Connector Pin-Outs: Wiring Dodge Dakota III

Blend Door Actuator Connector End View

ACTUATOR-BLEND DOOR - 6 WAY CAV CIRCUIT FUNCTION 1 C61 DB/LG BLEND DOOR DRIVER 2 - - 3 - - 4 - - 5 - - 6 C34 20DB/LB COMMON DOOR DRIVER

Floor To Defrost Mode Door Actuator Connector End View

ACTUATOR-MODE DOOR-FLOOR TO DEFROST - 6 WAY CAV CIRCUIT FUNCTION 1 C801 20DB/OR MODE DOOR 2 DRIVER 2 - - 3 - - 4 - - 5 - - 6 C34 20DB/LB COMMON DOOR DRIVER

Floor To Panel Mode Door Actuator Connector End View

ACTUATOR-MODE DOOR-FLOOR TO PANEL - 6 WAY CAV CIRCUIT FUNCTION 1 C29 20DB MODE DOOR 1 DRIVER 2 - - 3 - - 4 - - 5 - - 6 C34 20DB/LB COMMON DOOR DRIVER

Recirculation Door Actuator Connector End View

ACTUATOR-RECIRCULATION DOOR - 6 WAY CAV CIRCUIT FUNCTION 1 C32 20DB/TN RECIRCULATION DOOR DRIVER 2 - - 3 - - 4 - - 5 - - 6 C34 20DB/LB COMMON DOOR DRIVER

Driver Squib Airbag 1 Connector End View

AIRBAG-DRIVER SQUIB 1 - BROWN 2 WAY CAV CIRCUIT FUNCTION 1 R45 20BK/BL DRIVER SQUIB 1 LINE 1 2 R43 20OR/BL DRIVER SQUIB 1 LINE 2

Scheme 9

Driver Squib Airbag 2 Connector End View

AIRBAG-DRIVER SQUIB 2 - BLACK 2 WAY CAV CIRCUIT FUNCTION 1 R63 20OR/BL DRIVER SQUIB 2 LINE 1 2 R61 20BR/BL DRIVER SQUIB 2 LINE 2

Passenger Airbag Squib Connector End View

AIRBAG-PASSENGER SQUIB - 4 WAY CAV CIRCUIT FUNCTION 1 R62 20LB/VT PASSENGER SQUIB 2 LINE 2 2 R64 20LB/WT PASSENGER SQUIB 2 LINE 1 3 R44 20LB/OR PASSENGER SQUIB 1 LINE 1 4 R42 20LB/BR PASSENGER SQUIB 1 LINE 2

Left Side Curtain Airbag Connector End View

AIRBAG-SIDE CURTAIN-LEFT - 2 WAY CAV CIRCUIT FUNCTION 1 R1 20LB/BR LEFT CURTAIN SQUIB 1 LINE 2 2 R3 20LB/OR LEFT CURTAIN SQUIB 1 LINE 1

Right Side Curtain Airbag Connector End View

AIRBAG-SIDE CURTAIN-RIGHT - 2 WAY CAV CIRCUIT FUNCTION 1 R2 20WT/LB RIGHT CURTAIN SQUIB 1 LINE 2 2 R4 20OR/LB RIGHT CURTAIN SQUIB 1 LINE 1

Radio Amplifier (Premium) Connector End View (C1)

AMPLIFIER-RADIO C1 (PREMIUM) - 14 WAY CAV CIRCUIT FUNCTION 1 X201 16GY/VT AMPLIFIED LEFT FRONT SPEAKER (+) 2 X202 20DG/VT AMPLIFIED RIGHT FRONT SPEAKER (+) 3 X205 18GY/LG AMPLIFIED LEFT REAR SPEAKER (+) 4 X206 20DG/LG AMPLIFIED RIGHT REAR SPEAKER (+) 5 X209 16GY/OR AMPLIFIED LEFT I/P SPEAKER (+) 6 X208 20GY/DG AMPLIFIED RIGHT I/P SPEAKER (+) 7 X291 16GY/YL AMPLIFIED LEFT FRONT SPEAKER (-) 8 X292 20DG/YL AMPLIFIED RIGHT FRONT SPEAKER (-) 9 X295 18GY/DG AMPLIFIED LEFT REAR SPEAKER(-) 10 - - 11 - - 12 X296 20LG/GY AMPLIFIED RIGHT REAR SPEAKER(-) 13 X299 16GY/YL AMPLIFIED LEFT I/P SPEAKER (-) 14 X298 20GY/LG AMPLIFIED RIGHT I/P SPEAKER (-)

Radio Amplifier (Premium) Connector End View (C2)

AMPLIFIER-RADIO C2 (PREMIUM) - 20 WAY CAV CIRCUIT FUNCTION 1 - - 2 - - 3 - - 4 A116 16YL/RD FUSED B(+) 5 - - 6 D55 20WT/OR CAN B BUS(+) 7 X51 18DG/DB RADIO-LEFT REAR AUDIO (+) 8 X52 18GY/DB RADIO-RIGHT REAR AUDIO (+) 9 Z513 16BK GROUND 10 - - 11 - - 12 - - 13 A116 16YL/RD FUSED B(+) 14 - - 15 - - 17 D54 20WT CAN B BUS(-) 18 X57 18DG/OR RADIO-LEFT REAR AUDIO (-) 19 X58 18GY/OR RADIO-RIGHT REAR AUDIO (-) 20 Z980 16BK GROUND

Heated Backlite (Power) Connector End View

BACKLITE-HEATED (POWER) - 1 WAY CAV CIRCUIT FUNCTION 1 C15 12BK/DG FUSED REAR WINDOW DEFOGGER RELAY OUTPUT

Heated Backlite (Ground) Connector End View

BACKLITE-HEATED (GROUND) - 1 WAY CAV CIRCUIT FUNCTION 1 Z255 12BK GROUND

Positive Battery Connector End View

BATTERY (POSITIVE) - 1 WAY CAV CIRCUIT FUNCTION A1 A1 04RD B(+)

Scheme 10

Negative Battery Connector End View

BATTERY (NEGATIVE) - 2 WAY CAV CIRCUIT FUNCTION B1 Z100 04BK/VT GROUND B2 Z1 04BK GROUND

Scheme 11

Engine Side Inline Connector End View (C100)

C100 - (ENGINE SIDE) CAV CIRCUIT 1 A955 16RD 2 D201 20WT/DG 3 T16 16YL/OR (A/T) 3 T2 20DG/WT (M/T) 4 T15 20YL/BK (A/T) 5 - 6 F1 20PK/WT 7 C3 20DB/YL 8 A924 18RD 9 T313 18YL/LG 10 T315 14YL/BR 11 Z904 20BK 12 A919 18RD 13 F924 20PK/YL 14 F202 20PK/GY

Headlamp And Dash Side Inline Connector End View (C100)

C100 - (HEADLAMP AND DASH SIDE) CAV CIRCUIT 1 A955 16RD 2 D201 20WT/DG (4X4) 3 T16 16YL/OR (A/T) 3 T2 20DG/WT (M/T) 4 T15 20YL/BK (A/T) 5 - 6 F1 20PK/WT 7 C3 20DB/YL 8 A924 18RD (4X4) 9 T313 18YL/LG (4X4) 10 T315 14YL/BR (4X4) 11 Z904 16BK (A/T) 11 Z904 20BK (M/T) 12 A919 18RD 13 F924 20PK/YL 14 F202 20PK/GY

Inline (Headlamp And Dash Side) Connector End View (C101)

C101 - (HEADLAMP AND DASH SIDE) CAV CIRCUIT 1 K399 18BR/GY 2 K299 18BR/OR 3 D65 20WT/LG . 4 D64 20WT/LB 5 D16 20WT/OR (A/T) 6 D15 20BR/WT (A/T) 7 D20 20WT/LG 8 D21 20WT/GY 9 T41 20YL/DB (A/T) 10 K900 20DB/DG 11 T103 20YL/OR 12 T6 20DG (A/T) 13 G180 20VT/YL 14 T316 14YL/GY

Engine Side Inline Connector End View (C101)

C101 - (ENGINE SIDE) CAV CIRCUIT 1 K399 18BR/GY 2 K299 18BR/OR 3 D65 20WT/LG 4 D64 20WT/LB 5 D16 20WT/OR (A/T) 6 D15 20BR/WT (A/T) 7 D20 20WT/LG 8 D21 20WT/GY 9 T41 20YL/DB (A/T) 10 K900 20DB/DG 11 T103 20YL/OR (4X4) 12 T6 20DG (A/T) 13 G180 20VT/YL (4X4) 14 T316 14YL/GY (4X4)

Battery Side Inline Connector End View (C102)

C102 - (BATTERY SIDE) CAV CIRCUIT 1 T750 14YL/GY

Inline (Headlamp And Dash Side) Connector End View (C102)

C102 - (HEADLAMP AND DASH SIDE) CAV CIRCUIT 1 T750 14YL/GY

Inline (Headlamp And Dash Side) Connector End View (C103)

C103 - (HEADLAMP AND DASH SIDE) CAV CIRCUIT 1 - 2 A915 10RD 3 C15 12DB/WT (EXCEPT BASE)

Body Side Inline Connector End View (C103)

C103 - (BODY SIDE) CAV CIRCUIT 1 - 2 A915 10RD 3 C15 12BK/DG (EXCEPT BASE)

Scheme 12

Inline (Headlamp And Dash Side) Connector End View (C104)

C104 - (HEADLAMP AND DASH SIDE) CAV CIRCUIT 1 C16 20DB/GY (EXCEPT BASE) 2 D54 20WT 3 D55 20WT/OR 4 - 5 L50 18WT/LB 6 F21 20PK/DG 7 A920 18RD/BK 8 - 9 F525 18TN/PK 10 A956 20RD . 11 F201 20PK/OR 12 A901 18RD 13 - 14 L1 18WT/LG 15 Z945 18BK 16 A940 18RD

Body Side Inline Connector End View (C104)

C104 - NATURAL (BODY SIDE) CAV CIRCUIT 1 C16 DB/GY 2 D54 20WT 2 D54 20WT (SATELLITE RADIO) 3 D55 20WT/OR 3 D55 20WT/OR (SATELLITE RADIO) 4 - 5 L50 16WT/LB 6 F21 20BK/LB 6 F21 20BK/LB 7 A920 18RD/BK 8 - 9 F525 16TN/PK 10 A956 20RD 11 F201 20PK/OR 12 A901 16RD 13 - 14 L1 20BK/DG 14 L1 20BK/DG 15 Z945 20BK 16 A940 16RD

Chassis Side Inline Connector End View (C105)

C105 - (CHASSIS SIDE) CAV CIRCUIT 1 Z201 18BK 2 Z904 20BK 3 N5 20DB/WT 4 B222 20DG/WT 5 B22 20DG/YL 6 L77 20PK/RD 7 K106 20VT/LB 8 B400 12DG (TRAILER TOW) 9 L674 20LG (TRAILER TOW) 10 K107 20VT/WT 11 L78 20WT/OR 12 N1 18DB/OR 13 N4 20DB/YL 14 L673 20YL (TRAILER TOW)

Scheme 13

Inline (Headlamp And Dash Side) Connector End View (C105)

C105 - (HEADLAMP AND DASH SIDE) CAV CIRCUIT 1 Z201 18BK 2 Z904 20BK 3 N5 20DB/WT 4 B222 20DG/WT . 5 B22 20DG/YL 6 L77 20PK/RD 7 K106 20VT/LB 8 B400 12DG (TRAILER TOW) 9 L674 20LG (TRAILER TOW) 10 K107 20VT/WT 11 L78 20WT/OR 12 N1 18DB/OR 13 N4 20DB/YL 14 L673 20YL (TRAILER TOW)

Inline (Headlamp And Dash Side) Connector End View (C106)

C106 - (HEADLAMP AND DASH SIDE) CAV CIRCUIT 1 L76 20PK/RD PREMIUM 2 A100 12RD/VT PREMIUM 3 L62 18WT/OR 4 L63 18WT/DG 5 Z362 20BK/BR 6 Z363 20BK/DG 7 Z945 18BK 8 L1 18WT/LG 9 - 10

Chassis Side Inline Connector End View (C106)

C106 - (CHASSIS SIDE) CAV CIRCUIT 1 L76 20PK/RD (TRAILER TOW) 2 A100 12RD/VT (TRAILER TOW) 3 L62 18WT/OR 4 L63 18WT/DG 5 Z362 20BK/BR 6 Z363 20BK/DG 7 Z945 18BK 8 L1 18WT/LG 9 - 10

Scheme 14

Body Side Inline Connector End View (C200)

C200 - (BODY SIDE) CAV CIRCUIT 1 - 2 - 3 X735 20B/DG 4 X835 20BK/TN 5 - 6 X51 16DG/DB 7 - 8 X57 16DG/OR 9 - 10 L14 20WT/BK 11 - 12 - 13 G75 20VT 14 G161 20VT/DG 15 G778 18VT/BK 16 - 17 G160 20VT/LG 18 G74 20VT/WT 19 - 20 - 21 - 22 - 23 - 24 - 25 - 26 - 27 - 28 - 29 - 30 - 31 X53 20DG 32 X712 20BK/GY 33 X55 20DG/BR 34 - 35 X917 20DG 36 - 37 X17 20DG/OR 38 B25 20DG/WT 39 X16 20DG/LB 40 X793 20BK/RD 41 - 42 - 43 - 44 - 45 X730 20BK/OR 46 X792 20BK/VT 47 X722 20BK/DB 48 - 49 G77 20VT/GY 50 - 51 G76 20VT/YL 52 - 53 - 54 X54 16GY 55 X56 16DG/BR 56 R57 20LG/GY 57 - 58 X52 16GY/DB 59 - 60 X58 16GY/OR 61 - 62 P393 18LG 63 P392 18LG/DB 64 P5 18TN/OR 65 - 66 - 67 - 68 - 69 - 70 - 71 P1 18TN/LG 72 F30 14PK/YL

Scheme 15

I/P Side Inline Connector End View (C200)

C200 - (I/P SIDE) CAV CIRCUIT 1 - 2 - 3 X735 20DB 4 X835 20OR/GY 5 - 6 X51 18DG/DB 7 - 8 X57 18DG/OR 9 - 10 L14 20WT/BK 11 - 12 - 13 G75 20VT 14 G161 20VT/DG 15 G778 18VT/BK 16 - 17 G160 20VT/LG 18 G74 20VT/WT 19 - 20 - 21 - 22 - 23 - 24 - 25 - 26 - 27 - 28 - 29 - 30 - 31 X53 20DG 32 X712 20DG/LB 33 X55 20DG/BR 34 - 35 X917 20DG 36 - 37 X17 20DG/OR 38 B25 20DG/WT 39 X16 20DG/LB 40 X793 20LB/YL 41 - 42 - 43 - 44 - 45 X730 20GY/YL 46 X792 20LB/RD 47 X722 20LB/BK 48 - 49 G77 20VT/GY 50 - 51 G76 20VT/YL 52 - 53 - 54 X54 18GY 55 X56 18GY/BR 56 R57 20LG/GY 57 - 58 X52 18GY/DB 59 - 60 - 61 - 62 P393 18LG 63 P392 18LG/DB 64 P5 18TN/OR 65 - 66 - 67 - 68 - 69 - 70 - 71 P1 18TN/LG 72 F30 14PK/YL

Headlamp And Dash Side Inline Connector End View (C201)

C201 - (HEADLAMP AND DASH SIDE) CAV CIRCUIT 1 F306 18DB/PK 2 - 3 A924 18RD 4 - 5 F961 16PK/LB 6 - 7 - 8 - 9 F1 20PK/WT 10 - 11 D51 20PK/RD 12 F983 20PK/YL 13 D52 20WT/LB 14 A103 20GY/RD 15 - 16 N4 20DB/YL 17 B29 20DG/WT 18 - 19 V30 20VT/WT 20 T6 20DG 21 - 22 V37 20VT 23 - 24 A117 20RD/DG 25 R79 20LB/VT 26 R81 20LB/WT 27 - 28 F201 20PK/OR 29 - 30 - 31 R80 20VT/LB 32 R82 20WT/LB 33 - 34 F100 20PK/VT 35 - 36 D54 20WT 37 D55 20WT/OR 38 - 39 F504 20GY/PK 40 N5 20DB/WT 41 K900 20DB/DG 42 D21 20WT/GY 43 - 44 D20 20WT/LG 45 - 46 - 47 D15 20BR/WT 48 D16 20WT/OR 49 - 50 V32 20VT/YL 51 - 52 - 53 A116 16YL/RD 54 - 55 F21 20PK/DG 56 - 57 L50 18WT/LB 58 F202 20PK/GY 59 - 60 - 61 A923 18RD 62 A918 18RD 63 A927 12RD/OR 64 A904 12RD/LB 65 A917 12RD 66 A953 12RD 67 F984 12PK/LG 68 F941 14PK/LG 69 F921 12PK/WT 70 F901 16PK 71 F982 12PK/YL 72 A920 18RD/BK

Ip Side Inline Connector End View (C201)

