DIGITS 1, 2, AND 3
Paint procedure
DIGIT 4
Open Space
DIGITS 5 THROUGH 7
Primary Paint
DIGIT 8 AND 9
Open Space
DIGITS 10 THROUGH 12
Secondary Paint
DIGIT 13 AND 14
Open Space
DIGITS 15 THROUGH 18
Interior Trim Code
DIGIT 19
Open Space
DIGITS 20, 21, AND 22
Engine Code
- EER = 2.7 L, V-6 Cylinder, 24 Valve, DOHC, Gasoline, Aluminum Block (MPI)
- EGG = 3.5 L, V -6 Cylinder, 24 Valve, High Output, Gasoline, Aluminum Block (MPI)
- ESF = 6.1 L, V-8 Cylinder, HEMI, Gasoline (SMPI)
- EZB = 5.7 L, V-8 Cylinder, HEMI, Multi-Displacement, Gasoline
DIGIT 23
Open Space
DIGITS 1 THROUGH 12
Vehicle Order Number
DIGITS 13, THROUGH 15
Vinyl Roof Code
DIGITS 16 AND 17
Open space
DIGITS 18 AND 19
Vehicle Shell Line
- LX
DIGITS 20
Carline
- C = Chrysler
- D = Dodge
DIGIT 21
Price Class
- E = Economy
- H = High Line
- L = Low Line
- M = Medium
- P = Premium
- S = Sport
- X = Special
DIGITS 22 AND 23
Body Type
- 48 = Four Door Sedan Tall
- 49 = Hatchback Tall
Transmission Codes
- DG6 = 4-Speed Electronic Automatic Transmission
- DGJ = 5-Speed Automatic Transmission
Open Space
DIGIT 5
Market Code
- C = Canada
- B = International
- M = Mexico
- U = United States
DIGIT 6
Open Space
DIGITS 7 THROUGH 23
Vehicle Identification Number
- (Refer to «VEHICLE IDENTIFICATION NUMBER»(ref-256031-S02880645622007060500000) ) for proper breakdown of VIN code.
IF TWO BODY CODE PLATES ARE REQUIRED
The last code shown on either plate will be followed by END. When two plates are required, the last code space on the first plate will indicate (CTD)
When a second plate is required, the first four spaces of each line will not be used due to overlap of the plates.
FASTENER USAGE
| WARNING | Use of an incorrect fastener may result in component damage or personal injury. |
Fasteners and torque specifications references in this article are identified in metric and SAE format.
During any maintenance or repair procedures, it is important to salvage all fasteners (nuts, bolts, etc.) for reassembly. If the fastener is not salvageable, a fastener of equivalent specification must be used.
Most stripped threaded holes can be repaired using a Helicoil®. Follow the vehicle or Helicoil® recommendations for application and repair procedures.
Scheme 7
| 1 | High Beam | 13 | Rear Window Washer |
|---|---|---|---|
| 2 | Fog Lamps | 14 | Fuel |
| 3 | Headlamp, Parking Lamps, Panel Lamps | 15 | Engine Coolant Temperature |
| 4 | Turn Warning | 16 | Battery Charging Condition |
| 5 | Hazard Warning | 17 | Engine Oil |
| 6 | Windshield Washer | 18 | Seat Belt |
| 7 | Windshield Wiper | 19 | Brake Failure |
| 8 | Windshield Wiper and Washer | 20 | Parking Brake |
| 9 | Windscreen Demisting and Defrosting | 21 | Front Hood |
| 10 | Ventilating Fan | 22 | Rear hood (Decklid) |
| 11 | Rear Window Defogger | 23 | Horn |
| 12 | Rear Window Wiper | 24 | Lighter |
The graphic symbols illustrated in the following International Control and Display Symbols Chart are used to identify various instrument controls. The symbols correspond to the controls and displays that are located on the instrument panel.
Scheme 8
The Manufacturer Plate is located in the engine compartment on the passenger side rear corner of the hood. The plate contains five lines of information
- Vehicle Identification Number (VIN)
- Gross Vehicle Mass (GVM)
- Gross Train Mass (GTM)
- Gross Front Axle Rating (GFAR)
- Gross Rear Axle Rating (GRAR)
Scheme 9
The metric system is based on quantities of one, ten, one hundred, one thousand and one million.
