STARTER SPECIFICATIONS
| Application | Specification |
|---|
| Cranking Amperage (1) | 125-200 Amps |
| Cranking Voltage (Gasoline & CNG Engines) | 7.5 Volts |
| (1) With engine at full operating temperature. |
| (1) | With engine at full operating temperature. |
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Intermediate Steering Shaft Coupler Bolt | 35 (47) |
| Starter Mounting Bolts |
| 2.5L | 40 (54) |
| 3.9L & 5.2L | 50 (68) |
| Stud Nut (3.9L & 5.2L) | 20 (27) |
| INCH Lbs. (N.m) |
| Battery Terminal Nut (3.9L & 5.2L) | 90 (10) |
| Solenoid Terminal Nut (3.9L & 5.2L) | 55 (6) |
Starter System Wiring Diagram (2.5L). Scheme 1
Scheme 1: Starter System Wiring Diagram (2.5L)
Starter System Wiring Diagram (Except 2.5L). Scheme 2
Scheme 2: Starter System Wiring Diagram (Except 2.5L)