C201 - (IP SIDE) CAV CIRCUIT 1 F306 18DB/PK 2 - 3 A924 16RD 4 - 5 F961 14PK/LB 6 - 7 - 8 - 9 F1 20PK/WT 10 - 11 D51 20PK/RD 12 F983 20PK/YL 13 D52 20WT/LB 14 A103 18GY/RD 15 - 16 N4 20DB/YL 17 B29 20DG/WT 18 - 19 V30 20VT/WT 20 T6 20DG 21 - 22 V37 20VT 23 - 24 A117 18RD/DG 25 R79 20LB/VT 26 R81 20LB/WT 27 - 28 F201 20PK/OR 29 - 30 - 31 R80 20VT/LB 32 R82 20WT/LB 33 - 34 F100 20PK/VT 35 - 36 D54 20WT 37 D55 20WT/OR 38 - 39 F504 20GY/PK 40 N5 20DB/WT 41 K900 20DB/DG 42 D21 20WT/GY 43 - 44 D20 20WT/LG 45 - 46 - 47 D15 20BR/WT 48 D16 20WT/OR 49 - 50 V32 20VT/YL 51 - 52 - 53 A116 16YL/RD 54 - 55 F21 20PK/DG (2X4) 55 F21 20PK/DG (4X4) 56 - 57 L50 16WT/LB 58 F202 20PK/GY 59 - 60 - 61 A923 16RD 62 A918 18RD/LB 63 A927 10RD/OR 64 A904 12RD/LB 65 A917 10RD 66 A953 12RD 67 F984 12PK/YL (BASE) 67 F984 12PK/YL (EXCEPT BASE) 68 F941 14PK/LG 69 F921 10PK/WT 70 F901 14PK 71 F982 12PK/YL 72 A920 18RD/BK

HVAC Side Inline Connector End View (C202)

C202 - (HVAC SIDE) CAV CIRCUIT 1 C21 20DB/LG 2 C121 20DB/DG 3 C61 20DB/LG 4 C801 20DB/OR 5 C32 20DB/TN 6 C29 20DB 7 C7 12DB 8 C75 12DB/GY 9 - 10 - 11 C71 16DB/BR 12 C72 14DB/OR 13 C73 14DB/VT 14 - 15 C34 20DB/LB 16

I/P Side Inline Connector End View (C202)

C202 - NATURAL (I/P SIDE) CAV CIRCUIT 1 C21 20DB/LG 2 C121 20DB/DG 3 C61 20DB/LG 4 C801 20LB/RD 5 C32 20DB/TN 6 C29 20DB 7 C7 12DB 8 C75 12DB/GY 9 - 10 - 11 C71 16DB/BR 12 C72 14DB/OR 13 C73 12DB/VT 14 - 15 C34 20DB/LB 16

Scheme 16

Inline (I/P Side) Connector End View (C203)

C203 - (I/P SIDE) CAV CIRCUIT 1 - 2 M22 20YL/OR 3 Z955 20BK 4 M28 20YL/TN 5 A918 18RD/LB (EXCEPT BASE) 5 A918 18RD/LB (HIGHLINE) 7 - 8 - 9 - 10 D55 20WT/OR (EXCEPT BASE) 11 D54 20WT (EXCEPT BASE) 12 Z993 18BK (EXCEPT BASE) 13 - 14

Inline (Headliner Side) Connector End View (C203)

C203 - (HEADLINER SIDE) CAV CIRCUIT 1 - 2 M22 20YL/OR 3 Z955 20BK 4 M28 20YL/TN 5 A918 18RD/LB (OVERHEAD CONSOLE) 6 - 7 - 8 - 9 - 10 D55 20WT/OR 10 D55 20WT/OR (OVERHEAD CONSOLE) 11 D54 20WT 11 D54 20WT (OVERHEAD CONSOLE) 12 Z993 18BK 12 Z993 18BK (OVERHEAD CONSOLE) 13 - 14

Scheme 17

Inline (Left Front Door Side) Connector End View (C300)

C300 - (LEFT FRONT DOOR SIDE) CAV CIRCUIT 1 Z940 20BK (EXCEPT BASE) 2 Z13 16BK/WT (EXCEPT BASE) 3 P393 18LG (EXCEPT BASE) 4 P74 20TN/YL (EXCEPT BASE) 5 Z917 20BK (BASE) 6 Q26 14OR/GY (EXCEPT BASE) 7 Q611 14OR/RD (QUAD CAB) 8 Q15 14OR/LB (QUAD CAB) 9 Q412 14TN/YL (QUAD CAB) 10 Q16 14OR/TN (EXCEPT BASE) 11 Q411 14OR/BK (QUAD CAB) 12 F30 14PK/YL (EXCEPT BASE) 13 C16 20DB/GY (EXCEPT BASE) 14 P76 20TN/RD (EXCEPT BASE) 15 Q612 14OR/DB (QUAD CAB) 16 P72 20TN/DG (EXCEPT BASE)

Scheme 18

Body Side Inline Connector End View (C300)

C300 - (BODY SIDE) CAV CIRCUIT 1 Z940 20BK (EXCEPT BASE) 2 Z13 16BK/WT (EXCEPT BASE) 3 P393 18LG (EXCEPT BASE) 4 P74 20TN/YL (EXCEPT BASE) 5 - 6 Q26 14OR/GY (EXCEPT BASE) 7 Q611 14OR/RD (QUAD CAB) 8 Q15 14OR/LB (QUAD CAB) 9 Q412 14TN/YL (QUAD CAB) 10 Q16 14OR/TN (QUAD CAB) 11 Q411 14OR/BK (QUAD CAB) 12 F30 14PK/YL (EXCEPT BASE) 13 C16 20DB/GY (EXCEPT BASE) 14 P76 20TN/RD (EXCEPT BASE) 15 Q612 14OR/DB (QUAD CAB) 16 P72 20TN/DG (EXCEPT BASE)

Inline (Left Front Door Side) Connector End View (C301)

C301 - (LEFT FRONT DOOR SIDE) CAV CIRCUIT 1 - 2 - 3 X209 18GY/OR (PREMIUM AUDIO) 4 X53 20DG (BASE AUDIO) 4 X201 16GY/VT (PREMIUM AUDIO) 5 X299 18GY/YL (PREMIUM AUDIO) 6 X55 20DG/BR (BASE AUDIO) 6 X291 16GY/YL (PREMIUM AUDIO) 7 P1 18TN/LG (EXCEPT BASE) 8 G75 20VT 9 G161 20VT/DG (EXCEPT BASE) 10 A940 16RD (EXCEPT BASE)

Body Side Inline Connector End View (C301)

C301 - (BODY SIDE) CAV CIRCUIT 1 - 2 - 3 X209 16GY/OR (PREMIUM AUDIO) 4 X53 20DG (BASE AUDIO) 4 X201 16GY/VT (PREMIUM AUDIO) 5 X299 16GY/YL (PREMIUM AUDIO) 6 X55 20DG/BR (BASE AUDIO) 6 X291 16GY/YL (PREMIUM AUDIO) 7 P1 18TN/LG (EXCEPT BASE) 8 G75 20VT 9 G161 20VT/DG (EXCEPT BASE) 10 A940 16RD (EXCEPT BASE)

Body Side Inline Connector End View (C302)

C302 - (BODY SIDE) CAV CIRCUIT 1 Z974 20BK/OR (EXCEPT BASE) 2 Z944 20BK/LG 3 P72 20TN/DG (EXCEPT BASE) 4 P76 20TN/RD (EXCEPT BASE) 5 P74 20TN/YL (EXCEPT BASE) 6 F30 14PK/YL (EXCEPT BASE) 7 Q16 14OR/TN (EXCEPT BASE) 8 Q15 14OR/LB (EXCEPT BASE) 9 Q26 14OR/GY (EXCEPT BASE) 10 C16 20DB/GY (EXCEPT BASE) 11 P392 18LG/DB 12 Z917 20BK (BASE) 13 - 14 - 15 - 16

Inline (Right Front Door Side) Connector End View (C302)

C302 - (RIGHT FRONT DOOR SIDE) CAV CIRCUIT 1 Z974 20BK/OR (EXCEPT BASE) 2 Z944 20BK/LG 3 P72 20TN/DG (EXCEPT BASE) 4 P76 20TN/RD (EXCEPT BASE) 5 P74 20TN/YL (EXCEPT BASE) 6 F30 14PK/YL (EXCEPT BASE) 7 Q16 14OR/TN (EXCEPT BASE) 8 Q15 14OR/LB (EXCEPT BASE) 9 Q26 14OR/GY (EXCEPT BASE) 10 C16 20DB/GY (EXCEPT BASE) 11 P392 18LG/DB 12 - 13 - 14 - 15 - 16

Inline (Right Front Door Side) Connector End View (C303)

C303 - (RIGHT FRONT DOOR SIDE) CAV CIRCUIT 1 X298 20GY/LG (PREMIUM AUDIO) 2 X208 20GY/DG (PREMIUM AUDIO) 3 - 4 - 5 X56 16DG/BR (BASE AUDIO) 5 X292 20DG/YL (PREMIUM AUDIO) 6 X54 16GY (BASE AUDIO) 6 X202 20DG/VT (PREMIUM AUDIO) 7 G74 20VT/WT 8 G160 20VT/LG (EXCEPT BASE) 9 G778 18VT/BK 10

Body Side Inline Connector End View (C303)

C303 - (BODY SIDE) CAV CIRCUIT 1 X298 20GY/LG (PREMIUM AUDIO) 2 X208 20GY/DG (PREMIUM AUDIO) 3 - 4 - 5 X56 16DG/BR (BASE AUDIO) 5 X292 20DG/YL (PREMIUM AUDIO) 6 X54 16GY (BASE AUDIO) 6 X202 20DG/VT (PREMIUM AUDIO) 7 G74 20VT/WT 8 G160 20VT/LG (EXCEPT BASE) 9 G778 18VT/BK (EXCEPT BASE) 10

Console Side Inline (Base) Connector End View (C304)

C304 (BASE) - (CONSOLE SIDE) CAV CIRCUIT 1 A12 16RD/TN 2 Z1 16BK

Body Side Inline (Premium) Connector End View (C304)

C304 (PREMIUM) - (BODY SIDE) CAV CIRCUIT 1 F525 16TN/PK 2 P968 20TN/LG 3 P687 20TN/PK 4 P688 20TN/LG 5 A901 16RD 6 - 7 P187 16LG/BR 8 P188 16LG/VT 9 - 10 Z738 18BK/WT

Scheme 19

Body Side Inline (Base) Connector End View (C304)

C304 (BASE) - (BODY SIDE) CAV CIRCUIT 1 A901 16RD 2 Z738 18BK/WT

Console Side Inline (Premium) Connector End View (C304)

C304 (PREMIUM) - (CONSOLE SIDE) CAV CIRCUIT 1 F500 18VT/BR 2 P144 20BK/LG 3 P141 20TN/LB 4 P142 20TN/DB 5 A12 16RD/TN 6 - 7 P131 18RD/DG 8 P130 18RD/TN 9 - 10 Z1 16BK

Body Side Inline (Quad Cab) Connector End View (C306)

C306 (QUAD CAB) - (BODY SIDE) CAV CIRCUIT 1 X52 16GY/DB (BASE AUDIO) 1 X206 20DG/LG (PREMIUM AUDIO) 2 X58 16GY/OR (BASE AUDIO) 2 X296 20LG/GY (PREMIUM AUDIO) 3 Z927 20BK (EXCEPT BASE) 4 Q612 14OR/DB (EXCEPT BASE) 5 G76 20VT/YL 6 P392 18LG/DB (EXCEPT BASE) 7 Q15 14OR/LB (EXCEPT BASE) 8 Q412 14TN/YL (EXCEPT BASE) 9 G778 18VT/BK (EXCEPT BASE) 10 Z917 20BK (BASE AUDIO)

Right Rear Door Side Inline (Quad Cab) Connector End View (C306)

C306 (QUAD CAB) - (RIGHT REAR DOOR SIDE) CAV CIRCUIT 1 X52 16GY/DB (BASE) 1 X206 20DG/LG (EXCEPT BASE) 2 X58 16GY/OR (BASE) 2 X296 20LG/GY (EXCEPT BASE) 3 Z927 20BK (EXCEPT BASE) 4 Q612 14OR/DB (EXCEPT BASE) 5 G76 20VT/YL 6 P392 18LG/DB (EXCEPT BASE) 7 Q15 14OR/LB (EXCEPT BASE) 8 Q412 14TN/YL (EXCEPT BASE) 9 G778 18VT/BK (EXCEPT BASE) 10 Z917 20BK (BASE)

Inline (Left Seat Side) Connector End View (C307)

C307 - (LEFT SEAT SIDE) CAV CIRCUIT 1 Z975 12BK (EXCEPT BASE) 2 A915 10RD (EXCEPT BASE) 3 R261 20LB/WT 4 R57 20LG/GY 5 Z949 20BK 6 R263 20LB/VT

Body Side Inline Connector End View (C307)

C307 - (BODY SIDE) CAV CIRCUIT 1 Z975 12BK (EXCEPT BASE) 2 A915 10RD (EXCEPT BASE) 3 R261 20LB/WT 4 R57 20LG/GY 5 Z949 20BK 6 R263 20LB/VT

Body Side Inline (Quad Cab) Connector End View (C308)

C308 (QUAD CAB) - (BODY SIDE) CAV CIRCUIT 1 X51 16DG/DB (BASE AUDIO) 1 X205 18GY/LG (PREMIUM AUDIO) 2 X57 16DG/OR (BASE AUDIO) 3 Z941 20BK (EXCEPT BASE) 4 P5 18TN/OR (EXCEPT BASE) 5 G77 20VT/GY 6 Q611 14OR/RD (EXCEPT BASE) 7 P393 18LG (EXCEPT BASE) 8 Q15 14OR/LB (EXCEPT BASE) 9 Q411 14OR/BK (EXCEPT BASE) 10 Z917 20BK (BASE AUDIO)

Left Rear Door Side Inline (Quad Cab) Connector End View (C308)

C308 (QUAD CAB) - (LEFT REAR DOOR SIDE) CAV CIRCUIT 1 X51 18DG/DB (BASE AUDIO) 1 X205 18GY/LG (PREMIUM AUDIO) 2 X57 18DG/OR (BASE AUDIO) 2 X295 18GY/DG (PREMIUM AUDIO) 3 Z941 20BK 4 P5 18TN/OR 5 G77 20VT/GY 6 Q611 14OR/RD (EXCEPT BASE) 7 P393 18LG 8 Q15 14OR/LB (PWR CONV.) 9 Q411 14OR/BK (PWR CONV.) 10 Z917 20BK (BASE)

Scheme 20

Ignition Capacitor Connector End View

CAPACITOR-IGNITION - 2 WAY CAV CIRCUIT FUNCTION 1 A955 16RD ASD RELAY OUTPUT 2

Circuit Window Door Lock Breaker Connector End View

CIRCUIT BREAKER-WINDOW/DOOR LOCK - 2 WAY CAV CIRCUIT FUNCTION 1 F984 12PK/YL FUSED IGNITION SWITCH OUTPUT (RUN-ACC) 2 F30 14PK/YL FUSED IGNITION SWITCH OUTPUT (RUN-ACC)

Clockspring Connector End View (C1)

CLOCKSPRING C1 - 6 WAY CAV CIRCUIT FUNCTION 1 X20 20GY/WT (REMOTE AUDIO) RADIO CONTROL MUX 2 G902 20VT/OR (REMOTE AUDIO) SWITCH MUX RETURN 3 - - 4 V37 20VT S/C SWITCH NO. 1 SIGNAL 5 K900 20DB/DG SENSOR GROUND 6 X3 20DG/VT HORN SWITCH SENSE

Clockspring Connector End View (C2)

CLOCKSPRING C2 - 4 WAY CAV CIRCUIT FUNCTION 1 R61 20LG/VT DRIVER SQUIB 2 LINE 2 2 R63 20LG/WT DRIVER SQUIB 2 LINE 1 3 R43 20LG/BR DRIVER SQUIB 1 LINE 2 4 R45 20LG/OR DRIVER SQUIB 1 LINE 1

Clockspring Connector End View (C3)

CLOCKSPRING C3 - 4 WAY CAV CIRCUIT FUNCTION 1 X3 20DG/VT HORN SWITCH SENSE 2 K900 22DB/DG SENSOR GROUND 2 K900 22DB/DG SENSOR GROUND 3 V37 22VT S/C SWITCH NO. 1 SIGNAL 3 V37 22VT S/C SWITCH NO. 1 SIGNAL 4 V38 22VT/OR NOT USED 4 V38 22VT/OR NOT USED

Clockspring Connector End View (C4)

CLOCKSPRING C4 - 2 WAY CAV CIRCUIT FUNCTION 1 G902 22VT/BR SWITCH MUX RETURN 1 G902 22VT/BR SWITCH MUX RETURN 2 X20 22GY/WT RADIO CONTROL MUX 2 X20 22GY/WT RADIO CONTROL MUX

Instrument Cluster Connector End View (C1)

