Overhead Console - Electrical Diagnostics: Diagnosis Dodge Charger V

Accessories Control Systems 1 illustration ~830 words

DIAGNOSTIC CODE INDEX

DTCDescription
B1A32UNIVERSAL GARAGE DOOR SWITCH 1 STUCK
B1A33UNIVERSAL GARAGE DOOR SWITCH 2 STUCK
B1A34UNIVERSAL GARAGE DOOR SWITCH 3 STUCK
B2217EVIC/EOM/CMTC INTERNAL
B222DECU UNABLE TO CONFIGURE / CONFIGURATION NOT LEARNED
B2331VEHICLE NEEDS DEGAUSSED
U0019CAN B BUS
U0141LOST COMMUNICATION WITH FRONT CONTROL MODULE
U0151LOST COMMUNICATION WITH OCCUPANT RESTRAINT CONTROLLER
U0154LOST COMMUNICATION WITH OCCUPANT CLASSIFICATION MODULE
U0155LOST COMMUNICATION WITH CLUSTER/CCN
U0159LOST COMMUNICATION WITH PARKING ASSIST CONTROL MODULE
U0164LOST COMMUNICATION WITH HVAC CONTROL MODULE
U0167LOST COMMUNICATION WITH INTRUSION TRANSCEIVER CONTROL MODULE
U0168LOST COMMUNICATION WITH VEHICLE SECURITY CONTROL MODULE (SKREEM/WCM)
U0169LOST COMMUNICATION WITH SUNROOF CONTROL MODULE
U0184LOST COMMUNICATION WITH RADIO
U0186LOST COMMUNICATION WITH AUDIO AMPLIFIER
U0195LOST COMMUNICATION WITH SDARS
U0196LOST COMMUNICATION WITH VEHICLE ENTERTAINMENT CONTROL MODULE
U0197LOST COMMUNICATION WITH HANDS FREE PHONE MODULE
U0199LOST COMMUNICATION WITH DRIVER DOOR MODULE
U0200LOST COMMUNICATION WITH PASSENGER DOOR MODULE
U0208LOST COMMUNICATION WITH HEATED SEAT CONTROL MODULE
U0209LOST COMMUNICATION WITH MEMORY SEAT CONTROL MODULE
U0212LOST COMMUNICATION WITH SCCM-CAN-B
U0231LOST COMMUNICATION WITH RAIN SENSING MODULE
U0241LOST COMMUNICATION WITH AUTO HIGHBEAM HEADLAMP CONTROL MODULE

DIAGNOSTIC CODE INDEX

Diagnostic Test

  1. 1) REPLACE THE ELECTRONIC OVERHEAD MODULE When this code is set, the Electronic Overhead Module must be replaced. Repair Replace the Electronic Overhead Module in accordance with the Service Information. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) .
  1. 1) REPLACE THE ELECTRONIC OVERHEAD MODULE When this code is set, the Electronic Overhead Module must be replaced. Repair Replace the Electronic Overhead Module in accordance with the Service Information. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) .
  1. 1) REPLACE THE ELECTRONIC OVERHEAD MODULE When this code is set, the Electronic Overhead Module must be replaced. Repair Replace the Electronic Overhead Module in accordance with the Service Information. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) .
  1. 1) VERIFY OPERATION OF THE ELECTRONIC OVERHEAD MODULE Turn the ignition on. With the scan tool, erase Electronic Overhead Module DTCs. With the scan tool, activate the Electronic Overhead Module self test. Wait for self test to complete. With the scan tool, read Electronic Overhead Module DTCs. Does the scan tool display: B2217-EVIC/EOM/CMTC INTERNAL? YES Replace the Electronic Overhead Module in accordance with the service information. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) . NO Test complete. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) .
  1. 1) CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, record and erase any Electronic Overhead Module DTCs. Turn the ignition off, wait 30 seconds then turn the ignition on. With the scan tool, read DTCs. Is the DTC active? Yes Go To 2) . No The condition that caused this code to set is not present at this time. Using the wiring diagram as a guide, inspect the wiring and connectors for an intermittent condition. Operate the system several times and recheck for active DTCs. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) .
  2. 2) CHECK COMMUNICATION TO THE FRONT CONTROL MODULE With the scan tool, check to see if the Front Control Module is active on the bus. Is the scan tool able to communicate with the Front Control Module? Yes Replace the Electronic Overhead Module in accordance with the Service Information. Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) . No Refer to the symptom list for problems related to Communication. «(Refer to ELECTRICAL/ELECTRONIC CONTROL MODULES - DIAGNOSIS AND TESTING)»(ref-255952-S37788235782007060500000) Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) .
  1. 1) PERFORM THE VEHICLE DEMAGNETIZING PROCEDURE NOTE: A blank compass display indicates that vehicle degaussing is required. NOTE: After demagnetizing, the vehicle will enter Auto Fast-Cal when the ignition is turned on. NOTE: Ensure that the correct compass variance is stored in the compass memory. See «COMPASS VARIATION ADJUSTMENT»(ref-255972-S09842817652007060500000) . View repair. Repair Refer to «COMPASS DEMAGNETIZING»(ref-255972-S14104080022007060500000) . Perform BODY VERIFICATION TEST - VER 1. «(Refer to BODY VERIFICATION TEST - VER 1)»(ref-255944-S31737016002007060500000) .

