Overhead Console - Electrical Diagnostics: Diagnosis Dodge Dakota III

Accessories Control Systems 2 illustrations ~493 words

DIAGNOSTIC CODE INDEX

DTCDescription
B1A32UNIVERSAL GARAGE DOOR SWITCH 1 STUCK
B1A33UNIVERSAL GARAGE DOOR SWITCH 2 STUCK
B1A34UNIVERSAL GARAGE DOOR SWITCH 3 STUCK
B2217EVIC/EOM/CMTC INTERNAL
B222DECU UNABLE TO CONFIGURE / CONFIGURATION NOT LEARNED
B2331VEHICLE NEEDS DEGAUSSED
U0019CAN B BUS
U0141LOST COMMUNICATION WITH FRONT CONTROL MODULE
U0155LOST COMMUNICATION WITH CLUSTER/CCN
U0212LOST COMMUNICATION WITH SCCM

DIAGNOSTIC CODE INDEX

Diagnostic Test

  1. 1) REPLACE THE ELECTRONIC OVERHEAD MODULE When this code is set, the Electronic Overhead Module must be replaced. Repair Replace the Electronic Overhead Module. See «OVERHEAD CONSOLE - SERVICE INFORMATION»(ref-247649-S17525378962007020100000) . Perform «BODY VERIFICATION TEST - VER 1»(ref-247618-S35373433422007020100000) .
  1. 1) VERIFY OPERATION OF THE ELECTRONIC OVERHEAD MODULE Turn the ignition on. With the scan tool, erase Electronic Overhead Module DTCs. With the scan tool, activate the Electronic Overhead Module self test. With the scan tool, read Electronic Overhead Module DTCs. Does the scan tool display DTC B2217-EVIC/EOM/CMTC INTERNAL? YES Replace the Electronic Overhead Module. See «OVERHEAD CONSOLE - SERVICE INFORMATION»(ref-247649-S17525378962007020100000) . Perform «BODY VERIFICATION TEST - VER 1»(ref-247618-S35373433422007020100000) . NO Test complete.
  1. 1) TEST FOR AN INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase any Electronic Overhead Module DTCs. Turn the ignition off, wait 10 seconds then turn the ignition on. With the scan tool, read DTCs. Does the scan tool display: B222D - ECU UNABLE TO CONFIGURE / CONFIGURATION NOT LEARNED? Yes Go To step 2) . No The condition that caused this code to set is not present at this time. Using the wiring diagram as a guide, inspect the wiring and connectors for an intermittent condition. Operate the system several times and recheck for active DTCs. Perform «BODY VERIFICATION TEST - VER 1»(ref-247618-S35373433422007020100000) .
  2. 2) VERIFY COMMUNICATION WITH FRONT CONTROL MODULE With the scan tool in ECU VIEW, read active modules on the bus. Does the scan tool show the Front Control Module active on the bus? Yes Go To step 3) . No Refer to the Communication category for the related symptoms. Perform «BODY VERIFICATION TEST - VER 1»(ref-247618-S35373433422007020100000) .
  3. 3) CHECK FRONT CONTROL MODULE FOR ACTIVE DTCs With the scan tool, erase FCM DTCs. Turn the ignition off. Wait approximately 10 seconds. Turn the ignition on. With the scan tool, read FCM DTCs. Are any active DTCs present? Yes Refer to symptom list for problems related to the Front Control Module. Perform «BODY VERIFICATION TEST - VER 1»(ref-247618-S35373433422007020100000) . No Replace the Front Control Module. See «MODULE-FRONT CONTROL»(ref-247618-S23650772252007020100000) . Perform «BODY VERIFICATION TEST - VER 1»(ref-247618-S35373433422007020100000) .
  1. 1) PERFORM THE VEHICLE DEMAGNETIZING PROCEDURE NOTE: A blank compass display indicates that vehicle degaussing is required. NOTE: After demagnetizing, the vehicle will enter Auto Fast-Cal when the ignition is turned on. NOTE: Ensure that the correct compass variance is stored in the compass memory. See «COMPASS VARIATION ADJUSTMENT»(ref-247649-S19299866852007020100000) . Refer to «COMPASS DEMAGNETIZING»(ref-247649-S38803876182007020100000) . View repair. Repair When the Demagnetizing Procedure is complete, perform the Verification Test. Perform «BODY VERIFICATION TEST - VER 1»(ref-247618-S35373433422007020100000) .

Scheme 12

Scheme 12: Circuit Schematic

(Refer to ELECTRICAL/ELECTRONIC CONTROL MODULES - DIAGNOSIS AND TESTING) for the diagnostic test procedure.

(Refer to ELECTRICAL/ELECTRONIC CONTROL MODULES - DIAGNOSIS AND TESTING) for the diagnostic test procedure.

(Refer to ELECTRICAL/ELECTRONIC CONTROL MODULES - DIAGNOSIS AND TESTING) for the diagnostic test procedure.

Scheme 13

Scheme 13: Circuit Schematic
