Electronic Overhead Module (Eom) - Electrical Diagnostics: Other Dodge Dakota III рестайлинг

Monitor Conditions

1. When Monitored: With the ignition on.

Set Conditions

1. Set Condition: The Electronic Overhead Module (CMTC) detects an internal switch failure.

Possible Causes

1. When Monitored: With the ignition on.

1. Set Condition: The Electronic Overhead Module (CMTC) detects an internal switch failure.

1. When Monitored: With the ignition on.

1. Set Condition: The Electronic Overhead Module (CMTC) detects an internal switch failure.

1. When Monitored: With the ignition on.

1. Set Condition: The Electronic Overhead Module (CMTC) detects an internal failure.

1. When Monitored: With the ignition on.

1. Set Condition: The Electronic Overhead Module (CMTC) does not receive the configuration information from the Front Control Module.

1. When Monitored: With the ignition on.

1. Set Condition: The magnetic field around the vehicle is greater than 2.4 gauss.

1. When Monitored: Continuously.

1. Set Condition: Whenever the Can B Bus (+) or Can B Bus (-) circuit is open, shorted to voltage or shorted to ground, this code will set.

Scheme 408

Scheme 409

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTCs Cycle the ignition from on to off 3 times. Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display U0019-CAN B BUS? Yes Go to step 2 No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Front Control (FCM) - Standard Procedure»(ref-352654-S37713291802010010600000)
2. CHECK FRONT CONTROL MODULE DTCs With the scan tool, read Front Control Module DTCs. Does the scan tool display any CAN B BUS DTCs - ACTIVE? Yes Go to and perform the appropriate diagnostic procedure. Refer to «DTC-Based Diagnostics/MODULE, Front Control (FCM) - Diagnosis and Testing»(ref-352654-S29617915202010010600000) No Go to step 3
3. (D55) CAN B BUS (+) CIRCUIT OPEN Turn the ignition off. Disconnect the Electronic Overhead Module (CMTC) harness connector. Disconnect the Front Control Module C1 harness connector. Measure the resistance of the (D55) Can B Bus (+) circuit between the Front Control Module C1 harness connector and the Electronic Overhead Module (CMTC) harness connector. Is the resistance below 2.0 ohms? Yes Go to step 4 No Repair the (D55) Can B Bus (+) circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Front Control (FCM) - Standard Procedure»(ref-352654-S37713291802010010600000)
4. (D54) CAN B BUS (-) CIRCUIT OPEN Measure the resistance of the (D54) Can B Bus (-) circuit between the Front Control Module C1 harness connector and the Electronic Overhead Module (CMTC) harness connector. Is the resistance below 2.0 ohms? Yes Replace the Electronic Overhead Module. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Front Control (FCM) - Standard Procedure»(ref-352654-S37713291802010010600000) No Repair the (D54) Can B Bus (-) circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Front Control (FCM) - Standard Procedure»(ref-352654-S37713291802010010600000)

Scheme 410

1. When Monitored: Continuously when the ignition is on. Battery voltage between 10 and 16 volts. Ignition Off Draw (IOD) fuse installed. Front Control Module (FCM) is configured correctly.

1. Set Condition: Bus messages not received from the FCM for approximately two to five seconds.

1. When Monitored: Continuously when the ignition is on. Battery voltage between 10 and 16 volts. Ignition Off Draw (IOD) fuse installed. Front Control Module (FCM) is configured correctly.

1. Set Condition: Bus messages not received from the Cluster for approximately two to five seconds.
