Speed Control: Removal & Installation Dodge Dakota III

REMOVAL

The speed control servo assembly (6) is attached to the right inner fender under the air cleaner filter housing.

Scheme 7

1. Disconnect negative battery cable at battery.
2. Remove air cleaner filter housing assembly.
3. Disconnect vacuum line (1) at servo.
4. Disconnect electrical connector (5) at servo.
5. Remove three servo mounting screws (3).
6. Disconnect servo cable at throttle body. Refer to «CABLE-SPEED CONTROL»(ref-247660-S28649061702007020100000) . Note: The servo and mounting bracket displayed is a typical unit.
7. Remove 2 mounting nuts (1) holding servo cable sleeve (4) to bracket.
8. Pull speed control cable sleeve and servo away from servo mounting bracket to expose cable retaining clip (3) and remove clip. Note: The servo mounting bracket displayed is a typical bracket and may/may not be applicable to this model vehicle.
9. Remove servo (2) from mounting bracket. While removing, note orientation of servo to bracket.

INSTALLATION

1. Position servo (2) to mounting bracket.
2. Align hole in cable connector with hole in servo pin. Install cable-to-servo retaining clip (3).
3. Insert servo mounting studs through holes in servo mounting bracket.
4. Install two servo-to-mounting bracket nuts (1) and tighten. Refer to torque specifications.
5. Position servo assembly (6) to inner fender and install three screws (3). Tighten 3 screws. Refer to torque specifications.
6. Connect vacuum line (1) to servo.
7. Connect electrical connector (5) to servo.
8. Connect servo cable (2) to throttle body. Refer to «CABLE-SPEED CONTROL»(ref-247660-S28649061702007020100000) .
9. Install air filter housing assembly.
10. Connect negative battery cable to battery.
11. Before starting engine, operate accelerator pedal to check for any binding.

1. Position switch to steering wheel.
2. Install switch mounting screw and tighten. Refer to torque specifications.
3. Plug electrical connector into switch.
4. Install airbag module. Refer to «RESTRAINTS - SERVICE INFORMATION»(ref-247645) .
5. Connect negative battery cable to battery.

The vacuum reservoir (2) is attached to the bottom of the windshield wiper cowel panel (1).

1. Remove cowel panel.
2. Disconnect vacuum line (5) at reservoir.
3. The reservoir is attached using three clips. Pry out on clips for removal.
4. Remove reservoir from cowel.

1. Position reservoir (2) onto windshield wiper cowel (1).
2. Install three clips (2) to reservoir. Attach reservoir to cowel panel by pushing clips into cowel panel (1).
3. Connect vacuum line (5) to reservoir fitting.
4. Install windshield wiper cowel (1).