CLUSTER C1 - 26 WAY CAV CIRCUIT FUNCTION 1 Z946 16BK GROUND 2 P392 18LG/DB (EXCEPT BASE) DOOR LOCK DRIVER RIGHT DOORS 3 B25 20DG/WT PARK BRAKE SWITCH SENSE 4 L914 20WT FOG LAMP INDICATOR DRIVER 5 R57 20LG/GY DRIVER SEAT BELT SWITCH SENSE 6 G75 20VT DRIVER DOOR AJAR SWITCH SENSE 7 X20 20GY/WT (REMOTE AUDIO) RADIO CONTROL MUX 8 G77 20VT/GY LEFT REAR DOOR AJAR SWITCH SENSE 9 G15 20VT/TN KEY-IN IGNITION SWITCH SENSE 10 X3 20DG/VT HORN SWITCH SENSE 11 P5 18TN/OR (EXCEPT BASE) DOOR UNLOCK DRIVER LEFT REAR 12 P1 18TN/LG (EXCEPT BASE) DOOR UNLOCK DRIVER LEFT FRONT 13 A924 16RD FUSED B(+) 14 - - 15 P393 18LG (EXCEPT BASE) DOOR LOCK DRIVER LEFT DOORS 16 W52 20BR/YL FRONT WIPER SWITCH MUX 17 F961 18PK/LB IGNITION SWITCH OUTPUT (START) 18 G39 20VT/LB (HIGHLINE) SUN SENSOR SIGNAL 19 - - 20 - - 21 K77 20BR/WT (4X4) 5 VOLT SELECTOR SWITCH SUPPLY 22 - - 23 - - 24 B30 20DG/OR BTSI SOLENOID CONTROL 25 G778 18VT/BK (EXCEPT BASE) DOOR UNLOCK DRIVER RIGHT DOORS 26 A924 16RD FUSED B(+)

Instrument Cluster Connector End View (C2)

CLUSTER C2 - 16 WAY CAV CIRCUIT FUNCTION 1 G194 20VT/LG HIGH BEAM/FRONT WASHER SWITCH MUX 2 G160 20VT/LG (EXCEPT BASE) PASSENGER DOOR LOCK SWITCH MUX 3 G161 20VT/DG (EXCEPT BASE) DRIVER DOOR LOCK SWITCH MUX 4 E2 20OR/BR INDICATOR DIMMER SIGNAL 5 L307 20PK/RD HEADLAMP SWITCH MUX 6 N5 20DB/WT FUEL LEVEL SENSOR RETURN 7 - - 8 L12 20WT/OR TURN SIGNAL INPUT MUX 9 G939 20VT/DB (HIGHLINE) SUN SENSOR RETURN 10 L900 20WT/YL HEADLAMP SWITCH MUX RETURN 11 G902 20VT/OR SWITCH MUX RETURN 12 K977 20BR/WT (4WD) MODE SELECT 13 D54 20WT CAN B BUS(-) 14 D55 20WT/OR CAN B BUS(+) 15 - - 16 N4 20DB/YL FUEL LEVEL SENSOR NO. 1 SIGNAL

Scheme 21

Instrument Cluster Connector End View (C3)

CLUSTER C3 - 26 WAY CAV CIRCUIT FUNCTION 1 M28 20YL/TN GLOVE BOX LAMP DRIVER 2 L14 20WT/BK CARGO LAMP DRIVER 3 - - 4 - - 5 - - 6 E12 20OR/GY PANEL LAMPS DRIVER 7 - - 8 E11 20OR/DB (4WD) PANEL LAMPS DRIVER 9 E19 20OR/BR PANEL LAMPS DIMMER SIGNAL 10 E33 20OR PANEL LAMPS DRIVER 11 M22 20YL/OR COURTESY LAMPS DRIVER 12 F21 20PK/DG FUSED IGNITION SWITCH OUTPUT (START) 13 F1 20PK/WT FUSED IGNITION SWITCH OUTPUT (RUN-START) 14 A117 18RD/DG FUSED B(+) (I.O.D.) 15 A117 18RD/DG FUSED B(+) (I.O.D.) 16 G95 20VT/BR (4WD) 4WD NEUTRAL INDICATOR 17 - - 18 - - 19 - - 20 - - 21 - - 22 G76 20VT/YL RIGHT REAR DOOR AJAR SWITCH SENSE 23 G74 20VT/WT PASSENGER DOOR AJAR SWITCH SENSE 24 F983 20PK/YL FUSED IGNITION SWITCH OUTPUT (RUN-ACC) 25 A920 18RD/BK FUSED B(+) 26 Z948 18BK GROUND

Scheme 22

A/C Compressor Clutch Connector End View

CLUTCH-A/C COMPRESSOR - 2 WAY CAV CIRCUIT FUNCTION 1 C3 20DB/YL A/C CLUTCH RELAY OUTPUT 2 Z153 20BK/GY GROUND

Ignition Coil 1 Connector End View

COIL-IGNITION-NO. 1 - 3 WAY CAV CIRCUIT FUNCTION 1 K19 18DB/DG COIL CONTROL NO. 1 2 A955 16RD ASD RELAY OUTPUT 3

Scheme 23

Ignition Coil 2 Connector End View

COIL-IGNITION-NO. 2 - 3 WAY CAV CIRCUIT FUNCTION 1 K17 18DB/TN COIL CONTROL NO. 2 2 A955 16RD ASD RELAY OUTPUT 3

Ignition Coil 3 Connector End View

COIL-IGNITION-NO. 3 - 3 WAY CAV CIRCUIT FUNCTION 1 K18 18DB/OR COIL CONTROL NO. 3 2 A955 16RD ASD RELAY OUTPUT 3

Scheme 24

Ignition Coil 4 Connector End View

COIL-IGNITION-NO. 4 - 3 WAY CAV CIRCUIT FUNCTION 1 K15 18DB COIL CONTROL NO. 4 2 A955 16RD ASD RELAY OUTPUT 3

Ignition Coil 5 Connector End View

COIL-IGNITION-NO. 5 - 3 WAY CAV CIRCUIT FUNCTION 1 K16 18DB/YL COIL CONTROL NO. 5 2 A955 16RD ASD RELAY OUTPUT 3

Ignition Coil 6 Connector End View

COIL-IGNITION-NO. 6 - 3 WAY CAV CIRCUIT FUNCTION 1 K10 18DB/OR COIL CONTROL NO. 6 2 A955 16RD ASD RELAY OUTPUT 3

Ignition Coil 7 (4.7L) Connector End View

COIL-IGNITION-NO. 7 (4.7L) - 3 WAY CAV CIRCUIT FUNCTION 1 K97 18BR COIL CONTROL NO. 7 2 A955 16RD ASD RELAY OUTPUT 3

Ignition Coil 8 (4.7L) Connector End View

COIL-IGNITION-NO. 8 (4.7L) - 3 WAY CAV CIRCUIT FUNCTION 1 K98 18DB/YL COIL CONTROL NO. 8 2 A955 16RD ASD RELAY OUTPUT 3

A/C Heater Control Connector End View (C1)

CONTROL-A/C-HEATER C1 - 16 WAY CAV CIRCUIT FUNCTION 1 F504 20GY/PK FUSED IGNITION SWITCH OUTPUT (RUN) 2 Z24 20BK/OR GROUND 3 - - 4 - - 5 - - 6 C21 20DB/LG EVAPORATOR TEMPERATURE SENSOR SIGNAL 7 C121 DB/DG SENSOR GROUND 8 E12 20OR/GY PANEL LAMPS DRIVER 9 C61 20DB/LG BLEND DOOR DRIVER 10 C29 20DB MODE DOOR 1 DRIVER 11 C32 20DB/TN RECIRCULATION DOOR DRIVER 12 C801 20LB/RD MODE DOOR 2 DRIVER 13 C34 20DB/LB COMMON DOOR DRIVER 14 - - 15 D54 20WT CAN B BUS(-) 16 D55 20WT/OR CAN B BUS(+)

A/C Heater Control Connector End View (C2)

CONTROL-A/C-HEATER C2 - 10 WAY CAV CIRCUIT FUNCTION 1 - - 2 C71 16DB/BR BLOWER MOTOR LOW SPEED 3 C73 12DB/VT BLOWER MOTOR M2 SPEED 4 - - 5 Z961 12BK GROUND 6 - - 7 C72 14DB/OR BLOWER MOTOR M1 SPEED 8 - - 9 - - 10 C75 12DB/GY BLOWER MOTOR HIGH SPEED

Scheme 25

Data Link Connector, Connector End View

DATA LINK CONNECTOR - 16 WAY CAV CIRCUIT FUNCTION 1 - - 2 - - 3 - - 4 Z11 18BK/LG GROUND 5 Z111 18BK/WT GROUND 6 D52 20WT/LB CAN C DIAGNOSTIC (+) 7 D21 20WT/GY SCI TRANSMIT (PCM) 8 - - 9 D16 20WT/OR SCI RECEIVE (TCM) 10 - - 11 - - 12 D20 20WT/LG SCI RECEIVE (PCM) 13 - - 14 D51 20PK/RD CAN C DIAGNOSTIC (-) 15 D15 20BR/WT SCI TRANSMIT (TCM) 16 A918 18RD/LB FUSED B(+)

B+ Generator Connector End View

GENERATOR (B+) - 1 WAY CAV CIRCUIT FUNCTION 1 A1 04RD B(+)

Generator Connector End View

GENERATOR - 2 WAY CAV CIRCUIT FUNCTION 1 K20 18BR/GY GEN FIELD CONTROL 2 Z20 18BR/BK GROUND

Driver Cushion Pad Heater (Heated Seats) Connector End View

HEATER-CUSHION PAD-DRIVER (HEATED SEATS) - 4 WAY CAV CIRCUIT FUNCTION 1 P187 16LG/BR LEFT SEAT HEATER B(+) DRIVER 2 P687 20TN/PK HEATED SEAT TEMP SENSOR - LEFT FRONT 3 P968 20TN/LG HEATED SEAT SENSOR RETURN 4 Z970 20BK GROUND

Passenger Cushion Pad Heater (Heated Seats) Connector End View

HEATER-CUSHION PAD-PASSENGER (HEATED SEATS) - 4 WAY CAV CIRCUIT FUNCTION 1 P188 16LG/VT RIGHT SEAT HEATER B(+) DRIVER 2 P688 20TN/LG HEATED SEAT TEMP SENSOR - RIGHT FRONT 3 P968 20TN/LG HEATED SEAT SENSOR RETURN 4 Z969 20BK GROUND

Horn 1 Connector End View

HORN-NO. 1 - 1 WAY CAV CIRCUIT FUNCTION 1 X2 18DG/OR HORN RELAY OUTPUT

Horn 2 Connector End View

HORN-NO. 2 - 1 WAY CAV CIRCUIT FUNCTION 1 X2 18DG/OR HORN RELAY OUTPUT

Scheme 26

Fuel Injector 1 Connector End View

INJECTOR-FUEL-NO. 1 - 2 WAY CAV CIRCUIT FUNCTION 1 K11 18BR/YL INJECTOR CONTROL NO. 1 2 A955 16RD ASD RELAY OUTPUT

Fuel Injector 2 Connector End View

INJECTOR-FUEL-NO. 2 - 2 WAY CAV CIRCUIT FUNCTION 1 K12 18BR/DB INJECTOR CONTROL NO. 2 2 A955 16RD ASD RELAY OUTPUT

Fuel Injector 3 Connector End View

INJECTOR-FUEL-NO. 3 - 2 WAY CAV CIRCUIT FUNCTION 1 K13 18BR/LB INJECTOR CONTROL NO. 3 2 A955 16RD ASD RELAY OUTPUT

Fuel Injector 4 Connector End View

INJECTOR-FUEL-NO. 4 - 2 WAY CAV CIRCUIT FUNCTION 1 K14 18BR/TN INJECTOR CONTROL NO. 4 2 A955 16RD ASD RELAY OUTPUT

Fuel Injector 5 Connector End View

INJECTOR-FUEL-NO. 5 - 2 WAY CAV CIRCUIT FUNCTION 1 K38 18BR/OR INJECTOR CONTROL NO. 5 2 A955 16RD ASD RELAY OUTPUT

Fuel Injector 6 Connector End View

INJECTOR-FUEL-NO. 6 - 2 WAY CAV CIRCUIT FUNCTION 1 K58 18BR/VT INJECTOR CONTROL NO. 6 2 A955 16RD ASD RELAY OUTPUT

Fuel Injector 7 (4.7L) Connector End View

INJECTOR-FUEL-NO. 7 (4.7L) - 2 WAY CAV CIRCUIT FUNCTION 1 K26 18BR/YL INJECTOR CONTROL NO. 7 2 A955 16RD ASD RELAY OUTPUT

Fuel Injector 8 (4.7L) Connector End View

INJECTOR-FUEL-NO. 8 (4.7L) - 2 WAY CAV CIRCUIT FUNCTION 1 K28 18BR/LB INJECTOR CONTROL NO. 8 2 A955 16RD ASD RELAY OUTPUT

Left Backup Lamp Connector End View

LAMP-BACKUP-LEFT - 2 WAY CAV CIRCUIT FUNCTION 1 L1 18WT/LG BACK-UP LAMP FEED 2 Z363 20BK/DG GROUND

Right Backup Lamp Connector End View

LAMP-BACKUP-RIGHT - 2 WAY CAV CIRCUIT FUNCTION 1 L1 18WT/LG BACK-UP LAMP FEED 2 Z362 20BK/BR GROUND

Center Bezel Lamp Connector End View

LAMP-CENTER BEZEL - 2 WAY CAV CIRCUIT FUNCTION 1 E33 20OR PANEL LAMPS DRIVER 2 Z407 20BK/OR GROUND

Front Dome Lamp Connector End View

LAMP-DOME-FRONT - 3 WAY CAV CIRCUIT FUNCTION A M28 20YL/TN GLOVE BOX LAMP DRIVER B Z955 20BK GROUND C M22 20YL/OR COURTESY LAMPS DRIVER

Rear Dome Lamp Connector End View

LAMP-DOME-REAR - 3 WAY CAV CIRCUIT FUNCTION 1 M22 20YL/OR COURTESY LAMPS DRIVER 2 M28 20YL/TN GLOVE BOX LAMP DRIVER 3 Z955 20BK GROUND

Left Front Fog Lamp Connector End View

LAMP-FOG-LEFT FRONT - 2 WAY CAV CIRCUIT FUNCTION A L89 18WT/YL FRONT FOG LAMP RELAY OUTPUT B Z349 20BK/YL GROUND

Right Front Fog Lamp Connector End View

LAMP-FOG-RIGHT FRONT - 2 WAY CAV CIRCUIT FUNCTION A L89 18WT/YL FRONT FOG LAMP RELAY OUTPUT B Z348 20BK/OR GROUND

Scheme 27

Left Headlamp Lamp Connector End View

LAMP-HEADLAMP-LEFT - 3 WAY CAV CIRCUIT FUNCTION 1 L43 18WT/DB LEFT LOW BEAM DRIVER 2 Z912 18BK GROUND 3 L33 18WT/LG LEFT HIGH BEAM DRIVER

Right Headlamp Lamp Connector End View

LAMP-HEADLAMP-RIGHT - 3 WAY CAV CIRCUIT FUNCTION 1 L44 18WT/TN RIGHT LOW BEAM DRIVER 2 Z929 18BK GROUND 3 L34 18WT/GY RIGHT HIGH BEAM DRIVER

Scheme 28

High Mounted Stop Lamp Connector End View

LAMP-HIGH MOUNTED STOP - 6 WAY CAV CIRCUIT FUNCTION 1 L14 20WT/BK CARGO LAMP DRIVER 2 Z945 20BK GROUND 3 L50 16WT/LB BRAKE LAMP SWITCH OUTPUT 4 Z945 20BK/OR GROUND 5 - - 6

Left License Lamp Connector End View

LAMP-LICENSE-LEFT - 2 WAY CAV CIRCUIT FUNCTION 1 L77 20PK/RD PARK LAMP RELAY OUTPUT 2 Z945 18BK GROUND

Left Front Park Turn Lamp Connector End View

LAMP-PARK/TURN-LEFT FRONT - 3 WAY CAV CIRCUIT FUNCTION 1 Z377 20BK/BR GROUND 2 L77 20PK/RD FUSED PARK LAMP RELAY OUTPUT 3 L61 18WT/LG LEFT FRONT TURN SIGNAL CONTROL

Right Front Park Turn Lamp Connector End View

LAMP-PARK/TURN-RIGHT FRONT - 3 WAY CAV CIRCUIT FUNCTION 1 Z378 20BK/TN GROUND 2 L78 20WT/OR FUSED PARK LAMP RELAY OUTPUT (RIGHT) 3 L60 18WT/TN RIGHT FRONT TURN SIGNAL CONTROL

Passenger Airbag On/Off Indicator Lamp Connector End View

LAMP-PASSENGER AIRBAG ON/OFF INDICATOR - 6 WAY CAV CIRCUIT FUNCTION 1 - - 2 - - 3 G104 20VT/GY PASSENGER AIRBAG INDICATOR DRIVER 4 F201 20PK/OR FUSED IGNITION SWITCH OUTPUT (RUN-START) 5 - - 6

Left Tail Stop Lamp/Turn Lamp Connector End View

LAMP-TAIL/STOP/TURN-LEFT - 3 WAY CAV CIRCUIT FUNCTION 1 L63 18WT/DG LEFT REAR TURN SIGNAL CONTROL 2 L77 20PK/RD PARK LAMP RELAY OUTPUT 3 Z363 20BK/DG GROUND

