INTRODUCTION
Use this article to quickly find specifications related to servicing and on-vehicle adjustments. This article may be used for quick reference when you are familiar with proper adjustment procedures and only need a specification.
CAPACITIES
| Load Test (Amps) | (1) CCA Rating @ 0°F (Amps) | (2) Reserve Capacity (Min.) |
|---|
| 200 | 400 | 100 |
| 250 | 500 | 110 |
| 315 | 625 | 120 |
| 375 | 750 | 125 |
| (1) CCA rating is current a battery can deliver for 30 seconds and maintain a terminal voltage of 7.2 volts or greater at specified temperature. (2) Reserve capacity is length of time a battery can deliver 25 amps and maintain a minimum terminal voltage of 10.5 volts at 80°F (27°C). |
| (1) | CCA rating is current a battery can deliver for 30 seconds and maintain a terminal voltage of 7.2 volts or greater at specified temperature. |
| (2) | Reserve capacity is length of time a battery can deliver 25 amps and maintain a minimum terminal voltage of 10.5 volts at 80°F (27°C). |
FLUID CAPACITIES (AWD & FWD)
| Application | Specification |
|---|
| Cooling System (Includes Heater) |
| 2.5L | (1) 9.5 qts. (9.0L) |
| 3.0L & 3.3L | (1) 10.0 qts. (9.5L) |
| Crankcase (Includes Filter) | 4.5 qts. (4.3L) |
| Automatic Transaxle (Dexron-II) |
| A-413 (Except Fleet) | 8.9 qts. (8.4L) |
| A-413 (Fleet Only) | 9.2 qts. (8.7L) |
| A-413/A-670 Lock-Up | 8.5 qts. (8.0L) |
| A-604 Lock-Up | 9.1 qts. (8.6L) |
| Power Steering (Dexron-II) | 1.7 pts. (0.8L) |
| (1) Add 1 qt. (.95L) if equipped with rear heater. |
| (1) | Add 1 qt. (.95L) if equipped with rear heater. |
FLUID CAPACITIES (AWD & FWD)
FLUID CAPACITIES (RWD & 4WD)
| Application | Specification |
|---|
| Cooling System (Includes Heater) |
| Dakota |
| 2.5L | 9.8 qts. (9.3L) |
| 3.9L | 14.0 qts. (13.2L) |
| 5.2L | 14.3 qts. (13.5L) |
| All Others |
| 2.5L & 3.9 | 15.1 qts. (14.3L) |
| 5.2L (Except AW-150) | 17.0 qts. (16.1L) |
| 5.2L (AW-150) | 16.5 qts. (15.6L) |
| 5.9L (Except AW-150) | 15.5 qts. (14.7L) |
| 5.9L (AW-150) | 15.0 qts. (14.2L) |
| Crankcase (Includes Filter) | 4.5 qts. (4.3L) |
| Transfer Case |
| NP-205 (1) | 4.5 pts. (2.1L) |
| NP-231 (1) | 2.5 pts. (1.2L) |
| NP-241 (2) | 6.0 pts. (2.8L) |
| Rear Axle (SAE 80W-90/API GL-4) |
| Chrysler 7 1/4" | 3.0 pts. (1.4L) |
| Chrysler 8 1/4" | 4.4 pts. (2.1L) |
| Chrysler 9 1/4" | 4.5 pts. (2.1L) |
| Dana 60 | 6.0 pts. (2.8L) |
| Dana 70 | 7.0 pts. (3.3L) |
| Front Axle (SAE 80W-90/API GL-4) |
| Dakota | 2.6 pts. (1.2L) |
| All Others |
| Spicer 44FBJ | 5.6 pts. (2.6L) |
| Spicer 60F | 6.5 pts. (3.1L) |
| Automatic Transmission (Dexron-II) |
| A-500 (3.9L & 5.2L) | 5.2 qts. (4.4L) |
| A-518 (5.2L & 5.9L) | 10.2 qts. (9.6L) |
| A-727 (5.9L) | 8.4 qts. (7.9L) |
| A-998 (3.9L) | 8.6 qts. (8.1L) |
| A-999 (5.2L) | 8.6 qts. (8.1L) |
| Manual Transmission (SAE 5W-30 SG/API GL-4) |
| NP-435 (4-Speed) | 3.5 qts. (3.3L) |
| NP-2500 (5-Speed) | 2.0 qts. (1.9L) |
| Getrag 360 (5-speed) | 3.5 qts. (3.3L) |
| Power Steering (DOT-3 Grade) |
| Dakota RWD | 1.7 pts. (0.8L) |
| Dakota 4WD | 2.5 pts. (1.2L) |
| All Others | 2.7 pts. (1.3L) |
| (1) Recommended lubricant for the NP205 and NP231 is SAE 90W API GL-5 Multipurpose gear oil. (2) Recommended lubricant for the NP241 is Mopar ATF Plus, type 7176, or DexronIII. |
