TORQUE
| DESCRIPTION | N.m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| Tilt Lever Release Knob Bracket Mounting Screws | 4.5 | 40 | |
| Ignition Switch Mounting Screws | 3 | 26 | |
| Gear Shift Lever Assembly Mounting Screws | 12 | 105 | |
| Steering Column Mounting Nuts | 28 | 250 | |
| Steering Wheel Bolt | 61 | 45 | |
| Steering Coupler Shaft Upper Pinch Bolt To Column | 57 | 42 | |
| Steering Coupler Shaft Lower Pinch Bolt To Gear | 57 | 42 | |
| Steering Coupler Shaft Midpoint Pinch Bolt | 57 | 42 | |
| Toe Plate Nuts | 12 | 105 |
TORQUE
Scheme 1
- Disconnect the negative battery cable.
- Lock the steering wheel with the tire in the straight position.
- Remove and discard the upper pinch bolt (2) from the upper coupling at the column (1).
- Lower the steering coupler shaft (3) from the column (1).
- Remove the toe plate (5) nuts (6).
- Remove and discard the lower coupler pinch bolt (4) from the lower steering coupling shaft (3).
- Remove the steering coupling shaft (3) from the vehicle.
| DESCRIPTION | N.m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| Rack and Pinion Steering Gear Gear to Frame Bolts | 258 | 190 | |
| Steering Gear Intermediate Shaft Bolt To Column | 57 | 42 | |
| Steering Coupler Shaft Lower Pinch Bolt To Gear | 57 | 42 | |
| Tie Rod End Knuckle Nut | 108 | 80 | |
| Tie Rod End Jam Nut | 75 | 55 | |
| Power Steering Line Pressure Line | 31 | 23 | |
| Power Steering Line Return Line | 37 | 27 |
TORQUE
Scheme 2
Scheme 3
Scheme 4
| DESCRIPTION | N.m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| Power Steering Pump Pump Mounting Bolts | 28 | 21 | |
| Power Steering Pressure Line to Pump | 31 | 23 | |
| Power Steering Pressure line to Gear | 31 | 23 | |
| Power Steering Return line to Gear | 37 | 27 |
TORQUE
Scheme 5
Scheme 6
- Siphon the power steering system.
- Raise and support the vehicle.
- Disconnect the hose clamps (2).
- Disconnect the hoses (1) at the cooler.
- Remove the cooler mounting bolts (1).
- Remove the cooler (2).