Right Tail Stop Lamp/Turn Lamp Connector End View

LAMP-TAIL/STOP/TURN-RIGHT - 3 WAY CAV CIRCUIT FUNCTION 1 L62 18WT/OR RIGHT REAR TURN SIGNAL CONTROL 2 L78 20WT/OR FUSED PARK LAMP RELAY OUTPUT (RIGHT) 3 Z362 20BK/BR GROUND

Left Front Door Latch (Power Convenience) Connector End View

LATCH-DOOR-LEFT FRONT (POWER CONVENIENCE) - 4 WAY CAV CIRCUIT FUNCTION 1 G75 20VT DRIVER DOOR AJAR SWITCH SENSE 2 Z940 20BK GROUND 3 P1 18TN/LG DOOR UNLOCK DRIVER LEFT FRONT 4 P393 18LG DOOR LOCK DRIVER LEFT DOORS

Scheme 29

Left Front Door Latch (Base) Connector End View

LATCH-DOOR-LEFT FRONT (BASE) - 2 WAY CAV CIRCUIT FUNCTION 1 G75 20VT DRIVER DOOR AJAR SWITCH SENSE 2 Z917 20BK GROUND

Scheme 30

Left Rear Door Latch (Quad Cab Base) Connector End View

LATCH-DOOR-LEFT REAR (QUAD CAB BASE) - 2 WAY CAV CIRCUIT FUNCTION 1 G77 20VT/GY LEFT REAR DOOR AJAR SWITCH SENSE 2 Z917 20BK GROUND

Scheme 31

Left Rear Door Latch (Quad Cab Power Convenience) Connector End View

LATCH-DOOR-LEFT REAR (QUAD CAB POWER CONVENIENCE) - 4 WAY CAV CIRCUIT FUNCTION 1 G77 20VT/GY LEFT REAR DOOR AJAR SWITCH SENSE 2 Z941 20BK GROUND 3 P5 18TN/OR DOOR UNLOCK DRIVER LEFT REAR 4 P393 18LG DOOR LOCK DRIVER LEFT DOORS

Scheme 32

Right Front Door Latch (Power Convenience) Connector End View

LATCH-DOOR-RIGHT FRONT (POWER CONVENIENCE) - 4 WAY CAV CIRCUIT FUNCTION 1 G74 20VT/WT PASSENGER DOOR AJAR SWITCH SENSE 2 Z944 20BK/LG GROUND 3 G778 18VT/BK DOOR UNLOCK DRIVER RIGHT DOORS 4 P392 18LG/DB DOOR LOCK DRIVER RIGHT DOORS

Right Front Door Latch (Base) Connector End View

LATCH-DOOR-RIGHT FRONT (BASE) - 2 WAY CAV CIRCUIT FUNCTION 1 G74 20VT/WT PASSENGER DOOR AJAR SWITCH SENSE 2 Z917 20BK GROUND

Right Rear Door Latch (Quad Cab Base) Connector End View

LATCH-DOOR-RIGHT REAR (QUAD CAB BASE) - 2 WAY CAV CIRCUIT FUNCTION 1 G76 20VT/YL RIGHT REAR DOOR AJAR SWITCH SENSE 2 Z917 20BK GROUND

Scheme 33

Right Rear Door Latch (Quad Cab Power Convenience) Connector End View

LATCH-DOOR-RIGHT REAR (QUAD CAB POWER CONVENIENCE) - 4 WAY CAV CIRCUIT FUNCTION 1 G76 20VT/YL RIGHT REAR DOOR AJAR SWITCH SENSE 2 Z927 20BK GROUND 3 G778 18VT/BK DOOR UNLOCK DRIVER RIGHT DOORS 4 P392 18LG/DB DOOR LOCK DRIVER RIGHT DOORS

Inside Rearview Mirror Connector End View (C1)

MIRROR-INSIDE REARVIEW C1 - 7 WAY CAV CIRCUIT FUNCTION 1 F21 20BK/LB FUSED IGNITION SWITCH OUTPUT (START) 2 Z957 20BK/GY GROUND 3 L1 20BK/DG BACK-UP LAMP FEED 4 - - 5 - - 6 - - 7

Inside Rearview Mirror (Hands Free) Connector End View (C2)

MIRROR-INSIDE REARVIEW C2 (HANDS FREE) - 12 WAY CAV CIRCUIT FUNCTION 1 - - 2 - - 3 - - 4 X722 20BK/DB MICROPHONE 2 IN (+) 5 X735 20BK/DG HANDS FREE MICROPHONE SHIELD 6 X712 20BK/GY MICROPHONE 1 IN (+) 7 X793 20BK/RD MICROPHONE FEED 8 - - 9 X730 20BK/OR VOICE RECOGNITION/PHONE SWITCH SIGNAL 10 - - 11 X835 20BK/TN SENSOR GROUND 12 X792 20BK/VT MICROPHONE IN (-)

Driver Outside Rearview Mirror (Power Convenience) Connector End View

MIRROR-OUTSIDE REARVIEW-DRIVER (POWER CONVENIENCE) - 12 WAY CAV CIRCUIT FUNCTION 1 P71 20DB DRIVER MIRROR VERTICAL DRIVER 2 P76 20TN/RD MIRROR COMMON DRIVER 3 P75 20RD DRIVER MIRROR HORIZONTAL DRIVER 4 C16 20DB/GY FUSED REAR WINDOW DEFOGGER RELAY OUTPUT 5 Z940 20BK GROUND 6 - - 7 - - 8 - - 9 - - 10 - - 11 - - 12

Passenger Outside Rearview Mirror (Power Convenience) Connector End View

MIRROR-OUTSIDE REARVIEW-PASSENGER (POWER CONVENIENCE) - 12 WAY CAV CIRCUIT FUNCTION 1 P72 20TN/DG PASSENGER MIRROR VERTICAL DRIVER 2 P76 20TN/RD MIRROR COMMON DRIVER 3 P74 20TN/YL PASSENGER MIRROR HORIZONTAL DRIVER 4 C16 20DB/GY FUSED REAR WINDOW DEFOGGER RELAY OUTPUT 5 Z944 20BK/LG GROUND 6 - - 7 - - 8 - - 9 - - 10 - - 11 - - 12

Antilock Brakes Module (AWAL) Connector End View

MODULE-ANTI-LOCK BRAKES (AWAL) - 46 WAY CAV CIRCUIT FUNCTION 1 - - 2 A111 18DG/RD FUSED B(+) 3 D65 20WT/LG CAN C BUS(+) 4 - - 5 - - 6 B29 20DG/WT BRAKE SWITCH SIGNAL 7 - - 8 - - 9 - - 10 - - 11 - - 12 B9 20DG/LG LEFT FRONT WHEEL SPEED SENSOR SUPPLY 13 B8 20DG/TN LEFT FRONT WHEEL SPEED SENSOR SIGNAL 14 - - 15 - - 16 Z923 18BK GROUND 17 - - 18 D64 20WT/LB CAN C BUS(-) 19 - - 20 - - 21 - - 22 - - 23 - - 24 - - 25 - - 26 B7 20DG/VT RIGHT FRONT WHEEL SPEED SENSOR SUPPLY 27 B6 20DG/WT RIGHT FRONT WHEEL SPEED SENSOR SIGNAL 28 - - 29 - - 30 - - 31 A107 12TN/RD FUSED B(+) 32 F500 20DG/PK FUSED RUN RELAY OUTPUT 33 B20 20DG/OR BRAKE FLUID LEVEL SWITCH SENSE 34 - - 35 - - 36 - - 37 - - 38 - - 39 - - 40 - - 41 B22 20DG/YL REAR WHEEL SPEED SENSOR SIGNAL 42 B222 20DG/WT REAR WHEEL SPEED SENSOR SUPPLY 43 - - 44 - - 45 Z107 12BK/DG GROUND 46

Scheme 34

Antilock Brakes Module (RWAL) Connector End View

MODULE-ANTI-LOCK BRAKES (RWAL) - 14 WAY CAV CIRCUIT FUNCTION 1 B222 20DG/WT REAR WHEEL SPEED SENSOR SUPPLY 2 D65 20WT/LG CAN C BUS(+) 3 D64 20WT/LB CAN C BUS(-) 4 F500 20DG/PK FUSED RUN RELAY OUTPUT 5 - - 6 Z107 12BK/DG GROUND 7 A107 12TN/RD FUSED B(+) 8 B22 20DG/YL REAR WHEEL SPEED SENSOR SIGNAL 9 B29 20DG/WT BRAKE SWITCH SIGNAL 10 - - 11 B20 20DG/OR BRAKE FLUID LEVEL SWITCH SENSE 12 - - 13 - - 14

Scheme 35

Electronic Overhead Module Connector End View

MODULE-ELECTRONIC OVERHEAD - 6 WAY CAV CIRCUIT FUNCTION 1 - - 2 A918 18RD/LB FUSED B(+) 3 D55 20WT/OR CAN B BUS(+) 4 D54 20WT CAN B BUS(-) 5 Z993 18BK GROUND 6

Front Control Module Connector End View (C1)

MODULE-FRONT CONTROL C1 - 24 WAY CAV CIRCUIT FUNCTION 1 Z116 18BK/VT GROUND 2 D55 20WT/OR CAN B BUS(+) 3 D54 20WT CAN B BUS(-) 4 - - 5 D52 20WT/LB CAN C DIAGNOSTIC (+) 6 D51 20PK/RD CAN C DIAGNOSTIC (-) 7 - - 8 D65 20WT/LG CAN C BUS(+) 9 D64 20WT/LB CAN C BUS(-) 10 - - 11 C18 20LB/BR A/C PRESSURE SIGNAL 12 - - 13 - - 14 - - 15 - - 16 T103 20YL/OR 5 VOLT SUPPLY 17 D201 20WT/DG MODE SENSOR A 18 W1 20BR/TN WASHER FLUID LEVEL SWITCH SENSE 19 K25 20DB/VT BATT TEMP SIGNAL 20 K91 20DB/YL BATT TEMP RETURN 21 L50 18WT/LB BRAKE LAMP SWITCH OUTPUT 22 Z117 18BK/WT GROUND 23 - - 24 Z965 18BK GROUND

Scheme 36

Front Control Module Connector End View (C2)

MODULE-FRONT CONTROL C2 - 12 WAY CAV CIRCUIT FUNCTION 1 L44 18WT/TN RIGHT LOW BEAM DRIVER 2 - - 3 - - 4 G31 20VT/OR AAT SIGNAL 5 G931 20VT/BR SENSOR GROUND 6 L43 18WT/DB LEFT LOW BEAM DRIVER 7 L33 18WT/LG LEFT HIGH BEAM DRIVER 8 L60 18WT/TN RIGHT FRONT TURN SIGNAL CONTROL 9 - - 10 L61 18WT/LG LEFT FRONT TURN SIGNAL CONTROL 11 Z947 18BK GROUND 12 L34 18WT/GY RIGHT HIGH BEAM DRIVER

Scheme 37

Front Control Ipm Module Connector End View

MODULE-FRONT CONTROL IPM - 49 WAY CAV CIRCUIT FUNCTION 1 Z921 GROUND 2 A908 FUSED B(+) 3 A906 FUSED B(+) 4 A905 FUSED B(+) 5 A907 FUSED B(+) 6 A909 FUSED B(+) 7 L1 BACK-UP LAMP FEED 8 T315 SHIFT MOTOR CONTROL A 9 T316 SHIFT MOTOR CONTROL B 10 C115 DEFOGGER RELAY CONTROL 11 - - 12 W10 FRONT WASHER PUMP MOTOR CONTROL 13 - - 14 - - 15 A920 FUSED B(+) 16 - - 17 F202 FUSED IGNITION SWITCH OUTPUT (RUN-START) 18 Z118 GROUND 19 Z909 GROUND 20 - - 21 L656 RIGHT TRAILER TOW BRAKE LAMP RELAY CONTROL 22 L655 LEFT TRAILER TOW BRAKE LAMP RELAY CONTROL 23 - - 24 Z909 GROUND 25 Z118 GROUND 26 L139 FOG LAMP RELAY CONTROL 27 W5 WIPER ON/OFF RELAY CONTROL 28 - - 29 W2 WIPER HIGH/LOW RELAY CONTROL 30 A955 ASD RELAY OUTPUT 31 W7 WIPER PARK SWITCH SENSE 32 Z909 GROUND 33 Z118 GROUND 34 L62 RIGHT REAR TURN SIGNAL CONTROL 35 G180 FCM SENSOR RETURN 36 - - 37 - - 38 - - 39 - - 40 T2 LOW/REVERSE SOLENOID CONTROL 41 Z118 GROUND 42 - - 43 L63 LEFT REAR TURN SIGNAL CONTROL 44 - - 45 T313 NOT USED 46 - - 47 X4 HORN RELAY CONTROL 48 L779 PARK LAMP RELAY CONTROL 49

Fuel Pump Module Connector End View

MODULE-FUEL PUMP - 4 WAY CAV CIRCUIT FUNCTION 1 Z201 18BK GROUND 2 N5 20DB/WT FUEL LEVEL SENSOR RETURN 3 N4 20DB/YL FUEL LEVEL SENSOR NO. 1 SIGNAL 4 N1 18DB/OR FUEL PUMP RELAY OUTPUT

Scheme 38

Hands Free Module Connector End View

MODULE-HANDS FREE - 22 WAY CAV CIRCUIT FUNCTION 1 A918 18RD/LB FUSED B(+) 2 - - 3 - - 4 D54 20WT CAN B BUS(-) 5 X722 20LB/BK MICROPHONE 2 IN (+) 6 - - 7 - - 8 X716 20GY/TN CNV-HANDS FREE VOICE (+) 9 X776 20TN/GY CNV-HANDS FREE VOICE (-) 10 X795 20DG COMMON AUDIO OUTPUT 11 - - 12 - - 13 - - 14 D55 20WT/OR CAN B BUS(+) 15 X730 20GY/YL VOICE RECOGNITION/PHONE SWITCH SIGNAL 16 X712 20DG/LB MICROPHONE 1 IN (+) 17 X792 20LB/RD MICROPHONE IN (-) 18 X735 20DB HANDS FREE MICROPHONE SHIELD 19 - - 20 X793 20LB/YL MICROPHONE FEED 21 X835 20OR/GY SENSOR GROUND 22 Z939 20BK GROUND

Heated Seat Module Connector End View

MODULE-HEATED SEAT - 14 WAY CAV CIRCUIT FUNCTION 1 P7 20LB/BK DRIVER HEATED SEAT SWITCH OUTPUT 2 P144 20BK/LG HEATED SEAT SENSOR RETURN 3 P130 18RD/TN RIGHT SEAT HEATER B(+) DRIVER 4 F500 18VT/BR FUSED IGNITION SWITCH OUTPUT (RUN) 5 P131 18RD/DG LEFT SEAT HEATER B(+) DRIVER 6 F500 18VT/BR FUSED IGNITION SWITCH OUTPUT (RUN) 7 P142 20TN/DB HEATED SEAT TEMP SENSOR - RIGHT FRONT 8 P141 20TN/LB HEATED SEAT TEMP SENSOR - LEFT FRONT 9 P8 20LB/WT PASSENGER HEATED SEAT SWITCH OUTPUT 10 P138 20VT/LG PASSENGER SEAT LOW HEAT LED DRIVER 11 P140 20VT/BK PASSENGER SEAT HIGH HEAT LED DRIVER 12 P137 20VT/DG DRIVER SEAT LOW HEAT LED DRIVER 13 Z1 18BK GROUND 14 P139 20VT/WT DRIVER SEAT HIGH HEAT LED DRIVER

Integrated Power Module Connector End View (C1)

MODULE-INTEGRATED POWER C1 - 20 WAY CAV CIRCUIT FUNCTION 1 - - 2 W7 20BR/GY FRONT WIPER PARK SWITCH SENSE 3 - - 4 F202 20PK/GY FUSED IGNITION SWITCH OUTPUT (RUN-START) 5 G180 20VT/YL FCM SENSOR RETURN 6 - - 7 - - 8 - - 9 - - 10 - - 11 T752 20DG/OR STARTER RELAY CONTROL 12 - - 13 - - 14 K51 20BR/GY ASD RELAY CONTROL 15 T313 18YL/LG NOT USED 16 - - 17 - - 18 - - 19 - - 20 T2 20DG/WT (M/T) LOW/REVERSE SOLENOID CONTROL

Integrated Power Module Connector End View (C2)

MODULE-INTEGRATED POWER C2 - 20 WAY CAV CIRCUIT FUNCTION 1 F202 20PK/GY FUSED IGNITION SWITCH OUTPUT (RUN-START) 2 - - 3 - - 4 - - 5 F924 20PK/YL FUSED IGNITION SWITCH OUTPUT (START) 6 K31 20BR FUEL PUMP RELAY CONTROL 7 T15 20YL/BK (A/T) TRANSMISSION CONTROL RELAY CONTROL 8 A956 20RD FUSED B(+) 9 - - 10 Z915 20BK GROUND 11 - - 12 C13 20LB/OR A/C CLUTCH RELAY CONTROL 13 C3 20DB/YL A/C CLUTCH RELAY OUTPUT 14 L77 20PK/RD PARK LAMP RELAY OUTPUT 15 L77 20PK/RD PARK LAMP RELAY OUTPUT 16 L78 20WT/OR FUSED PARK LAMP RELAY OUTPUT (RIGHT) 17 L78 20WT/OR FUSED PARK LAMP RELAY OUTPUT (RIGHT) 18 - - 19 F1 20PK/WT FUSED IGNITION SWITCH OUTPUT (RUN) 20