Scheme 14

Scheme 14: Circuit Schematic

(Refer to ELECTRICAL/ELECTRONIC CONTROL MODULES - DIAGNOSIS AND TESTING) for the diagnostic test procedure.

(Refer to ELECTRICAL/ELECTRONIC CONTROL MODULES - DIAGNOSIS AND TESTING) for the diagnostic test procedure.

(Refer to ELECTRICAL/ELECTRONIC CONTROL MODULES - DIAGNOSIS AND TESTING) for the diagnostic test procedure.

(Refer to ELECTRICAL/ELECTRONIC CONTROL MODULES - DIAGNOSIS AND TESTING) for the diagnostic test procedure.

(Refer to ELECTRICAL/ELECTRONIC CONTROL MODULES - DIAGNOSIS AND TESTING) for the diagnostic test procedure.

(Refer to ELECTRICAL/ELECTRONIC CONTROL MODULES - DIAGNOSIS AND TESTING) for the diagnostic test procedure.

(Refer to ELECTRICAL/ELECTRONIC CONTROL MODULES - DIAGNOSIS AND TESTING) for the diagnostic test procedure.

(Refer to ELECTRICAL/ELECTRONIC CONTROL MODULES - DIAGNOSIS AND TESTING) for the diagnostic test procedure.

(Refer to ELECTRICAL/ELECTRONIC CONTROL MODULES - DIAGNOSIS AND TESTING) for the diagnostic test procedure.

(Refer to ELECTRICAL/ELECTRONIC CONTROL MODULES - DIAGNOSIS AND TESTING) for the diagnostic test procedure.

(Refer to ELECTRICAL/ELECTRONIC CONTROL MODULES - DIAGNOSIS AND TESTING) for the diagnostic test procedure.

(Refer to ELECTRICAL/ELECTRONIC CONTROL MODULES - DIAGNOSIS AND TESTING) for the diagnostic test procedure.

(Refer to ELECTRICAL/ELECTRONIC CONTROL MODULES - DIAGNOSIS AND TESTING) for the diagnostic test procedure.

(Refer to ELECTRICAL/ELECTRONIC CONTROL MODULES - DIAGNOSIS AND TESTING) for the diagnostic test procedure.

(Refer to ELECTRICAL/ELECTRONIC CONTROL MODULES - DIAGNOSIS AND TESTING) for the diagnostic test procedure.

(Refer to ELECTRICAL/ELECTRONIC CONTROL MODULES - DIAGNOSIS AND TESTING) for the diagnostic test procedure.

(Refer to ELECTRICAL/ELECTRONIC CONTROL MODULES - DIAGNOSIS AND TESTING) for the diagnostic test procedure.

(Refer to ELECTRICAL/ELECTRONIC CONTROL MODULES - DIAGNOSIS AND TESTING) for the diagnostic test procedure.

(Refer to ELECTRICAL/ELECTRONIC CONTROL MODULES - DIAGNOSIS AND TESTING) for the diagnostic test procedure.

(Refer to ELECTRICAL/ELECTRONIC CONTROL MODULES - DIAGNOSIS AND TESTING) for the diagnostic test procedure.

(Refer to ELECTRICAL/ELECTRONIC CONTROL MODULES - DIAGNOSIS AND TESTING) for the diagnostic test procedure.
