DIAGNOSTIC CODE INDEX

DIAGNOSTIC CODE INDEX

DIAGNOSTIC TEST

1. CHECK FOR AN ACTIVE DTC NOTE: Before proceeding with the diagnostic procedure, verify that the connections are proper made, properly seated and verify proper pin terminal tension. A loose connection at any of SCCM connectors may cause the DTC to set. Turn the ignition on. Press each Remote Radio Switch twice. With the scan tool, read DTCs Does the scan tool display this DTC as active? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST.
2. LEFT OR RIGHT REMOTE RADIO SWITCH NOTE: Check for a stuck Remote Radio Switch. Repair as necessary. With the scan tool, view the switch status. Status can be viewed in the SCCM data display. NOTE: With the switches not pressed, the value for the remote switches should read "Not Set". Left Remote Radio Switch SWS Seek Up SWS Preset SWS Seek Down Right Remote Radio Switch SWS Volume Up SWS Audio Mode SWS Volume Down Does the scan tool display the correct status of the switches in the data display? Yes Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST. No WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Do not place an intact non-deployed airbag face down on a hard surface, the airbag propels into the air if accidentally deployed. Failure to follow these instructions may result in possible serious or fatal injury. NOTE: Visually and physically inspect the wiring harness between the Remote Radio Switch harness connectors and the Right Steering Wheel Switch (Speed Control Switch) harness connector. Repair any damaged wires, connectors, and open/spread terminals. If harness is OK, proceed with test. Replace the Remote Radio Switch that does not display the correct value in the data display. Refer to «SWITCH, REMOTE RADIO, REMOVAL»(ref-489310-S25054844912012072600000) . Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST.

1. CHECK FOR AN ACTIVE DIAGNOSTIC TROUBLE CODE (DTC) Turn the ignition on. Press each switch on the Left Steering Wheel Switch assembly twice. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Do not place an intact non-deployed airbag face down on a hard surface, the airbag propels into the air if accidentally deployed. Failure to follow these instructions may result in possible serious or fatal injury. NOTE: Check for a stuck Left Steering Wheel Control Switch. NOTE: Visually and physically inspect the wiring harness between the Left Steering Wheel Control Switch harness connector and the Right Steering Wheel Control Switch (Speed Control Switch) harness connector. Repair any damaged wires, connectors, and open/spread terminals. If harness is OK, proceed with test. Replace the Left Steering Wheel Control Switch in accordance with the Service Information. Once switch has been replaced, press it twice to initialize it. If problem persists, replace the Right Steering Wheel Switch (Speed Control Switch) in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST. No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST.

1. CHECK FOR AN ACTIVE DIAGNOSTIC TROUBLE CODE (DTC) Turn the ignition on. Press the Steering Column Tilt Switch twice in all directions. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the Steering Column Control Module (SCCM) in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST. No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST.

1. CHECK FOR AN ACTIVE DIAGNOSTIC TROUBLE CODE (DTC) Turn the ignition on. Press the Steering Column Tilt Switch twice in all directions. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the Steering Column Control Module (SCCM) in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST. No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST.

Scheme 5

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

1. CHECK FOR AN ACTIVE DIAGNOSTIC TROUBLE CODE (DTC) Turn the ignition on. Press the Front Washer Switch twice. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the Steering Column Control Module (SCCM) in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST. No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST.

1. CHECK FOR AN ACTIVE DIAGNOSTIC TROUBLE CODE (DTC) Turn the ignition on. With the scan tool, read DTCs Does the scan tool display this DTC as active? Yes WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Do not place an intact non-deployed airbag face down on a hard surface, the airbag propels into the air if accidentally deployed. Failure to follow these instructions may result in possible serious or fatal injury. NOTE: Visually and physically inspect the wiring harness between the Horn Switch harness connector and the Right Steering Wheel Switch (Speed Control Switch) harness connector. Repair any damaged wires, connectors, and open/spread terminals. If harness is OK, proceed with test. Replace the Horn Switch in accordance with the Service Information. Once the switch has been replaced, press it twice to initialize it. If problem still persists, replace the Right Steering Wheel Switch (Speed Control Switch) in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST. No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST.