Integrated Power Module Connector End View (C3)

MODULE-INTEGRATED POWER C3 - 40 WAY CAV CIRCUIT FUNCTION 1 A917 12RD FUSED B(+) 2 A953 12RD FUSED B(+) 3 F961 16PK/LB IGNITION SWITCH OUTPUT (START) 4 - - 5 L674 20LG (TRAILER TOW) RIGHT TRAILER TOW BRAKE LAMP RELAY OUTPUT 6 L673 20YL (TRAILER TOW) LEFT TRAILER TOW BRAKE LAMP RELAY OUTPUT 7 X2 18DG/OR HORN RELAY OUTPUT 8 X2 18DG/OR HORN RELAY OUTPUT 9 F941 14PK/LG IGNITION SWITCH OUTPUT (RUN-START) 10 - - 11 A111 18DG/RD (AWAL) FUSED B(+) 12 A117 20RD/DG FUSED B(+) (I.O.D.) 13 - - 14 - - 15 L76 20PK/RD (TRAILER TOW) TRAILER TOW RELAY OUTPUT 16 A918 18RD FUSED B(+) 17 - - 18 - - 19 - - 20 - - 21 - - 22 - - 23 - - 24 - - 25 A923 18RD FUSED B(+) 26 A940 18RD FUSED B(+) 27 A901 18RD FUSED B(+) 28 A103 20GY/RD FUSED B(+) 29 A116 16YL/RD FUSED B(+) 30 - - 31 A924 18RD FUSED B(+) 32 A100 12RD/VT (TRAILER TOW) FUSED B(+) 33 L89 18WT/YL (FOG LAMPS) FRONT FOG LAMP RELAY OUTPUT 34 L89 18WT/YL (FOG LAMPS) FRONT FOG LAMP RELAY OUTPUT 35 F201 20PK/OR FUSED IGNITION SWITCH OUTPUT (RUN-START) 36 F21 20PK/DG FUSED IGNITION SWITCH OUTPUT (START) 37 - - 38 - - 39 C15 12DB/WT (EBL) FUSED REAR WINDOW DEFOGGER RELAY OUTPUT 40 A107 12TN/RD FUSED B(+)

Integrated Power Module Connector End View (C4)

MODULE-INTEGRATED POWER C4 - 40 WAY CAV CIRCUIT FUNCTION 1 - - 2 A915 10RD FUSED B(+) 3 - - 4 - - 5 - - 6 - - 7 - - 8 - - 9 A920 18RD/BK FUSED B(+) 10 - - 11 - - 12 - - 13 F306 18DB/PK FUSED B(+) 14 Z967 18BK GROUND 15 N1 18DB/OR FUEL PUMP RELAY OUTPUT 16 A400 14TN/RD (TRAILER TOW) FUSED B(+) 17 - - 18 - - 19 - - 20 - - 21 - - 22 - - 23 - - 24 - - 25 A955 16RD ASD RELAY OUTPUT 26 Z903 18BK GROUND 27 W10 18BR FRONT WASHER PUMP MOTOR CONTROL 28 F984 12PK/YL FUSED IGNITION SWITCH OUTPUT (RUN-ACC) 29 T16 16YL/OR (A/T) TRANSMISSION CONTROL RELAY OUTPUT 30 A919 18RD FUSED B(+) 31 - - 32 A904 12RD/LB FUSED B(+) 33 - - 34 - - 35 L62 18WT/OR RIGHT REAR TURN SIGNAL CONTROL 36 - - 37 - - 38 F901 16PK IGNITION SWITCH OUTPUT (RUN) 39 Z921 14BK GROUND 40 A927 12RD/OR FUSED B(+)

Integrated Power Module Connector End View (C5)

MODULE-INTEGRATED POWER C5 - 40 WAY CAV CIRCUIT FUNCTION 1 - - 2 F982 12PK/YL IGNITION SWITCH OUTPUT (RUN-ACC) 3 - - 4 C16 20DB/GY (EBL) FUSED REAR WINDOW DEFOGGER RELAY OUTPUT 5 - - 6 - - 7 F983 20PK/YL FUSED IGNITION SWITCH OUTPUT (RUN-ACC) 8 F504 20GY/PK FUSED IGNITION SWITCH OUTPUT (RUN) 9 T750 14YL/GY STARTER RELAY OUTPUT 10 F525 18TN/PK FUSED IGNITION SWITCH OUTPUT (RUN) 11 - - 12 F100 20PK/VT FUSED IGNITION SWITCH OUTPUT (RUN) 13 - - 14 - - 15 - - 16 Z902 14BK GROUND 17 - - 18 - - 19 - - 20 - - 21 - - 22 - - 23 - - 24 F500 20DG/PK FUSED IGNITION SWITCH OUTPUT (RUN) 25 W4 14BR/OR FRONT WIPER HIGH/LOW RELAY HIGH SPEED OUTPUT 26 Z909 20BK GROUND 27 L1 18WT/LG BACK-UP LAMP FEED 28 T315 14YL/BR SHIFT MOTOR CONTROL A 29 T316 14YL/GY SHIFT MOTOR CONTROL B 30 - - 31 - - 32 W3 14BR/WT FRONT WIPER HIGH/LOW RELAY LOW SPEED OUTPUT 33 - - 34 - - 35 - - 36 - - 37 L63 18WT/DG LEFT REAR TURN SIGNAL CONTROL 38 - - 39 Z118 18BK/YL GROUND 40 F921 12PK/WT FUSED IGNITION SWITCH OUTPUT (RUN)

Integrated Power Module Connector End View

MODULE-INTEGRATED POWER EYELET - 1 WAY CAV CIRCUIT FUNCTION L1 A1 04RD B(+)

Occupant Classification Module Connector End View (C1)

MODULE-OCCUPANT CLASSIFICATION C1 - 10 WAY CAV CIRCUIT FUNCTION 1 A956 20RD FUSED B(+) 2 F201 20PK/OR FUSED IGNITION SWITCH OUTPUT (RUN-START) 3 - - 4 D55 20WT/OR CAN B BUS(+) 5 D54 20WT CAN B BUS(-) 6 - - 7 R263 20LB/VT DRIVER SEAT POSITION SENSOR VOLTAGE 8 - - 9 R261 20LB/WT DRIVER SEAT POSITION SENSOR DATA 10 Z917 20BK GROUND

Occupant Classification Module Connector End View (C2)

MODULE-OCCUPANT CLASSIFICATION C2 - BLACK 12 WAY CAV CIRCUIT FUNCTION 1 R701 20LG SEAT WEIGHT SENSOR 5 VOLT 2 R264 20VT/LB PASSENGER SEAT POSITION SENSOR VOLTAGE 3 R717 20LG/DG SEAT WEIGHT LEFT FRONT SENSOR SIGNAL 4 - - 5 R718 20LB/DG SEAT WEIGHT RIGHT FRONT SENSOR SIGNAL 6 - - 7 R706 20LB/OR SEAT WEIGHT RIGHT REAR SENSOR SIGNAL 8 - - 9 R705 20LG/OR SEAT WEIGHT LEFT REAR SENSOR SIGNAL 10 - - 11 R262 20WT/LB PASSENGER SEAT POSITION SENSOR DATA 12 R728 20LB/YL SEAT WEIGHT SENSOR GROUND

Scheme 39

Occupant Restraint Controller Module Connector End View (C1)

MODULE-OCCUPANT RESTRAINT CONTROLLER C1 - 32 WAY CAV CIRCUIT FUNCTION 1 R53 20LG/YL DRIVER SEAT BELT TENSIONER LINE 2 2 R55 20LG/DG DRIVER SEAT BELT TENSIONER LINE 1 3 R56 20LB/DG PASSENGER SEAT BELT TENSIONER LINE 1 4 R54 20LB/YL PASSENGER SEAT BELT TENSIONER LINE 2 5 - - 6 - - 7 - - 8 - - 9 - - 10 - - 11 - - 12 - - 13 - - 14 - - 15 R13 20LG/VT (SIDE AIRBAG) LEFT SIDE IMPACT SENSOR 1 SIGNAL 16 R16 20BR/LG (SIDE AIRBAG) RIGHT SIDE IMPACT SENSOR 1 GROUND 17 - - 18 - - 19 R15 20LG/BR (SIDE AIRBAG) LEFT SIDE IMPACT SENSOR 1 GROUND 20 Z104 20BK/LG GROUND 21 - - 22 - - 23 - - 24 R14 20TN/LG (SIDE AIRBAG) RIGHT SIDE IMPACT SENSOR 1 SIGNAL 25 R1 20LB/BR (SIDE AIRBAG) LEFT CURTAIN SQUIB 1 LINE 2 26 R3 20LB/OR (SIDE AIRBAG) LEFT CURTAIN SQUIB 1 LINE 1 27 R4 20OR/LB (SIDE AIRBAG) RIGHT CURTAIN SQUIB 1 LINE 1 28 R2 20WT/LB (SIDE AIRBAG) RIGHT CURTAIN SQUIB 1 LINE 2 29 - - 30 - - 31 - - 32

Occupant Restraint Controller Module Connector End View (C2)

MODULE-OCCUPANT RESTRAINT CONTROLLER C2 - 32 WAY CAV CIRCUIT FUNCTION 1 R43 20LG/BR DRIVER SQUIB 1 LINE 2 2 R45 20LG/OR DRIVER SQUIB 1 LINE 1 3 R63 20LG/WT DRIVER SQUIB 2 LINE 1 4 R61 20LG/VT DRIVER SQUIB 2 LINE 2 5 R42 20LB/BR PASSENGER SQUIB 1 LINE 2 6 R44 20LB/OR PASSENGER SQUIB 1 LINE 1 7 R64 20LB/WT PASSENGER SQUIB 2 LINE 1 8 R62 20LB/VT PASSENGER SQUIB 2 LINE 2 9 G104 20VT/GY PASSENGER AIRBAG INDICATOR DRIVER 10 - - 11 - - 12 R82 20WT/LB RIGHT FRONT IMPACT SENSOR GROUND 13 - - 14 - - 15 D55 20WT/OR CAN B BUS(+) 16 F201 20PK/OR FUSED IGNITION SWITCH OUTPUT (RUN-START) 17 - - 18 - - 19 R104 20LB/LG PASSENGER AIRBAG MUX SWITCH RETURN 20 R81 20LB/WT LEFT FRONT IMPACT SENSOR GROUND 21 - - 22 - - 23 D54 20WT CAN B BUS(-) 24 F100 20PK/VT FUSED IGNITION SWITCH OUTPUT (RUN) 25 R79 20LB/VT LEFT FRONT IMPACT SENSOR SIGNAL 26 R80 20VT/LB RIGHT FRONT IMPACT SENSOR SIGNAL 27 R106 20LG/LB PASSENGER AIRBAG MUX SWITCH SENSE 28 - - 29 - - 30 - - 31 - - 32

Powertrain Control Module (3.7L) Connector End View (C1)

MODULE-POWERTRAIN CONTROL C1 (3.7L) - BLACK/BLACK 38 WAY CAV CIRCUIT FUNCTION 1 - - 2 - - 3 - - 4 - - 5 - - 6 - - 7 - - 8 - - 9 Z913 16BK GROUND 10 - - 11 F202 20PK/GY FUSED IGNITION SWITCH OUTPUT (RUN-START) 12 F1 20PK/WT FUSED IGNITION SWITCH OUTPUT (RUN-START) 13 - - 14 - - 15 - - 16 - - 17 - - 18 Z937 16BK GROUND 19 - - 20 G6 18VT/GY ENGINE OIL PRESSURE SIGNAL 21 - - 22 - - 23 - - 24 - - 25 D20 20WT/LG SCI RECEIVE (PCM) 26 D16 20WT/OR SCI RECEIVE (TCM) 27 F856 20YL/PK 5 VOLT SUPPLY 28 - - 29 A919 18RD FUSED B(+) 30 F924 20PK/YL FUSED IGNITION SWITCH OUTPUT (RUN) 31 K141 18DB/YL O2 1/2 SIGNAL 32 K902 20BR/DG O2 RETURN (UPSTREAM) 33 K243 20BR O2 2/2 SIGNAL 34 D65 20WT/LG CAN C BUS(+) 35 D64 20WT/LB CAN C BUS(-) 36 D21 20WT/GY SCI TRANSMIT (PCM) 37 D15 20BR/WT (A/T) SCI TRANSMIT (TCM) 38

Powertrain Control Module (4.7L) Connector End View (C1)

MODULE-POWERTRAIN CONTROL C1 (4.7L) - BLACK/BLACK 38 WAY CAV CIRCUIT FUNCTION 1 K98 18DB/YL COIL CONTROL NO. 8 2 - - 3 K97 18BR COIL CONTROL NO. 7 4 K28 18BR/LB INJECTOR CONTROL NO. 8 5 K26 18BR/YL INJECTOR CONTROL NO. 7 6 - - 7 - - 8 - - 9 Z913 16BK GROUND 10 - - 11 F202 20PK/GY FUSED IGNITION SWITCH OUTPUT (RUN-START) 12 F1 20PK/WT FUSED IGNITION SWITCH OUTPUT (RUN-START) 13 - - 14 - - 15 - - 16 - - 17 - - 18 Z937 16BK GROUND 19 - - 20 G6 18VT/GY ENGINE OIL PRESSURE SIGNAL 21 - - 22 - - 23 - - 24 - - 25 D20 20WT/LG SCI RECEIVE (PCM) 26 D16 20WT/OR SCI RECEIVE (TCM) 27 F856 20YL/PK 5 VOLT SUPPLY 28 - - 29 A919 18RD FUSED B(+) 30 F924 20PK/YL FUSED IGNITION SWITCH OUTPUT (RUN) 31 K141 18DB/YL O2 1/2 SIGNAL 32 K902 20BR/DG O2 RETURN (UPSTREAM) 33 K243 20BR O2 2/2 SIGNAL 34 D65 20WT/LG CAN C BUS(+) 35 D64 20WT/LB CAN C BUS(-) 36 D21 20WT/GY SCI TRANSMIT (PCM) 37 D15 20BR/WT (A/T) SCI TRANSMIT (TCM) 38

Powertrain Control Module (4.7L) Connector End View (C2)

MODULE-POWERTRAIN CONTROL C2 (4.7L) - BLACK/ORANGE 38 WAY CAV CIRCUIT FUNCTION 1 K10 18DB/OR COIL CONTROL NO. 6 2 K16 18DB/YL COIL CONTROL NO. 5 3 K15 18DB COIL CONTROL NO. 4 4 K58 18BR/VT INJECTOR CONTROL NO. 6 5 K38 18BR/OR INJECTOR CONTROL NO. 5 6 - - 7 K18 18DB/OR COIL CONTROL NO. 3 8 K35 20DB/VT EGR SOL CONTROL 9 K17 18DB/TN COIL CONTROL NO. 2 10 K19 18DB/DG COIL CONTROL NO. 1 11 K14 18BR/TN INJECTOR CONTROL NO. 4 12 K13 18BR/LB INJECTOR CONTROL NO. 3 13 K12 18BR/DB INJECTOR CONTROL NO. 2 14 K11 18BR/YL INJECTOR CONTROL NO. 1 15 - - 16 - - 17 K199 18BR/VT O2 2/1 HEATER CONTROL 18 K99 18BR/TN O2 1/1 HEATER CONTROL 19 K20 18BR/GY GEN FIELD CONTROL 20 K2 20VT/OR ECT SIGNAL 21 K22 20BR/OR TP NO. 1 SIGNAL 22 K34 20DB/LG EGR SIGNAL 23 K1 20VT/BR MAP SIGNAL 24 K942 20BR/LG KNOCK SENSOR NO. 1 RETURN 25 K42 20DB/OR KNOCK SENSOR NO. 1 SIGNAL 26 - - 27 K900 20DB/DG SENSOR GROUND 28 K961 20BR/VT IAC SIGNAL 29 F855 20PK/YL 5 VOLT SUPPLY 30 K21 20BR/WT IAT SIGNAL 31 K41 20DB/LB O2 1/1 SIGNAL 32 K904 20DB/DG O2 RETURN (DOWNSTREAM) 33 K43 20DB/LG O2 2/1 SIGNAL 34 K44 20DB/GY CMP SIGNAL 35 K24 20BR/LB CKP SIGNAL 36 K242 20BR/WT KNOCK SENSOR NO. 2 SIGNAL 37 K924 20PK/RD KNOCK SENSOR NO. 2 RETURN 38 K61 20VT/GY IAC CONTROL

Scheme 40

Powertrain Control Module (3.7L) Connector End View (C2)

