Ignition Control - Service Information: Removal & Installation Dodge Dakota III рестайлинг

REMOVAL

The ASD relay is located in the engine compartment within the Integrated Power Module (IPM). Refer to label on IPM cover for relay location.

1. Remove IPM cover.
2. Remove relay from IPM.
3. Check condition of relay terminals and IPM connector terminals for damage or corrosion. Repair if necessary before installing relay.
4. Check for pin height (pin height should be the same for all terminals within the IPM connector). Repair if necessary before installing relay.

INSTALLATION

The ASD relay is located in the Integrated Power Module (IPM). Refer to label on IPM cover for relay location.

1. Install relay to IPM.
2. Install cover to IPM.

Note. The ignition key must be in the key cylinder for cylinder removal. The key cylinder must be removed first before installing ignition switch.

Scheme 5

Scheme 6

Scheme 7

Scheme 8

1. Before installing ignition switch, rotate the slot in the switch to the ON position.
2. Connect the electrical connector to rear of the ignition switch. Make sure that locking tabs are fully seated into wiring connector.
3. Position switch (1) to column and install the mounting screws (2). Tighten screw to 3 N.m (26 in. lbs.). 1 - IGNITION SWITCH 2 - TILT LEVER MECHANISM
4. Install the tilt lever bracket (2) mounting screws. Tighten screws to 4.5 N.m (40 in. lbs.). 1 - Ignition Switch Mounting Screws 2 - Non-Tilt Mounting Bracket Screws
5. If the column is non-tilt install the bracket. Tighten screws (2) to 4.5 N.m (40 in. lbs.). 1 - KEY CYLINDER 2 - GEAR SHIFT LEVER 3 - MOUNTING HOLES 4 - STEERING COLUMN 5 - IGNITION SWITCH
6. Position the wire retainer into the tilt lever bracket.
7. Reconnect the lower clockspring connectors.
8. Install the key cylinder (1)
9. Install steering column upper and lower shrouds.
10. Enable the airbag system. Refer to «Restraints/AIR BAG, Driver - Installation»(ref-352646-S26849056562010010600000) .