| (1) | Recommended lubricant for the NP205 and NP231 is SAE 90W API GL-5 Multipurpose gear oil. |
| (2) | Recommended lubricant for the NP241 is Mopar ATF Plus, type 7176, or DexronIII. |
FLUID CAPACITIES (RWD & 4WD)
REPLACEMENT INTERVALS (AWD & FWD)
| Component | Interval (Miles) |
|---|
| 2.5L, 3.0L & 3.3L |
| Air Filter | 30,000 |
| Coolant | (1) 52,500 |
| Oil | 7500 |
| Oil Filter | (2) 15,000 |
| Spark Plugs | 30,000 |
| (1) Every 30,000 thereafter. (2) If mileage is less than 7500 miles (5000 miles on turbo) each 12 months, replace filter at each oil change. |
| (1) | Every 30,000 thereafter. |
| (2) | If mileage is less than 7500 miles (5000 miles on turbo) each 12 months, replace filter at each oil change. |
REPLACEMENT INTERVALS (AWD & FWD)
REPLACEMENT INTERVALS (RWD & 4WD)
| Component | Interval (Miles) |
|---|
| Light-Duty Service |
| Air Filter | 30,000 |
| Coolant | 30,000 |
| Fuel Filter | As Necessary |
| Oil | 7,500 |
| Oil Filter | (1) 15,000 |
| Spark Plugs | 30,000 |
| Heavy-Duty Service |
| Air Filter | 24,000 |
| Coolant | 30,000 |
| Fuel Filter | As Necessary |
| Oil | 6,000 |
| Oil Filter | 12,000 |
| Spark Plugs | 30,000 |
| (1) If mileage is less than 7,500 miles each 12 months, replace filter at each oil change. |
| (1) | If mileage is less than 7,500 miles each 12 months, replace filter at each oil change. |
REPLACEMENT INTERVALS (RWD & 4WD)
DRIVE BELT ADJUSTMENT - 4-CYLINDER
| Application | Tension Lbs. (kg) |
|---|
| A/C Compressor |
| New Belt | 125 (56.7) |
| Used Belt | 80 (36.3) |
| Alternator/Water Pump Poly "V" |
| New Belt | 130 (59.0) |
| Used Belt | 80 (36.3) |
| Power Steering Pump |
| New Belt | 105 (47.6) |
| Used Belt | 80 (36.3) |
BELT ADJUSTMENT - 4-CYLINDER
DRIVE BELT ADJUSTMENT - V6
| Application | Tension Lbs. (kg) |
|---|
| 3.0L |
| A/C Compressor |
| New Belt | 125 (56.7) |
| Used Belt | 80 (36.3) |
| Alternator/Water & Power Steering Pumps |
| New or Used Belt | Dynamic Tensioner |
| 3.3L |
| New or Used Belt | Dynamic Tensioner |
| 3.9L |
| All Belts |
| New Belt | 100-140 (45.4-63.5) |
| Used Belt | 60-90 (27.2-40.9) |
DRIVE BELT ADJUSTMENT - V8
| Application | Tension Lbs. (kg) |
|---|
| All Belts |
| New Belt | 100-140 (45.4-63.5) |
| Used Belt | 60-90 (27.2-40.9) |
ENGINE COMPRESSION
Check engine compression with engine at normal operating temperature at specified cranking speed, all spark plugs removed and throttle wide open.
| Application | Specification |
|---|
| Compression Ratio |
| 2.5L | 8.9:1 |
| 3.0L | 8.85:1 |
| 3.3L | 8.9:1 |
| 3.9L | 9.0:1 |
| 5.2L | 9.0:1 |
| 5.9L | 8.1:1 |
| Compression Pressure |
| 3.0L | (1) 178 psi (12.5 kg/cm 2 ) |
| All Other Engines | (2) 100 psi (7.0 kg/cm 2 ) |
| (1) At 250 RPM. (2) Minimum compression pressure is given. Maximum difference between each cylinder should not exceed 25 percent. |
| (2) | Minimum compression pressure is given. Maximum difference between each cylinder should not exceed 25 percent. |
COMPRESSION SPECIFICATIONS
VALVE CLEARANCE
All engines are equipped with hydraulic lifters and do not require valve adjustment. Valve clearance is zero lash with engine at operating temperature.