MODULE-POWERTRAIN CONTROL C2 (3.7L) - BLACK/ORANGE 38 WAY CAV CIRCUIT FUNCTION 1 K10 18DB/OR COIL CONTROL NO. 6 2 K16 18DB/YL COIL CONTROL NO. 5 3 K15 18DB COIL CONTROL NO. 4 4 K58 18BR/VT INJECTOR CONTROL NO. 6 5 K38 18BR/OR INJECTOR CONTROL NO. 5 6 - - 7 K18 18DB/OR COIL CONTROL NO. 3 8 - - 9 K17 18DB/TN COIL CONTROL NO. 2 10 K19 18DB/DG COIL CONTROL NO. 1 11 K14 18BR/TN INJECTOR CONTROL NO. 4 12 K13 18BR/LB INJECTOR CONTROL NO. 3 13 K12 18BR/DB INJECTOR CONTROL NO. 2 14 K11 18BR/YL INJECTOR CONTROL NO. 1 15 - - 16 - - 17 K199 18BR/VT O2 2/1 HEATER CONTROL 18 K99 18BR/TN O2 1/1 HEATER CONTROL 19 K20 18BR/GY GEN FIELD CONTROL 20 K2 20VT/OR ECT SIGNAL 21 K22 20BR/OR TP NO. 1 SIGNAL 22 - - 23 K1 20VT/BR MAP SIGNAL 24 K942 20BR/LG KNOCK SENSOR NO. 1 RETURN 25 K42 20DB/OR KNOCK SENSOR NO. 1 SIGNAL 26 - - 27 K900 20DB/DG SENSOR GROUND 28 K961 20BR/VT IAC SIGNAL 29 F855 20PK/YL 5 VOLT SUPPLY 30 K21 20BR/WT IAT SIGNAL 31 K41 20DB/LB O2 1/1 SIGNAL 32 K904 20DB/DG O2 RETURN (DOWNSTREAM) 33 K43 20DB/LG O2 2/1 SIGNAL 34 K44 20DB/GY CMP SIGNAL 35 K24 20BR/LB CKP SIGNAL 36 K242 20BR/WT KNOCK SENSOR NO. 2 SIGNAL 37 K924 20PK/RD KNOCK SENSOR NO. 2 RETURN 38 K61 20VT/GY IAC CONTROL

Powertrain Control Module Connector End View (C3)

MODULE-POWERTRAIN CONTROL C3 - BLACK/NATURAL 38 WAY CAV CIRCUIT FUNCTION 1 - - 2 - - 3 K51 20BR/GY ASD RELAY CONTROL 4 - - 5 V35 20VT/OR S/C VENT SOL CONTROL 6 - - 7 V32 20VT/YL S/C SUPPLY 8 K106 20VT/LB NVLD SOL CONTROL 9 K299 18BR/OR O2 1/2 HEATER CONTROL 10 K399 18BR/GY O2 2/2 HEATER CONTROL 11 C13 20LB/OR A/C CLUTCH RELAY CONTROL 12 V36 20VT/YL S/C VACUUM SOL CONTROL 13 - - 14 - - 15 - - 16 - - 17 - - 18 - - 19 A955 16RD ASD RELAY OUTPUT 20 K52 20DB/WT EVAP PURGE SOL CONTROL 21 T41 20YL/DB (A/T) TRS T41 SENSE (P/N SENSE) 21 T141 20YL/OR (M/T) TRS T141 SENSE (P/N SENSE) 22 - - 23 B29 20DG/WT BRAKE SWITCH SIGNAL 24 - - 25 - - 26 - - 27 - - 28 A955 16RD ASD RELAY OUTPUT 29 K70 20DB/BR EVAP PURGE SOL SIGNAL 30 - - 31 - - 32 - - 33 - - 34 V37 20VT S/C SWITCH NO. 1 SIGNAL 35 K107 20VT/WT NVLD SWITCH SIGNAL 36 - - 37 K31 20BR FUEL PUMP RELAY CONTROL 38 T752 20DG/OR STARTER RELAY CONTROL

Scheme 41

Powertrain Control Module (545RFE) Connector End View (C4)

MODULE-POWERTRAIN CONTROL C4 (545RFE) - BLACK/GREEN 38 WAY CAV CIRCUIT FUNCTION 1 T60 20YL/RD OD SOLENOID CONTROL 2 T259 20YL/DG 4C SOLENOID CONTROL 3 - - 4 T140 20BR/YL MS SOLENOID CONTROL 5 - - 6 T219 20DG/YL 2C SOLENOID CONTROL 7 - - 8 T59 20VT/PK UD SOLENOID CONTROL 9 - - 10 T20 20DG/WT L/R SOLENOID CONTROL 11 T118 20DG PRESSURE CONTROL SOLENOID CONTROL 12 Z908 16BK GROUND 13 Z977 16BK GROUND 14 Z904 20BK GROUND 15 T1 20YL/PK TRS T1 SENSE 16 T3 20YL/PK TRS T3 SENSE 17 T6 20DG TOW/HAUL OVERDRIVE OFF SWITCH SENSE 18 T15 20YL/BK TRANSMISSION CONTROL RELAY CONTROL 19 T16 16YL/OR TRANSMISSION CONTROL RELAY OUTPUT 20 T48 20BR/YL 4C PRESSURE SWITCH SENSE 21 T29 20LB/RD UD PRESSURE SWITCH SENSE 22 T9 20DG/TN OD PRESSURE SWITCH SENSE 23 - - 24 - - 25 - - 26 T4 20BR/YL TRS T2 SENSE 27 - - 28 T16 16YL/OR TRANSMISSION CONTROL RELAY OUTPUT 29 T50 20VT/RD L/R PRESSURE SWITCH SENSE 30 T147 20BR/YL 2C PRESSURE SWITCH SENSE 31 T38 20YL/BR LINE PRESSURE SENSOR SIGNAL 32 T14 20YL/PK OUTPUT SPEED SENSOR SIGNAL 33 T52 20YL/PK INPUT SPEED SENSOR SIGNAL 34 T13 20DG/VT SENSOR GROUND 35 T54 20YL/PK TRANSMISSION TEMPERATURE SENSOR SIGNAL 36 - - 37 T42 20YL/PK TRS T42 SENSE 38 T16 16YL/OR TRANSMISSION CONTROL RELAY OUTPUT

Powertrain Control Module (42RLE) Connector End View (C4)

MODULE-POWERTRAIN CONTROL C4 (42RLE) - BLACK/GREEN 38 WAY CAV CIRCUIT FUNCTION 1 T60 20YL/RD OD SOLENOID CONTROL 2 T59 20VT/PK UD SOLENOID CONTROL 3 - - 4 - - 5 - - 6 T19 20YL/DB 2-4 SOLENOID CONTROL 7 - - 8 - - 9 - - 10 T20 20DG/WT L/R SOLENOID CONTROL 11 - - 12 Z908 16BK GROUND 13 Z977 16BK GROUND 14 Z904 20BK GROUND 15 T1 20YL/PK TRS T1 SENSE 16 T3 20YL/PK TRS T3 SENSE 17 T6 20DG TOW/HAUL OVERDRIVE OFF SWITCH SENSE 18 T15 20YL/BK TRANSMISSION CONTROL RELAY CONTROL 19 T16 16YL/OR TRANSMISSION CONTROL RELAY OUTPUT 20 - - 21 - - 22 T9 20DG/TN OD PRESSURE SWITCH SENSE 23 - - 24 - - 25 - - 26 - - 27 - - 28 T16 16YL/OR TRANSMISSION CONTROL RELAY OUTPUT 29 T50 20VT/RD L/R PRESSURE SWITCH SENSE 30 T47 20YL/DG 2-4 PRESSURE SWITCH SENSE 31 - - 32 T14 20YL/PK OUTPUT SPEED SENSOR SIGNAL 33 T52 20YL/PK INPUT SPEED SENSOR SIGNAL 34 T13 20DG/VT SENSOR GROUND 35 T54 20YL/PK TRANSMISSION TEMPERATURE SENSOR SIGNAL 36 - - 37 T42 20YL/PK TRS T42 SENSE 38 T16 16YL/OR TRANSMISSION CONTROL RELAY OUTPUT

Sentry Key Remote Entry Module Connector End View

MODULE-SENTRY KEY REMOTE ENTRY - 8 WAY CAV CIRCUIT FUNCTION 1 - - 2 - - 3 F202 20PK/GY FUSED IGNITION SWITCH OUTPUT (RUN-START) 4 Z109 20BK/GY GROUND 5 A918 18RD/LB FUSED B(+) 6 D55 20WT/OR CAN B BUS(+) 7 D54 20WT CAN B BUS(-) 8

Blower Motor Connector End View

MOTOR-BLOWER - 2 WAY CAV CIRCUIT FUNCTION 1 C70 12DB/YL BLOWER MOTOR DRIVER 2 C7 12DB BLOWER MOTOR SUPPLY

Idle Air Control Motor Connector End View

MOTOR-IAC - 2 WAY CAV CIRCUIT FUNCTION 1 K961 20BR/VT IAC SIGNAL 2 K61 20VT/GY IAC CONTROL

Scheme 42

Left Front Window Motor Connector End View

MOTOR-WINDOW-LEFT FRONT - 2 WAY CAV CIRCUIT FUNCTION A Q21 14OR/WT DRIVER WINDOW DRIVER DOWN B Q11 14OR/LG DRIVER WINDOW DRIVER UP

Scheme 43

Left Rear Window Motor (Quad Cab/Power Convenience) Connector End View

MOTOR-WINDOW-LEFT REAR (QUAD CAB/POWER CONVENIENCE) - 2 WAY CAV CIRCUIT FUNCTION A Q211 14TN/LB LEFT REAR WINDOW DRIVER (DOWN) B Q111 14TN/YL LEFT REAR WINDOW DRIVER (UP)

Scheme 44

Right Front Window Motor Connector End View

MOTOR-WINDOW-RIGHT FRONT - 2 WAY CAV CIRCUIT FUNCTION A Q22 14OR/VT PASSENGER WINDOW DRIVER DOWN B Q12 14OR/BR PASSENGER WINDOW DRIVER UP

Right Rear Window Motor (Quad Cab/Power Convenience) Connector End View

MOTOR-WINDOW-RIGHT REAR (QUAD CAB/POWER CONVENIENCE) - 2 WAY CAV CIRCUIT FUNCTION A Q212 14OR/VT RIGHT REAR WINDOW DRIVER (DOWN) B Q112 14OR/BR RIGHT REAR WINDOW DRIVER (UP)

Windshield Wiper Motor Connector End View

MOTOR-WINDSHIELD WIPER - 6 WAY CAV CIRCUIT FUNCTION 1 - - 2 W7 20BR/GY FRONT WIPER PARK SWITCH SENSE 3 - - 4 Z103 14BK/WT GROUND 5 W3 14BR/WT FRONT WIPER HIGH/LOW RELAY LOW SPEED OUTPUT 6 W4 14BR/OR FRONT WIPER HIGH/LOW RELAY HIGH SPEED OUTPUT

Power Console Outlet Connector End View

POWER OUTLET-CONSOLE - 3 WAY CAV CIRCUIT FUNCTION 1 A12 16RD/TN FUSED B(+) 2 - - 3 Z1 16BK GROUND

Power Instrument Panel Outlet Connector End View

POWER OUTLET-INSTRUMENT PANEL - 3 WAY CAV CIRCUIT FUNCTION 1 F306 18DB/PK FUSED B(+) 2 - - 3 Z959 18BK GROUND

Scheme 45

Windshield Washer Pump Connector End View

PUMP-WASHER-WINDSHIELD - 2 WAY CAV CIRCUIT FUNCTION 1 W10 18BR FRONT WASHER PUMP MOTOR CONTROL 2 Z243 18BK GROUND

Scheme 46

Radio Connector End View (C1)

RADIO C1 - 22 WAY CAV CIRCUIT FUNCTION 1 A920 18RD/BK FUSED B(+) 2 - - 3 - - 4 X716 20GY/TN (HANDS FREE) CNV-HANDS FREE VOICE (+) 5 D55 20WT/OR CAN B BUS(+) 6 D54 20WT CAN B BUS(-) 7 X54 18GY (BASE) RADIO-RIGHT FRONT AUDIO (+) 8 X56 18GY/BR (BASE) RADIO-RIGHT FRONT AUDIO (-) 9 X55 20DG/BR (BASE) RADIO-LEFT FRONT AUDIO (-) 10 X53 20DG (BASE) RADIO-LEFT FRONT AUDIO (+) 11 Z514 16BK/LG GROUND 12 A920 18RD/BK FUSED B(+) 13 - - 14 - - 15 - - 16 X776 20TN/GY (HANDS FREE) CNV-HANDS FREE VOICE (-) 17 X795 20DG (HANDS FREE) COMMON AUDIO OUTPUT 18 X51 18DG/DB RADIO-LEFT REAR AUDIO (+) 19 X57 18DG/OR RADIO-LEFT REAR AUDIO (-) 20 X58 18GY/OR RADIO-RIGHT REAR AUDIO (-) 21 X52 18GY/DB RADIO-RIGHT REAR AUDIO (+) 22 Z515 16BK GROUND

Scheme 47

Radio (Satellite Radio) Connector End View (C2)

RADIO C2 (SATELLITE RADIO) - 10 WAY CAV CIRCUIT FUNCTION 1 X16 20DG/LB AUDIO SIGNAL RIGHT (+) 2 X917 20DG AUDIO SIGNAL COMMON 3 - - 4 - - 5 - - 6 X17 20DG/OR AUDIO SIGNAL LEFT (+) 7 - - 8 - - 9 - - 10

Satellite Receiver Connector End View

RECEIVER-SATELLITE - 12 WAY CAV CIRCUIT FUNCTION 1 A920 18RD/BK FUSED B(+) 2 - - 3 Z960 20BK/DB GROUND 4 - - 5 - - 6 X17 20DG/OR AUDIO SIGNAL LEFT (+) 7 D54 20WT CAN B BUS(-) 8 D55 20WT/OR CAN B BUS(+) 9 - - 10 - - 11 X917 20DG AUDIO SIGNAL COMMON 12 X16 20DG/LB AUDIO SIGNAL RIGHT (+)

Scheme 48

Blower Motor Resistor Connector End View

RESISTOR-BLOWER MOTOR - 5 WAY CAV CIRCUIT FUNCTION 1 C75 12DB/GY BLOWER MOTOR HIGH SPEED 2 C70 12DB/YL BLOWER MOTOR DRIVER 3 C73 14DB/VT BLOWER MOTOR M2 SPEED 4 C72 14DB/OR BLOWER MOTOR M1 SPEED 5 C71 16DB/BR BLOWER MOTOR LOW SPEED

Driver Seat Belt Tensioner Connector End View

SEAT BELT-TENSIONER-DRIVER - 2 WAY CAV CIRCUIT FUNCTION 1 R53 20LG/YL DRIVER SEAT BELT TENSIONER LINE 2 2 R55 20LG/DG DRIVER SEAT BELT TENSIONER LINE 1

Passenger Seat Belt Tensioner Connector End View

SEAT BELT-TENSIONER-PASSENGER - 2 WAY CAV CIRCUIT FUNCTION 1 R54 20LB/YL PASSENGER SEAT BELT TENSIONER LINE 2 2 R56 20LB/DG PASSENGER SEAT BELT TENSIONER LINE 1

Ambient Air Temperature Sensor Connector End View

SENSOR-AMBIENT AIR TEMPERATURE - 2 WAY CAV CIRCUIT FUNCTION 1 G31 20VT/OR AAT SIGNAL 2 G931 20VT/BR SENSOR GROUND

Scheme 49

Battery Temperature Sensor Connector End View

SENSOR-BATTERY TEMPERATURE - 2 WAY CAV CIRCUIT FUNCTION 1 K25 20DB/VT BATT TEMP SIGNAL 2 K91 20DB/YL BATT TEMP RETURN

Camshaft Position Sensor Connector End View

SENSOR-CAMSHAFT POSITION - 3 WAY CAV CIRCUIT FUNCTION 1 K44 20DB/GY CMP SIGNAL 2 K900 20DB/DG SENSOR GROUND 3 F856 20YL/PK 5 VOLT SUPPLY

Scheme 50

Crankshaft Position Sensor (3.7L) Connector End View

SENSOR-CRANKSHAFT POSITION (3.7L) - 3 WAY CAV CIRCUIT FUNCTION 1 K24 20BR/LB CKP SIGNAL 2 K900 20DB/DG SENSOR GROUND 3 F855 20PK/YL 5 VOLT SUPPLY

Scheme 51

Crankshaft Position Sensor (4.7L) Connector End View

SENSOR-CRANKSHAFT POSITION (4.7L) - 3 WAY CAV CIRCUIT FUNCTION 1 K24 20BR/LB CKP SIGNAL 2 K900 20DB/DG SENSOR GROUND 3 F855 20PK/YL 5 VOLT SUPPLY

Engine Coolant Temperature Sensor Connector End View

SENSOR-ENGINE COOLANT TEMPERATURE - 2 WAY CAV CIRCUIT FUNCTION 1 K2 20VT/OR ECT SIGNAL 2 K900 20DB/DG SENSOR GROUND

Scheme 52

Evaporator Temperature Sensor Connector End View

SENSOR-EVAPORATOR TEMPERATURE - 2 WAY CAV CIRCUIT FUNCTION 1 C21 20DB/LG EVAPORATOR TEMPERATURE SENSOR SIGNAL 2 C121 20DB/DG SENSOR GROUND

