Scheme 1
| CALL OUT | DESCRIPTION | QUANTITY |
|---|---|---|
| 1 | Hood Switch Harness | 1 |
| 2 | Hood Switch | 1 |
| 3 | Wireless Ignition Node (WIN) | 1 |
| 4 | FOBIK | 2 |
| 5 | WIN Antenna | 1 |
| 6 | Zip Ties | 10 |
| CAUTION | XBM remote start can ONLY be installed on vehicles that have the following factory options: Automatic Transmission, Remote Keyless Entry and Immobilizer. WinFobik based vehicles, the sales code must be added to the database and the Restore Vehicle Configuration (using a diagnostic scan tool) must be performed prior to installing the new WIN module. Failure to do so will render the WIN module's remote start function inoperative. The technician should wait 1/2 hour between adding XBM sales code in DealerConnect before installing the WIN module & restoring vehicle configuration. In the interim, the technician can install all other components except the WIN module. |
PROCEDURE STEPS
