Power Mirrors - Electrical Diagnostics: Other Dodge Charger V

Monitor Conditions

1. When Monitored: Continuously.

Set Conditions

1. Set Condition: When the Driver Door Module receives a mirror movement command from the switch but then senses an open or shorted circuit on one of the switch sense circuits for over 100 ms, this code will set.

Possible Causes

1. When Monitored: Continuously.

1. Set Condition: When the Driver Door Module receives a mirror movement command from the switch for over 30 seconds, this code will set.

1. When Monitored: Continuously.

1. Set Condition: When the Driver Door Module senses voltage below 4.3 volts on the Mirror Position Sensor Supply circuit for over 30 ms, this code will set. NOTE: This test covers both the Driver and Passenger code depending on the side the code appeared in.

Scheme 7

Scheme 8

Scheme 9

1. 1) TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTC's Operate the Mirror Switch in all directions several times. Cycle the ignition from on to off three times. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display B1D09 or B1D12-MIRROR POSITION SENSOR POWER SUPPLY CIRCUIT LOW? Yes Go To 2. No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) .
2. 2) TEST FOR A SHORTED MIRROR Turn the ignition off. Disconnect the appropriate mirror connector. Turn the ignition on. Measure the voltage between the (P145) or (P146) Mirror Position Sensor Supply circuit and the ((P69) or (P66) Mirror Sensor Ground circuit. Is the voltage above 4.6 volts? Yes Replace the Mirror. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) . No Go to 3.
3. 3) TEST THE (P145) OR (P146) MIRROR POSITION SENSOR SUPPLY WIRE Turn the ignition off. Disconnect the appropriate Driver Door Module connector. Measure the resistance between ground and the (P145) or (P146) Mirror Position Sensor Supply circuit. Is the resistance below 5000.0 ohms? Yes Repair the (P145) or (P146) Mirror Position Sensor Supply circuit for a short to ground. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) . No Go to 4.
4. 4) TEST THE (P145) OR (P146) MIRROR POSITION SENSOR SUPPLY WIRE SHORTED TO THE (P69) OR (P66) MIRROR SENSOR GROUND CIRCUIT. Measure the resistance between the (P145) or (P146) Mirror Position Sensor Supply circuit and the (P69) or (P66) Mirror Sensor Ground circuit. Is the resistance below 5000.0 ohms? Yes Repair the (P145) or (P146) Mirror Position Sensor Supply circuit for a short to the (P69) or (P66) Sensor Ground Circuit. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) . No Replace the appropriate Driver Door Module. Perform BODY VERIFICATION TEST - VER 1 «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) .

1. When Monitored: Continuously.

1. Set Condition: When the Driver/Passenger Door Module senses voltage above 5.5 volts on the Mirror Position Sensor Supply circuit for over 30 ms, this code will set. NOTE: This test covers both the Driver and Passenger code depending on the side the code appeared in.

Scheme 10

Scheme 11

Scheme 12

Scheme 13

1. 1) TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTC's Operate the Mirror Switch in all directions several times. Cycle the ignition from on to off three times. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display B1D0A or B1d13-MIRROR POSITION SENSOR POWER SUPPLY CIRCUIT HIGH? Yes Go To 2. No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) .
2. 2) TEST FOR AN OPEN MIRROR Turn the ignition off. Disconnect the appropriate mirror connector. Turn the ignition on. Measure the voltage between the (P145) or (P146) Mirror Position Sensor Supply circuit and the ((P69) or (P66) Mirror Sensor Ground circuit. Is the voltage between 4.8 and 5.2 volts? Yes Replace the Mirror. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) . No Go to 3.
3. 3) TEST THE (P145) OR (P146) MIRROR POSITION SENSOR SUPPLY WIRE FOR AN OPEN Turn the ignition off. Disconnect the appropriate Door Module C4 connector. Measure the resistance between the (P145) or (P146) Mirror Position Sensor Supply circuit between the Module connector and the Mirror connector. Is the resistance below 2.0 ohms? No Repair the (P145) or (P146) Mirror Position Sensor Supply circuit for an open. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) . Yes Go to 4.
4. 4) TEST THE (P69) OR (P66) MIRROR SENSOR GROUND WIRE FOR AN OPEN Measure the resistance of the ((P69) or (P66) Mirror Sensor Ground circuit between the Module connector and the Mirror connector. Is the resistance below 2.0 ohms? No Repair the (P69) or (P66) Mirror Sensor Ground circuit for an open. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) . Yes Go to 5. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) .
5. 5) TEST THE (P145) OR (P146) MIRROR POSITION SENSOR SUPPLY WIRE SHORTED TO VOLTAGE Turn the ignition on. Measure the voltage between ground and the (P145) or (P146) Mirror Position Sensor Supply circuit. Is there any voltage present? Yes Repair the (P145) or (P146) Mirror Position Sensor Supply circuit for a short to voltage. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) . No Replace the appropriate Door Module. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) .

