Wiring diagram: Headlights — Headlights circuit Dodge Challenger III

Components on these wiring diagrams

Click a component to highlight it on every diagram it appears on.

• A/C Front Heater Module
• Auto Headlamps Signal
• Can B
• Can B Bus
• Cluster
• Engine Compt
• Front Fog Lamp Relay Control
• Fused B
• Ground
• Headlamp Sw Mux Rtn
• Headlamp Switch
• Headlamp Switch Mux
• Headlamp Switch Mux Rtn
• High — Beam
• Left Front Assembly Lamp
• Left High Beam Driver
• Left Low Beam Driver
• Panel Lamps Dimmer Sig
• Panel Lamps Dimmer Signal
• Panel Lamps Driver
• Park Brk Sw Sns
• Parking Brake Switch
• Processor
• Right Front Assembly Lamp
• Right High Beam Driver
• Right Low Beam Driver
• Sun Sensor
• Sun Sensor Return
• Switch Mux Headlamp
• Totally Integrated Power Module Electronics
• Turn Signal Switch Steering Control Module
• W/O Hid Lamps W/ Hid Lamps