1. CHECK FOR AN ACTIVE DIAGNOSTIC TROUBLE CODE (DTC) Turn the ignition on. Actuate the Flash To Pass/Optical Horn Switch twice. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the Steering Column Control Module (SCCM) in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST. No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST.

1. CHECK FOR AN ACTIVE DIAGNOSTIC TROUBLE CODE (DTC) NOTE: If steering system service has been performed and the Steering Angle Sensor (SAS) has been installed incorrectly, this DTC may set. Refer to «STEERING SYSTEM»(ref-489286) to verify repairs have been performed correctly. Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the Steering Column Control Module (SCCM) in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST. No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST.

1. RELATED DTC(S) PRESENT IN THE PCM Ignition on, engine not running. With the scan tool, select View DTCs in the Powertrain Control Module (PCM). Are there any charging system or related battery voltage DTCs present in the PCM? Yes Refer to «DTC INDEX»(ref-489396) and perform the appropriate diagnostic procedure . Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST. No Go To 2 .
2. CHECK FOR AN ACTIVE DIAGNOSTIC TROUBLE CODE (DTC) Ignition on, engine not running. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the Steering Column Control Module (SCCM) in accordance with the Service information. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST. No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST.

1. RELATED DTC(S) PRESENT IN PCM Turn the ignition on. With the scan tool, select View DTCs in the Powertrain Control Module (PCM). Are there any charging system or related battery voltage DTCs present in the PCM? Yes Refer to «DTC INDEX»(ref-489396) and perform the appropriate diagnostic procedure . No Go To 2 .
2. CHECK FOR AN ACTIVE DIAGNOSTIC TROUBLE CODE (DTC) With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Go To 3 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST.
3. (A913) FUSED B(+) CIRCUIT OPEN OR SHORTED TO GROUND Turn the ignition off. Disconnect the Steering Control Module C1 harness connector. Turn the ignition on. Measure the voltage of the (A913) Fused B(+) circuit. Is battery voltage present? Yes Go To 4 . No Repair the (A913) Fused B(+) circuit for an open or short to ground. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST.
4. (Z910) GROUND CIRCUIT OPEN OR HIGH RESISTANCE Turn the ignition off. Measure the resistance between ground and the (Z910) Ground circuit. Is the resistance below 5.0 Ohms? Yes Replace the Steering Column Control Module (SCCM) in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST. No Repair the (Z910) Ground circuit for an open or high resistance. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST.

1. RELATED DTC(S) PRESENT IN THE PCM Ignition on, engine not running. With the scan tool, select View DTCs in the Powertrain Control Module (PCM). Are there any charging system or related battery voltage DTCs present in the PCM? Yes Refer to «DTC INDEX»(ref-489396) and perform the appropriate diagnostic procedure . Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST. No Go To 2 .
2. CHECK FOR AN ACTIVE DIAGNOSTIC TROUBLE CODE (DTC) Ignition on, engine not running. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the Steering Column Control Module (SCCM) in accordance with the Service information. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST. No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST.

1. CHECK FOR AN ACTIVE DIAGNOSTIC TROUBLE CODE (DTC) Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the Steering Column Control Module (SCCM) in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST. No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST.

1. CHECK FOR AN ACTIVE DIAGNOSTIC TROUBLE CODE (DTC) Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the Steering Column Control Module (SCCM) in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST. No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST.

1. CHECK FOR AN ACTIVE DIAGNOSTIC TROUBLE CODE (DTC) Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the Steering Column Control Module (SCCM) in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST. No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST.

1. CHECK FOR AN ACTIVE DIAGNOSTIC TROUBLE CODE (DTC) Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the Steering Column Control Module (SCCM) in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST. No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST.