Left Front Impact Sensor Connector End View

SENSOR-FRONT IMPACT-LEFT - 2 WAY CAV CIRCUIT FUNCTION 1 R81 20LB/WT LEFT FRONT IMPACT SENSOR GROUND 2 R79 20LB/VT LEFT FRONT IMPACT SENSOR SIGNAL

Right Front Impact Sensor Connector End View

SENSOR-FRONT IMPACT-RIGHT - 2 WAY CAV CIRCUIT FUNCTION 1 R82 20WT/LB RIGHT FRONT IMPACT SENSOR GROUND 2 R80 20VT/LB RIGHT FRONT IMPACT SENSOR SIGNAL

Input Speed Sensor (A/T) Connector End View

SENSOR-INPUT SPEED (A/T) - 2 WAY CAV CIRCUIT FUNCTION 1 T52 20YL/PK INPUT SPEED SENSOR SIGNAL 2 T13 20DG/VT SENSOR GROUND

Intake Air Temperature Sensor Connector End View

SENSOR-INTAKE AIR TEMPERATURE - 2 WAY CAV CIRCUIT FUNCTION 1 K21 20BR/WT IAT SIGNAL 2 K900 20DB/DG SENSOR GROUND

Knock Sensor Connector End View

SENSOR-KNOCK - 4 WAY CAV CIRCUIT FUNCTION 1 K42 20DB/OR KNOCK SENSOR NO. 1 SIGNAL 2 K942 20BR/LG KNOCK SENSOR NO. 1 RETURN 3 K242 20BR/WT KNOCK SENSOR NO. 2 SIGNAL 4 K924 20PK/RD KNOCK SENSOR NO. 2 RETURN

Scheme 53

Line Pressure Sensor (4.7L A/T) Connector End View

SENSOR-LINE PRESSURE (4.7L A/T) - 4 WAY CAV CIRCUIT FUNCTION 1 K900 20DB/DG SENSOR GROUND 2 F856 20YL/PK 5 VOLT SUPPLY 3 T38 20YL/BR LINE PRESSURE SENSOR SIGNAL 4

Scheme 54

Map Sensor Connector End View

SENSOR-MAP - 3 WAY CAV CIRCUIT FUNCTION 1 K1 20VT/BR MAP SIGNAL 2 K900 20DB/DG SENSOR GROUND 3 F856 20YL/PK 5 VOLT SUPPLY

Output Speed Sensor (A/T) Connector End View

SENSOR-OUTPUT SPEED (A/T) - 2 WAY CAV CIRCUIT FUNCTION 1 T14 20YL/PK OUTPUT SPEED SENSOR SIGNAL 2 T13 20DG/VT SENSOR GROUND

Left Front Oxygen Sensor (3.7L) Connector End View

SENSOR-OXYGEN-LEFT FRONT (3.7L) - 4 WAY CAV CIRCUIT FUNCTION 1 K99 18BR/TN O2 1/1 HEATER CONTROL 2 Z43 18BK/LB GROUND 3 K902 20BR/DG O2 RETURN (UPSTREAM) 4 K41 20DB/LB O2 1/1 SIGNAL

Scheme 55

Left Front Oxygen Sensor (4.7L) Connector End View

SENSOR-OXYGEN-LEFT FRONT (4.7L) - 4 WAY CAV CIRCUIT FUNCTION 1 K99 18BR/TN O2 1/1 HEATER CONTROL 2 Z43 18BK/LB GROUND 3 K902 20BR/DG O2 RETURN (UPSTREAM) 4 K41 20DB/LB O2 1/1 SIGNAL

Left Rear Oxygen Sensor (3.7L) Connector End View

SENSOR-OXYGEN-LEFT REAR (3.7L) - 4 WAY CAV CIRCUIT FUNCTION 1 K299 18BR/OR O2 1/2 HEATER CONTROL 2 Z42 18BK/LG GROUND 3 K904 20DB/DG O2 RETURN (DOWNSTREAM) 4 K141 18DB/YL O2 1/2 SIGNAL

Left Rear Oxygen Sensor (4.7L) Connector End View

SENSOR-OXYGEN-LEFT REAR (4.7L) - 4 WAY CAV CIRCUIT FUNCTION 1 K299 18BR/OR O2 1/2 HEATER CONTROL 2 Z42 18BK/LG GROUND 3 K904 20DB/DG O2 RETURN (DOWNSTREAM) 4 K141 18DB/YL O2 1/2 SIGNAL

Right Front Oxygen Sensor (3.7L) Connector End View

SENSOR-OXYGEN-RIGHT FRONT (3.7L) - 4 WAY CAV CIRCUIT FUNCTION 1 K199 18BR/VT O2 2/1 HEATER CONTROL 2 Z934 18BK GROUND 3 K902 20BR/DG O2 RETURN (UPSTREAM) 4 K43 20DB/LG O2 2/1 SIGNAL

Right Front Oxygen Sensor (4.7L) Connector End View

SENSOR-OXYGEN-RIGHT FRONT (4.7L) - 4 WAY CAV CIRCUIT FUNCTION 1 K199 18BR/VT O2 2/1 HEATER CONTROL 2 Z934 18BK GROUND 3 K902 20BR/DG O2 RETURN (UPSTREAM) 4 K43 20DB/LG O2 2/1 SIGNAL

Right Rear Oxygen Sensor (3.7L) Connector End View

SENSOR-OXYGEN-RIGHT REAR (3.7L) - 4 WAY CAV CIRCUIT FUNCTION 1 K399 18BR/GY O2 2/2 HEATER CONTROL 2 Z992 18BK GROUND 3 K904 20DB/DG O2 RETURN (DOWNSTREAM) 4 K243 20BR O2 2/2 SIGNAL

Right Rear Oxygen Sensor (4.7L) Connector End View

SENSOR-OXYGEN-RIGHT REAR (4.7L) - 4 WAY CAV CIRCUIT FUNCTION 1 K399 18BR/GY O2 2/2 HEATER CONTROL 2 Z992 18BK GROUND 3 K904 20DB/DG O2 RETURN (DOWNSTREAM) 4 K243 20BR O2 2/2 SIGNAL

Driver Seat Track Position Sensor Connector End View

SENSOR-SEAT TRACK POSITION-DRIVER - 2 WAY CAV CIRCUIT FUNCTION 1 R261 20LB/WT DRIVER SEAT POSITION SENSOR DATA 2 R263 20LB/VT DRIVER SEAT POSITION SENSOR VOLTAGE

Passenger Seat Track Position Sensor Connector End View

SENSOR-SEAT TRACK POSITION-PASSENGER - 2 WAY CAV CIRCUIT FUNCTION 1 R262 20WT/LB PASSENGER SEAT POSITION SENSOR DATA 2 R264 20VT/LB PASSENGER SEAT POSITION SENSOR VOLTAGE

Left Front Seat Weight Sensor Connector End View

SENSOR-SEAT WEIGHT-LEFT FRONT - 4 WAY CAV CIRCUIT FUNCTION 1 R701 20LG SEAT WEIGHT SENSOR 5 VOLT 2 R728 20LB/YL SEAT WEIGHT SENSOR GROUND 3 - - 4 R717 20LG/DG SEAT WEIGHT LEFT FRONT SENSOR SIGNAL

Left Rear Seat Weight Sensor Connector End View

SENSOR-SEAT WEIGHT-LEFT REAR - 4 WAY CAV CIRCUIT FUNCTION 1 R701 20LG SEAT WEIGHT SENSOR 5 VOLT 2 R728 20LB/YL SEAT WEIGHT SENSOR GROUND 3 - - 4 R705 20LG/OR SEAT WEIGHT LEFT REAR SENSOR SIGNAL

Right Front Seat Weight Sensor Connector End View

SENSOR-SEAT WEIGHT-RIGHT FRONT - 4 WAY CAV CIRCUIT FUNCTION 1 R701 20LG SEAT WEIGHT SENSOR 5 VOLT 2 R728 20LB/YL SEAT WEIGHT SENSOR GROUND 3 - - 4 R718 20LB/DG SEAT WEIGHT RIGHT FRONT SENSOR SIGNAL

Right Rear Seat Weight Sensor Connector End View

SENSOR-SEAT WEIGHT-RIGHT REAR - 4 WAY CAV CIRCUIT FUNCTION 1 R701 20LG SEAT WEIGHT SENSOR 5 VOLT 2 R728 20LB/YL SEAT WEIGHT SENSOR GROUND 3 - - 4 R706 20LB/OR SEAT WEIGHT RIGHT REAR SENSOR SIGNAL

Left Side Impact Sensor 1 Connector End View

SENSOR-SIDE IMPACT-LEFT 1 - 2 WAY CAV CIRCUIT FUNCTION 1 R15 20LG/BR LEFT SIDE IMPACT SENSOR 1 GROUND 2 R13 20LG/VT LEFT SIDE IMPACT SENSOR 1 SIGNAL

Right Side Impact Sensor 1 Connector End View

SENSOR-SIDE IMPACT-RIGHT 1 - 2 WAY CAV CIRCUIT FUNCTION 1 R16 20BR/LG RIGHT SIDE IMPACT SENSOR 1 GROUND 2 R14 20TN/LG RIGHT SIDE IMPACT SENSOR 1 SIGNAL

Sun Sensor (Highline) Connector End View

SENSOR-SUN (HIGHLINE) - 4 WAY CAV CIRCUIT FUNCTION 1 - - 2 - - 3 G939 20VT/DB SUN SENSOR RETURN 4 G39 20VT/LB SUN SENSOR SIGNAL

Throttle Position Sensor (4.7L) Connector End View

SENSOR-THROTTLE POSITION (4.7L) - 3 WAY CAV CIRCUIT FUNCTION 1 F855 20PK/YL 5 VOLT SUPPLY 2 K22 20BR/OR TP NO. 1 SIGNAL 3 K900 20DB/DG SENSOR GROUND

Scheme 56

Throttle Position Sensor (3.7L) Connector End View

SENSOR-THROTTLE POSITION (3.7L) - 3 WAY CAV CIRCUIT FUNCTION 1 F855 20PK/YL 5 VOLT SUPPLY 2 K900 20DB/DG SENSOR GROUND 3 K22 20BR/OR TP NO. 1 SIGNAL

Transmission Range Sensor (3.7L A/T) Connector End View

SENSOR-TRANSMISSION RANGE (3.7L A/T) - 10 WAY CAV CIRCUIT FUNCTION 1 T16 16YL/OR TRANSMISSION CONTROL RELAY OUTPUT 2 - - 3 K900 20DB/DG SENSOR GROUND 4 T54 20YL/PK TRANSMISSION TEMPERATURE SENSOR SIGNAL 5 - - 6 - - 7 T1 20YL/PK TRS T1 SENSE 8 T3 20YL/PK TRS T3 SENSE 9 T42 20YL/PK TRS T42 SENSE 10 T41 20YL/DB TRS T41 SENSE (P/N SENSE)

Scheme 57

Left Front Wheel Speed Sensor (AWAL) Connector End View

SENSOR-WHEEL SPEED-ABS-LEFT FRONT (AWAL) - 2 WAY CAV CIRCUIT FUNCTION 1 B8 20DG/TN LEFT FRONT WHEEL SPEED SENSOR SIGNAL 2 B9 20DG/LG LEFT FRONT WHEEL SPEED SENSOR SUPPLY

Rear Wheel Speed Sensor Connector End View

SENSOR-WHEEL SPEED-ABS-REAR - 2 WAY CAV CIRCUIT FUNCTION 1 B22 20DG/YL REAR WHEEL SPEED SENSOR SIGNAL 2 B222 20DG/WT REAR WHEEL SPEED SENSOR SUPPLY

Right Front Wheel Speed Sensor (AWAL) Connector End View

SENSOR-WHEEL SPEED-ABS-RIGHT FRONT (AWAL) - 2 WAY CAV CIRCUIT FUNCTION 1 B6 20DG/WT RIGHT FRONT WHEEL SPEED SENSOR SIGNAL 2 B7 20DG/VT RIGHT FRONT WHEEL SPEED SENSOR SUPPLY

Scheme 58

Speed Control Servo Connector End View

SERVO-SPEED CONTROL - 4 WAY CAV CIRCUIT FUNCTION 1 V36 20VT/YL S/C VACUUM SOL CONTROL 2 V35 20VT/OR S/C VENT SOL CONTROL 3 V30 20VT/WT S/C BRAKE SWITCH OUTPUT 4 Z155 20BK/LG GROUND

Brake Transmission Shift Solenoid Connector End View

SOLENOID-BRAKE TRANSMISSION SHIFT - 2 WAY CAV CIRCUIT FUNCTION 1 B30 20DG/OR BTSI SOLENOID CONTROL 2 Z101 20BK/VT GROUND

EVAP Purge Solenoid Connector End View

SOLENOID-EVAP/PURGE - 2 WAY CAV CIRCUIT FUNCTION 1 K70 20DB/BR EVAP PURGE SOL SIGNAL 2 K52 20DB/WT EVAP PURGE SOL CONTROL

Left Front Door Speaker Connector End View

SPEAKER-LEFT FRONT DOOR - 3 WAY CAV CIRCUIT FUNCTION 1 X53 20DG (BASE) RADIO-LEFT FRONT AUDIO (+) 1 X201 16GY/VT (PREMIUM) AMPLIFIED LEFT FRONT DOOR SPEAKER (+) 2 - - 3 X55 20DG/BR (BASE) RADIO-LEFT FRONT AUDIO (-) 3 X291 16GY/YL (PREMIUM) AMPLIFIED LEFT FRONT DOOR SPEAKER (-)

Scheme 59

Left Rear Speaker (Club Cab) Connector End View

SPEAKER-LEFT REAR (CLUB CAB) CAV CIRCUIT FUNCTION 1 X51 16DG/DB (BASE) RADIO-LEFT REAR AUDIO (+) 1 X205 18GY/LG (PREMIUM) AMPLIFIED LEFT REAR SPEAKER (+) 2 - - 3 X57 16DG/OR (BASE) RADIO-LEFT REAR AUDIO (-) 3 X295 18GY/DG (PREMIUM) AMPLIFIED LEFT REAR SPEAKER (-)

Left Rear Door Speaker (Quad Cab) Connector End View

SPEAKER-LEFT REAR DOOR (QUAD CAB) - 3 WAY CAV CIRCUIT FUNCTION 1 X51 16DG/DB (BASE) RADIO-LEFT REAR AUDIO (+) 1 X205 18GY/LG (PREMIUM) AMPLIFIED LEFT REAR DOOR SPEAKER (+) 2 - - 3 X57 16DG/OR (BASE) RADIO-LEFT REAR AUDIO (-) 3 X295 18GY/DG (PREMIUM) AMPLIFIED LEFT REAR DOOR SPEAKER (-)

Right Front Door Speaker Connector End View

SPEAKER-RIGHT FRONT DOOR - 3 WAY CAV CIRCUIT FUNCTION 1 X54 16GY (BASE) RADIO-RIGHT FRONT AUDIO (+) 1 X202 20DG/VT (PREMIUM) AMPLIFIED RIGHT FRONT DOOR SPEAKER (+) 2 - - 3 X56 16DG/BR (BASE) RADIO-RIGHT FRONT AUDIO (-) 3 X292 20DG/YL (PREMIUM) AMPLIFIED RIGHT FRONT DOOR SPEAKER (-)

Scheme 60

Right Rear Speaker (Club Cab) Connector End View

SPEAKER-RIGHT REAR (CLUB CAB) - 3 WAY CAV CIRCUIT FUNCTION 1 X52 16GY/DB (BASE) RADIO-RIGHT REAR AUDIO (+) 1 X206 20DG/LG (PREMIUM) AMPLIFIED RIGHT REAR SPEAKER (+) 2 - - 3 X58 16GY/OR (BASE) RADIO-RIGHT REAR AUDIO (-) 3 X296 20LG/GY (PREMIUM) AMPLIFIED RIGHT REAR SPEAKER (-)

Right Rear Door Speaker (Quad Cab) Connector End View

SPEAKER-RIGHT REAR DOOR (QUAD CAB) - 3 WAY CAV CIRCUIT FUNCTION 1 X52 16GY/DB (BASE) RADIO-RIGHT REAR AUDIO (+) 1 X206 20DG/LG (PREMIUM) AMPLIFIED RIGHT REAR DOOR SPEAKER (+) 2 - - 3 X58 16GY/OR (BASE) RADIO-RIGHT REAR AUDIO (-) 3 X296 20LG/GY (PREMIUM) AMPLIFIED RIGHT REAR DOOR SPEAKER(-)

Left Front Tweeter Speaker (Premium) Connector End View

SPEAKER-TWEETER-LEFT FRONT (PREMIUM) - 3 WAY CAV CIRCUIT FUNCTION 1 X209 18GY/OR AMPLIFIED LEFT I/P SPEAKER (+) 2 - - 3 X299 18GY/YL AMPLIFIED LEFT I/P SPEAKER (-)

