TORQUE
| Description | N.m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| All Screws NOT Listed Below | 2 | 17 | |
| A/C Accumulator Bracket Nuts/Bolts | 6.8 | 60 | |
| A/C Compressor to Engine Bolt (#3) | 40 | 30 | |
| A/C Compressor to Engine Bolts (except #3) | 55 | 41 | |
| A/C Condenser to Radiator Bolts | 4.5 | 40 | |
| Compressor Shaft Bolt | 19 | 168 | |
| HVAC Housing to Engine Side of Dash Panel Nuts | 7 | 62 | |
| HVAC Housing to Passenger Side of Dash Panel Bolts | 3 | 26 | |
| Refrigerant Line to A/C Compressor Nut | 23 | 17 | |
| Refrigerant Line to A/C Condenser Nut | 23 | 17 | |
| Suction Line to A/C Accumulator Nut | 23 | 17 |
Scheme 1
Scheme 2
Scheme 3
Scheme 4
The blend door actuator (1) is a reversible, 12 volt direct current (DC), servo motor. The blend door actuator is located on the top of the HVAC housing. The blend door actuator is interchangeable with the actuators for the mode-air and recirculation-air doors. Each actuator is contained within an identical black molded plastic housing with an integral wire connector receptacle (2). Each actuator also has an identical output shaft with splines (3) that connects it to its respective door linkage and three integral mounting tabs (4) that allow the actuator to be secured to the HVAC housing. The blend door actuator does not require mechanical indexing to the blend-air doors, as it is electronically calibrated by the A/C-heater control.
The blend door actuator can be accessed for serviced by removing the instrument panel.
REFRIGERANT CHARGE CAPACITY
| Application | Capacity |
|---|---|
| All models | 0.567 kg (1.25 lbs.) |
REFRIGERANT CHARGE CAPACITY
Scheme 5
The fixed A/C orifice tube is installed in the A/C liquid line and provides a restriction in the liquid refrigerant line between the A/C condenser and the A/C evaporator. This restriction established the pressure differential between the high and low-pressure sides of the A/C system.
The A/C orifice tube includes a diffuser screen (1), O-ring seals (2) to seal it to the inner wall of the A/C liquid line, an inlet filter screen (3) and the fixed orifice (4).