1. CHECK FOR AN ACTIVE DIAGNOSTIC TROUBLE CODE (DTC) Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the Steering Column Control Module (SCCM) in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST. No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST.

1. CHECK FOR AN ACTIVE DIAGNOSTIC TROUBLE CODE (DTC) Turn the ignition on. With the scan tool, read DTCs Does the scan tool display this DTC as active? Yes WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Do not place an intact non-deployed airbag face down on a hard surface, the airbag propels into the air if accidentally deployed. Failure to follow these instructions may result in possible serious or fatal injury. NOTE: Visually and physically inspect the wiring harness between the Right Steering Wheel Switch (Speed Control Switch) harness connector and the SCCM harness connector. Repair any damaged wires, connectors, and open/spread terminals. If harness is OK, proceed with test. Replace the Right Steering Wheel Switch (Speed Control Switch) in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST. No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST.

1. CHECK FOR AN ACTIVE DIAGNOSTIC TROUBLE CODE (DTC) Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Do not place an intact non-deployed airbag face down on a hard surface, the airbag propels into the air if accidentally deployed. Failure to follow these instructions may result in possible serious or fatal injury. NOTE: Visually and physically inspect the wiring harness between the Right Steering Wheel Switch (Speed Control Switch) harness connector and the SCCM harness connector. Repair any damaged wires, connectors, and open/spread terminals. If harness is OK, proceed with test. Replace the Right Steering Wheel Switch (Speed Control Switch) in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST. No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST.

1. CHECK FOR AN ACTIVE DIAGNOSTIC TROUBLE CODE (DTC) Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Do not place an intact non-deployed airbag face down on a hard surface, the airbag propels into the air if accidentally deployed. Failure to follow these instructions may result in possible serious or fatal injury. NOTE: Visually and physically inspect the wiring harness between the Right Steering Wheel Switch (Speed Control Switch) harness connector and the SCCM harness connector. Repair any damaged wires, connectors, and open/spread terminals. If harness is OK, proceed with test. Replace the Right Steering Wheel Switch (Speed Control Switch) in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST. No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST.

1. CHECK FOR AN ACTIVE DIAGNOSTIC TROUBLE CODE (DTC) Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST.
2. SPEED CONTROL SWITCH Turn the ignition off. WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Do not place an intact non-deployed airbag face down on a hard surface, the airbag propels into the air if accidentally deployed. Failure to follow these instructions may result in possible serious or fatal injury. NOTE: Visually and physically inspect the wiring harness between the Right Steering Wheel Switch (Speed Control Switch) harness connector and the SCCM harness connector. Repair any damaged wires, connectors, and open/spread terminals. If harness is OK, proceed with test. Replace the Right Steering Wheel Switch (Speed Control Switch) in accordance with the Service Information. Turn the ignition on. Move the Speed Control Switch to each position several times. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the Steering Column Control Module (SCCM) in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST. No Test Complete. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST.

1. CHECK FOR AN ACTIVE DIAGNOSTIC TROUBLE CODE (DTC) Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Do not place an intact non-deployed airbag face down on a hard surface, the airbag propels into the air if accidentally deployed. Failure to follow these instructions may result in possible serious or fatal injury. NOTE: Visually and physically inspect the wiring harness between the Right Steering Wheel Switch (Speed Control Switch) harness connector and the SCCM harness connector. Repair any damaged wires, connectors, and open/spread terminals. If harness is OK, proceed with test. Replace the Right Steering Wheel Switch (Speed Control Switch) in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST. No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST.

1. CHECK FOR AN ACTIVE DIAGNOSTIC TROUBLE CODE (DTC) Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Do not place an intact non-deployed airbag face down on a hard surface, the airbag propels into the air if accidentally deployed. Failure to follow these instructions may result in possible serious or fatal injury. NOTE: Visually and physically inspect the wiring harness between the Right Steering Wheel Switch (Speed Control Switch) harness connector and the SCCM harness connector. Repair any damaged wires, connectors, and open/spread terminals. If harness is OK, proceed with test. Replace the Right Steering Wheel Switch (Speed Control Switch) in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST. No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST.