The following chart will assist in converting metric units to equivalent English and SAE units, or vise versa.
| MULTIPLY | BY | TO GET | MULTIPLY | BY | TO GET |
|---|---|---|---|---|---|
| In-lbs | X 0.11298 | = Newton Meters (N.m) | N.m | X 8.851 | = in-lbs |
| Ft-lbs | X 1.3558 | = Newton Meters (N.m) | N.m | X 0.7376 | = ft-lbs |
| Inches Hg (60° F) | X 3.377 | = Kilopascals (kPa) | KPa | X 0.2961 | = Inches Hg |
| Psi | X 6.895 | = Kilopascals (kPa) | KPa | X 0.145 | = psi |
| Inches | X 25.4 | = Millimeters (mm) | Mm | X 0.03937 | = Inches |
| Feet | X 0.3048 | = Meters (M) | M | X 3.281 | = Feet |
| Yards | X 0.9144 | = Meters | M | X 1.0936 | = Yards |
| Mph | X 1.6093 | = Kilometers/Hr. (Km/h) | Km/h | X 0.6214 | = mph |
| Feet/Sec | X 0.3048 | = Meters/Sec (M/S) | M/S | X 3.281 | = Feet/Sec |
| Mph | X 0.4470 | = Meters/Sec (M/S) | M/S | X 2.237 | = mph |
| Kilometers/Hr. (Km/h) | X 0.27778 | = Meters/Sec (M/S) | M/S | X 3.600 | Kilometers/Hr. (Km/h) |
CONVERSION FORMULAS AND EQUIVALENT VALUES
| 1 inch = 25 Millimeters | 1 Cubic Inch = 16 Cubic Centimeters |
|---|---|
| 1 Foot = 0.3 Meter | 1 Cubic Foot = 0.03 Cubic Meter |
| 1 Yard = 0.9 Meter | 1 Cubic Yard = 0.8 Cubic Meter |
| 1 Mile = 1.6 Kilometers |
COMMON METRIC EQUIVALENTS
(Scheme 9)to convert torque values listed in metric Newton- meters (N.m). Also, use the chart to convert between millimeters (mm) and inches (in.).
VECI LABEL
All vehicles are equipped with a combined VECI label. This label is located in the engine compartment.
The VECI label contains the following
- Engine family and displacement
- Evaporative family
- Emission control system schematic
- Certification application
- Engine timing specifications (if adjustable)
- Idle speeds (if adjustable)
- Spark plug and gap
The label also contains an engine vacuum schematic. There are unique labels for vehicles built for sale in the state of California and the country of Canada. Canadian labels are written in both the English and French languages. These labels are permanently attached and cannot be removed without defacing information and destroying label.
Scheme 10
The Vehicle Identification Number (VIN) plate is attached to the top left side of the instrument panel. The VIN contains 17 characters that provide data concerning the vehicle. Refer to VIN DECODING INFORMATION to determine the identification of a vehicle.
To protect the consumer from theft and possible fraud the manufacturer is required to include a Check Digit at the ninth position of the Vehicle Identification Number. The check digit is used by the manufacturer and government agencies to verify the authenticity of the vehicle and official documentation. The formula to use the check digit is not released to the general public.