IGNITION COIL
| Application | Primary | Secondary |
|---|
| 2.5L & 3.0L |
| Chrysler Prestolite | 1.34-1.55 | 9,400-11,700 |
| Diamond | 0.96-1.18 | 11,300-15,300 |
| Toyodenso | 0.95-1.20 | 11,300-13,300 |
| 3.3L |
| Diamond | 0.52-0.63 | 11,600-15,800 |
| Toyodenso | 0.51-0.61 | 11,500-13,500 |
| 3.9L, 5.2L & 5.9L |
| Chrysler Essex | 1.34-1.55 | 9,000-12,200 |
| Chrysler UTC | 1.34-1.55 | 9,000-12,200 |
| Diamond | 1.34-1.55 | 15,000-19,000 |
IGNITION COIL RESISTANCE (Ohms @ 70-80°F (21-27°C)
HIGH TENSION WIRE RESISTANCE
| Application | Minimum Ohms | Maximum Ohms |
|---|
| All Wires | 250 Per Inch | 1000 Per Inch |
HIGH TENSION WIRE RESISTANCE
SPARK PLUGS
| Application | Champion No. |
|---|
| 2.5L | RN12YC |
| 3.0L |
| Standard | RN11YC4 |
| Optional | BPR5ES-II |
| 3.3L | RN16YC5 |
| 3.9L | RN12YC |
| 5.2L & 5.9L | RN12YC |
| Application | Gap In. (mm) | Torque Ft. Lbs. (N.m) |
|---|
| 2.5L | .036 (.91) | 20 (28) |
| 3.0L | .041 (1.00) | 20 (28) |
| 3.3L | .050 (1.27) | 20 (28) |
| 3.9L, 5.2L & 5.9L | .035 (.89) | 30 (41) |
SPARK PLUG SPECIFICATIONS
FIRING ORDER & TIMING MARKS
| WARNING | On 3.0L V6, the firing order and the spark plug connection order on the top of the distributor do not match. Circuits internal to the distributor cap differ from the external spark plug wire connections. This is intentional and is done to avoid spark plug wires crossover. (Scheme 2) |
Firing Order & Distributor Rotation (2.5L). Scheme 1
Scheme 1: Firing Order & Distributor Rotation (2.5L)
Firing Order & Distributor Rotation (3.0L). Scheme 2
Scheme 2: Firing Order & Distributor Rotation (3.0L)
Firing Order (3.3L). Scheme 3
Scheme 3: Firing Order (3.3L)
Firing Order & Distributor Rotation (3.9L). Scheme 4
Scheme 4: Firing Order & Distributor Rotation (3.9L)
Scheme 5
Scheme 5: Firing Order & Distributor Rotation (5.2L & 5.9L)
IGNITION TIMING
| Application | Man. Trans. | Auto. Trans. |
|---|
| 2.5L | 10-14 @ 850 | 10-14 @ 850 |
| 3.0L | N/A | 10-14 @ 700 |
| 3.3L | N/A | (1) 14-18 @ 750 |
| 3.9L, 5.2L & 5.9L | (2) 8-12 | (2) 8-12 |
| (1) Ignition timing is not adjustable. (2) At idle. |
| (1) | Ignition timing is not adjustable. |
IGNITION TIMING (Degrees BTDC @ RPM)
ELECTRONIC SPARK ADVANCE CHECK
Note. Always refer to Emissions Control Label in engine compartment before attempting service. If manual and label differ, always use emission label specifications.
| Application | Man. Trans. | Auto. Trans. |
|---|
| 2.5L | 17-25 @ 2000 | 17-25 @ 2000 |
| 3.0L | N/A | 34-42 @ 2000 |
| 3.3L (1) |
| Federal | N/A | 24-32 @ 2000 |
| California | N/A | 33-41 @ 2000 |
| 3.9L, 5.2L & 5.9L | N/A | N/A |
| (1) Ignition timing is not adjustable. |
| (1) | Ignition timing is not adjustable. |
ELECTRONIC SPARK ADVANCE (Degrees BTDC @ RPM)
FUEL PUMP
Note. Fuel pump performance means fuel pressure and volume availability, not regulated fuel pressure.
| Application | Pressure psi (kg/cm 2 ) |
|---|
| 2.5L |
| Dakota | 14.5 (1.0) |
| Caravan & Voyager | 39 (2.7) |
| 3.0L & 3.3L | 48 (3.4) |
| 3.9L, 5.2L & 5.9L | 14.5 (1.0) |
IDLE SPEED & MIXTURE
Note. Mixture is controlled by Single Board Engine Controller (BEC). No adjustment is possible.
| Application | Man. Trans. | Auto. Trans. |
|---|
| 2.5L | 850 | 850 |
| 3.0L | N/A | 700 |
| 3.3L | N/A | 750 |
| 3.9L, 5.2L & 5.9L | N/A | N/A |
| Application | RPM |
|---|
| 2.5L | 1050-1250 |
MINIMUM AIRFLOW RATE SPECIFICATIONS - 4-CYLINDER
| Application | RPM |
|---|
| 3.0L | 750-950 |
| 3.3L & 3.9L | 700-950 |
MINIMUM AIRFLOW RATE SPECIFICATIONS - V6
THROTTLE POSITION SENSOR
| Terminals | Volts |
|---|
| At Idle | 1.5 |
| At Wide Open Throttle | 3.4 |
| (1) Measure voltage at throttle position sensor center terminal. |
| (1) | Measure voltage at throttle position sensor center terminal. |
THROTTLE POSITION SENSOR VOLTAGE TEST (1)