Scheme 14

1. When Monitored: Continuously.

1. Set Condition: When the Driver/Passenger Door Module senses a value below the parameter of the mirror sensor on the Mirror Vertical Position Signal circuit for over 60 ms, this code will set. NOTE: This test covers both the Driver and Passenger code depending on the side the code appeared in.

Scheme 15

Scheme 16

Scheme 17

1. 1) TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTC's Operate the Mirror Switch in all directions several times. Cycle the ignition from on to off three times. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display B1D0C or B1D15-MIRROR VERTICAL POSITION SENSOR INPUT CIRCUIT LOW? Yes Go To 2. No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) .
2. 2) TEST FOR A SHORTED MIRROR Disconnect the appropriate mirror connector. With the scan tool, erase DTC's. Operate the Mirror Switch in all directions several times. Cycle the ignition from on to off three times. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display B1D0C or B1D15-MIRROR VERTICAL POSITION SENSOR INPUT CIRCUIT LOW? No Replace the Mirror. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) . Yes Go to 3.
3. 3) TEST THE (P67) OR (P64) MIRROR VERTICAL POSITION SIGNAL WIRE FOR A SHORT TO GROUND Turn the ignition off. Disconnect the appropriate Door Module C4 connector. Measure the resistance between ground and the (P67) or (P64) Mirror Vertical Position Signal circuit. Is the resistance below 5000.0 ohms? Yes Repair the (P67) or (P64) Mirror Vertical Position Signal circuit for a short to ground. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) . No Go to 4.
4. 4) TEST THE (P67) OR (P64) MIRROR VERTICAL POSITION SIGNAL CIRCUIT SHORTED TO THE (P69) OR (P66) MIRROR SENSOR GROUND CIRCUIT. Measure the resistance between the (P67) or (P64) Mirror Vertical Position Signal circuit and the (P69) or (P66) Mirror Sensor Ground circuit. Is the resistance below 5000.0 ohms? Yes Repair the (P67) or (P64) Mirror Vertical Position Signal circuit for a short to the (P69) or (P66) Sensor Ground Circuit. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) . No Replace the appropriate Door Module. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) .

1. When Monitored: Continuously.

1. Set Condition: When the Driver/Passenger Door Module senses a value above the parameter of the mirror sensor on the Mirror Vertical Position Signal circuit for over 60 ms, this code will set. NOTE: This test covers both the Driver and Passenger code depending on the side the code appeared in.

Scheme 18

Scheme 19

1. 1) TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTC's Operate the Mirror Switch in all directions several times. Cycle the ignition from on to off three times. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display B1D0D or B1D16-MIRROR VERTICAL POSITION SENSOR INPUT CIRCUIT HIGH? Yes Go To 2. No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) .
2. 2) TEST FOR A SHORTED MIRROR Disconnect the appropriate mirror connector. With the scan tool, erase DTC's. Operate the Mirror Switch in all directions several times. Cycle the ignition from on to off three times. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display B1D0D or B1D16-MIRROR VERTICAL POSITION SENSOR INPUT CIRCUIT HIGH? No Replace the Mirror. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) . Yes Go to 3.
3. 3) TEST THE (P67) OR (P64) MIRROR VERTICAL POSITION SIGNAL WIRE FOR A SHORT TO VOLTAGE Turn the ignition off. Disconnect the appropriate Door Module C4 connector. Measure the voltage between the (P67) or (P64) Mirror Vertical Position Signal circuit and ground. Is there any voltage present? Yes Repair the (P67) or (P64) Mirror Vertical Position Signal circuit for a short to voltage. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) . No Go to 4.
4. 4) TEST THE (P69) OR (P66) MIRROR SENSOR GROUND WIRE FOR AN OPEN Measure the resistance of the (P69) or (P66) Mirror Sensor Ground circuit between the Module connector and the Mirror connector. Is the resistance below 2.0 ohms? No Repair the (P69) or (P66) Mirror Sensor Ground circuit for an open. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) . Yes Go to 5.
5. 5) TEST THE (P67) OR (P64) MIRROR VERTICAL POSITION SIGNAL WIRE FOR AN OPEN Measure the resistance of the (P67) or (P64) Mirror Vertical Position Signal circuit between the Module connector and the Mirror connector. Is the resistance below 2.0 ohms? No Repair the (P67) or (P64) Mirror Vertical Position Signal circuit for an open. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) . Yes Replace the appropriate Door Module. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) .