| POSITION | INTERPRETATION | CODE = DESCRIPTION |
|---|---|---|
| 1 | Country of Origin | 1 = Manufactured by DaimlerChrysler Canada Inc. |
| 2 | Make | A = Chrysler (Hatchback) |
| B = Dodge (Sedan) | ||
| C = Chrysler (Sedan) | ||
| D = Dodge (Hatchback) | ||
| 3 | Vehicle Type | 3 = Passenger Car |
| 4 = Multipurpose Passenger Vehicle Without Side Air Bags Sales Code (CGS) (Hatchback) | ||
| 8 = Multipurpose Passenger Vehicle With Side Air Bags Sales Code (CGS) (Hatchback) | ||
| 4 | Restraint System | H = Restraint System Air bags Front Next Generation Multi-Stage Sales Code (CG1) With Side Air Bags Sales Code (CGS) |
| J = Restraint System Air Bags Front Next Generation Multi Stage Sales Code (CG1) Without Side Air Bags Sales Code (CGS) | ||
| K = Restraint System Advanced Multistages Front Air Bags Sales Code (CG3) With Side Air Bags Sales Code (CGS) | ||
| L = Restraint System Advanced Multistage Front Air Bags Sales Code (CG3) With Side Air Bags Sales Code (CGS) | ||
| 4 = Multipurpose Passenger Vehicle Without Side Air Bags Sales Code (CGS) (Hatchback) | ||
| 8= Multipurpose Passenger Vehicle With Side Air Bags Sales Code (CGS) (Hatchback) | ||
| Gross Vehicle Weight Rating | E = 3001- 4000 lbs. (1361- 1814) KG (Hatchback) | |
| F = 4001- 5000 lbs. (1815 - 2267) KG (Hatchback) | ||
| 5 | Vehicle Line | A = 300 / 300C / SRT-8/ Charger (RWD) (LWD) |
| K = 300 / 300C (AWD) (LWD) | ||
| R = 300C/ SRT-8 (RWD) (RHD) | ||
| V = 300 Touring / Magnum (RWD) | ||
| Z = 300 Touring Magnum (AWD) | ||
| 6 | Series | 4 - H High Line |
| 5 = P Premium | ||
| 6 = S Sport | ||
| 7 = X Special | ||
| B = 4 Speed Automatic, Sales Code (DG6) | ||
| B = 4 Speed Automatic VLP, Sales Code (DGV) | ||
| E = 5 Speed Automatic, Sales Code (DGJ) | ||
| 7 | Body Style | 3 = 4 Door Sedan Tall |
| 7 = Hatchback Tall | ||
| 8 | Engine | D = 3.0L V-6 cyl. Turbo Diesel Sales Code (EXL) |
| G = 3.5L V-6 cyl. High Output 24 Valve MPI Gasoline Sales Code (EGG) | ||
| H = 5.7L V-8 cyl. HEMI Multiple Displacement Gasoline Sales Code (EZB) | ||
| M = 3.0L V6 CYL 24 Valve Turbo Diesel Sales Code (EXL) (Hatchback) | ||
| R = 2.7L V6 Cyl. 24V DOHC Gasoline (MPI) Sales Code (EER) | ||
| T = 2.7L V6 CYL 24 Valve DOHC Gasoline MPI Sales Code (EER) (Hatchback) | ||
| V = 3.5l V6 CYL 24 Valve High Output Gasoline, Sales Code (EZB) (Hatchback) | ||
| W = 6.1L V8 CYL SRT HEMI Gasoline SMPI, Sales Code (ESF) | ||
| 2 = 5.7L V8 CYL HEMI Multiple Displacement Gasoline Sales Code ( EZB) (Hatchback) | ||
| 3 = 6.1L V8 CYL SRT HEMI Gasoline SMPI, Sales Code (ESF) (Hatchback) | ||
| 9 | Check Digit | 0 through 9 or X |
| 10 | Model Year | 6 = 2006 |
| 11 | Assembly Plant | H = Brampton Assembly |
| 12 Through 17 | Vehicle Build Sequence | Six Digit Number Assigned By Assembly Plant |
VIN DECODING INFORMATION
Scheme 11
A vehicle certification label is attached to every DaimlerChrysler Corporation vehicle. The label certifies that the vehicle conforms to all applicable Federal Motor Vehicle Standards. The label also lists
- Month and year of vehicle manufacture.
- Gross Vehicle Weight Rating (GVWR). The gross front and rear axle weight ratings (GAWR's) are based on a minimum rim size and maximum cold tire inflation pressure.
- Vehicle Identification Number (VIN).
- Type of vehicle.
- Type of rear wheels.
- Bar code.
- Month, Day and Hour (MDH) of final assembly.
- Paint and Trim codes.
- Country of origin.
The label is located on the driver-side door shut-face.
