FASTENER TORQUE
| Description | N.m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| All Screws NOT Listed Below | 2 | 17 | |
| A/C Compressor to Engine | Specific fastener placement and torque pattern required. Refer to COMPRESSOR, A/C, INSTALLATION . | ||
| A/C Condenser to Radiator Bolts | 5 | 44 | |
| A/C Expansion Valve to Evaporator Tube Tapping Block Bolts | 11 | 97 | |
| Air Distribution Housing Halves Screws | 2.2 | 20 | |
| Air Distribution Housing to HVAC Housing Screws | 2.2 | 20 | |
| Air Inlet Housing to HVAC Housing Screws | 2.2 | 20 | |
| Blower Motor Screws | 2.2 | 20 | |
| Compressor Shaft Bolt | 19 | 168 | |
| Flange to HVAC Housing Screws | 2.2 | 20 | |
| Floor Console Duct to Floor Panel Screws | 2.2 | 20 | |
| Fresh Air Inlet Housing to Dash Panel Nuts | 7 | 62 | |
| Heater Core Retaining Bracket to Air Distribution Housing Screw | 2.2 | 20 | |
| HVAC Housing Halves Screws | 2.2 | 20 | |
| HVAC Housing to Engine Side of Dash Panel Nuts | 7 | 62 | |
| HVAC Housing to Passenger Side of Dash Panel Nuts | 3 | 26 | |
| Instrument Panel/demister Ducts to Instrument Panel Screw | 2.2 | 20 | |
| Liquid Line Front to Rear Section Nut | 22 | 16 | |
| Refrigerant Lines to A/C Expansion Valve Nut | 23 | 17 | |
| Refrigerant Line to A/C Compressor Nut | 23 | 17 | |
| Refrigerant Line to A/C Condenser Nut | 22 | 16 | |
| Refrigerant Line Bracket to Strut Tower Bolt | 11 | 97 | |
| Receiver/drier to A/C Condenser Bolt | 22 | 16 | |
| Receiver/drier Bracket to A/C Condenser Screw | 5 | 44 | |
| Suction Line Front to Rear Section Nut | 22 | 16 | |
| Strut Support to Strut Tower Bolts | 38 | 28 | |
SPECIFICATIONS
| Application | Capacity |
|---|---|
| All Models | 709 g (1.56 lbs.) |
REFRIGERANT CHARGE CAPACITY
Scheme 1
The A/C expansion valve controls the amount of refrigerant entering the A/C evaporator. The A/C expansion valve is of a thermostatic expansion valve (TXV) design and consists of an aluminum H-valve type body (1), with an integral thermal sensor (2). The A/C expansion valve is located at the dash panel between the A/C refrigerant lines and the A/C evaporator.