Scheme 20

1. When Monitored: Continuously.

1. Set Condition: When the Driver/Passenger Door Module senses a value below the parameter of the mirror sensor on the Mirror Horizontal Position Signal circuit for over 60 ms, this code will set. NOTE: This test covers both the Driver and Passenger code depending on the side the code appeared in.

Scheme 21

Scheme 22

1. 1) TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTC's Operate the Mirror Switch in all directions several times. Cycle the ignition from on to off three times. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display B1D0F or B1D18-MIRROR HORIZONTAL POSITION SENSOR INPUT CIRCUIT LOW? Yes Go To 2. No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) .
2. 2) TEST FOR A SHORTED MIRROR Disconnect the appropriate mirror connector. With the scan tool, erase DTC's. Operate the Mirror Switch in all directions several times. Cycle the ignition from on to off three times. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display B1D0F or B1D18-MIRROR HORIZONTAL POSITION SENSOR INPUT CIRCUIT LOW? No Replace the Mirror. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) . Yes Go to 3.
3. 3) TEST THE (P65) OR (P68) MIRROR HORIZONTAL POSITION SIGNAL WIRE FOR A SHORT TO GROUND Turn the ignition off. Disconnect the appropriate Door Module C4 connector. Measure the resistance between ground and the (P65) or (P68) Mirror Horizontal Position Signal circuit. Is the resistance below 5000.0 ohms? Yes Repair the (P65) or (P68) Mirror Horizontal Position Signal circuit for a short to ground. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) . No Go to 4.
4. 4) TEST THE (P65) OR (P68) MIRROR HORIZONTAL POSITION SIGNAL CIRCUIT SHORTED TO THE (P69) OR (P66) MIRROR SENSOR GROUND CIRCUIT. Measure the resistance between the (P65) or (P68) Mirror Horizontal Position Signal circuit and the (P69) or (P66) Mirror Sensor Ground circuit. Is the resistance below 5000.0 ohms? Yes Repair the (P65) or (P68) Mirror Horizontal Position Signal circuit for a short to the (P69) or (P66) Sensor Ground Circuit. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) . No Replace the appropriate Door Module. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) .

1. When Monitored: Continuously.

1. Set Condition: When the Driver/Passenger Door Module senses a value above the parameter of the mirror sensor on the Mirror Horizontal Position Signal circuit for over 60 ms, this code will set. NOTE: This test covers both the Driver and Passenger code depending on the side the code appeared in.

