TORQUE SPECIFICATIONS
| Application | INCH Lbs. (N.m) |
|---|
| Central Timer Module (CTM) | 20 (2.2) |
| Front Wiper |
| Motor Mounting Bolts | 72 (8) |
| Pivot Shaft Nut | 212 (24) |
| Switch Screws | 17 (2) |
| Rear Wiper |
| Motor Mounting Bolts | 72 (8) |
| Pivot Shaft Nut | 43 (4) |
| Wiper/Washer Switch | 17 (2) |
Rear Wiper/Washer System Wiring Diagram (Durango). Scheme 1
Scheme 1: Rear Wiper/Washer System Wiring Diagram (Durango)
Front Wiper/Washer System Wiring Diagram (Durango). Scheme 2
Scheme 2: Front Wiper/Washer System Wiring Diagram (Durango)
Front Wiper/Washer System Wiring Diagram (Dakota). Scheme 3
Scheme 3: Front Wiper/Washer System Wiring Diagram (Dakota)