1. CHECK FOR AN ACTIVE DIAGNOSTIC TROUBLE CODE (DTC) Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Do not place an intact non-deployed airbag face down on a hard surface, the airbag propels into the air if accidentally deployed. Failure to follow these instructions may result in possible serious or fatal injury. NOTE: Visually and physically inspect the wiring harness between the Right Steering Wheel Switch (Speed Control Switch) harness connector and the SCCM harness connector. Repair any damaged wires, connectors, and open/spread terminals. If harness is OK, proceed with test. Replace the Right Steering Wheel Switch (Speed Control Switch) in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST. No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST.

1. CHECK FOR AN ACTIVE DIAGNOSTIC TROUBLE CODE (DTC) NOTE: Before proceeding with the diagnostic procedure, verify that the connections are properly made, seated and verify proper pin terminal tension. A loose connection at any of the SCCM connectors may cause the DTC to set. Turn the ignition on. Press the Upshift Switch twice in all directions. (The scan tool can be used to monitor switch status. Status can be viewed in the SCCM data display.) With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST.
2. RIGHT REMOTE RADIO SWITCH (PADDLE SHIFTER) NOTE: Check for a stuck Upshift Switch. Repair as necessary. With the scan tool, view the switch status. Status can be viewed in the SCCM data display. While monitoring the Upshift Switch status with the scan tool, actuate the switch multiple times. Does the scan tool display the correct status of the switch in the data display? Yes Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST. No WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Do not place an intact non-deployed airbag face down on a hard surface, the airbag propels into the air if accidentally deployed. Failure to follow these instructions may result in possible serious or fatal injury. NOTE: Visually and physically inspect the wiring harness between the Remote Radio Switch harness connectors and the Right Steering Wheel Switch (Speed Control Switch) harness connector. Repair any damaged wires, connectors, and open/spread terminals. If harness is OK, proceed with test. Replace the Right Remote Radio Switch in accordance with the Service Information. Refer to «SWITCH, REMOTE RADIO, REMOVAL»(ref-489310-S25054844912012072600000) . Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST.

1. CHECK FOR AN ACTIVE DIAGNOSTIC TROUBLE CODE (DTC) NOTE: Before proceeding with the diagnostic procedure, verify that the connections are properly made, seated and verify proper pin terminal tension. A loose connection at any of the SCCM connectors may cause the DTC to set. Turn the ignition on. Press the Downshift Switch twice. (The scan tool can be used to monitor switch status. Status can be viewed in the SCCM data display.) With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST.
2. LEFT REMOTE RADIO SWITCH (PADDLE SHIFTER) NOTE: Check for a stuck Downshift Switch. Repair as necessary. With the scan tool, view the switch status. Status can be viewed in the SCCM data display. While monitoring the Downshift Switch status with the scan tool, actuate the switch multiple times. Does the scan tool display the correct status of the switch in the data display? Yes Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST. No WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Do not place an intact non-deployed airbag face down on a hard surface, the airbag propels into the air if accidentally deployed. Failure to follow these instructions may result in possible serious or fatal injury. NOTE: Visually and physically inspect the wiring harness between the Remote Radio Switch harness connectors and the Right Steering Wheel Switch (Speed Control Switch) harness connector. Repair any damaged wires, connectors, and open/spread terminals. If harness is OK, proceed with test. Replace the Left Remote Radio Switch in accordance with the Service Information. Refer to «SWITCH, REMOTE RADIO, REMOVAL»(ref-489310-S25054844912012072600000) . Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST.