Scheme 23

Scheme 24

Scheme 25

1. 1) TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTC's Operate the Mirror Switch in all directions several times. Cycle the ignition from on to off three times. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display B1D10 or B1D19-MIRROR HORIZONTAL POSITION SENSOR INPUT CIRCUIT HIGH? Yes Go To 2. No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) .
2. 2) TEST FOR AN OPEN MIRROR Disconnect the appropriate mirror connector. Turn the ignition on. Measure the voltage between the (P65) or (P68) Mirror Horizontal Position Signal circuit and the (P69) or (P66) Mirror Sensor Ground circuit. Is the voltage between 4.8 and 5.2 volts? Yes Replace the Mirror. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) . No Go to 3.
3. 3) TEST THE (P65) OR (P68) MIRROR HORIZONTAL POSITION SIGNAL WIRE FOR A SHORT TO VOLTAGE Turn the ignition off. Disconnect the appropriate Door Module C4 connector. Turn the ignition on. Measure the voltage between the (P65) or (P68) Mirror Horizontal Position Signal circuit and ground. Is there any voltage present? Yes Repair the (P65) or (P68) Mirror Horizontal Position Signal circuit for a short to voltage. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) . No Go to 4.
4. 4) TEST THE (P69) OR (P66) MIRROR SENSOR GROUND WIRE FOR AN OPEN Turn the ignition off. Measure the resistance of the (P69) or (P66) Mirror Sensor Ground circuit between the Module connector and the Mirror connector. Is the resistance below 2.0 ohms? No Repair the (P69) or (P66) Mirror Sensor Ground circuit for an open. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) . Yes Go to 5.
5. 5) TEST THE (P65) OR (P68) MIRROR HORIZONTAL POSITION SIGNAL WIRE FOR AN OPEN Measure the resistance of the (P65) or (P68) Mirror Horizontal Position Signal circuit between the Module connector and the Mirror connector. Is the resistance below 2.0 ohms? No Repair the (P65) or (P68) Mirror Horizontal Position Signal circuit for an open. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) . Yes Replace the appropriate Door Module. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) .

Scheme 26

1. When Monitored: Continuously.

1. Set Condition: When the Memory Mirror Module senses a value below the tolerance of the mirror motor on the Mirror Vertical Motor Control circuit for over 10 ms, this code will set. NOTE: This test covers both the Driver and Passenger code depending on the side the code appeared in.

Scheme 27

Scheme 28

1. 1) TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTC's Operate the Mirror Switch in all directions several times. Cycle the ignition from on to off three times. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display B1D1E or B1D2A-MIRROR VERTICAL MOTOR CONTROL CIRCUIT/PERFORMANCE? Yes Go To 2. No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) .
2. 2) TEST FOR A SHORTED MIRROR Disconnect the appropriate mirror connector. With the scan tool, erase DTC's. Operate the Mirror Switch in all directions several times. Cycle the ignition from on to off three times. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display B1D1E or B1D2A-MIRROR VERTICAL MOTOR CONTROL CIRCUIT/PERFORMANCE? No Replace the Mirror. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) . Yes Go to 3.
3. 3) TEST THE (P71) OR (P72) MIRROR VERTICAL MOTOR DRIVER WIRE FOR A SHORT TO GROUND Turn the ignition off. Disconnect the appropriate Door Module C4 connector. Measure the resistance between ground and the (P71) or (P72) Mirror Vertical Motor Driver circuit. Is the resistance below 5000.0 ohms? Yes Repair the (P71) or (P72) Mirror Vertical Motor Driver circuit for a short to ground. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) . No Go to 4.
4. 4) TEST THE (P71) OR (P72) MIRROR VERTICAL MOTOR DRIVER CIRCUIT SHORTED TO THE (Z912) GROUND CIRCUIT. Measure the resistance between the (P71) or (P72) Mirror Vertical Motor Driver circuit and the (Z912) or (Z911) Ground circuit. Is the resistance below 5000.0 ohms? Yes Repair the (P71) or (P72) Mirror Vertical Motor Driver circuit for a short to the (Z912) or (Z911) Ground Circuit. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) . No Replace the appropriate Door Module. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) .

Scheme 29

1. When Monitored: Continuously.

1. Set Condition: When the Driver/Passenger Door Module senses a value below the tolerance of the mirror motor on the Mirror Horizontal Motor Driver circuit for over 10 ms, this code will set. NOTE: This test covers both the Driver and Passenger code depending on the side the code appeared in.

