TORQUE CHART
| DESCRIPTION | N.m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| Shock Absorber Upper Nut | 102 | 75 | |
| Shock Absorber Lower Bolt | 81 | 60 | |
| Lower Suspension Arm Frame Nuts | 244 | 180 | |
| Lower Suspension Arm Ball Joint Nut | 75 | 55 | |
| Upper Suspension Arm Frame Nuts | 102 | 75 | |
| Upper Suspension Arm Ball Joint Nut | 75 | 55 | |
| Stabilizer Bar Frame Bolt | 61 | 45 | |
| Stabilizer Link to Lower Control Arm | 169 | 125 | |
| Stabilizer Link Stabilizer Bar Nut | 37 | 27 | |
| Hub/Bearing Bolts | 163 | 120 | |
| Tie Rod End to Knuckle Nut | 75 | 55 | |
| Tie Rod End Jam Nut | 75 | 55 |
TORQUE SPECIFICATIONS
Scheme 1
Scheme 2
Scheme 3
Scheme 4
Scheme 5
Scheme 6
Scheme 7
Scheme 8
Scheme 9
Scheme 10
Scheme 11
Scheme 12
| DESCRIPTION | N.m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| Shock Absorber Lower Nut | 102 | 75 | |
| Shock Absorber Upper Bolt | 102 | 75 | |
| Stabilizer Retainer to the Axle | 61 | 45 | |
| Stabilizer Link to Stabilizer Bar | 102 | 75 | |
| Stabilizer Link to Frame | 102 | 75 | |
| Jounce Bumper Bolts | 41 | 30 |
TORQUE SPECIFICATIONS
Scheme 13
- Raise and support the vehicle.
- Remove the bolts (2) securing the jounce bumper (1).
- Remove the jounce bumper (1).