1. CHECK FOR AN ACTIVE DIAGNOSTIC TROUBLE CODE (DTC) Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Do not place an intact non-deployed airbag face down on a hard surface, the airbag propels into the air if accidentally deployed. Failure to follow these instructions may result in possible serious or fatal injury. NOTE: Visually and physically inspect the wiring harness between the Right Steering Wheel Switch (Speed Control Switch) harness connector and the SCCM harness connector. Repair any damaged wires, connectors, and open/spread terminals. If harness is OK, proceed with test. Replace the Right Steering Wheel Switch (Speed Control Switch) in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST. No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST.

1. CHECK FOR AN ACTIVE DIAGNOSTIC TROUBLE CODE (DTC) Turn the ignition on. Press the Gear Selector Switch twice in all directions. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the Steering Column Control Module (SCCM) in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST. No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST.

1. ACTIVE DTC Ignition on, engine not running. With the scan tool, select view DTCs. Is the DTC Active at this time? Yes Diagnose the U0002-00-CAN C BUS OFF PERFORMANCE as the U0001-CAN C BUS CIRCUIT test. Refer to «DIAGNOSIS AND TESTING»(ref-489354-S02400701022012072600000) and perform the U0001-CAN C Bus diagnostic procedure. No Refer to «DIAGNOSIS AND TESTING»(ref-489311-S04448603792012072600000) and perform the Stored Lost Communication DTCs diagnostic procedure.

1. VERIFY THE DTC IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. Using the scan tool, read the active DTCs. Is the DTC active at this time? Yes Refer to «DIAGNOSIS AND TESTING»(ref-489354-S02400701022012072600000) and perform the U0100-Lost Communication with PCM diagnostic procedure. No Refer to «DIAGNOSIS AND TESTING»(ref-489311-S04448603792012072600000) and perform the Stored Lost Communication DTCs diagnostic procedure.

1. VERIFY DTC IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read active DTCs. Is this DTC active? Yes Refer to «DIAGNOSIS AND TESTING»(ref-489354-S02400701022012072600000) and perform the U0141-Lost Communication with IPM (FCM/TIPM) diagnostic procedure. No Refer to «DIAGNOSIS AND TESTING»(ref-489311-S04448603792012072600000) and perform the Stored Lost Communication DTCs diagnostic procedure.

1. VERIFY DTC IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read active DTCs. Is this DTC active? Yes Refer to «DIAGNOSIS AND TESTING»(ref-489354-S02400701022012072600000) and perform the U0155-Lost Communication with Cluster/CCN diagnostic procedure. No Refer to «DIAGNOSIS AND TESTING»(ref-489311-S04448603792012072600000) and perform the Stored Lost Communication DTCs diagnostic procedure.

1. CHECK FOR AN ACTIVE DIAGNOSTIC TROUBLE CODE (DTC) Turn the ignition on. With the scan tool, read DTCs Does the scan tool display this DTC as active? Yes WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Do not place an intact non-deployed airbag face down on a hard surface, the airbag propels into the air if accidentally deployed. Failure to follow these instructions may result in possible serious or fatal injury. NOTE: Visually and physically inspect the wiring harness between the Right Steering Wheel Switch (Speed Control Switch) harness connector and the SCCM harness connector. Repair any damaged wires, connectors, and open/spread terminals. If harness is OK, view repair. Replace the Right Steering Wheel Switch (Speed Control Switch) in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST. No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST.

1. CHECK FOR AN ACTIVE DIAGNOSTIC TROUBLE CODE (DTC) NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. NOTE: Diagnose any CAN Bus DTCs that may be set in other modules before proceeding with this diagnostic procedure. Turn the ignition on. With the scan tool, read active DTCs. Dose the scan tool display this DTC as active? Yes If no other CAN Bus DTCs are set in other modules and the SCCM is the only one reporting this DTC, replace the SCCM in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST. No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Refer to «STANDARD PROCEDURE»(ref-489354-S40173642412012072600000) and perform the BODY VERIFICATION TEST.
