Starting System: Specifications Dodge Charger V

TORQUE

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

1. Disconnect negative battery cable
2. Install steering wheel holder locking steering wheel in straight-ahead position.
3. Raise vehicle and support.
4. Remove the underbody splash shield.
5. Starter assembly.
6. Remove the intermediate steering shaft center bolt.
7. Bolt removed.
8. Separate the intermediate steering shaft upper and lower shaft.
9. Disconnect the electrical connection from the starter.
10. Remove the 3 starter mounting bolts and wiring clip.
11. Pull starter forward and down.
12. Work starter up and around exhaust.
13. Work starter past the intermediate steering shaft.
14. Remove starter from vehicle.

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

1. Disconnect negative battery cable.
2. Raise vehicle and support.
3. Remove the rear belly pan.
4. Remove the middle belly pan.
5. Disconnect the battery connection.
6. Disconnect the solenoid connection.
7. Remove the 2 mounting bolts.
8. Remove starter from vehicle.

Scheme 17

1. Disconnect negative battery cable
2. Install steering wheel holder locking steering wheel in straight-ahead position.
3. Raise vehicle and support.
4. Remove the underbody splash shield.
5. Starter assembly.
6. Remove the intermediate steering shaft center bolt.
7. Bolt removed.
8. Separate the intermediate steering shaft upper and lower shaft.
9. Disconnect the electrical connection from the starter.
10. Remove the 3 starter mounting bolts and wiring clip.
11. Pull starter forward and down.
12. Work starter up and around exhaust.
13. Work starter past the intermediate steering shaft.
14. Remove starter from vehicle.

Scheme 18

1. Disconnect and isolate negative battery cable.
2. Raise and support vehicle.
3. Remove three starter mounting bolts (1).
4. Move starter motor (2) towards front of vehicle far enough for nose of starter to clear. Always support starter motor (2) during this process. Do not let starter motor hang from wire harness.
5. Remove battery cable-to-solenoid nut.
6. Remove solenoid wire from solenoid stud.
7. Remove starter motor.