Scheme 61

Right Front Tweeter Speaker (Premium) Connector End View

SPEAKER-TWEETER-RIGHT FRONT (PREMIUM) - 3 WAY CAV CIRCUIT FUNCTION 1 X208 20GY/DG AMPLIFIED RIGHT I/P SPEAKER (+) 2 - - 3 X298 20GY/LG AMPLIFIED RIGHT I/P SPEAKER (-)

Starter Connector End View

STARTER - 1 WAY CAV CIRCUIT FUNCTION 1 T750 14YL/GY STARTER RELAY OUTPUT

Scheme 62

B-Positive Starter Connector End View

STARTER (B+) - 1 WAY CAV CIRCUIT FUNCTION 1 A1 06RD B(+)

Glove Box Lamp And Glove Box Switch Connector End View

SWITCH AND LAMP-GLOVE BOX - 2 WAY CAV CIRCUIT FUNCTION 1 M28 20YL/TN GLOVE BOX LAMP DRIVER 2 Z328 20BK/TN GROUND

Scheme 63

Backup Lamp Switch Connector End View

SWITCH-BACK UP LAMP - 2 WAY CAV CIRCUIT FUNCTION 1 T2 20DG/WT LOW/REVERSE SOLENOID CONTROL 2 Z906 20BK GROUND

Scheme 64

Clutch Interlock Switch Connector End View

SWITCH-CLUTCH INTERLOCK - 2 WAY CAV CIRCUIT FUNCTION 1 Z905 20BK GROUND 2 T141 20YL/OR TRS T141 SENSE (P/N SENSE)

Headlamp Switch Connector End View

SWITCH-HEADLAMP - 10 WAY CAV CIRCUIT FUNCTION 1 L307 20PK/RD HEADLAMP SWITCH MUX 2 E2 20OR/BR INDICATOR DIMMER SIGNAL 3 L900 20WT/YL HEADLAMP SWITCH MUX RETURN 4 E19 20OR/BR PANEL LAMPS DIMMER SIGNAL 5 Z942 20BK GROUND 6 L914 20WT FOG LAMP INDICATOR DRIVER 7 - - 8 - - 9 - - 10

Scheme 65

Driver Heated Seat Switch Connector End View

SWITCH-HEATED SEAT-DRIVER - 6 WAY CAV CIRCUIT FUNCTION 1 P137 20VT/DG DRIVER SEAT LOW HEAT LED DRIVER 2 - - 3 Z1 20BK GROUND 4 F500 18VT/BR FUSED IGNITION SWITCH OUTPUT (RUN) 5 P139 20VT/WT DRIVER SEAT HIGH HEAT LED DRIVER 6 P7 20LB/BK DRIVER HEATED SEAT SWITCH OUTPUT

Passenger Heated Seat Switch Connector End View

SWITCH-HEATED SEAT-PASSENGER - 6 WAY CAV CIRCUIT FUNCTION 1 P138 20VT/LG PASSENGER SEAT LOW HEAT LED DRIVER 2 - - 3 Z1 20BK GROUND 4 F500 18VT/BR FUSED IGNITION SWITCH OUTPUT (RUN) 5 P140 20VT/BK PASSENGER SEAT HIGH HEAT LED DRIVER 6 P8 20LB/WT PASSENGER HEATED SEAT SWITCH OUTPUT

Scheme 66

Horn Switch Connector End View

SWITCH-HORN - 1 WAY CAV CIRCUIT FUNCTION 1 X3 20DG/VT HORN SWITCH SENSE

Ignition Switch Connector End View

SWITCH-IGNITION - 14 WAY CAV CIRCUIT FUNCTION 1 A927 10RD/OR FUSED B(+) 2 F901 14PK IGNITION SWITCH OUTPUT (RUN) 3 F941 14PK/LG IGNITION SWITCH OUTPUT (RUN-START) 4 A923 16RD FUSED B(+) 5 G15 20VT/TN KEY-IN IGNITION SWITCH SENSE 6 Z943 20BK GROUND 7 A917 10RD FUSED B(+) 8 C7 10DB BLOWER MOTOR SUPPLY 9 F984 12PK/YL FUSED IGNITION SWITCH OUTPUT (RUN-ACC) 10 F982 12PK/YL IGNITION SWITCH OUTPUT (RUN-ACC) 11 A904 12RD/LB FUSED B(+) 12 A953 12RD FUSED B(+) 13 F961 14PK/LB IGNITION SWITCH OUTPUT (START) 14 F921 10PK/WT FUSED IGNITION SWITCH OUTPUT (RUN)

Mirror Switch (Power Convenience) Connector End View

SWITCH-MIRROR (POWER CONVENIENCE) - 10 WAY CAV CIRCUIT FUNCTION 1 - - 2 F30 16PK/YL FUSED IGNITION SWITCH OUTPUT (RUN-ACC) 3 P76 20TN/RD MIRROR COMMON DRIVER 4 Z13 20BK/WT GROUND 5 A940 16RD FUSED B(+) 6 P72 20TN/DG PASSENGER MIRROR VERTICAL DRIVER 7 P71 20DB DRIVER MIRROR VERTICAL DRIVER 8 P74 20TN/YL PASSENGER MIRROR HORIZONTAL DRIVER 9 P75 20RD DRIVER MIRROR HORIZONTAL DRIVER 10

Scheme 67

Multifunction Switch Connector End View

SWITCH-MULTIFUNCTION - 4 WAY CAV CIRCUIT FUNCTION 1 G194 20VT/LG HIGH BEAM/FRONT WASHER SWITCH MUX 2 G902 20VT/OR SWITCH MUX RETURN 3 L12 20WT/OR TURN SIGNAL INPUT MUX 4 W52 20BR/YL FRONT WIPER SWITCH MUX

Oil Pressure Switch Connector End View

SWITCH-OIL PRESSURE - 2 WAY CAV CIRCUIT FUNCTION 1 G6 18VT/GY ENGINE OIL PRESSURE SIGNAL 2

Scheme 68

Parking Brake Switch Connector End View

SWITCH-PARKING BRAKE - 1 WAY CAV CIRCUIT FUNCTION 1 B25 20DG/WT PARK BRAKE SWITCH SENSE

Passenger Airbag On/Off Switch Connector End View

SWITCH-PASSENGER AIRBAG ON/OFF - 6 WAY CAV CIRCUIT FUNCTION 1 R106 20LG/LB PASSENGER AIRBAG MUX SWITCH SENSE 2 R104 20LB/LG PASSENGER AIRBAG MUX SWITCH RETURN 3 - - 4 - - 5 - - 6

Left Rear Power Window Switch (Quad Cab/Power Convenience) Connector End View

SWITCH-POWER WINDOW-LEFT REAR (QUAD CAB/POWER CONVENIENCE) - 6 WAY CAV CIRCUIT FUNCTION 1 Q611 14OR/RD MASTER WINDOW SWITCH LEFT REAR (DOWN) 2 Q211 14TN/LB LEFT REAR WINDOW DRIVER (DOWN) 3 Q111 14TN/YL LEFT REAR WINDOW DRIVER (UP) 4 Q411 14OR/BK MASTER WINDOW SWITCH LEFT REAR (UP) 5 - - 6 Q15 14OR/LB MASTER WINDOW SWITCH PASSENGER DOWN

Scheme 69

Right Rear Power Window Switch (Quad Cab/Power Convenience) Connector End View

SWITCH-POWER WINDOW-RIGHT REAR (QUAD CAB/POWER CONVENIENCE) - 6 WAY CAV CIRCUIT FUNCTION 1 Q612 14OR/DB MASTER WINDOW SWITCH RIGHT REAR (DOWN) 2 Q212 14OR/VT RIGHT REAR WINDOW DRIVER (DOWN) 3 Q112 14OR/BR RIGHT REAR WINDOW DRIVER (UP) 4 Q412 14TN/YL MASTER WINDOW SWITCH RIGHT REAR (UP) 5 - - 6 Q15 14OR/LB MASTER WINDOW SWITCH PASSENGER DOWN

Left Remote Radio Switch Connector End View

SWITCH-REMOTE RADIO-LEFT - 2 WAY CAV CIRCUIT FUNCTION 1 X20 22GY/WT RADIO CONTROL MUX 2 G902 22VT/BR MULTI-FUNCTION SWITCH MUX RETURN

Scheme 70

Right Remote Radio Switch Connector End View

SWITCH-REMOTE RADIO-RIGHT - 2 WAY CAV CIRCUIT FUNCTION 1 X20 22GY/WT RADIO CONTROL MUX 2 G902 22VT/BR MULTI-FUNCTION SWITCH MUX RETURN

Driver Seat Belt Switch Connector End View

SWITCH-SEAT BELT-DRIVER - 2 WAY CAV CIRCUIT FUNCTION 1 Z949 20BK GROUND 2 R57 20LG/GY DRIVER SEAT BELT SWITCH SENSE

Driver Seat Switch (Power Convenience) Connector End View

SWITCH-SEAT-DRIVER (POWER CONVENIENCE) - 12 WAY CAV CIRCUIT FUNCTION 1 A915 10RD FUSED B(+) 2 Z975 12BK GROUND 3 - - 4 P21 10LG/TN DRIVER SEAT FRONT RISER DOWN DRIVER 5 - - 6 - - 7 - - 8 P19 10LG/LB DRIVER SEAT FRONT RISER UP DRIVER 9 P15 10LG/WT DRIVER SEAT HORIZONTAL FORWARD DRIVER 10 P17 10LG/DG DRIVER SEAT HORIZONTAL REARWARD DRIVER 11 P13 10LG/OR DRIVER SEAT REAR RISER DOWN DRIVER 12 P11 10LG/YL DRIVER SEAT REAR RISER UP DRIVER

Left Speed Control Switch Connector End View

SWITCH-SPEED CONTROL-LEFT - 3 WAY CAV CIRCUIT FUNCTION A V38 22VT/OR NOT USED B K900 22DB/DG SENSOR GROUND C V37 22VT S/C SWITCH NO. 1 SIGNAL

Scheme 71

Right Speed Control Switch Connector End View

SWITCH-SPEED CONTROL-RIGHT - 3 WAY CAV CIRCUIT FUNCTION A V38 22VT/OR NOT USED B K900 22DB/DG SENSOR GROUND C V37 22VT S/C SWITCH NO. 1 SIGNAL

Stop Lamp Switch Connector End View

SWITCH-STOP LAMP - 6 WAY CAV CIRCUIT FUNCTION 1 A103 18GY/RD FUSED B(+) 2 L50 16WT/LB BRAKE LAMP SWITCH OUTPUT 3 V30 20VT/WT S/C BRAKE SWITCH OUTPUT 4 V32 20VT/YL S/C SUPPLY 5 Z429 20BK/OR GROUND 6 B29 20DG/WT BRAKE SWITCH SIGNAL

Tow Overdrive Off Switch/Haul Overdrive Switch Off Connector End View

SWITCH-TOW/HAUL OVERDRIVE OFF - 2 WAY CAV CIRCUIT FUNCTION 1 T6 20DG TOW/HAUL OVERDRIVE OFF SWITCH SENSE 2 Z953 20BK GROUND

Transfer Case Selector Switch (4WD) Connector End View

SWITCH-TRANSFER CASE SELECTOR (4WD) - 10 WAY CAV CIRCUIT FUNCTION 1 K77 20BR/WT 5 VOLT SELECTOR SWITCH SUPPLY 2 - - 3 K977 20BR/WT MODE SELECT 4 E11 20OR/DB PANEL LAMPS DRIVER 5 Z973 20BK GROUND 6 G95 20VT/BR 4WD NEUTRAL INDICATOR 7 F21 20PK/DG FUSED IGNITION SWITCH OUTPUT (START) 8 - - 9 - - 10

Driver Window Switch/Door Lock Switch (Club Cab) Connector End View (C1)

SWITCH-WINDOW/DOOR LOCK-DRIVER C1 (CLUB CAB) - 8 WAY CAV CIRCUIT FUNCTION 1 - - 2 F30 14PK/YL FUSED IGNITION SWITCH OUTPUT (RUN-ACC) 3 Z940 20BK GROUND 4 Z13 16BK/WT GROUND 5 - - 6 Q21 14OR/WT DRIVER WINDOW DRIVER DOWN 7 Q11 14OR/LG DRIVER WINDOW DRIVER UP 8 G161 20VT/DG DRIVER DOOR LOCK SWITCH MUX

Scheme 72

Driver Window Switch/Door Lock Switch (Club Cab) Connector End View (C2)

SWITCH-WINDOW/DOOR LOCK-DRIVER C2 (CLUB CAB) - 6 WAY CAV CIRCUIT FUNCTION 1 - - 2 - - 3 - - 4 - - 5 Q26 14OR/GY MASTER WINDOW SWITCH PASSENGER DOWN 6 Q16 14OR/TN MASTER WINDOW SWITCH PASSENGER UP

Driver Express Window Switch/Door Lock Switch (Quad Cab) Connector End View (C1)

SWITCH-WINDOW/DOOR LOCK-DRIVER EXPRESS C1 (QUAD CAB) - 8 WAY CAV CIRCUIT FUNCTION 1 - - 2 F30 14PK/YL FUSED IGNITION SWITCH OUTPUT (RUN-ACC) 3 Z940 20BK GROUND 4 Z13 16BK/WT GROUND 5 Q15 14OR/LB MASTER WINDOW SWITCH PASSENGER DOWN 6 Q21 14OR/WT DRIVER WINDOW DRIVER DOWN 7 Q11 14OR/LG DRIVER WINDOW DRIVER UP 8 G161 20VT/DG DRIVER DOOR LOCK SWITCH MUX

Driver Express Window Switch/Door Lock Switch (Quad Cab) Connector End View (C2)

SWITCH-WINDOW/DOOR LOCK-DRIVER EXPRESS C2 (QUAD CAB) - 6 WAY CAV CIRCUIT FUNCTION 1 Q411 14OR/BK MASTER WINDOW SWITCH LEFT REAR (UP) 2 Q412 14TN/YL MASTER WINDOW SWITCH RIGHT REAR (UP) 3 Q612 14OR/DB MASTER WINDOW SWITCH RIGHT REAR (DOWN) 4 Q611 14OR/RD MASTER WINDOW SWITCH LEFT REAR (DOWN) 5 Q26 14OR/GY MASTER WINDOW SWITCH PASSENGER DOWN 6 Q16 14OR/TN MASTER WINDOW SWITCH PASSENGER UP

Passenger Window Switch/Door Lock Switch Connector End View

SWITCH-WINDOW/DOOR LOCK-PASSENGER - 8 WAY CAV CIRCUIT FUNCTION 1 Q26 14OR/GY MASTER WINDOW SWITCH PASSENGER DOWN 2 Q22 14OR/VT PASSENGER WINDOW DRIVER DOWN 3 Q12 14OR/BR PASSENGER WINDOW DRIVER UP 4 Q15 14OR/LB MASTER WINDOW SWITCH PASSENGER DOWN 5 F30 14PK/YL FUSED IGNITION SWITCH OUTPUT (RUN-ACC) 6 G160 20VT/LG PASSENGER DOOR LOCK SWITCH MUX 7 Z974 20BK/OR GROUND 8 Q16 14OR/TN MASTER WINDOW SWITCH PASSENGER UP

A/C Pressure Transducer Connector End View

TRANSDUCER-A/C PRESSURE - 4 WAY CAV CIRCUIT FUNCTION 1 G180 20VT/YL FCM SENSOR RETURN 2 T103 20YL/OR 5 VOLT SUPPLY 3 C18 20LB/BR A/C PRESSURE SIGNAL 4

Scheme 73

Trailer Tow Wiring Connector End View

WIRING-TRAILER TOW 4 WAY - 4 WAY CAV CIRCUIT FUNCTION 1 Z976 12BK GROUND 2 L76 20PK/RD TRAILER TOW RELAY OUTPUT 3 L673 20YL LEFT TRAILER TOW BRAKE LAMP RELAY OUTPUT 4 L674 20LG RIGHT TRAILER TOW BRAKE LAMP RELAY OUTPUT

WIRING-TRAILER TOW 7 WAY - 10 WAY CAV CIRCUIT FUNCTION 1 - - 2 L674 20LG RIGHT TRAILER TOW BRAKE LAMP RELAY OUTPUT 3 L1 18WT/LG BACK-UP LAMP FEED 4 A100 12RD/VT FUSED B(+) 5 L76 20PK/RD TRAILER TOW RELAY OUTPUT 6 - - 7 B400 12DG TRAILER TOW ELECTRIC BRAKE OUTPUT 8 Z976 12BK GROUND 9 Z976 12BK GROUND 10 L673 20YL LEFT TRAILER TOW BRAKE LAMP RELAY OUTPUT

Scheme 74

Trailer Tow Electric Brake Wiring Connector End View

WIRING-TRAILER TOW ELECTRIC BRAKE - 4 WAY CAV CIRCUIT FUNCTION 1 A400 14TN/RD FUSED B(+) 2 B400 12DG TRAILER TOW ELECTRIC BRAKE OUTPUT 3 L50 18WT/LB BRAKE LAMP SWITCH OUTPUT 4 Z910 18BK GROUND 5 6