Scheme 30

Scheme 31

1. 1) TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTC's Operate the Mirror Switch in all directions several times. Cycle the ignition from on to off three times. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display B1D22 or B1D2E-MIRROR HORIZONTAL MOTOR CONTROL CIRCUIT/PERFORMANCE? Yes Go To 2. No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) .
2. 2) TEST FOR A SHORTED MIRROR Disconnect the appropriate mirror connector. With the scan tool, erase DTC's. Operate the Mirror Switch in all directions several times. Cycle the ignition from on to off three times. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display B1D22 or B1D2E-MIRROR HORIZONTAL MOTOR CONTROL CIRCUIT/PERFORMANCE? No Replace the Mirror. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) . Yes Go to 3.
3. 3) TEST THE (P75) OR (P74)) MIRROR HORIZONTAL MOTOR DRIVER WIRE FOR A SHORT TO GROUND Turn the ignition off. Disconnect the appropriate Door Module C4 connector. Measure the resistance between ground and the (P75) or (P74) Mirror Horizontal Motor Driver circuit. Is the resistance below 5000.0 ohms? Yes Repair the (P75) or (P74) Mirror Horizontal Motor Driver circuit for a short to ground. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) . No Go to 4.
4. 4) TEST THE (P75) OR (P74) MIRROR HORIZONTAL MOTOR DRIVER CIRCUIT SHORTED TO THE (Z912) OR (Z911) GROUND CIRCUIT. Measure the resistance between the (P75) or (P74) Mirror Horizontal Driver circuit and the (Z912) or (Z911) Ground circuit. Is the resistance below 5000.0 ohms? Yes Repair the (P75) or (P74) Mirror Horizontal Motor Driver circuit for a short to the (Z912) or (Z911) Mirror Heater Ground Circuit. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) . No Replace the appropriate Door Module. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) .

Scheme 32

1. When Monitored: Continuously.

1. Set Condition: When the Memory Select Switch MUX is under 2.6 volts for over 30 seconds.

Scheme 33

Scheme 34

Scheme 35

1. 1) TEST FOR INTERMITTENT CONDITION With the scan tool, record and erase DTC's Press the Memory Set Switch several times in all positions. Cycle the ignition from on to off three times. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display MEMORY SWITCH INPUT CIRCUIT STUCK? Yes Go To 2. No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) .
2. 2) MEMORY SELECTOR SWITCH SHORTED TO GROUND With the scan tool, erase DTC's. Disconnect the Memory Set Switch connector. Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display MEMORY SWITCH INPUT CIRCUIT STUCK? No Replace the Memory Set Switch. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) . Yes Go to 3.
3. 3) (P200) MEMORY SELECT SWITCH MUX CIRCUIT SHORT TO THE GROUND Disconnect the Driver Door Module C3 connector. Measure the resistance between ground and the (P200) Memory Select Switch MUX circuit. Is the resistance below 10000.0 ohms? Yes Repair the Memory Select Switch MUX wire for a short to ground. Perform the BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) . No Go to 4.
4. 4) (P200) MEMORY SELECT SWITCH MUX CIRCUIT SHORT TO THE (G920) MEMORY SELECT SWITCH RETURN CIRCUIT Measure the resistance between the (P200) Memory Select Switch MUX circuit and the (G920) Memory Select Switch Return circuit in the Driver Door Module C3 connector. Is the resistance below 10000.0 ohms? Yes Repair the (P200) Memory Select Switch MUX circuit for a short to the (G920) Memory Select Switch return circuit. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) . No Replace the Driver Door Module. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) .

1. When Monitored: Engine running.

1. Set Condition: This code is set immediately after the Door Module detects voltage under 11.3 volts on the (A913) Fused B(+) circuit.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding.

Scheme 36

1. 1) CHECK PCM FOR CHARGING SYSTEM DTC With the scan tool, read Powertrain Control Module DTC's. Are there any Charging System DTC's set in the Powertrain Control Module? Yes (Refer to «DIAGNOSIS AND TESTING»(ref-255999-S21755650642007060500000) ) for Charging System diagnostic procedures. No Go To 2. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) .
2. 2) VERIFY THAT DTC B210D-BATTERY VOLTAGE LOW IS ACTIVE With the scan tool, record and erase DTC's Turn the ignition switch to the OFF position then start the engine and let run for one minute. With the scan tool, read DTC's. Does the DTC B210D-BATTERY VOLTAGE LOW reset? Yes Go To 3. No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) .
3. 3) CHECK THE VOLTAGE ON THE (A913) FUSED B(+) CIRCUIT Disconnect the appropriate Door Module C4 connector. NOTE: Check connectors - Clean and repair as necessary. Start the engine and let idle. Measure the voltage on the (A913) Fused B(+) circuit at the Door Module C4 connector and compare to voltage at the vehicle battery. Is the voltage at the Door Module C4 connector the same as measured at the battery? Yes Replace the Driver/Passenger Door Module in accordance with the service information. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) . No Repair the (A913) Fused B(+) circuit as necessary. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) .

