = Meters (M) | M | X 3.281 | = Feet |
| Yards | X 0.9144 | = Meters | M | X 1.0936 | = Yards |
| Mph | X 1.6093 | = Kilometers/Hr. (Km/h) | Km/h | X 0.6214 | = mph |
| Feet/Sec | X 0.3048 | = Meters/Sec (M/S) | M/S | X 3.281 | = Feet/Sec |
| Mph | X 0.4470 | = Meters/Sec (M/S) | M/S | X 2.237 | = mph |
| Kilometers/Hr. (Km/h) | X 0.27778 | = Meters/Sec (M/S) | M/S | X 3.600 | Kilometers/Hr. (Km/h) |
CONVERSION FORMULAS AND EQUIVALENT VALUES
| Inch to Millimeters | Cubic Inch to Cubic Centimeters |
|---|---|
| 1 inch = 25 Millimeters | 1 Cubic Inch = 16 Cubic Centimeters |
| 1 Foot = 0.3 Meter | 1 Cubic Foot = 0.03 Cubic Meter |
| 1 Yard = 0.9 Meter | 1 Cubic Yard = 0.8 Cubic Meter |
| 1 Mile = 1.6 Kilometers |
COMMON METRIC EQUIVALENTS
THREADED HOLE REPAIR
Most stripped threaded holes can be repaired using a Helicoil®. Follow the vehicle or Helicoil® recommendations for application and repair procedures.