1. When Monitored: Engine running.

1. Set Condition: This code is set immediately after the Door Module detects voltage over 15 volts on the (A913) Fused B(+) circuit.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding.

1. When Monitored: Ignition on.

1. Set Condition: This code is set immediately if the Driver/Passenger Door Module internal self test fails.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding.

1. When Monitored: Continuously.

1. Set Condition: Whenever the CAN B Bus (+) or CAN B (-) circuit is open.

Scheme 37

Scheme 38

1. 1) CHECK FOR ACTIVE DTCS With the scan tool, read the active DTC's. Cycle the ignition switch from off to on at least five times, leaving the ignition on for a minimum of 90 seconds per cycle. With the scan tool, read the active DTC's. Does the scan tool display this DTC as active? Yes Go To 2. No If the DTC is stored, check for an intermittent condition. Visually inspect the related wiring harness connectors. Look for broken, bent, pushed out, or corroded terminals.
2. 2) CHECK FRONT CONTROL MODULE DTC's With the scan tool, read Front Control Module active DTC's Does the scan tool display any CAN B BUS DTC's - ACTIVE? Yes «(Refer to ELECTRICAL/ELECTRONIC CONTROL MODULES - DIAGNOSIS AND TESTING)»(ref-255952-S37788235782007060500000) No Go To 3.
3. 3) (D55) CAN B BUS (+) CIRCUIT OPEN Turn the ignition off. Disconnect the negative battery cable. Disconnect the Driver Door Module C4 connector. Disconnect the Front Control Module C1 connector. Measure the resistance of the (D55) CAN B Bus (+) circuit between the Front Control Module C1 connector and the Driver Door Module C4 connector. Is the resistance below 2.0 ohms? Yes Go To 4. No Repair the (D55) CAN B Bus (+) circuit for an open. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) .
4. 4) (D54) CAN B BUS (-) CIRCUIT OPEN Measure the resistance of the (D54) CAN B Bus (-) circuit between the Front Control Module C1 connector and the Driver Door Module C4 connector. Is the resistance below 2.0 ohms? Yes Replace the Driver Door Module in accordance with the service information. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) . No Repair the (D54) CAN B Bus (-) circuit for an open. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) .

Scheme 39

1. When Monitored: Continuously.

1. Set Condition: Whenever the CAN B Bus (+) or CAN B (-) circuit is open.

Scheme 40

Scheme 41

1. 1) CHECK FOR ACTIVE DTCS With the scan tool, read the active DTC's. Cycle the ignition switch from off to on at least five times, leaving the ignition on for a minimum of 90 seconds per cycle. With the scan tool, read the active DTC's. Does the scan tool display this DTC as active? Yes Go To 2. No If the DTC is stored, check for an intermittent condition. Visually inspect the related wiring harness connectors. Look for broken, bent, pushed out, or corroded terminals.
2. 2) CHECK FRONT CONTROL MODULE DTC's With the scan tool, read Front Control Module active DTC's Does the scan tool display any CAN B BUS DTC's - ACTIVE? Yes «(Refer to ELECTRICAL/ELECTRONIC CONTROL MODULES - DIAGNOSIS AND TESTING)»(ref-255952-S37788235782007060500000) No Go To 3.
3. 3) (D55) CAN B BUS (+) CIRCUIT OPEN Turn the ignition off. Disconnect the negative battery cable. Disconnect the Passenger Door Module C4 connector. Disconnect the Front Control Module C1 connector. Measure the resistance of the (D55) CAN B Bus (+) circuit between the Front Control Module C1 connector and the Passenger Door Module C4 connector. Is the resistance below 2.0 ohms? Yes Go To 4. No Repair the (D55) CAN B Bus (+) circuit for an open. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) .
4. 4) (D54) CAN B BUS (-) CIRCUIT OPEN Measure the resistance of the (D54) CAN B Bus (-) circuit between the Front Control Module C1 connector and the Passenger Door Module C4 connector. Is the resistance below 2.0 ohms? Yes Replace the Passenger Door Module in accordance with the service information. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) . No Repair the (D54) CAN B Bus (-) circuit for an open. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) .
